OLP-37XV2 OPTICAL POWER METER
1 INTRODUCTION
1INTRODUCTION
OLP-37XV2 Optical Power Meter
The OLP-37XV2 is a specialized optical power meter designed
for use cases such as system/network qualification, subscriber
activation, and troubleshooting of passive optical network (PON)
and radio frequency over glass (RFoG) installations.
The instrument performs wavelength selective optical power
measurements suitable for testing G-PON networks, as defined
in ITU-T G.983/4 or IEEE 802.3ah and XGS-PON networks, as
defined in ITU-T G.9807.1 respectively.
An integrated pass/fail analysis feature simplifies standard
conformity and optical budget/margin testing, and provides
unambiguous measurement result presentation.
With PC-based reporting, all test results can be summarized in a
professional, industry-proven report.
Main features
The OLP-37XV2 offers many helpful features that are optimized
to workflows of typical telecom and cable TV operators, and thus
ensure that test times are kept as short as possible.
• Accurate and repeatable wavelength selective power
measurements
• Unambiguous pass/fail result presentation and user definable
pass/fail thresholds
• Data storage for up to 1000 measurements
• USB-C interface for measurement data transfer to a laptop or
PC
• Easy operation and instantly ready to operate
• Versatile power supply options using dry or rechargeable
batteries or via the USB-C interface
• Automatic power-off (can be disabled)
• Color-coded test head cover for easy distinction between APC
and PC connector types
• Display of G-PON and XGS-PON signals simultaneously
• Smart-Reporter PC software for data management and report
generation

6 OLP-37XV2
1 INTRODUCTION
OPERATING MANUAL UPDATE
Operating manual update
If the operating instructions about features provided by your
device are missing, please visit the Viavi web site to check if
additional information is available.
To download the latest operating instructions:
1. Visit the Viavi web site at
www.viavisolutions.com .
2. Search for SmartPocket V2.
3. Open the download area and download the operating
instructions if available.

OLP-37XV2 7
SYMBOLS USED IN THIS OPERATING MANUAL
1 INTRODUCTION
Symbols used in this operating manual
Various elements are used in this operating manual to draw
attention to special meanings or important points in the text.
Symbols and terms used in warnings
The following warnings, symbols and terms are used in this
document in compliance with the American National Standard
ANSI Z535.6-2011:
NOTICE
Follow the instructions carefully to avoid damage to or
destruction of the instrument.
CAUTION
Follow the instructions carefully to avoid a low or medium risk
of injury to persons.
WARNING
Follow the instructions carefully to avoid potential death or
severe injury to persons.
DANGER
Follow the instructions carefully to avoid death or severe
injury to persons.
High Voltage
Follow the instructions carefully to avoid damage to the
instrument or severe injury to persons.
This safety instruction is given if the danger is due to high
voltage.
Laser
Follow the instructions carefully to avoid damage to the
instrument or severe injury to persons.
This safety instruction is given if the danger is due to laser
radiation. Information specifying the laser class is also given.

8 OLP-37XV2
1 INTRODUCTION
SYMBOLS USED IN THIS OPERATING MANUAL
Warning format
All warnings have the following format:
The following character formats are used in this operating
manual:
WARNING
Type and source of danger
Consequences of ignoring the warning
JAction needed to avoid danger.
IRequirement
This requirement must be met first; e.g.
IThe device is switched on.
J
1.
2.
Instruction
Follow the instructions given (the numbers indicate the order
in which the instructions should be followed); e.g.
JSelect mode.
Italics
Result
Indicates the result of following an instruction; e.g.
The page opens.
Bold
type face
Pages, controls, and display elements
Screen pages, controls, and display elements are indicated in
bold type.
Text in
blue
Cross references
Cross references are indicated in blue type. When using the
PDF version, just click on the blue text to skip to the cross
reference.
[MODE] Device keys
Device keys are indicated within square brackets.

OLP-37XV2 9
WARNING SYMBOLS ON THE DEVICE
2 SAFETY INFORMATION
2SAFETY INFORMATION
Warning symbols on the device
Proper use
This instrument is intended for measurements on optical fiber
devices and systems.
JPlease make sure the instrument is not operated outside the
permitted ambient conditions.
JObserve the specified measurement range.
JAlways make sure that the instrument is in proper working
order before switching it on.
Warning symbols indicating a potential hazard
JA warning symbol on the device indicates a potential hazard.
In all cases where the a warning symbol is shown on the
display or labeled on the device, the operating manual must
be consulted to learn more about the nature of the potential
hazard and any actions that have to be taken.

10 OLP-37XV2
2 SAFETY INFORMATION
LASER SAFETY
Laser safety
Battery operation
WARNING
Dangerous laser radiation
Laser radiation can cause irreparable damage to the eyes
and skin.
The maximum permitted power for the OLP-37XV2 means that
the optical input signals can reach Hazard Level 4, depending
on the device type.
Bear this in mind when using the OLP-37XV2.
JAlways be aware of the hazard level of the device to be
connected.
JConnect all optical fibers before switching on the radiation
source.
JSwitch off the laser source before disconnecting the optical
fibers.
JNever look directly into the output of a laser source or into
an optical fiber connected to it.
JAlways cover unused ports.
JHeed the normal precautions for working with laser radiation
and consider local regulations.
WARNING
Explosion danger
Short-circuiting the batteries can result in overheating,
explosion or ignition of the batteries and their surround-
ings.
JNever short-circuit the battery contacts by touching both
contacts simultaneously with an electrically conductive
object.
JOnly use AA size dry batteries or rechargeable batteries.
JTake care to insert the batteries correctly.
JNever use batteries based on lithium.

OLP-37XV2 11
VENTILATION
2 SAFETY INFORMATION
Ventilation
WARNING
Explosion danger
Dry batteries must not be recharged.
JThe OLP-37XV2 does not have a recharge function for
rechargeable batteries, so there is no danger when using dry
batteries.
JRead the manual of the external charging device.
NOTICE
Insufficient ventilation
Insufficient ventilation can damage the device or adversely
affect its function and safety.
JEnsure adequate ventilation when operating the instrument.

12 OLP-37XV2
3 GETTING STARTED
UNPACKING THE DEVICE
3GETTING STARTED
Unpacking the device
Packing material
We suggest that you keep the original packing material. It is
designed for reuse (unless it is damaged during shipping). Using
the original packing material ensures that the device is properly
protected during shipping.
Checking the package contents
Your device is shipped with the following accessories:
• 2.5 mm universal adapter
• 2 dry batteries AA
• Operating manual
• Belt bag
Checking for shipping damage
After you unpack the device, check to see if it has been damaged
during shipping. This is particularly likely if the packaging is
visibly damaged. If there is damage, do not attempt to operate
the device. Doing so can cause further damage. In case of
damage, please contact your local Viavi Sales Company.
Addresses can be found at
www.viavisolutions.com.
Recovery following storage/shipping
Condensation can occur if a device that is stored or shipped at a
low temperature is brought into a warm environment. To prevent
damage, wait until no more condensation is visible on the
surface of the device before powering it up. Do not operate the
instrument until it has reached its specified temperature range
and wait until it has cooled down if the instrument was stored at
a high temperature (see
“Environmental conditions” on page 30 ).

OLP-37XV2 13
DEVICE OVERVIEW
3 GETTING STARTED
Device overview
1
6
5
4
3
2
1 Test head cover
2 Fixed SC adapter
3 Display
4 Key pad
Representation in the user manual:
[]Context sensitive keys (here left key is selected)
[MODE] Mode/Settings key
[G]Save/Results key
[E]Power key
5 USB interface
For power supply and measurement data downloads and updates.
6 Battery compartment (on rear of the device)

14 OLP-37XV2
3 GETTING STARTED
POWER SUPPLY
Keys
The key pad contains two types of keys:
•Context sensitive keys: The functions of these keys depend
on the selected mode or menu and is shown in the display
above the key.
•Function keys: The functions of these keys are always the same
and shown on the key itself.
Key usage (first and second function levels)
The function keys and the context sensitive keys in certain
modes have two function levels.
A second function level is indicated by two cascading frames.
•Short press: Select the first level function.
•Long press: Holding the key for at least 2 sec. opens the
second level. You then have access to additional functions or a
menu to change settings.
Power Supply
NOTE: The devices are not designed for batteries based on lithium.
The following power sources can be used to operate the
OLP-37XV2:
• Two 1.5 V dry batteries (Mignon AA size, alkaline type
recommended)
• Two 1.2 V NiMH rechargeable batteries (Mignon AA size)
• via AC adapter over USB interface
Short press Long press
Press to switch the device on/off.
Context keys Left key: Select mode G-PON >
XGS-PON > Dual > ...
–
Center key: Abs>Ref –
Right key: Select mode dBm/Watt
> Loss > PF Abs > PF Loss > ...
Select dBm or Watt
MODE key – Open the settings menu.
Save/Result key Store the current measurement. Open the list of saved
measurements.

OLP-37XV2 15
POWER SUPPLY
3 GETTING STARTED
Battery operation
Replacing the batteries
The battery compartment is on the back of the device.
1. Pull down the lid to open the battery compartment.
NOTICE: Take care to insert the batteries correctly.
The correct polarity is indicated by a diagram inside the battery
compartment.
2. Insert new batteries or replace dead ones.
3. Close the battery compartment.
4. Press [E] to switch on.
NOTE: The batteries cannot be recharged with the OLP-37XV2.
General tips on using batteries
• Never use batteries based on lithium.
• Always handle batteries with care.
• Do not drop or damage the batteries or expose them to
excessively high temperatures.
• Do not store rechargeable batteries for more than one or two
days at very high temperatures (e.g. in a vehicle), either
separately or fitted in the device.
• Do not leave discharged batteries in the device for a long time
if it is not being used.
• Do not store rechargeable batteries for more than 6 months
without recharging them at intervals.
• Avoid deep discharging of the batteries as this can cause the
cell polarity to reverse and make the battery useless.
WARNING
Dangers in handling batteries
Handling batteries may be dangerous. Please note the
following safety instructions.
JPlease note the battery operation safety information in the
section
“Battery operation” on page 10 .
Replacing the batteries
JDo not replace individual batteries. Always change both
batteries at the same time.
JAlways use batteries of the same type; i.e. do not mix
rechargeable and non-rechargeable batteries.

16 OLP-37XV2
3 GETTING STARTED
POWER SUPPLY
Protecting the environment
Please dispose of any unwanted dry batteries and rechargeable
batteries carefully. They should also be removed from the
instrument if it is to be scrapped. If facilities in your country exist
for collecting waste or for recycling, please make use of them
rather than throwing the batteries in the normal trash. You will
often be able to return used batteries to the place where you
purchase new ones. Any dry or rechargeable batteries that you
purchased from Viavi can be returned to one of our Service
Centers for disposal.
Operation from AC power
To fit one of the mains plug adapters:
JSee
Fig. 1 and follow the instructions which are shown on the
packaging of the mains plug adapter.
Fig. 1 Fitting the mains plug adapter
To operate the OLP-37XV2 from AC power:
1. Connect the USB-C connector power cord to the OLP-37XV2.
2. Plug the mains plug adapter into the AC receptacle.
1 2
3 4

OLP-37XV2 17
SWITCHING THE DEVICE ON/OFF
4 OPERATION
4OPERATION
Switching the device on/off
The OLP-37XV2 has two battery power modes:
To switch the device on/off:
JPress [E] to switch the device on/off.
Selecting a power mode
To change the power mode:
IThe device is switched on.
1. Long press [MODE] to open the settings menu.
2. Use [] to select ECON.
3. Press [ ] to select power mode:
ON = ECON
OFF = PERM
4. Press [MODE] to close the menu.
Mode Icon Description
Permanent ON
(PERM)
The device is switched on
permanently.
Automatic OFF
(ECON)
The device switches off 20 minutes
after the last operation.
This function is only available when
the device is powered from
batteries.

18 OLP-37XV2
4 OPERATION
DISPLAY ELEMENTS
Display elements
The following elements can be found in the display.
1
2
3
Display of one value (here G-PON) Display of both values in Dual mode
1 – Status bar
PON Mode
Further modes for future use.
Bluetooth® is active
Bluetooth connction allows for data transfer via the MobileTech app (for future use).
7:15 Real Time Clock
Time can be changed via the settings menu.
Battery status in PERM power mode:
Device remains switched on.
Battery status in ECON power mode:
Device switches off 20 minutes after the last operation.
The device is powered via USB
2 – Center of display
... db/dBm Shows the measurement results in dBm, dB or W.
...-PON
... nm
Display of selected mode and wavelength.
3 – Context sensitive key functions
1490nm
Dual
Selection of mode: 1490 nm > 1577 nm > Dual >....
Short press: Setting current measurement value as new reference level.
Short press: Select mode dBm/Watt > Loss > PF Abs > PF Loss > ...
Long press: Toggle dBm <> Watt

OLP-37XV2 19
SETTINGS MENU
4 OPERATION
Settings menu
The following settings can be changed in the settings menu.
JTo open the settings menu long press [MENU].
Item Settings Description
Hour 1...12 JPress [] to change
setting:
– Press once to change one
step at a time.
– Hold down the key to
increase the step change
rate.
Minute 1...59
Year 2020...2030
Month 01...12
Day 01...31
About Show device data
including last
calibration date
JPress [] to confirm setting.
JPress [ ] to return to the
settings menu.
Factory Reset Reset
Auto Lambda ON/OFF Press [ ] (right context
key to toggle ON/OFF
Bluetooth LE ON/OFF
ECON ON/OFF
ON = ECON
OFF = PERM

20 OLP-37XV2
4 OPERATION
SELECTING A OPERATION MODE
Selecting a operation mode
The OLP-37XV2 provides three operation modes with following
displays:
•G-PON: Gigabit Passive Optical Network measurement at
1490 nm
•XGS-PON: 10-Gigabit-Capable Symmetric Passive Optical
Network measurement at 1577 nm
•Dual: Display of G-PON and XGS-PON simultaneously
To select a operation mode:
JPress [] to select a mode.
Fig. 2 Operation modes
