VICI DBS PG Plus Rack 100 User manual

1
PG PLUS RACK + ZERO AIR
& GC PLUS RACK USER MANUAL www.vicidbs.com
Version 2.00.0000
TECH SUPPORT
Europe, Asia, Africa, Australia & New Zealand:
[e-mail]
USA, Canada, Central & South America:
[e-mail]
Italy
ser[email protected]
VICI AG INTERNATIONAL
Parkstrasse 2
CH-6214 Schenkon
Switzerland
tel: [phone]
fax: [phone]
web: www.vicidbs.com
APPLICABLE MODELS
This manual is applicable to the following models:
• PG Plus Rack 100
• PG Plus Rack 160
• PG Plus Rack 250
• PG Plus Rack 300
• PG Plus Rack 500
• PG Plus Rack 600
• DB-FH-1800 Zero Air
• DB-FH-5000 Zero Air
Version 2.01.0000
• GC Plus Rack 1800
• GC Plus Rack 5000
• GC Plus Rack 10000
• GC Plus Rack 15000

2
PG PLUS RACK + ZERO AIR
& GC PLUS RACK USER MANUAL www.vicidbs.com
Version 2.00.0000
TABLE OF CONTENTS
1. VERSION HISTORY................................................................................................................................ 4
2. INTRODUCTION.................................................................................................................................... 4
2.1. SYMBOL DEFINITION .........................................................................................................................5
2.2 TRANSPORT AND STORAGE CONDITIONS ......................................................................................5
2.3. ENVIRONMENTAL CONDITIONS.......................................................................................................6
3. SAFETY.................................................................................................................................................. 6
3.1. NOTES ON FCC COMPLIANCE..........................................................................................................6
3.2. CORRECT USE ....................................................................................................................................6
4. SPECIFICATIONS ................................................................................................................................... 7
4.1. PG PLUS RACK .................................................................................................................................7-9
4.2. ZERO AIR OPTION..............................................................................................................................9
4.3. GC PLUS ZERO AIR RACK.................................................................................................................10
5. FUNCTIONALITY................................................................................................................................. 11
5.1. MOST COMMON OPTIONS............................................................................................................. 12
5.1.1. Part Numbers ...........................................................................................................................12
5.1.2. Remote Connections (I/O Board).............................................................................................12
5.1.3. Cascading.................................................................................................................................13
5.1.4. Auto Rell Option ....................................................................................................................14
6. THE UNIT............................................................................................................................................. 14
6.1. FRONT VIEW ..................................................................................................................................... 14
6.1.1. PG Plus Rack - H2 Only Model..................................................................................................14
6.1.2. PG Plus Rack - H2 + Zero Air Model.........................................................................................14
6.1.3. GC Plus Zero Air Rack ..............................................................................................................15
6.2. BACK VIEW ...................................................................................................................................... 15
6.2.1. PG Plus Rack - H2 Only Model..................................................................................................15
6.2.2. PG Plus Rack - H2 + Zero Air Model.........................................................................................16
6.2.3. GC Plus Zero Air Rack ..............................................................................................................16
6.3. TOP VIEW.......................................................................................................................................... 17
6.4. DIMENSIONS .................................................................................................................................... 18
6.5. SCHEMATICS ....................................................................................................................................18
6.5.1. Fluidics ................................................................................................................................18-20
6.5.2. Electronics...........................................................................................................................20-22
7. INSTALLATION AND INITIAL START-UP ............................................................................................. 23
7.1. RECEIVING THE GENERATOR..........................................................................................................23
7.2. PACKING LIST ...................................................................................................................................23
7.3. PLACING THE GENERATOR .............................................................................................................23
7.4. VOLTAGE SELECTION.......................................................................................................................24

3
PG PLUS RACK + ZERO AIR
& GC PLUS RACK USER MANUAL www.vicidbs.com
Version 2.00.0000
7.5. GAS CONNECTIONS........................................................................................................................24
7.5.1. Hydrogen Part..........................................................................................................................24
7.5.2. Zero Air Part .............................................................................................................................25
7.6. INITIAL START-UP..............................................................................................................................25
7.6.1. Filling the Water Tank...............................................................................................................25
7.6.2. Installing the Deionizer Bag .....................................................................................................26
7.6.3. Starting the Hydrogen Generator .......................................................................................27-28
7.7. STARTING THE ZERO AIR GENERATOR ......................................................................................28-29
8. OPERATION - HYDROGEN PART........................................................................................................ 30
8.1. LCD DISPLAY .....................................................................................................................................30
8.1.1. Layout of the Display................................................................................................................30
8.1.2. First Row - Status Information ..................................................................................................30
8.1.3. Second Row - Pressure Information .........................................................................................30
8.1.4. Third Row - Hydrogen Flow .....................................................................................................31
8.1.5. Fourth Row - Water Quality......................................................................................................31
8.1.6. Start/Stop-Reset Button ...........................................................................................................31
8.1.7. Exit-Menu Button .....................................................................................................................31
8.2. MENU STRUCTURE...........................................................................................................................32
8.3. CONFIGURE PARAMETERS.........................................................................................................33-34
8.4. DIAGNOSTIC DISPLAY .....................................................................................................................34
8.5. SPECIAL FUNCTIONS.......................................................................................................................35
9. OPERATION - ZERO AIR PART ............................................................................................................ 35
9.1. CONNECT POWER AND START UNIT..............................................................................................35
9.2. WARMING UP ...................................................................................................................................35
9.3. SHUTDOWN PROCEDURE ...............................................................................................................36
10. ERROR LIST - TROUBLESHOOTING .................................................................................................. 36
10.1. HYDROGEN PART ......................................................................................................................36-37
10.2. ZERO AIR PART ...............................................................................................................................37
10.2.1. Front Panel LED .....................................................................................................................37
10.2.2. Error Codes on Mainboard.....................................................................................................38
11. MAINTENANCE................................................................................................................................. 39
11.1. ROUTINE MAINTENANCE HYDROGEN PART................................................................................39
11.2. ROUTINE MAINTENANCE ZERO AIR PART....................................................................................39
11.2.1. Maintenance Kits....................................................................................................................40
11.2.2. Annual Maintenance Kit .........................................................................................................40
11.2.3. Three-Year Catalyst Replacement Kit.....................................................................................40
11.3. ANNUAL PRE-FILTER ELEMENT REPLACEMENT............................................................................40
11.4. THREE YEAR CATALYST CHAMBER REPLACEMENT...................................................................... 41
12. RETURNING THE UNIT...................................................................................................................... 42
13. SPARE PARTS LIST............................................................................................................................. 43
13.1. HYDROGEN PART ..................................................................................................................... 43-46
13.2. ZERO AIR PART ...............................................................................................................................46

4
PG PLUS RACK + ZERO AIR
& GC PLUS RACK USER MANUAL www.vicidbs.com
Version 2.00.0000
1. VERSION HISTORY
VERSION DATE COMMENT/CHANGE
1.00.0100 January 18, 2017 Layout, initial release - VICI DBS
1.01.0000 February 15, 2019 Update - VICI DBS
2.00.0000 December 15, 2020 New layout, images and graphics - VICI Gig Harbor Group
Error code implemented, spare part list corrected, minor
correction - VICI DBS
2.01.0000 May 3, 2021 Typing error between PG and NM, new spare parts list -
VICI DBS
2. INTRODUCTION
This manual provides operation and maintenance instructions for the rack models PG-100, PG-160, PG-250,
PG-300, PG-500, and PG-600 Plus hydrogen generators.
It includes the optional zero air generator 1800 / 5000 and the standalone zero air generator rack 1800, 5000,
10000 and 15000.

5
PG PLUS RACK + ZERO AIR
& GC PLUS RACK USER MANUAL www.vicidbs.com
Version 2.00.0000
2.1. SYMBOL DEFINITIONS
SYMBOL DESCRIPTION
General warning. Caution is necessary when operating the device or control
close to where the symbol is placed, or to indicate that the current situation
needs operator awareness or operator action in order to avoid undesirable
consequences.
The manual must be consulted in all cases where this symbol is marked on
the device.
Risk of asphyxia. Caution is necessary when operating the device in a not
sufciently ventilated area.
Oxidant material. Caution is necessary due to the presence of oxidant material.
WEEE symbol. When discard this product, it must be sent to separate collection
facilities for recovery and recycling.
Fuse. Notify replaceable fuse place.
2.2. TRANSPORT AND STORAGE CONDITIONS
TEMPERATURE Minimum +4º C, Maximum +45º C
HUMIDITY < 90% RH, non-condensing
SHOCKS & VIBRATIONS DURING TRANSPORT Shocks < 1g; vibrations < 0.2g/5Hz
INSTRUMENT POSITION Horizontal
THE ABOVE-MENTIONED VALUES ARE FOR AN INSTRUMENT TRANSPORTED IN ITS ORIGINAL NEW
PACKAGING.
Recommendations for Transport
When the instrument is shipped back to the factory for repair, the generator should be packed in the original
packaging with the inlets and outlets protected against dust or particles.
OR
OR
OR

6
PG PLUS RACK + ZERO AIR
& GC PLUS RACK USER MANUAL www.vicidbs.com
Version 2.00.0000
2.3. ENVIRONMENTAL CONDITIONS
OPERATING TEMPERATURE Minimum +15º C, Maximum +40º C
HUMIDITY < 80% RH, non-condensing
ATMOSPHERIC PRESSURE From 850 to 1150 hPa
EXTERNAL VIBRATIONS < 0.05g/25Hz
INSTRUMENTS POSITION Horizontal
3. SAFETY
3.1. NOTES OF FCC COMPLIANCE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in an installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna
• Increase the distance between the equipment and the receiver
• Connect the equipment to an outlet on a circuit different from that to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
3.2. CORRECT USE
The hydrogen generator is designed to produce hydrogen for laboratory use. The unit should only be used
for this purpose, according to the specications and instructions provided in this manual. In particular, the
following warnings must always be observed:
• Indoor use only
• Never operate the unit at temperatures below 0°C (32°F). This will cause irreversible damage to the
electrolysis cell.
• Use only pure, deionized water (see “Filling the Water Tank”)
• Operate the unit in a room with sufcient ventilation (see “Placing the unit”)
• Always unplug the unit from the mains power supply before accessing the internal components for service
or repair work

7
PG PLUS RACK + ZERO AIR
& GC PLUS RACK USER MANUAL www.vicidbs.com
Version 2.00.0000
WARNING: Any changes or modications to this equipment not expressly approved
by the manufacturer may void the user’s authority to operate the equipment.
PG PLUS
100 RACK
PG PLUS
160 RACK
PG PLUS
250 RACK
PG PLUS
300 RACK
PG PLUS
500 RACK
PG PLUS
600 RACK
Flow mL/min 100 160 250 300 500 600
Purity >99.9996%
Dewpoint at 7 barg (100 psig) -25ºC (-13ºF)
Outlet pressure barg (psig) 0.5 to 11 (7 to 160)
Technology PEM (Proton Exchange Membrane) - 100% Titanium cell
Drying system Regenerative permeation membrane
Deionized water quality Minimum < 1 µS/cm @25ºC - 1 MΩ cm @25ºC - ASTM II
Recommended < 0.2 µS/cm @25ºC - 5 MΩ cm @25ºC - ASTM II
External water tank (liters) External 10 liter bottle and internal pump
Safety Automatic shut down - internal/external hydrogen leak,
overpressure and low water
Display Touch screen with operating parameters, system status and safety alarms
LED indicators Power on/off, system ready, errors
Interface USB mod A
Electrical supply 110-120V 60Hz / 220-240V 50Hz
Power consumption (watts) 65 95 115 130 180 280
Dimensions mm (inches) 19” Rack W x 3U H x 500D (19.6)
Weight kg (lbs) 17 (37.4) 19 (41.9)
Shipping dimensions mm (in) 720W x 375H x 565D (28.3W x 14.7H x 22.2D)
Shipping weight kg (lb) 21 (46) 23 (50)
Operating temp oC (oF) 15 to 35 (59 to 95)
Outlet connection 1/8" Compression
Certication CE, FCC, MET (UL and CSA compliant)
MODELS & SPECS
4. SPECIFICATIONS
4.1. PG PLUS RACK

8
PG PLUS RACK + ZERO AIR
& GC PLUS RACK USER MANUAL www.vicidbs.com
Version 2.00.0000
Hydrogen ow rate at Standard
Temperature and Pressure
(20°C, 1 barg)
Cell-Type:
Proton Exchange Membrane (PEM)
100% Ti Cell
Part-Number (PN)
PG Plus Rack 100 0-100 cc/min Cell-PN: DB-CELL-MI
PG Plus Rack 160 0-160 cc/min Cell-PN: DB-CELL-MI
PG Plus Rack 250 0-250 cc/min Cell-PN: DB-CELL-MU1
PG Plus Rack 300 0-300 cc/min Cell-PN: DB-CELL-MU1
PG Plus Rack 500 0-500 cc/min Cell-PN: DB-CELL-MU2
PG Plus Rack 600 0-600 cc/min Cell-PN: DB-CELL-MU2
4.2. ZERO AIR OPTION
DB-FH-1800 or DB-FT-1800 DB-FH-5000 or DB-FT-5000
Flow mL/min 1800 5000
Purity - hydrocarbons + CO <0.1 ppm
Inlet pressure barg (psig) 4.5 to 10 (65 to 145)
Inlet air quality Clean dry compressed air ISO8573-1:2010 Class 1.2.1
Max outlet pressure barg (psig) 5 (73)
Max HC in 100 ppm
Max CO in 50 ppm
Technology Platinum catalyst
LED indicators Power on/off, system ready, errors
Warm up time (minutes) 45
Electrical supply 110-120V 60Hz / 220-240V 50Hz
Power consumption (watts) 200 550
Operating temperature ºC (ºF) 15 to 35 (59 to 95)
Inlet connection 1/4” Compression
Outlet connection 1/8” Compression
Certication CE, FCC, MET (UL and CSA compliant)
MODELS & SPECS

9
PG PLUS RACK + ZERO AIR
& GC PLUS RACK USER MANUAL www.vicidbs.com
Version 2.00.0000
4.3. GC PLUS ZERO AIR RACK
GC PLUS
1800 RACK
GC PLUS
5000 RACK
GC PLUS
10000 RACK
GC PLUS
15000 RACK
Flow mL/min 1800 5000 10000 15000
Purity - hydrocarbons <0.1 ppm
Purity - CO <0.1 ppm
Inlet pressure barg (psig) 4.5 to 10 (65 to 145)
Inlet air quality Clean dry compressed air ISO8573-1:2010 Class 1.2.1
Max outlet pressure barg (psig) 1 (15) drop from inlet
Max HC in 100 ppm
Max CO in 50 ppm
Technology Platinum catalyst
LED indicators Power on/off, system ready, errors
Warm up time (minutes) 45
Electrical supply 110-120V 60Hz / 220-240V 50Hz
Power consumption (watts) 200 550 550 550
Dimensions mm (in) 19”W x 3UH x 500D (19”W x 3UH x 19.6D)
Weight kg (lbs) 15 (33)
Shipping dimensions mm (in) 720W x 565H x 375D (28.3W x 22.2H x 14.7D)
Shipping weight kg (lbs) 19 (42)
Operating temp oC (oF) 15 to 35 (59 to 95)
Inlet connection 1/4” Compression
Outlet connection 1/8" Compression
Certication CE, FCC, MET (UL and CSA compliant)
MODELS & SPECS

10
PG PLUS RACK + ZERO AIR
& GC PLUS RACK USER MANUAL www.vicidbs.com
Version 2.00.0000
5. FUNCTIONALITY
The hydrogen generator produces pure hydrogen (and oxygen as a by-product) by the electrolysis of water.
The key element of the generator is an electrochemical cell which contains a solid polymer electrolyte. No
free acids or alkalines are used. Deionized or pure distilled water is the only liquid which will come into
contact with the cell. As this is consumed it must be relled from time to time as required.
The hydrogen is passing the hydrogen/water separator and the permeation drying tube. The pressure is
controlled by current. The hydrogen then passes through the outlet port at the rear.
WATER
TANK
HYDROGEN
PRESSURE
RELIEF
HYDROGEN
OUTLET
PRESSURE
SENSOR
GAS/LIQUID
SEPARATOR
HYDROGEN
CELL
DRAIN
PORT
WATER PUMP
FLOW SENSOR
PERMEATION
DRYING MEMBRANE
PERMEATION
DRYING MEMBRANE
SHUTOFF
VALVE

11
PG PLUS RACK + ZERO AIR
& GC PLUS RACK USER MANUAL www.vicidbs.com
Version 2.00.0000
5.1. MOST COMMON OPTIONS
5.1.1. Part Number s
OPTION PART NUMBER
BOARDS/INTERFACES
I/O Board DB-10155
Remote Control RS232 (software + cable) DB-PH200-107
Remote Control USB (software + cable) DB-PH200-108
CASCADING OPTION
Cascading Hardware Kit DB-CASC-001
On/Off and Non-Return Valve DB-CASC-002
Buffer Reservoir 0.75 Liters DB-CASC-003
Cable for Cascading, Requires I/O Board DB-10157
PR with Pressure Gauge DB-CASC-004
Cascading Hardware Kit - High Purity DB-CASC-005
Pressure Regulator with Pressure Gauge - High Purity DB-CASC-006
AUTO-REFILL OPTION
Rell Valve - Replacing Inlet Pump (for H2O pressurized lines) DB-RH200-020
5.1.2. Remote Connections (I/O Board)
The hydrogen generators are tted with an optional remote-control feature, which allows the user to remotely
check the status of the generator and to start/stop the production of hydrogen. The contacts used in the
remote control are potentially free relay contacts. The contacts can be congured via software as normally
open or normally closed (see the Conguration section). The maximum voltage and current ratings for the
contacts are 1A / 48V. The pin conguration of the remote connector is shown in the table below.
Remote Connector Pin Conguration:
PIN DESCRIPTION
1+2 Start (12-30 VDC polarity independent)
3+4 Standby
5+6 Reaching external pressure
9+10 Low water level
11+12 Bad water
13+14 Change water

12
PG PLUS RACK + ZERO AIR
& GC PLUS RACK USER MANUAL www.vicidbs.com
Version 2.00.0000
GAS LINE
PRESSURE CONTROLLER
NON RETURN VALVE NON RETURN VALVES
H2OUT
GENERATOR 1
H2OUT
GENERATOR 2
H2OUT
GENERATOR 3
CONFIGURATION
Cascading Mode: YES
N. Gen H2 in Cascading: 3
ID Number: 1
RS-485 Port 1 RS-485 Port 2
CONFIGURATION
Cascading Mode: YES
N. Gen H2 in Cascading: 3
ID Number: 2
RS-485 Port 1 RS-485 Port 2
CONFIGURATION
Cascading Mode: YES
N. Gen H2 in Cascading: 3
ID Number: 3
RS-485 Port 1 RS-485 Port 2
5.1.3. Cascading
This option requires the I/O board option.
The RS-485 interface allows up to 10 generators to be operated in parallel mode. The generators are
connected to an external non return valve to a gas line. The pressure must be controlled with an external
pressure regulator. The outlet pressure is xed to 10.3 bars. This mode allows up to 10 generators in a
cascading group.
How does cascading work?
The communication of the generators is done via the RS-485 Interface. For a correct communication each
generator needs a unique ID number. ID number must start from 1. Each generator must know how many
generators are connected in the cascading group. As soon as the generators are powered up, one generator
becomes the master, and controls the others (slaves). If there is a problem with the master, one of the slave
generators will become the master.
Every generator can be forced to be the master, in the menu you will nd the function “Force to Master,”just
select this function and acknowledge.
When a generator is the master, you can see the letter “M” in the menu button, while the slaves show the
letter “S”.
For part-numbers for the cascading option please consult the parts list above.
CAUTION: The cascading function will only work properly if the gas outlets of all the
generators are connected to the same gas line.

13
PG PLUS RACK + ZERO AIR
& GC PLUS RACK USER MANUAL www.vicidbs.com
Version 2.00.0000
5.1.4. Auto-Rell Option
Auto rell is standard in the rack version with a lling pump. As an option a valve can be factory installed to
connect the generator to a pressurized deionizer water line. A maximum pressure of 4.5bar is allowed.
6. THE UNIT
6.1. FRONT VIEW
6.1.1. PG Plus Rack - H2Only Model
Touchscreen Display Easy access to the internal water tank
Water Drain to remove the water
from the internal water tank
On/Off Switch
USB Port
Control Buttons
6.1.2. PG Plus Rack - H2+ Zero Air Model
Air Information Display
Air Outlet Pressure Gauge
Air Outlet Pressure Regulator
Air On/Off Switch

14
PG PLUS RACK + ZERO AIR
& GC PLUS RACK USER MANUAL www.vicidbs.com
Version 2.00.0000
6.1.3. GC Plus Zero Air
Air Information Display Air Outlet Pressure Gauge
Air Outlet Pressure Regulator
Air On/Off Switch
Service Indicator
6.2. BACK VIEW
6.2.1. PG Plus Rack - H2Only Model
H2 Outlet
H2 Outlet Relief Valve
IO Board Option
External Water Tank Inlet 110/230 V Inlet
USE CORRECT FUSE
REMOVE PLUG BEFORE USE

15
PG PLUS RACK + ZERO AIR
& GC PLUS RACK USER MANUAL www.vicidbs.com
Version 2.00.0000
6.2.2. PG Plus Rack - H2+ Zero Air Model
H2 Outlet
H2 Outlet Relief Valve
IO Board Option External Water
Tank Inlet
110/230 V Inlet
REMOVE PLUG BEFORE USE
USE CORRECT FUSE
Compressed Air Inlet Zero Air Outlet
6.2.3. GC Plus Zero Air Rack
110/230 V Inlet
USE CORRECT FUSE
Compressed Air Inlet Zero Air Outlet

16
PG PLUS RACK + ZERO AIR
& GC PLUS RACK USER MANUAL www.vicidbs.com
Version 2.00.0000
6.3. TOP VIEW

17
PG PLUS RACK + ZERO AIR
& GC PLUS RACK USER MANUAL www.vicidbs.com
Version 2.00.0000
6.4. DIMENSIONS
133.4 mm (5.3 in)
500 mm (19.7 in)
482.6 mm (19 in)
6.5. SCHEMATICS
6.5.1. Fluidics
The hydrogen generator produces pure hydrogen (and oxygen as a by-product) by the electrolysis of water.
The key element of the generator is an electrochemical cell which contains a solid polymer electrolyte. No
free acids or alkalines are used. Deionized or pure distilled water is the only liquid which will come into
contact with the cell. As this is consumed it must be relled from time to time as required.
The hydrogen is passing the hydrogen/water separator and the permeation drying tube. The pressure is
controlled by current. The hydrogen then passes through the outlet port at the rear.
Air from the external compressed air source goes rst trough an external dust lter. Then it will pass through a
catalytic oven that will remove the CO and CH4. After cooling, the air is ready.

18
PG PLUS RACK + ZERO AIR
& GC PLUS RACK USER MANUAL www.vicidbs.com
Version 2.00.0000
PG PLUS RACK P/N 100/160 250/300 500/600
CELL DB-CELL-MI DB-CELL-MU1 DB-CELL-MU2
GAS LIQUID SEPARATOR (GLS) DB-RH200-010
OVER PRESSURE RELIEF VALVE DB-H200-035
PERMA PURE TUBES DB-H200-034
System:
Schematic no:
Date:
Created:
Checked:
Released:
THIS DOCUMENT AND THE INFORMATION WHICH
IT CONTAINS SHALL NOT BE USED, EXPLOITED
OR SOLD, AND SHALL NOT BE REVEALED OR
DISCLOSED TO OTHERS WITHOUT THE EXPRESS
WRITTEN PERMISSION OF VICI. THIS DOCUMENT
SHALL REMAIN THE PROPERTY OF VICI AND
SHALL BE RETURNED UPON DEMAND.
R
Rev.:
Sheet:
By:
Description:
ECN no:
PG Plus Rack
water and hydrogen flow diagram 06.10.2020
06.10.2020
SBU
SB
1
1/1

19
PG PLUS RACK + ZERO AIR
& GC PLUS RACK USER MANUAL www.vicidbs.com
Version 2.00.0000
GC PLUS RACK P/N 1800 5000 10000 15000
INLET FILTER DB-10567
PRESSURE REGULATOR DB-RH200-015
FLOW RESTRICTOR DB-5000-0051 DB-5000-0052 DB-5000-0106 DB-5000-0107
CATALYST OVEN DB-10494 DB-10495 DB-10642 DB-10643
COOLING COIL DB-RH200-026 DB-RH200-027 DB-10424
CHECK VALVE DB-10640
OUTLET FILTER DB-10641
6.5.2. Electronics
System:
Schematic no:
Date:
Created:
Checked:
Released:
THIS DOCUMENT AND THE INFORMATION WHICH
IT CONTAINS SHALL NOT BE USED, EXPLOITED
OR SOLD, AND SHALL NOT BE REVEALED OR
DISCLOSED TO OTHERS WITHOUT THE EXPRESS
WRITTEN PERMISSION OF VICI. THIS DOCUMENT
SHALL REMAIN THE PROPERTY OF VICI AND
SHALL BE RETURNED UPON DEMAND.
R
Rev.:
Sheet:
By:
Description:
ECN no:
PG Plus Rack
electrical diagram 20.04.20
08.06.20
SBU
SB
1
1/(2)

20
PG PLUS RACK + ZERO AIR
& GC PLUS RACK USER MANUAL www.vicidbs.com
Version 2.00.0000
PG PLUS RACK P/N 100/160/250 300 500/600
POWER INLET DB-H200-045
POWER SUPPLY DB-PH200-003 DB-PH200-004
I/O BOARD DB-10155
DISPLAY BOARD DB-10648
DISPLAY MEMBRANE DB-H200-042
PG PLUS RACK MODEL MAIN BOARD INLET FAN OUTLET FAN
100 DB-RH201-008 DB-H200-040 DB-H200-040
160 DB-RH202-008
250 DB-RH203-008
300 DB-RH204-008
500 DB-RH205-008
600 DB-RH206-008
