CHRONO CLASSIC XLS ALARM
INSTRUCTION MANUAL

| 1
I. GENERAL INFORMATION :
– Multi-function movement 2
– Initial status 2
– Chronograph active 2
II. TECHNICAL INSTRUCTIONS :
– Setting the time and date 4
– Rapid date adjustment 4
– Reference time 6
– Setting alarm time 8
– Chronograph 10
VICTORINOX SWISS ARMY INSTRUCTIONS FOR USE

I. GENERAL INFORMATION
2 | Chrono Classic XLS Alarm – Instruction Manual
MULTI-FUNCTION MOVEMENT :
The alarm and chronograph are combined within this movement. All functions can be operated
with the 2 push-buttons and crown.
INITIAL STATUS (CHRONOGRAPH HANDS ARE AT ZERO POSITION) :
w Start the Chronograph with Pusher A
w Turn alarm on and off with Pusher B
CHRONOGRAPH ACTIVE :
Pusher B is also operative for the chronograph as soon as timing is started with Pusher A. At the
end of timing, when the chronograph hands are reset to zero, the pusher functions revert to their
initial status.
Alarm cannot be adjusted when the chronograph is active.

| 3
Seconds Counter Pusher A
Hour Hand
Crown
Date
Pusher B
Minute Hand
Hour & Minute counter
Alarm & Reference Time

4 | Chrono Classic XLS Alarm – Instruction Manual
SETTING THE TIME AND DATE :
w Pull out crown to position II
w Turn crown until yesterday’s date appears
w Pull out crown to position III (the alarm display changes from alarm time to reference time)
w Turn crown until correct date appears (at 12 midnight)
w Continue to turn crown to desired time
w Push in crown to position I (the alarm display changes from reference to alarm time)
RAPID DATE ADJUSTMENT :
w Pull out crown to position II
w Turn crown until correct date appears
w Push crown back to position I
Please Note : Resetting the time also requires the identical correction of the reference time –
please refer to “setting the reference time”.
II. TECHNICAL INSTRUCTIONS

| 5
I II III
Set time
Set date

6 | Chrono Classic XLS Alarm – Instruction Manual
REFERENCE TIME :
What is ‘reference time’ ? – The current time is displayed by the hour and minute hand, however
parallel to this, the reference time runs in the background. The alarm function refers to this refer-
ence time. This means that both the current time and reference time must always be synchronized
to ensure alarm sounds at correct time – any adjustments made to the current time have to also
be made to the reference time.
SETTING THE REFERENCE TIME :
w Pull out crown to position III
w Press pusher B for at least 2 seconds to activate setting mode
w Small minute hand will jump forward 1 second to indicate mode is active – reference time
can now be set to match current time
w Short pressing of pusher B (less than 1sec) moves reference time forward by the minute
w Medium pressing (1 – 2 sec) moves reference time forward by the hour
w Long pressing (longer than 2 sec) – reference time is moved forward until pusher is released
w Push in crown to position I
w Display changes from reference time to alarm time
w A signal indicates alarm is switched off
II. TECHNICAL INSTRUCTIONS

| 7
I III
Pusher B
Reference timeSmall minute hand

8 | Chrono Classic XLS Alarm – Instruction Manual
SETTING ALARM TIME :
Press pusher B for at least 2 seconds to activate setting mode. Small minute hand will jump
forward 1 second to indicate mode is active – alarm time can now be set
w Short pressing of pusher B (less than 1sec) moves alarm time forward by the minute
w Long pressing (longer than 2 sec) – alarm time is moved forward until pusher is released
Please Note: If the push button is not activated for 10 seconds, the alarm setting mode is
deactivated. At the same time two beeps are emitted to indicate alarm is on.
w Press pusher B to switch alarm on/off
– 1 beep – alarm off
– 2 beeps – alarm on
Please Note: The alarm can be set a maximum of 12 hours before the desired alarm time
II. TECHNICAL INSTRUCTIONS

| 9
Alarm time
Pusher B

10 | Chrono Classic XLS Alarm – Instruction Manual
CHRONOGRAPH :
The chronograph functions the same as on all chronograph models. Please refer to instructions
manual for how to use chrono.
REINITIALIZING THE CHRONOGRAPH HANDS:
w Pull out crown to position III
w Press pushers A and B simultaneously for at least 2 seconds
w The seconds chrono hand will rotate to indicate mode is activated
RESET SECONDS CHRONO HAND
w Press pusher A to revert hand to zero position
w Press pusher B to activate Hour & minutes reset-
RESET HOUR & MINUTES COUNTER
w Press pusher A to revert hands back to zero position
(Hands are mechanically coupled, so will revert together)
w Push in crown to position I
II. TECHNICAL INSTRUCTIONS

| 11
Seconds counter
Pusher A
Pusher B
Hour counter
Minute counter I III

VSAS08054
