Videofied IMD 200 User manual

Corner Mounting Holes
Note: Only two screws are
used for corner mounting (Le
or Right)
Corner Mounting
Flat Wall Mounting
Flat Wall
Mounting
Holes
The Motion Detector IMD 200/601/701 is a
wireless, indoor motion detector designed for
use in a Videofied security system. The motion
detector includes the following features:
> Lithium batteries for long life
> Standard motion coverage lens (30 ./9 m
distance)
> Dual tamper function provides detection of
both wall and cover tamper.
> Transmits check-in/status signal every 8 minutes
Product Summary
Installation Guidelines
For an easier installation, programming and RF testing should be
done to check for good communication between the control panel
and all system devices before mounting.
Install the detector and other system devices in the following order:
>Programming / RF Testing: Program detector and all other devices
into the control panel and test RF communication at each intended
device location to the control panel.
>Mounting: Mount detector at the tested location.
Mounting Rules
>Use proper tools and hardware.
>Mount indoors in a temperature controlled environment.
>Mount detector 2.1 to 2.3 m (6.9 to 7.5 .) from the floor.
>Respect Top and Bottom side of the Motion Viewer
>When possible, mount in a wall corner in order to aim at a complete
room
> Mount detector on an outside wall, aimed at area to protect.
>Do not aim detector at windows, especially those that let in direct
sunlight, or at heat sources such as lamps, fireplaces, radiators,
and heating vents.
>Do not aim detector at moving objects such as curtains, fans or
animals.
>Do not cover the Fresnel lens
Indoor Motion Detector IMD 200/601/701
PRODUCT INSTALLATION SHEET
www.videofied.com
Doc. - Ref. 214-IMD
Version : June 2013

Programming/RF Testing/Mounting
The following provides summarized steps for device programming,
testing, and mounting. For complete details, refer to the control panel
installation manual.
1 Loosen bottom screw. 1
Separate base from IMD. 2
2 Install 1 SAFT LS14500 3.6v batteries, observing correct
polarity.
3 Put control panel into programming/configuration mode.
4 Using a programmed alphanumeric keypad, proceed through
menus until the display shows ADD A NEW DEVICE.
5 Press Yes. The display shows PRESS PROGRAM BUTTON OF
DEVICE.
6 Press and release program button on the IMD using your finger
or a screw driver 1 . The programming button is located inside the
product on the top of the main PCB.
The IMD LED flashes red 2 .
7 Press Yes. The display shows RADIO RANGE TEST? Press Yes
again. The IMD LED starts flashing and keypad display shows TEST IN
PROGRESS.
8 Move the IMD to the intended mounting location and make sure
you receive a 9/9 indicating good communication with the control
panel.
9 Press YES to end the Radio Range Test, then press ESC/NO.
10 The display shows AREA ALLOCATION; AREA: 1. Press either
arrow button on the keypad until the desired AREA number appears,
then press YES. By default all devices in area 1 will be subject to the
entry and exit delays.
11 The display shows NAME + LOCATION:
Enter an appropriate device name (up to 16 characters). The name of
the device should describe its intended mounting location or zone.
Press YES. The display will show the device number and name for your
verification.
12 Mount the IMD on the wall:
> Follow the mounting rules on page 1
> Drill desired mounting holes in the IMD base and mark the
appropriate mounting holes on the wall.
> Drill pilot holes and install anchors where needed.
> Place base on mounting surface so that the pilot holes line up and
secure base with appropriate screws.
> Attach detector to base and secure with screw if required.
13 Press YES. The display shows FUNCTIONAL DEVICE TEST?
Press YES again and verify IMD operation. For example,
wave your hand in front of the sensor to activate the LED
which indicates detection.
14 Press YES to end the detection verification
15 The display shows ADD A NEW DEVICE? Repeat steps 1-14 for
remaining Devices.
16 When finished, exit from configuration mode by pressing and
holding the ESC/NO for 5 seconds.
①
②
②
Wait for keypad display to show DETECTOR (1 - 24) PROGRAMMED.
①
②
*Check that the LED flashes before staying RED
①
1
1
22
INSTALLATION SHEET
Indoor MotionViewer IMD 200/601/701
www.videofied.com

(EN) Security notes / (FR) Notes de sécurité / (DE) Hinweise zur Sicherheit
English Francais Deutsch
>Remove batteries before any maintenance!
>WARNING, there is a risk of explosion if a
battery is replaced by an incorrect type!
>Observe polarity when setting up the batteries!
>Do not throw used batteries! Bring them to your
installer or a collection point.
>Attention ! Il y a un risque d’explosion si l’une des
piles utilisées est remplacée par une pile de type
incorrect !
>Respectez la polarité lors de la mise en place des
piles !
>Ne jetez pas les piles usagées ! Ramenez-les à
votre installateur ou à un point de collecte spé-
cialisé.
>Batterien vor jeglichen Wartungsarbeiten
entfernen!
>Vorsicht, es besteht Explosionsgefahr, wenn eine
Batterie durch eine Batterie falschen Typs ersetzt
wird!
>Achten Sie beim Einsetzen der Batterien auf die
Polung!
>Entsorgen Sie Batterien nicht im normalen Haush-
altsmüll! Bringen Sie Ihre verbrauchten Batterien zu
den öffentlichen Sammelstellen.
FCC Regulatory Information for USA and CANADA
FCC Part 15.21 Changes or modifications made to this equipment not expressly approved by RSI VideoTechnologies may void the FCC authorization to operate this equip-
ment.
FCC Part 15.105 Class B
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
>Reorient or relocate the receiving antenna.
>Increase the separation between the equipment and receiver.
>Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
>Consult the dealer or an experienced radio/TV technician for help.
Radio frequency radiation exposure information according 2.1091 / 2.1093 / OET bulletin 65
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum
distance of 20 cm between the radiator and your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada.
Operation is subject to the following two conditions:
1This device may not cause harmful interference, and
2This device must accept any interference received, including interference that may cause undesired operation.
Cet appareil est conforme à la Partie 15 des règlementations de la FCC et avec la norme RSS-210 de l’Industrie Canadienne.
Son fonctionnement est soumis aux deux conditions suivantes :
1 Cet appareil ne doit pas causer d’interférences nuisibles et
2 Cet appareil doit accepter toute interférence reçue, y compris les interférences pouvant entraîner un fonctionnement indésirable.
INSTALLATION SHEET
Indoor MotionViewer IMD 200/601/701
www.videofied.com

Properties
Panel Compatibility XL, XLL, Visio, XT, XT-iP, XV, XV-iP, XTO, XTO-iP
Power requirements:
Type AA
Nominal Voltage 3.6v
Low battery limit 2.7v
Battery type SAFT, AA, Lithium, LS14500
Quantity 1
Battery life (estimated) Up to 4 years
Current Consumption:
Standby (1h average) 40 uA
Max 37 mA
RF Technology: S2View®Bidirectional Radio
Central Frequency 868MHz : IMD200(Europe, Africa, Asia)
915MHz : IMD601(USA, Canada, South America)
920MHz : IMD701(Australia, South America)
Radio type Spread Spectrum Bidirectional RF
Transmission security AES algorithm encryption
Supervision Panel polls devices every 8 minutes
Antenna Integrated
Tamper:
Wall and cover tamper
PIR Performance:
Technology Passive infrared DSP
Type Dual element
Lens Fresnel
Detection Angle 90°
Detection Distance Up to 40 /12m
Motion Detection pattern 24 facets
Physical Data
Operating temperature 14° to 104° F (-10° to +40° C)
Maximum relative humidity 75%, non-condensing
Material ABS—ULV0
Dimensions: (LxWxD): 2.75 x 2 x 1.5in
51.2 x 80.9 x 36.8mm
Weight 3 oz./58 g (without battery)
Installation / Mounting
Mounting Height 2 .1 to 2.3m / 6.5 to 7.5
Mounting on Wall:
On Flat Wall With 2 x Screws
In Corner With 2 x Screws
Closing of the Casing:
Closing by clip and screw if required by local legislation
Certifications & standards
868MHz - IMD200
Standards :
EN60950-1:2006+/A11:2009+/A1:2010
EN300220-1 V2.4.1
EN300220-2 V2.4.1
N F EN5 0130 - 4:19 95+/A1:19 98+/A 2:2 0 03;
NF EN50130-5:1998 Classe II
NF EN50131-2-2:2009 - Grade 2
NF EN50131-5-3:2005 - Grade 2
NF EN50131-6:2008 Grade 2 –Type C
Certifications
Europe CE / EN50131 Grade 2
Netherlands NCP
Singapour IDA
South Africa ICASA
915MHz FHSS - IMD601
Certifications
USA FCC Part 15C (FCC47 CFR Part 15)
Canada IC (RSS-210 Issue 8)
920MHz FHSS - IMD701
Certifications
Australia C-Tick (AS-NZS4268)
INSTALLATION SHEET
Indoor MotionViewer IMD 200/601/701
www.videofied.com
