Videotec MAXIMUS MPX User manual

EN English - Instructions manual
ENGLISH
MAXIMUS MPX -
MAXIMUS MPXT
Explosion proof stainless steel PTZ positioning system

Instructions manual - English - EN
3
Contents
ENGLISH
1 About this manual ......................................................................................................... 7
1.1 Typographical conventions.................................................................................................................................. 7
2 Notes on copyright and information on trademarks.................................................. 7
3 Safety rules..................................................................................................................... 7
4 Identication.................................................................................................................. 9
4.1 Product description and type designation..................................................................................................... 9
4.1.1 Version with thermal imaging camera...........................................................................................................................10
4.2 Product markings ..................................................................................................................................................10
5 Preparing the product for use .................................................................................... 11
5.1 Safety precautions before use...........................................................................................................................11
5.2 Unpacking and contents.....................................................................................................................................12
5.2.1 Unpacking................................................................................................................................................................................12
5.2.2 Contents....................................................................................................................................................................................12
5.3 Safely disposing of packaging material.........................................................................................................12
5.4 Preparatory work before installation..............................................................................................................13
5.4.1 Fixing to parapet or ceiling mount .................................................................................................................................13
5.4.2 Fixing with bracket................................................................................................................................................................14
5.4.3 Fixing the unit to the pole mount adapter or corner mount adapter................................................................14
5.4.3.1 Fixing with pole mount............................................................................................................................................................................14
5.4.3.2 Fixing with corner adapter......................................................................................................................................................................15
5.4.4 Fixing the sunshield..............................................................................................................................................................15
6 Assembling and installing .......................................................................................... 16
6.1 Installation................................................................................................................................................................16
6.1.1 Range of use............................................................................................................................................................................16
6.1.2 Methods of installation........................................................................................................................................................16
6.1.3 Connecting the cables to the base .................................................................................................................................17
6.1.4 Cable entry...............................................................................................................................................................................18
6.1.5 Connection of the power supply.....................................................................................................................................19
6.1.6 Connections of one or more video cables....................................................................................................................21
6.1.7 Connections of one or more optical ber.....................................................................................................................21
6.1.8 Connection of the ethernet cable ...................................................................................................................................22
6.1.9 Telemetry line connections................................................................................................................................................23
6.1.10 Alarm and relay connections..........................................................................................................................................24
6.1.10.1 Connecting an alarm with clean contact (dry contact)..............................................................................................................24
6.1.10.2 Relay connection......................................................................................................................................................................................24
6.1.11 Unit address, communication protocol and baud rate setting..........................................................................25
6.1.12 Conguration of the dip-switches................................................................................................................................25
6.1.13 Setting the conguration check mode.......................................................................................................................25
6.1.14 Setting the baud rate.........................................................................................................................................................26
6.1.15 Serial communication lines.............................................................................................................................................26
6.1.15.1 Two-way RS485 TX/RX line....................................................................................................................................................................27
6.1.15.2 Line RS485-1 reception, line RS485-2 repetition...........................................................................................................................27
6.1.15.3 Two-way RS422 line.................................................................................................................................................................................27
6.1.15.4 One-way RS485 line.................................................................................................................................................................................27

EN - English - Instructions manual
4
6.1.16 Serial line terminations and connections...................................................................................................................28
6.1.17 Setting the protocol...........................................................................................................................................................28
6.1.18 Setting the address.............................................................................................................................................................28
6.1.19 Earth wiring connection...................................................................................................................................................29
6.1.20 Junction box closing..........................................................................................................................................................29
7 Instructions for safe operation................................................................................... 30
7.1 Safe operation.........................................................................................................................................................30
7.1.1 Commissioning ......................................................................................................................................................................30
7.1.2 Safety rules...............................................................................................................................................................................31
7.1.3 Explosion prevention rules ................................................................................................................................................31
8 Switching on ................................................................................................................ 31
8.1 Before powering the device in an explosive atmosphere.......................................................................31
9 Conguration............................................................................................................... 32
9.1 On Screen Menu (OSM) .......................................................................................................................................32
9.1.1 How to use the joystick .......................................................................................................................................................32
9.2 How to move around the menus.....................................................................................................................32
9.3 How to change the settings...............................................................................................................................33
9.4 How to change the numeric elds ..................................................................................................................33
9.5 How to change text...............................................................................................................................................34
9.6 Conguring the system.......................................................................................................................................35
9.6.1 Main menu...............................................................................................................................................................................35
9.6.2 Language..................................................................................................................................................................................35
9.6.3 Camera menu..........................................................................................................................................................................35
9.6.3.1 Zone Titling Menu ......................................................................................................................................................................................36
9.6.3.2 Zone Titling Menu (Edit Zone) ...............................................................................................................................................................36
9.6.3.3 Masking Menu .............................................................................................................................................................................................37
9.6.3.4 Masking Menu (Edit Masks) ....................................................................................................................................................................38
9.6.3.5 How to create a new mask ......................................................................................................................................................................38
9.6.3.6 How to modify a mask ..............................................................................................................................................................................39
9.6.3.7 Advanced Setting Menu...........................................................................................................................................................................40
9.6.3.8 Advanced Setting Menu (Zoom)...........................................................................................................................................................40
9.6.3.9 Advanced Setting Menu (Focus)...........................................................................................................................................................41
9.6.3.10 Advanced Setting Menu (Exposure)..................................................................................................................................................41
9.6.3.11 Advanced Setting Menu (Infrared) ....................................................................................................................................................42
9.6.3.12 Advanced Setting Menu (White Balance)........................................................................................................................................43
9.6.3.13 Advanced Setting Menu (Other).........................................................................................................................................................44
9.6.4 Movement Menu...................................................................................................................................................................44
9.6.4.1 Manual Control Menu...............................................................................................................................................................................45
9.6.4.2 Manual Control Menu (Limits) ...............................................................................................................................................................45
9.6.4.3 Preset Menu..................................................................................................................................................................................................45
9.6.4.4 Preset Menu (Edit Preset).........................................................................................................................................................................46
9.6.4.5 Preset Menu (Preset Utilities)..................................................................................................................................................................46
9.6.4.6 Patrol Menu...................................................................................................................................................................................................47
9.6.4.7 Autopan Menu.............................................................................................................................................................................................47
9.6.4.8 Motion Recall Menu...................................................................................................................................................................................47
9.6.4.9 Advanced Menu..........................................................................................................................................................................................48
9.6.5 Display Menu ..........................................................................................................................................................................48
9.6.6 Options Menu.........................................................................................................................................................................49
9.6.6.1 Alarms Menu ................................................................................................................................................................................................49
9.6.7 Washer Menu ..........................................................................................................................................................................50

Instructions manual - English - EN
5
9.6.8 Default Menu ..........................................................................................................................................................................50
9.6.9 Info Menu .................................................................................................................................................................................50
9.6.10 Thermal Camera Menu......................................................................................................................................................51
9.6.10.1 Flat Field Correction Menu....................................................................................................................................................................52
9.6.10.2 Flat Field Correction Menu (Gain Switch Values) ..........................................................................................................................53
9.6.10.3 Video Setup Menu....................................................................................................................................................................................53
9.6.10.4 Gain Control Menu...................................................................................................................................................................................54
9.6.10.5 ROI Setup Menu........................................................................................................................................................................................55
9.6.10.6 Thermal Analysis Menu..........................................................................................................................................................................55
9.6.10.7 Thermal Analysis Menu (Spot Meter)................................................................................................................................................55
9.6.10.8 Thermal Analysis Menu (Isotherm) ....................................................................................................................................................56
9.6.10.9 Status Menu ...............................................................................................................................................................................................56
9.7 IP Board Conguration ........................................................................................................................................57
9.7.1 Minimum system requirements.......................................................................................................................................57
9.7.2 Conguration procedure....................................................................................................................................................57
9.7.2.1 WAN setting ..................................................................................................................................................................................................58
9.7.3 Installing the NVR software................................................................................................................................................60
9.7.3.1 Controlling PTZ movements...................................................................................................................................................................62
9.7.3.2 Preset and load positions.........................................................................................................................................................................63
10 Instructions for safe operation................................................................................. 64
10.1 Visualizing the state of the pan & tilt............................................................................................................64
10.2 Saving the current position (Preset).............................................................................................................65
10.2.1 Quick save..............................................................................................................................................................................65
10.2.2 Saving from the Menu.......................................................................................................................................................65
10.3 Recalling a position (Scan)...............................................................................................................................65
10.4 Enabling Patrol function...................................................................................................................................65
10.5 Enabling Autopan Function ............................................................................................................................65
10.6 Recalling a pattern (Tour).................................................................................................................................65
10.7 Recalling the Home position...........................................................................................................................66
10.8 Enabling the Wiper (Wiper) .............................................................................................................................66
10.9 Enabling the Washer (Washer) .......................................................................................................................66
10.10 Reboot the device ............................................................................................................................................66
10.11 Manual correction of a preset focusing....................................................................................................67
11 Maintaining and cleaning......................................................................................... 69
11.1 System conguration and statistics display ..............................................................................................69
11.2 Maintenance and cleaning by users.............................................................................................................69
11.2.1 Routine (to be carried out regularly)............................................................................................................................69
11.2.1.1 Cleaning the glass....................................................................................................................................................................................69
11.2.1.2 Cleaning the germanium window.....................................................................................................................................................69
11.2.1.3 Cleaning the device.................................................................................................................................................................................69
11.2.1.4 Inspecting the cables..............................................................................................................................................................................69
11.2.2 Extraordinary (to be done only under particular circumstances)......................................................................70
12 Disposal of waste materials...................................................................................... 70
13 Troubleshooting ........................................................................................................ 71
14 Technical data ............................................................................................................ 73
14.1 MPX ..........................................................................................................................................................................73
14.1.1 General....................................................................................................................................................................................73
14.1.2 Mechanical ............................................................................................................................................................................73

EN - English - Instructions manual
6
14.1.3 Electrical/Video....................................................................................................................................................................73
14.2 Communications.................................................................................................................................................74
14.2.4 Protocols.................................................................................................................................................................................74
14.2.5 Environment .........................................................................................................................................................................74
14.2.6 Certications.........................................................................................................................................................................74
14.2.7 Brackets and adapters.......................................................................................................................................................74
14.2.8 Accessories ............................................................................................................................................................................74
14.2.9 Package...................................................................................................................................................................................74
14.3 MPXT........................................................................................................................................................................75
14.3.1 General....................................................................................................................................................................................75
14.3.2 Mechanical ............................................................................................................................................................................75
14.3.3 Electrical/Video....................................................................................................................................................................75
14.4 Communications.................................................................................................................................................76
14.4.4 Protocols.................................................................................................................................................................................76
14.4.5 Environment .........................................................................................................................................................................76
14.4.6 Certications.........................................................................................................................................................................76
14.4.7 Brackets and adapters.......................................................................................................................................................76
14.4.8 Accessories ............................................................................................................................................................................76
14.4.9 Package...................................................................................................................................................................................76
14.5 Electrical rating ....................................................................................................................................................77
14.6 Cable glands..........................................................................................................................................................77
14.7 Camera....................................................................................................................................................................78
15 Technical drawings .................................................................................................... 83
A Appendix - Marking codes.......................................................................................... 85
A.1 ATEX Marking..........................................................................................................................................................85
A.2 IECEx Mark ...............................................................................................................................................................86
A.3 Gas group classication......................................................................................................................................87
B Appendix - Flamepath................................................................................................. 88

Instructions manual - English - EN
7
1 About this manual
Before installing and using this unit, please read this
manual carefully. Be sure to keep it handy for later
reference.
1.1 Typographical conventions
DANGER!
Explosion hazard.
Read carefully to avoid danger of explosion.
DANGER!
High level hazard.
Risk of electric shock. Disconnect the
power supply before proceeding with any
operation, unless indicated otherwise.
WARNING!
Medium level hazard.
This operation is very important for the
system to function properly. Please read
the procedure described very carefully and
carry it out as instructed.
INFO
Description of system specications.
We recommend reading this part carefully
in order to understand the subsequent
stages.
2 Notes on copyright and
information on trademarks
The quoted names of products or companies are
trademarks or registered trademarks.
3 Safety rules
The manufacturer declines all responsibility
for any damage caused by an improper use
of the appliances mentioned in this manual.
Furthermore, the manufacturer reserves
the right to modify its contents without any
prior notice. The documentation contained
in this manual has been collected with great
care, the manufacturer, however, cannot
take any liability for its use. The same thing
can be said for any person or company
involved in the creation and production of
this manual.
This device must be connected to an
earth conductor (protective earth). This
connection must be made only throught
the internal connector J1 (6.1.5 Connection
of the power supply, page19). External
equipotential bonding connections
must also be performed but only for
supplementary bonding connection to
earth, and required by local codes or
authority.
Fig. 1
External hole for Equipotential bonding
required by authority. Not to be intended as
protective earth connections.

EN - English - Instructions manual
8
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• To reduce the risk of ignition of hazardous
atmospheres, disconnect the equipment from the
supply circuit before opening. Keep the product
tightly closed when in operation.
• The equipment is certied for use in ambient
temperatures of -40°C to 60°C (-40°F / 140°F).
• Installation of this equipment shall be carried out
by suitably trained personnel in accordance with
the applicable code of practice IEC/EN 60079-14.
• Recapitulation of the certication marking as
detailed on drawing LABEL_DRAWING.
• The temperature of the surfaces of the device
is increased by exposure to direct sunlight. The
surface temperature class of the device was
determined only with ambient air temperature,
without taking into consideration direct sunlight.
• Choose an installation surface that is strong
enough to sustain the weight of the device, also
bearing in mind particular environmental aspects,
such as exposure to strong winds.
• Since the user is responsible for choosing the
surface to which the unit is to be anchored, we
do not supply the xing devices for attaching the
unit rmly to the particular surface. The installer is
responsible for choosing xing devices suitable for
the specic purpose on hand. Use methods and
materials capable of supporting at least 4 times the
weight of the device.
• This device is remotely controlled and may change
position at any time. It should be installed so that
no one can be hit by moving parts. It should be
installed so that moving parts cannot hit other
objects and create hazardous situations.
• Make sure that the device is rmly anchored.
• A power disconnect device must be included
in the electrical installation, and it must be very
quickly recognizable and operated if needed.
• It is only allowed to open the cover of the on-board
junction box for cabling of the device. The other
lids must be open from the manufacturer.
• Do not use power supply cables that seem worn
or old.
• For technical services, consult only and exclusively
authorized technicians.
• Before proceeding with installation check the
supplied material to make sure it corresponds
to the order specication by examining the
identication labels (4.2 Product markings, page
10).

Instructions manual - English - EN
9
4 Identification
4.1 Product description and type
designation
The MAXIMUS series explosion-proof pan-tilt-
zoom (PTZ) camera positioning devices have been
designed to allow movement, on both a horizontal
and a vertical plane of a in-built camera and to
operate in industrial environments in which there
may be an explosive atmosphere due to gas, vapours,
mists, or air or powder mixtures.
MAXIMUS PTZ devices, supplied complete with an in
built camera, are made of AISI 316L electropolished
stainless steel.
This unit basically consists of a base, a main body and
a housing for the camera.
Versions with a second housing for thermal cameras
are available.
The base has an on-board junction box that allows
very easy cabling of the system, and it comprises the
power supply electronics. There is a hole 3/4”NPT
on the base and the connection must to be done in
conformity with IEC/EN60079-14.
The main body contains the motors for horizontal
and vertical movements and the CPU and video
boards.
The camera housing contains a day/night module
with its electronics, an heater and a built-in wiper.
The PTZ device has an IP66 protection degree and
its operating temperature is - 40°C to 60°C (-40°F /
140°F).
MAXIMUS PTZ includes integrated high-performance
pan-and-tilt telemetry.
MAXIMUS PTZ oers continuous, high speed
rotation, positioning precision and superior image
quality, utmost sturdiness and simplied system
conguration.
Speed and precision are the predominant pan-and-
tilt characteristics, reaching 100°/s in continuous
horizontal rotation, with vertical range between -90°
to +90°.
MAXIMUS PTZ manages the preset, auto-pan and
patrol functions with an accuracy 0.02°.
The unit performs a continuous control of its position
to verify the correct positioning of the camera at any
time. This is a very useful function in case of severe
environmental conditions, such as strong wind and
heavy vibrations.
The choice of integrated SONY cameras oer 36x
and 28x zoom lenses, which allow the recording with
exceptional precision of both close-by and far away
objects, as well dynamic privacy zone masking.
Besides the OSD (On Screen Display) conguration,
the system is equipped with an RS485 interface for
complete system control and for the updating in
remote mode of the latest rmware version.
The simplied set-up software interface oers typical
preset congurations or the possibility to customize
the complete system.
Fig. 2MPX.

EN - English - Instructions manual
10
4.1.1 Version with thermal imaging
camera
The device can be provided with a thermal imaging
camera, which is installed inside a second housing,
whose window is made mainly of germanium which
guarantees the same strength and security properties
as those for standard glass (Fig. 3 MPXT.,
page10).
The thermal camera is an Uncooled Vanadium Oxide
microbolometer (VOx) with spectral band 7.5-13.5
μm; it delivers a thermal video of 320x 256 (PAL) and
320x240 (NTSC), with an image frequency of 8.3fps or
25 fps (PAL) and 7.5 or 30fps (NTSC).
The high sensitivity NEdT 50mK at f/1.0 ensures an
optimal thermal imaging. It supports 2x or 4x digital
zoom.
A choice of lens sizes is oered between 35mm,
25mm and 9mm, depending on the detection
distance required.
Fig. 3MPXT.
4.2 Product markings
02
01
03
05
06 07 08 09
10
11
04
Fig. 4
1. CE symbol
2. Manufacturer’s name and address
3. Model identication code
4. Ambient temperature of use referring to model
identication code
5. Serial number (the serial number are 12 numeric
characters, the second and the third digits
dene the last two numbers of the year of
manufacture)
6. Power supply voltage (V)
7. Absorption current (A)
8. Frequency (Hz)
9. Housing power consumption (W)
10. ATEX certication:
• ATEX certicate number
• Classication for zone type, protection method,
temperature class for which this product may be
used in compliance with the ATEX directive
11. IECEx certication:
• IECEx certicate number
• Classication for zone type, protection method
and temperature class for which this product
may be used in compliance with the IECEx
standard

Instructions manual - English - EN
11
5 Preparing the product for
use
Any change that is not expressly approved
by the manufacturer will invalidate both
the guarantee and certication.
Before installation, make sure the power
supply and protection specications of the
device correspond to those in the original
order. Use of unsuitable appliances can
cause serious hazards, risking the safety of
personnel and of the installation.
5.1 Safety precautions before use
The electrical installation in which the
unit is inserted must be equipped with a
15A maximum bipolar protection circuit
(magnetothermal), that must include a
bipolar automatic-type circuit breaker,
which must also envisage earth fault
current protection (magnetothermal +
dierential) with minimum distance of
3mm between contacts.
Make sure that all the devices are certied
for the application and for the environment
in which they will be installed.
The device can only be considered to be
switched o when the power supply has
been disconnected and the connection
cables to other devices have been removed.
A power disconnect device must be
included in the electrical installation, and
it must be very quickly recognizable and
operated if needed.
Before doing any technical work on the
device make sure that the power supply is
disconnected.
Make connections and tests in the
laboratory before carrying out installation
on site. Use appropriate tools for the
purpose.
Before proceeding with any operations,
make sure that the mains voltage is correct.
For handling there aren’t request of
particular demands to assigned sta,
therefore it is recommended, to carry out
such operation observing the common
rules of accident prevention.

EN - English - Instructions manual
12
5.2 Unpacking and contents
5.2.1 Unpacking
When the product is delivered, make sure that the
package is intact and that there are no signs that it
has been dropped or scratched.
If there are obvious signs of damage, contact the
supplier immediately.
Keep the packaging in case you need to send the
product for repairs.
5.2.2 Contents
Check the contents to make sure they correspond
with the list of materials as below:
Analog version:
• 1 explosion-proof
• 1 sunshield (2 if version with thermal camera)
• 1 document Important safety instructions
• 1 silicone sheath
• 2 ties
• 2 hexagon socket set screws
• Instructions manual
IP version:
• 1 explosion-proof
• 1 sunshield (2 if version with thermal camera)
• 1 document Important safety instructions
• 1 silicone sheath
• 2 ties
• 2 hexagon socket set screws
• 1 CD
• Instructions manual
Single Mode/Multi Mode optical ber version:
• 1 explosion-proof
• 1 sunshield (2 if version with thermal camera)
• 1 document Important safety instructions
• 3 silicone sheaths
• 6 ties
• 2 hexagon socket set screws
• 2 ber optic adapters
• Instructions manual
5.3 Safely disposing of packaging
material
The packaging material can all be recycled. The
installer technician will be responsible for separating
the material for disposal, and in any case for
compliance with the legislation in force where the
device is to be used.
Bear in mind that if the material has to be returned
due to a fault, using the original packaging for its
transport is strongly recommended.

Instructions manual - English - EN
13
5.4 Preparatory work before
installation
Use appropriate tools for the installation.
The particular nature of the site where the
device is to be installed may mean special
tools are required for installation.
Choose an installation surface that is
strong enough to sustain the weight of
the device, also bearing in mind particular
environmental aspects, such as exposure to
strong winds.
It should be installed so that no one can be
hit by moving parts. It should be installed
so that moving parts cannot hit other
objects and create hazardous situations.
Make sure that the device is rmly
anchored.
The device must be installed and
maintained only and exclusively by
qualied technical personnel.
For technical services, consult only and
exclusively authorized technicians.
Since the user is responsible for choosing
the surface to which the unit is to be
anchored, we do not supply the xing
devices for attaching the unit rmly to
the particular surface. The installer is
responsible for choosing xing devices
suitable for the specic purpose on hand. In
general use methods and materials capable
of supporting at least four times the weight
of the device.
It is possible to install the unit with several brackets.
We strongly recommend using only approved
brackets and accessories during installation.
5.4.1 Fixing to parapet or ceiling mount
Attach the adapter (01) to the bottom of the unit
using 4 stainless steel (A4 class 80) socket at head
cap screw M10 x 20mm (02).
Make sure the thread are free of dirt and debris.
Apply a generous amount of thread locking
compound (Loctite 270) into the threaded holes in
the base of the device.
Tighten them to 35Nm. The thread compound
must cure for one hour, allow for this period prior to
completing the installation.
01
02
Fig. 5
Use the external holes in the adapter to x the
assembled unit to the wall or to the pole. Use screws
that can bear at least 4 times the weight of the unit.
Ø 11
8
Ø 238
Ø 200
35
35
35
35
Fig. 6

EN - English - Instructions manual
14
5.4.2 Fixing with bracket
The bracket can be xed to the vertical wall. Use
screws and wall xing devices that can bear at least
four times the weight of the unit.
To x the device to the bracket, use 4 washers, 4
stainless steel grower washer and 4 hexagon stainless
steel bolts (A4 class 80) M10x20mm.
Make sure the thread are free of dirt and debris.
Apply a generous amount of thread locking
compound (Loctite 270) into the threaded holes in
the base of the device.
Tighten them to 35Nm. The thread compound
must cure for one hour, allow for this period prior to
completing the installation.
Fig. 7
5.4.3 Fixing the unit to the pole mount
adapter or corner mount adapter
To install the component on a pole or at a wall corner,
rst of all x the pan & tilt unit to the wall bracket (
5.4.2 Fixing with bracket, page14).
5.4.3.1 Fixing with pole mount
Fix the wall bracket to the pole mount adapter
using 4 washers, 4 stainless steel grower washer
and 4 hexagon stainless steel bolts (A4 class 80)
M10x30mm.
Make sure the thread are free of dirt and debris.
Apply a generous amount of thread locking
compound (Loctite 270) into the threaded holes in
the base of the device.
Tighten them to 35Nm. The thread compound
must cure for one hour, allow for this period prior to
completing the installation.
Fig. 8

Instructions manual - English - EN
15
5.4.3.2 Fixing with corner adapter
Fix the wall bracket to the corner mount adapter
using 4 washers, 4 stainless steel grower washers
4 hexagon stainless steel bolts (A4 class 80)
M10x30mm.
Make sure the thread are free of dirt and debris.
Apply a generous amount of thread locking
compound (Loctite 270) into the threaded holes in
the base of the device.
Tighten them to 35Nm. The thread compound
must cure for one hour, allow for this period prior to
completing the installation.
Fig. 9
5.4.4 Fixing the sunshield
Before running the wiring, x the sunshield to the
camera housing using the screws and washers.
Apply a generous amount of thread locking
compound (Loctite 270) into the threaded holes in
the base of the device.
The thread compound must cure for one hour, allow
for this period prior to completing the installation.
Fig. 10

EN - English - Instructions manual
16
6 Assembling and installing
Make all installation works and connections
in a non-explosive atmosphere.
Make sure that all the devices are certied
for the application and for the environment
in which they will be installed.
The following procedures should be carried
out with the power supply disconnected,
unless indicated otherwise.
The device must be installed only
and exclusively by qualied technical
personnel.
At Start up the system makes some
automatic calibration movements: do not
stay in the vicinity of the device when it is
powered.
Make sure that the installation complies
with local regulations and specications.
Videotec strongly recommend to test the device
conguration and performance in a oce\laboratory
before putting it in the nal installation site. (6.1.3
Connecting the cables to the base, page17).
6.1 Installation
6.1.1 Range of use
The unit is designed for use in a xed location, for
surveillance of areas classied as zone 1-21 and zone
2-22 potentially explosive atmospheres, using its
embedded cameras.
The installation temperature range is -40°C to 60°C
(-40°F/140°F).
The device is operative from-40°C to 60°C
(-40°F/140°F).
The unit has been built and certied in compliance
with directive 94/9/CE ATEX and with the
international standards IECEX, which dene its range
of application and minimum safety requirements.
The equipment has not been assessed as a safety
related device (as referred to by Directive 94/9/EC
Annex II, clause 1.5).
6.1.2 Methods of installation
The system can be installed only in a standard or
inverted position (ceiling mount). When installed
for inverted operation, the camera orientation and
controller functions are recongured for normal
operation through the system’s software.
Hardware adjustment is not required for inverted
operation.
Fig. 11

Instructions manual - English - EN
17
6.1.3 Connecting the cables to the base
Before doing any technical work or
maintenance on the device, make sure
that potentially explosive atmosphere is
not present. To reduce the risk of ignition
don’t open the device when a potentially
explosive atmosphere is present.
The electrical installation in which the
unit is inserted must be equipped with a
15A maximum bipolar protection circuit
(magnetothermal), that must include a
bipolar automatic-type circuit breaker,
which must also envisage earth fault
current protection (magnetothermal +
dierential) with minimum distance of
3mm between contacts.
A power disconnect device must be
included in the electrical installation, and
it must be very quickly recognizable and
operated if needed.
Before doing any technical work on the
device make sure that the power supply is
disconnected.
The device can only be considered to be
switched o when the power supply has
been disconnected and the connection
cables to other devices have been removed.
Do not use power supply cables that seem
worn or old.
Use adequate cable for higher temperature
than 80°C. And if installed in an external
ambient below –10°C the cable suitable for
the minimum ambient temperature at point
installation.
It is only allowed to open the cover of the
on-board junction box for cabling of the
device. The other lids must be open from
the manufacturer.
An on-board junction box with 3/4”NPT cable entry is
present on the base of the unit.
A threaded cap gives access to a connection board
with removable connectors that help the installer to
connect the cables.
An hexagon set screw is used to prevent the
unscrewing of the connection box threaded
cap. Remove it before unscrewing the cap.
Refer to the following images and information to
connect the wires and cables as required.
To connect the positioning unit remove the hexagon
socket set screw, the plastic cap and the threaded
cover.
The plastic cap thread is available only for shipping
and cannot be used for operation.
Fig. 12

EN - English - Instructions manual
18
Inside the junction box you'll nd an address
and protocol board and a connectors board with
removable connectors that make the cabling
procedure easy.
F
U
S
E
F
U
S
E
100nMBW3
L
N
VAR3
VAR1
AC
AL1
AL2
AL3
AL4
AL5
COM
RL1
RL1
RL2
RL2
GND
W
GND
B
A
B
A
IN
J1
J6
J2
J3
J8
J7
FUS1
VAR2
VIDEO - 1
VIDEO - 2
RS485
FUS2
J9
Fig. 13
6.1.4 Cable entry
Only MPXT series have 2 coax cable video
output.
To prevent the passage of ames or explosions from
the unit to the conduit system or cable gland to the
external environment, use connection in conformity
with IEC/EN60079-14.
All cable gland devices shall be certied in type of
explosion protection“d” and/or "tb", suitable for the
conditions of use and correctly installed.
When conduit is used, a suitable certied stopping
box, in type of explosion protection“d” and/or "tb",
suitable for the conditions of use and correctly
installed. Being tted within 25mm (1in) from the
enclosure wall.
To make the wirings, unplug the removable
connector from the connection board, cable all the
conductors on it and then plug the ying connector
on the board as shown.
Telemetry wiring.
F
U
S
E
F
U
S
E
100nMBW3
L
N
VAR3
VAR1
AC
AL1
AL2
AL3
AL4
AL5
COM
RL1
RL1
RL2
RL2
GND
W
GND
B
A
B
A
IN
J1
J9
J6
J2
J3
J8
J4
J7
FUS1
VAR2
VIDEO - 1
VIDEO - 2
RS485
ADDRESS & PROTOCOL
FUS2
Fig. 14
Take the J9 removable connector.
F
U
S
E
F
U
S
E
100nMBW3
L
N
VAR3
VAR1
AC
AL1
AL2
AL3
AL4
AL5
COM
RL1
RL1
RL2
RL2
GND
W
GND
B
A
B
A
IN
J1
J9 J6
J2
J3
J8
J4
J7
FUS1
VAR2
VIDEO - 1
VIDEO - 2
RS485
ADDRESS & PROTOCOL
FUS2
Fig. 15

Instructions manual - English - EN
19
Cable the wires on it.
F
U
S
E
F
U
S
E
100nMBW3
L
N
VAR3
VAR1
AC
AL1
AL2
AL3
AL4
AL5
COM
RL1
RL1
RL2
RL2
GND
W
GND
B
A
B
A
IN
J1
J6
J2
J3
J8
J4
J7
FUS1
VAR2
VIDEO - 1
VIDEO - 2
RS485
ADDRESS & PROTOCOL
FUS2
J9
Fig. 16
Plug the connector on the board.
F
U
S
E
F
U
S
E
100nMBW3
L
N
VAR3
VAR1
AC
AL1
AL2
AL3
AL4
AL5
COM
RL1
RL1
RL2
RL2
GND
W
GND
B
A
B
A
IN
J1
J9
J6
J2
J3
J8
J4
J7
FUS1
VAR2
VIDEO - 1
VIDEO - 2
RS485
ADDRESS & PROTOCOL
FUS2
Fig. 17
6.1.5 Connection of the power supply
Always make the electrical connections
with the power supply disconnected and
the circuit-breaker open.
When commencing installation make sure
that the specications for the power supply
for the installation correspond with those
required by the device.
Make sure that the power source and
connecting cables are suitable for the
power consumption of the system.
The building must be equipped with
a 15A maximum bipolar protection
circuit (magnetothermal), that must
include a bipolar automatic-type
circuit breaker, which must also
envisage earth fault current protection
(magnetothermal+dierential) with
minimum distance of 3mm between
contacts.
The device is available in versions for dierent power
supply voltages: the value for the particular device is
shown on its identication label.
Power cables to be used: AWG16 (1,5mm²).
• Earth wire type TEWN with cross section equal or
bigger than line and neutral cable.
• Line and neutral wire type TFFN or MTW
Pass the power cables through the entry device.
Take from the connectors board the removable male
connector J1. Connect the power wires following
the connector labeling for polarity as shown (Fig. 18,
page20).

EN - English - Instructions manual
20
Protective earth connections, use adequate cable
sections (up to 2.5mm² or AWG 14)
J1
Fig. 18
Earth cable should be about 10mm longer
than the other two, so that it will not be
disconnected accidentally if the cable is
stretched or pulled.
F
U
S
E
F
U
S
E
100nMBW3
L
N
VAR3
VAR1
AC
AL1
AL2
AL3
AL4
AL5
COM
RL1
RL1
RL2
RL2
GND
W
GND
B
A
B
A
IN
J1
J6
J2
J3
J8
J4
J7
FUS1
VAR2
VIDEO - 1
VIDEO - 2
RS485
ADDRESS & PROTOCOL
FUS2
J9
Fig. 19
The power supply cable should also be
covered by the silicone sheath (01) supplied
for this purpose, and fastened with the
corresponding tie (02). Furthermore, all
signal cables must be grouped together by
means of a strap (03).
F
U
S
E
F
U
S
E
100nMBW3
L
N
VAR3
VAR1
AC
AL1
AL2
AL3
AL4
AL5
COM
RL1
RL1
RL2
RL2
GND
W
GND
B
A
B
A
IN
J1
J6
J2
J3
J8
J4
J7
FUS1
VAR2
VIDEO - 1
VIDEO - 2
RS485
ADDRESS & PROTOCOL
FUS2
J9
02
01
Fig. 20
POWER SUPPLY CONNECTION
Colour Terminals
Power supply 24Vac
Dened by the installer (N) Neutral
Dened by the installer (L) Phase
Yellow/Green Earth
Power supply 230Vac
Blue (N) Neutral
Brown (L) Phase
Yellow/Green Earth
Power supply 120Vac
Blue (N) Neutral
Brown (L) Phase
Yellow/Green Earth
Tab. 1
