Videx DIGITAL GSM DOOR INTERCOM SYSTEM User manual

TECHNICAL MANUAL
EDITION 2.1.1
DIGITAL GSM DOOR
INTERCOM SYSTEM
(
U
p
to 1000 users
)

PAGE 2 of 32 DIGITAL GSM INTERCOM TECHNICAL MANUAL VER2.1.1

PAGE 3 of 32 DIGITAL GSM INTERCOM TECHNICAL MANUAL VER2.1.1
CONTENTS
MANUAL INTRODUCTION...............................................................................................................................................................................................4
SYSTEM INTRODUCTION ................................................................................................................................................................................................4
PRECAUTIONARY ADVICE ............................................................................................................................................................................................. 5
SYSTEM COMPONENTS.................................................................................................................................................................................................... 6
DIGITALMODULE.......................................................................................................................................................................................................6
DOORPANELMOUNTINGFRAMES............................................................................................................................................................................7
POWER SUPPLY.................................................................................................................................................................................................................. 7
WIRING DIAGRAMS .......................................................................................................................................................................................................... 8
PUSH TO EXIT BUTTON AND AUXILIARY INPUTS/OUTPUTS................................................................................................................................ 8
CABLE SIZE GUIDE............................................................................................................................................................................................................ 9
INSTALLATION .................................................................................................................................................................................................................. 9
PANEL CARE.......................................................................................................................................................................................................................9
TESTING, POWER UP AND RESET................................................................................................................................................................................ 10
RESETTOFACTORYDEFAULTS..................................................................................................................................................................................10
PROGRAMMING...............................................................................................................................................................................................................10
PROGRAMMING BY THE KEYPAD AND DISPLAY .................................................................................................................................................. 10
1‐ADD/EDITorDELETEanApartment.....................................................................................................................................................................12
2‐ADJUSTINGSYSTEMTIMES..................................................................................................................................................................................12
3–ADDITIONALSETTINGS.......................................................................................................................................................................................13
4‐ADJUSTINGSYSTEMSETTINGS............................................................................................................................................................................13
EXIT..........................................................................................................................................................................................................................14
PROGRAMMING BY PC................................................................................................................................................................................................... 14
PROGRAMMING BY TEXT MESSAGE ......................................................................................................................................................................... 19
CHANGINGANAPARTMENTSTELEPHONENUMBERS(STN)(STD)...........................................................................................................................20
CHANGINGANAPARTMENTSACCESSCODE(STC)...................................................................................................................................................20
CHANGINGANAPARTMENTSDIALTOOPENSETTING(STO)..................................................................................................................................21
CHANGINGANAPARTMENTSTIMEBANDSETTING(STB).......................................................................................................................................21
CHANGINGANAPARTMENTSNAME(STT)..............................................................................................................................................................21
ADDANEWAPARTMENTORQUERYAMEMORYLOCATION(MEM)......................................................................................................................22
SETCALLTIME(SPT).................................................................................................................................................................................................22
SETRELAYTIME(RLT)...............................................................................................................................................................................................23
SETAO(AUXILIARYOUTPUT)TIME(FORAOM=1ONLY)(AOT)..............................................................................................................................23
SETAO(AUXILIARYOUTPUT)MODE(AOM).............................................................................................................................................................23
DIVERTTIME(DIT)....................................................................................................................................................................................................24
CHANGINGTHEFOURDIGITCODE(CDE).................................................................................................................................................................24
FORCEDDIAL(DLE)...................................................................................................................................................................................................24
STORECREDITBALANCECHECKSTRING(SDL)..........................................................................................................................................................24
STORETHETIMEBAND(TBA)...................................................................................................................................................................................25
MICROPHONEVOLUME(MIC)..................................................................................................................................................................................25
SPEAKERVOLUME(SPK)...........................................................................................................................................................................................25
SPEECHBOARDVOLUME(SBV)................................................................................................................................................................................26
SPEECHBOARDMODE(SBM)...................................................................................................................................................................................26
SYSTEM OPERATION......................................................................................................................................................................................................27
USER COMMANDS........................................................................................................................................................................................................... 27
CHECKING THE BALANCE (BAL) ................................................................................................................................................................................ 28
UNDERSTANDING THE SIGNAL STRENGTH (SIG) ..................................................................................................................................................28
DIALLING INTO THE INTERCOM FROM ANOTHER TELEPHONE........................................................................................................................ 28
RECORD SHEET................................................................................................................................................................................................................ 28
TROUBLE SHOOTING...................................................................................................................................................................................................... 29

PAGE 4 of 32 DIGITAL GSM INTERCOM TECHNICAL MANUAL VER2.1.1
MANUAL INTRODUCTION
The information in this manual is intended as an installation and commissioning guide for
the digital GSM door intercom system. This manual should be read carefully before the
installation commences. Any damage caused to the equipment due to faulty installations
where the information in this manual has not been followed is not the responsibility of
Videx Security Ltd.
VIDEX run free training courses for engineers who have not installed this system before. Technical
help is also available on 0191 224 3174 during office hours or via e-mail [email protected].
SYSTEM INTRODUCTION
The system is designed to work on the same technology as mobile phones. It enables a
call to be made from an entry point (Door, gate etc), to any telephone number (mobile or
land line). Up to 1000 apartments can be programmed into the door panel, each able to
call two telephone numbers (If the first is busy or not answered, the call can be diverted to
the second). Additionally, each user can have a unique access code up to 6 digits, an
apartment number up to 6 digits, their numbers added to the dial to open list (to allow them
to dial into the panel and release the door/gate), a time band to restrict when this
apartment can receive calls and on the scroll panels, a user name up to 16 characters.
Features of the system include a dry contact relay output, an open collector auxiliary
output, push to exit input and switched 0V auxiliary input. Programming of the telephone
numbers and additional features can be carried out via the panel, PC using a specially
designed Windows program or text message. An additional access control feature is
included for all 2000 telephone numbers allowing a number of callers to open the
gate/door simply by dialling the telephone number of the intercom panel (The intercom
panel will not answer these calls but will activate the relay output).
A SIM card is required for this product but not supplied. It is recommended to choose the
SIM card which has the best coverage for the area in which the intercom panel will be
installed. Both contract and ‘Pay as you go’ SIM cards can be used but if using a ‘Pay as
you go’ we would recommend setting up an automatic top up to avoid running short on
credit and loosing the use of the intercom panel. Alternatively if you already have a
contract mobile phone it should be possible to get a second SIM card and telephone
number on the existing account. For more information contact the SIM card provider or
visit their web sites. Remember to restrict the spend ion the SIM card to avoid
unnecessarily large phone bills due to misuse or fault.
Network provider selection: It is imperative for the reliably operation of the system that
the best network provider for the area is selected. Problems such as network
disconnection can occur if the provider has signal or interference problems for that area.
We would recommend using a GSM signal strength meter to survey the intended antenna
location. Contact Videx for more information on where to purchase a tester. As an initial
check, also go to www.sitefinder.ofcom.org.uk and enter the postcode of the intended
installation. This will show all transmitters in the area. It is advised to choose the closest
one or if there are many then choose a transmitter working on 900MHz as this frequency
works best through obstacles such as walls, buildings etc. The antenna should always be
mounted vertically at the highest point possible. Metal structures and sources of
interference such as power cables, control panels etc can affect signals and so the
antenna should be mounted away from these.

PAGE 5 of 32 DIGITAL GSM INTERCOM TECHNICAL MANUAL VER2.1.1
When registering a new SIM you may be asked for the IMEI number. This is the unique
serial number of the GSM intercom and can be found on the rear of the module just below
the SIM holder on a white label. It’s the long number below the barcode.
TIMEBANDNOTE:Thisfeaturereliesonthenetworkproviderstimezonesettingandalsoiftheysupport
NITZ(NetworkIdentityandTimezone).Checkthetimeiscorrectwhenexitingprogrammingmode.Ifthe
time/datereturnediswrong,itmaybethattheydonotsupportitinwhichcasethisfeaturecannotbe
used.
PRECAUTIONARY ADVICE
oWhen mounting the GSM antenna, choose a location which is away from human interaction
and away from the intercom panel. Route the GSM antenna cable from the intercom panel
so that it is separate from the power supply cables and microphone wire. Always mount the
antenna vertically.
oAlways ensure the power is off to the intercom panel before inserting or removing the SIM
card.
oNew SIM cards will need registering before they can be used. Full details of how this is
done can normally be found in the SIM card pack. It will normally require that the SIM card
is inserted into a mobile phone, a number dialled and instructions followed. While the SIM is
in the mobile phone it would be a good time to disable any PIN codes, call diverts, ring back
and disable features such as voicemail and text alerts. Details of how to do this can be
found on the SIM card provider’s web site or by calling their customer services. Please use
one of the following SIM card providers (Vodafone, TMobile, O2 or Orange). We do not
recommend using 3 at this present time.
oTo be able to receive text messages from the intercom panel, the SIM card will require an
SMS service centre number. This is normally preinstalled on new SIM cards but if you are
having trouble receiving SMS messages you will need to confirm this by inserting the SIM
card into a telephone and using the telephones menu options to check it. If a number is not
programmed then it should be programmed while in the telephone (The number can be
obtained from the service provider).
oVoicemail and text alerts must be switched off on the SIM card when using the dial in to
release the door/gate feature. For Vodafone and O2 this can be done while the SIM card is
in the intercom panel. For Orange and T-Mobile the SIM card must be remove and put into
a mobile phone.
oWhen storing the intercom panel’s telephone number in your own mobile phone avoid using
an obvious name such as ‘Front Door, or ‘My Gate’ as this would make it easy to decipher if
your phone was lost or stolen.
oThe PIN request feature must be disabled on the SIM card before using it in the Intercom
panel. It is likely on a new SIM card that it will not be enabled but if it is, it will prevent the
system from working at all.
oThis product may not be suitable for installation in hospitals, health care facilities or in the
presence of flammable gases or liquids. Seek advice and authorisation before installing this
product in these locations.
IMPORTANT NOTE ABOUT SIM CARD
When using a pay monthly SIM card you must ask the service provider to put a spend limit
on the account (Vodafone call this service ‘spend checker’). This is to safeguard against
possible problems which could result in a large phone bill at the end of the month. All
providers offer this service. You will need to either ring them or e-mail them to set this up.
Automatic top ups should also have a monthly limit.

PAGE 6 of 32 DIGITAL GSM INTERCOM TECHNICAL MANUAL VER2.1.1
SYSTEM COMPONENTS
A system comprises of an intercom panel, power supply, SIM card and antenna. The
intercom panel is of modular design allowing it to be customised to the installation
requirements by including proximity access control, coded access or bioaccess.
DIGITAL MODULE
The digital panel is available for the 4000 Series modular design or flush vandal resistant.
There are two versions in the 4000 series design, name scroll facility which includes a
numeric keypad and 3 buttons to navigate tenants/company names on the display and a
alpha numeric version which includes a numeric keypad and letters A-F. The vandal
resistant panel is also available with letters A-I.
DIP SWITCH SETTINGS
There are 2 dip-switches located on the back of the module. They can be used to alter the
volume from the Door Intercom speaker. Additionally, the volume can also be adjusted
during a call via the telephone keypad.
SPEAKER VOLUME
LCD DISPLAY CONTRAST
CONNECTION DESCRIPTION
+12V 12Vdc – 14Vdc input
0V Ground connection
C Common connection of dry contact relay
NO Normally open connection of dry contact relay
NC Normally closed connection of dry contact relay
AO Auxiliary output switched 0V (Open collector output)
PTE Exit button input switched 0V (0V to trigger)
AI Auxiliary input switched 0V (0V to trigger, triggers AO)
ANTENNA
The GSM antenna connects to the SMA female bulkhead on the rear of the module. A
GSM antenna with a SMA male connector should be used.
Note: An antenna must always be connected and positioned vertically.
Note: Always route the GSM cable away from the microphone wires and the power
supply wires to avoid interference on the speech channels.
1 2 GAIN (dB)
ON ON 6
ON OFF 12
OFF ON 18
OFF OFF 23.5
ON
1 2
Relay contacts:
3A@24Vdc
3A@120Vac
Adjust the LCD contrast by turning the pot on the
rear of the panel next to the terminal connector.

PAGE 7 of 32 DIGITAL GSM INTERCOM TECHNICAL MANUAL VER2.1.1
DOOR PANEL MOUNTING FRAMES
Both surface and flush mounting frames are available. The size of the frame will depend
on the number of modules that make up the door panel. The last digit of the frame code
indicates the number of modules it will take. Frames are available in gun metal gray finish,
chrome finish (Suffix \C to the frame code) or gold finish (Suffix \G to the frame code).
Flush frames:
Surface frames:
POWER SUPPLY
The GSM intercom panel is designed to work with power supplies in the range or 12-
14Vdc. The power supply should be capable of supplying a constant current of no less
than 1 amp (If the system is to work with failsafe lock releases or magnetic locks we would
recommend a minimum of 2 amps). The following Videx power supplies can be used:-
AMR2-12 12-14Vdc 2A switched mode PSU
Art.521B 13.5Vdc 1A DIN box PSU
SP29 13.8Vdc 2A boxed PSU with battery backup facility
SP28 13.8Vdc 3A boxed PSU with battery backup facility

PAGE 8 of 32 DIGITAL GSM INTERCOM TECHNICAL MANUAL VER2.1.1
WIRING DIAGRAMS
PUSH TO EXIT BUTTON AND AUXILIARY INPUTS/OUTPUTS
Connections for push to exit button Connections for auxiliary input (Switched 0V)
and auxiliary output (Connected to 506N relay)
Auxiliary output is also triggered by pressing 6
on the handset during a call.

PAGE 9 of 32 DIGITAL GSM INTERCOM TECHNICAL MANUAL VER2.1.1
CABLE SIZE GUIDE
Connections for power supply output to intercom panel and lock release connections.
20m 50m 100m
Connections 0.5mm² 1.0mm² 1.5mm²
The power supply should be located as close to the intercom panel as possible for best performance.
Maximum acceptable resistance for above cables = 3Ω
INSTALLATION
- Check that all components are free from damage before installing (Do not proceed with
installation in the event of damage).
- Keep all packaging away from children.
- Do not obstruct the ventilation openings or slots on any of the devices.
- All connections to mains voltages must be made to the current national standards (IEE
Wiring regulations)
- Install an appropriate fused spur or isolation switch to isolate the mains.
- Isolate the mains before carrying out any maintenance work on the system.
- Avoid water ingress into the rear of the module, always seal the module frame after
installation using a suitable silicon based sealant.
- All intercom and access control cables must be routed separately from the mains.
Lock release back EMF protection : A capacitor must be fitted across the terminals on
an AC lock release and a diode must be fitted across the terminals on a DC lock release
as shown in the diagrams below to suppress back EMF voltages.
LOCK RELEASE
12V AC
~~ 0.1uF capacitor
+
-1N4002 +
-
12V DC
LOCK RELEASE
DIODE
PANEL CARE
The door panel’s facia is either mirror finish stainless steel, brushed stainless steel or matt
finish aluminium. It is important that the facia is cleaned on regular occasions to prevent
dirt build up and tarnishing of the metal. A general household metal polish can be used but
care should be taken to follow the grain of the metal when polishing and also avoid any
polish build up around the call buttons which may prevent the buttons from operating
correctly.

PAGE 10 of 32 DIGITAL GSM INTERCOM TECHNICAL MANUAL VER2.1.1
TESTING, POWER UP AND RESET
After connecting the power supply, antenna, lock output and auxiliary devices as shown in
this manual and before powering up a SIM card must be installed. The SIM holder can be
found on the back of the module under the label ‘SIM’. A SIM card from any supplier can
be used. Simply push the SIM card in (It will only fit one way). IMPORTANT: Replace the
label over the SIM hole.
- Check all the connections have been made correctly and then power up the system.
- The GSM intercom requires approximately 30 seconds too initialise properly. We
recommend not sending SMS messages or pressing buttons during this time.
- From power up; the panel display will first show the software version number for a few
seconds and then ‘WAIT’. After a delay the display will show the standby message.
- Once initialised, you can begin programming.
RESET TO FACTORY DEFAULTS
There are two reset modes available. The first will reset the master code only and the
second will reset everything and clear all stored telephone numbers.
RESET THE MASTER CODE TO 1111
1. Power down the intercom panel
2. Hold down the ‘Enter’ button (on VR4802 or 4802) or the ‘4’ button (on 4802R)
3. Power up continuing to hold the button
4. Wait for the display to revert to the standby message
5. The master code is now reset to 1111
FULL RESET (WARNING: THIS WILL COMPLETELY FORMAT THE MEMORY)
1. Power down the intercom panel
2. Hold down the ‘9’ button (on VR4802 or 4802) or the ‘3’ button (on 4802R)
3. Power up continuing to hold the button
4. When the display shows ‘WAIT’ release the button
5. After a delay, all settings are returned to factory defaults
The panel software is the same for both Alpha (VR4802, 4802) and scroll (4802R) style
panels. To initially set the panel, power up with the ‘7’ (on VR4802 or 4802) or power up
with the ‘2’ pressed (on 4802R). Keep the button pressed until the display reverts to the
standby message.
PROGRAMMING
Programming can be carried out either by the panel keypad & display or by PC.
Additionally, programming can be carried out via SMS text messages.
PROGRAMMING BY THE KEYPAD AND DISPLAY
The programming menu is protected by a 4 digit engineer’s code. The factory default is
1111. To enter programming mode, press ‘0’ followed by the 4 digit code and then press
enter. The programming flow chart is on the following page. An explanation of each
programming option can be found on the pages that follow.
