Viessmann VITOSOLIC 200 Quick guide

VITOSOLIC 200
Installation and
Service instructions
for heating engineers
Vitosolic 200
Electronic temperature differential control unit for solar heating systems
See "Applicability" on the last page.
5862Ă491Ă Băăă9/2003 Please keep safe

2
eneral information
Safety instructions
Please follow these safety instructions closely to prevent accidents and
material losses.
Safety regulations
Installation, commissioning,
inspection, maintenance and
repairs must only be carried
out by a competent person
(heating engineer/refrigeration
specialist/installation contractor).
Observe all current safety
regulations as defined by DIN,
DINĂEN, DV W and VDE (or local
regulations).
See also the safety instructions sheet
in the Vitotec Technical uide folder.
Before working on the equipment/
heating system/solar heating system,
isolate its mains electrical supply
(e.g. by removing a separate mains
fuse or by means of a mains
electrical isolator) and safeguard
against unauthorised reconnection.
Earthing/lightning protection of the
solar heating system
Install an electrical conductor on the
pipework system of the solar circuit
in the lower part of the building, to
comply with VDE or local regulations.
Connection of the collector system to
a new or existing lightning protection
facility or the provision of local
earthing should only be carried out
by authorised personnel, who must
take into account the conditions
applicable on site.
Repair work
It is not permitted to carry out repairs
on parts that fulfil a safety function.
Use only original Viessmann spare
parts, or equivalent parts that have
been approved by Viessmann.
Commissioning
The initial start-up must be carried
out by the system installer or a
designated commissioning engineer.
All actual values should be recorded
in a commissioning/service report.
Instructing the system user
The system installer must hand the
operating instructions to the system
user and instruct him/her in the
operation of the system.
¨ĂSafety instruction
In this instruction manual, this
heading denotes information which
must be observed to prevent
accidents and material losses.
¨This symbol denotes information
which must be observed to
prevent material losses.
5862Ă491Ă B

3
Index
In ex
System esigns
eneral notesĂ 5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
System designs 1 to 7Ă 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation an connections
Control unit installationĂ 51
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Summary of electrical connectionsĂ 52. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Actuators (pumps and valves)Ă 53. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High limit safety cut-outĂ 53. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Solar cellĂ 55. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SensorsĂ 56. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Heat meter extension kitĂ 58. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
KM BUS connectionĂ 59. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mains electrical connectionĂ 60. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Commissioning
Menu structure summaryĂ 61
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
StepsĂ 65. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Further details regarding individual steps 66. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service scans
Scanning temperatures and operating conditionsĂ 69
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Scanning heat volumeĂ 70. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting
Fault messagesĂ 71
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking sensorsĂ 72. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing the fuseĂ 72. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5862Ă491Ă B

4
Index
In ex (cont.)
Function escriptions
Summary of additional functionsĂ 73
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Summary of system parametersĂ 75. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BypassĂ 77. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
External heat exchangerĂ 80. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cooling functionĂ 80. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Special functions of tube collectorsĂ 80. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Collector cooling functionsĂ 81. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Return cooling functionĂ 81. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Frost protectionĂ 82. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parallel relayĂ 82. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Suppression of reheating by boilerĂ 82. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cylinder 2 ONĂ 84. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cylinder loadingĂ 85. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Additional DHW heating functionĂ 85. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Thermostat function, DT control unit and time switchesĂ 87. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parts listĂ89. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Appen ix
SpecificationĂ 89
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Declaration of conformityĂ 90. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Keywor in exĂ91. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ApplicabilityĂ92. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5862Ă491Ă B

5
System designs
General notes
Over the following pages, the
methods of operation have been
described, and the installation has
been depicted as different schemes.
A summary is provided which lists
essential control equipment.
The temperatures stated are guide
values; other values may be set to
meet particular requirements.
The circulation pumps referred to in
the examples (contained in
Solar-Divicon) are AC pumps.
A itional DHW heating function
According to DV WĂWĂ551/WĂ552,
systems with larger cylinder capacity
than 400Ălitres (incl. the solar
preheating stage) should be
pasteurised daily, i.e. the entire
water content must be heated to
60ĂºC once each day.
To meet this requirement, we
recommend that the system is
heated up, preferably late afternoon,
to ensure that the lower part of the
cylinder or the preheating stage is
cold again following the expected
hot water consumption (in the
evening and the following morning)
and can, therefore, be heated up
again by solar energy.
ĂSafety instructions
With temperatures higher than 60 º,
DHW temperature must be limited to
60 º by installing a mixing device,
e.g. a thermostatic mixing valve
(DHW cylinder accessory). The
mixing equipment does not prevent
the risk of scalding at the tap. The
installation of a mixer tap at the
draw-off point is required.
Abbreviations
KW Cold water
WW Hot water
RL Return
VL Flow
5862Ă491Ă B

6
System designs
System esign 1
Dual-mo e DHW heating with Vitocell-B 100 or Vitocell-B 300
DHW cylin ers
DHW heating without solar energy
The upper indirect coil of the DHW
cylinder is heated by a boiler. The
cylinder thermostat with cylinder
temperature sensor 6 of the boiler
control unit switches cylinder loading
pump 7.
DHW heating with solar energy
Solar circuit pump 4 is switched
ON and the DHW cylinder is heated,
if a temperature differential higher
than temperature differential DTon is
measured between collector
temperature sensor 2 and cylinder
temperature sensor 3.
Pump 4 is switched OFF if
Hthe actual temperature falls below
shutdown temperature differential
DToff
Hthe electronic temperature limit
(safety shutdown at 90 ºC) set at
the control unit or that set at the
high limit safety cut-out (if
required) is exceeded.
The additional function requirements
(see page 5) are met by circulation
pump 8.
For optional system extensions, see
pages 73 and 74.
5862Ă491Ă B

7
System designs
System esign 1 (cont.)
Settings
Main menu
>
Operator code
>
Set to 200
Main menu
>
Solar
>
Options
>
System
>
Set to 1 (as delivered condition)
Main menu
>
Solar
>
Setting values
Setting values As el.
con ition
Mo ifie
to
Tcylmax
Maximum cylinder temperature
60 ºC
DTon
Start-up temp. differential, circulation pump 4
5.0 K
DToff
Shutdown temp. differential, circulation pump 4
3.0 K
Tcolemoff 130 ºC*1
*1Set this value to 200 º if you do not want collector emergency OFF set up.
5862Ă491Ă B

8
System designs
System esign 1 (cont.)
ASolar panel
BSolar-Divicon
CDraw-off points
DDHW circulation
EDHW circulation output of boiler
control unit or on-site time switch
FHeating circuit
GOil/gas fired boiler
HDHW cylinder
KJunction box (on-site)
5862Ă491Ă B
B
2
28
5
21
A
GH
4
5
6
VL RL
3
D
8
KW
C
E
F
WW
7
K
ND S1 S2 S3 S4 S5 S6 S7 S8 S9 S10 S11 S12 CS10 ---- Imp1 Imp2 145 145
R4
LN
R6-A R6-R R5-R R5-A R3 R2 R1 R7-A R7-M R7-R
1

9
System designs
System esign 1 (cont.)
Item Description Part no.
Control of DHW cylin er heating by solar energy
1Vitosolic 200 7170Ă926
2Collector temperature sensor Standard
delivery
3Cylinder temperature sensor*1 Standard
delivery
4Solar circuit pump
(part of Solar-Divicon)
7170Ă931
or
7170Ă932
5High limit safety cut-out*2 (see pageĂ53) Z001Ą889
8Circulation pump (relayering) Vitoset price
list
DHW cylin er heating by boiler
6Cylinder temperature sensor Boiler control
unit standard
delivery*3
7Cylinder loading pump*4 DHW cylinder
accessories
*1Use a threaded elbow (standard delivery for VitocellĆB 100, accessory for Vitocell-B 300).
*2Vitocell-B 100: observe max. connectable absorber surface;
Vitocell-B 300: Use a cylinder cap (DHW cylinder accessory).
*3Accessory for Vitodens, Vitopend, Eurola and Pendola.
*4Standard for Vitodens, Vitopend, Eurola with DHW heating and Pendola.
5862Ă491Ă B

10
System designs
System esign 2
Dual-mo e DHW heating with Vitocell-B 100 or Vitocell-B 300
DHW cylin ers Ĉ 2 collector arrays with ifferent orientation
DHW heating without solar energy
The upper indirect coil of the DHW
cylinder is heated by a boiler. The
cylinder thermostat with connected
cylinder temperature sensorĂ6 of
the boiler control unit switches
cylinder loading pumpĂ7.
DHW heating with solar energy
Solar circuit pumpĂ4 or qP is
switched ON and the DHW cylinder
is heated, if a temperature
differential higher than temperature
differential DTon is measured
between collector temperature
sensorĂ2 or 9 and cylinder
temperature sensor 3.
PumpsĂ4 or qP are switched OFF if
Hthe actual temperature falls below
shutdown temperature differential
DToff
Hthe electronic temperature limit
(safety shutdown at 90 ºC) set at
the control unit or that set at the
high limit safety cut-out (if
required) is exceeded.
The additional function requirements
(see page 5) are met by circulation
pump 8.
For optional system extensions, see
pages 73 and 74.
5862Ă491Ă B

11
System designs
System esign 2 (cont.)
Settings
Main menu
>
Operator code
>
Set to 200
Main menu
>
Solar
>
Options
System
>
Set to 2
Hyd. type
>
Set to 1 (as delivered condition)
Main menu
>
Solar
>
Setting values
Setting values As el.
con ition
Mo ifie
to
Tcylmax
Maximum cylinder temperature
60 ºC
DTon
Start-up temp. differential, circulation pump 4
or qP
5.0 K
DToff
Shutdown temp. differential, circulation pump 4
or qP
3.0 K
Tcolemoff 130 ºC*1
*1Set this value to 200 º, if you do not want collector emergency OFF set up.
5862Ă491Ă B
>
>

12
System designs
System esign 2 (cont.)
ASolar panel
BSolar-Divicon
CSolar pump line
DDraw-off points
EDHW circulation
FDHW circulation output of boiler
control unit or on-site timer
GHeating circuit
HOil/gas fired boiler
KDHW cylinder
LJunction box (on-site)
5862Ă491Ă B
ND S1 S2 S3 S4 S5 S6 S7 S8 S9 S10 S11 S12 CS10 ---- Imp1 Imp2 145 145
R4
LN
R6-A R6-R R5-R R5-A R3 R2 R1 R7-A R7-M R7-R
B C
5
28
5
21
A
H
2
qP
6
7
D
VL RL
3
E
F
8
G
A
9
4
WW
KWK
L
1

13
System designs
System esign 2 (cont.)
Item Description Part no.
DHW cylin er heating by solar energy
1Vitosolic 200 7170Ă926
2Collector temperature sensor Standard
delivery
3Cylinder temperature sensor*1 Standard
delivery
4Solar circuit pump
(part of Solar-Divicon)
7170Ă931
or
7170Ă932
5High limit safety cut-out*2 (see pageĂ53) Z001Ą889
8Circulation pump (relayering) Vitoset price
list
9Collector temperature sensor 7814Ă617
qP Solar circuit pump
(contained in solar pump line)
7170Ă933
or
7170Ă934
DHW cylin er heating by boiler
6Cylinder temperature sensor Boiler control
unit standard
delivery*3
7Cylinder loading pump*4 DHW cylinder
accessories
*1Use a threaded elbow (standard delivery for VitocellĆB 100, accessory for Vitocell-B 300).
*2Vitocell-B 100: observe the max. connectable absorber surface;
Vitocell-B 300: Use a cylinder cap (DHW cylinder accessory).
*3Accessory for Vitodens, Vitopend, Eurola and Pendola.
*4Standard for Vitodens, Vitopend, Eurola with DHW heating and Pendola.
5862Ă491Ă B

14
System designs
System esign 3
Dual mo e DHW heating an central heating backup via a
calorifier
DHW heating without solar energy
The upper indirect coil of the DHW
cylinder is heated by a boiler. The
cylinder thermostat with connected
cylinder temperature sensorĂ6 of
the boiler control unit switches
cylinder loading pumpĂ7.
DHW heating with solar energy
Solar circuit pump 4 is switched
ON and the DHW cylinder is heated,
if a temperature differential higher
than temperature differential DTon is
measured between collector
temperature sensor 2 and cylinder
temperature sensor 3.
Pump 4 is switched OFF if
Hthe actual temperature falls below
shutdown temperature differential
DToff
Hthe electronic temperature limit
(safety shutdown at 90 ºC) set at
the control unit or that set at the
high limit safety cut-out (if
required) is exceeded.
The additional function requirements
(see page 5) are met by circulation
pump 8.
Central heating without solar energy
Diverter valve qW remains at zero
volts (setting "AB-B") if the
differential temperature between
calorifier temperature sensor qP and
central heating return temperature
sensor 9 falls below shutdown
temperature differential DT6off. No
flow through the heating water
calorifier takes place.
The boiler provides heat to the
heating circuit according to the
heating curve set at the boiler
control unit.
Central heating with solar energy
Circulation pumpĂqE for heating heat
exchanger qT is switched ON if the
DHW cylinder cannot be heated and
a temperature differential higher
than start-up temperature differential
DT2on is measured between collector
temperature sensor 2 and calorifier
temperature sensor qQ. If the actual
temperature falls below shutdown
temperature DT2off or when
maximum temperature Tcyl2max has
been reached, it is switched OFF.
Calorifier loading pump qR is
switched ON and the calorifier is
heated, if a temperature differential
higher than start-up temperature
differential DT5on is measured
between temperature sensor qZ
(heat exchanger) and calorifier
temperature sensor qQ.
5862Ă491Ă B

15
System designs
System esign 3 (cont.)
The pump will be switched OFF if the
actual temperature falls below
shutdown temperature differential
DT5off.
The temperature in the calorifier is
limited by the electronic temperature
limiter (safety shutdown at 90ĂºC) or
by the high limit safety cut-out (if
required). It will switch calorifier
loading pump qE OFF if the set
temperature is exceeded.
Circulation pump qE is switched OFF
for approx. 2 minutes, roughly every
15 minutes (values t stop and t circ
adjustable, see page 16), to check
whether the temperature at the
collector temperature sensor is high
enough to change over to DHW
cylinder heating. If, during this time,
DTon is exceeded, the DHW cylinder
continues to be heated.
Diverter valve qW is set to "AB-A" if
the differential temperature between
calorifier temperature sensor qP and
heating return temperature sensor 9
exceeds start-up temperature
differential DT6on; the heating return
water will be routed to the boiler via
the calorifier. If the temperature of
the preheated return water is
insufficient, the boiler reheats the
water to the necessary flow
temperature level.
If the actual temperature falls below
shutdown temperature differential
DT6off, the diverter valve will be set
to "AB-B".
For optional system extensions, see
pages 73 and 74.
Settings
Main menu
>
Operator code
>
Set to 200
Main menu
>
Solar
>
Options
System
>
Set to 3
Hyd. type
>
Set to 2
5862Ă491Ă B
>
>

16
System designs
System esign 3 (cont.)
Main menu
>
Solar
>
Setting values
Setting values As el.
con ition
Mo ifie
to
Tcylmax
Maximum cylinder temperature
60 ºC
Tcyl2max
Maximum calorifier temperature
60 ºC
DTon
Start-up temp. differential, circulation pumpĂ4
5.0 K
DToff
Shutdown temp. differential, circulation pumpĂ4
3.0 K
DT2on
Start-up temp. differential, circulation pumpĂqE
5.0 K
DT2off
Shutdown temp. differential, circulation pumpĂqE
3.0 K
PriorityCyl1 (see page 76) 1
PriorityCyl2 (see page 76) 2
Tcolemoff 130 ºC*1
*1Set this value to 200 º, if you do not want collector emergency OFF set up.
Main menu
>
Solar
>
Contractor
Contractor As el.
con ition
Mo ifie
to
t stop
Length of pump run interruption
ă2 min.
t circ
Interruption interval
15 min.
DT Col
The collector temperature must rise by DT Col
during the t stop time, in order to change over to
heating the consumer with priority 1.
2 K
5862Ă491Ă B

17
System designs
System esign 3 (cont.)
Main menu
>
System
>
Options
Options As el.
con ition
Change to
Thermost. 2
Thermostat function for maximum temperature
shutdown of calorifier loading pump qR
No Yes
DT Fct5
DT function for controlling calorifier loading
pumpā qR
No Yes
DT Fct6
DT function for controlling three-way diverter
valve qW
No Yes
Main menu
>
System
>
Setting values
Setting values As el.
con ition
Change to
Th2on
set the same value as for Tcyl2max (maximum
calorifier temperature), less 2 K
40 ºC
Th2off
set the same value as for Tcyl2max
45 ºC
DT5on
Start-up temp. differential, circulation pump qR
5.0 K
DT5off
Shutdown temp. differential, circulation pump qR
3.0 K
DT6on
Start-up temperature differential for controlling
three-way diverter valve qW
5.0 K
DT6off
Shutdown temperature differential for controlling
three-way diverter valve qW
3.0 K
5862Ă491Ă B

18
System designs
System esign 3 (cont.)
5862Ă491Ă B
8
2
A
BC
4qE
D
E
9
qP
qQ G
qT AB
BA
H
5
WW
VL RL
KW
qW
7
K
F
28
3
5
6
21
qZ
LL
5
qR
ND S1 S2 S3 S4 S5 S6 S7 S8 S9 S10 S11 S12 CS10 ---- Imp1 Imp2 145 145
R4
LN
R6-A R6-R R5-R R5-A R3 R2 R1 R7-A R7-M R7-R
1

19
System designs
System esign 3 (cont.)
ASolar panel
BSolar-Divicon
CSolar pump line
DDraw-off points
EDHW circulation
FDHW circulation output of boiler
control unit or on-site timer
GHeating water calorifier
HOil/gas fired boiler
KDHW cylinder
LJunction box (on-site)
5862Ă491Ă B

20
System designs
System esign 3 (cont.)
Item Description Part no.
DHW cylin er heating by solar energy
1Vitosolic 200 7170Ă926
2Collector temperature sensor Standard
delivery
3Cylinder temperature sensor*1 Standard
delivery
4Solar circuit pump
(part of Solar-Divicon)
7170Ă931
or
7170Ă932
5High limit safety cut-out*2 (see pageĂ53) Z001Ą889
8Circulation pump (relayering) Vitoset price
list
DHW cylin er heating by boiler
6Cylinder temperature sensor Boiler control
unit standard
delivery
7Cylinder loading pump DHW cylinder
accessories
Central heating with solar energy
9Return temperature sensor (heating circuit) 7170Ă965
qP Temperature sensor (calorifier), discharge 7170Ă965
qQ Temperature sensor (calorifier), reloading Standard
delivery
qW Three-way diverter valve 7814Ă924
qE Solar circuit pump for calorifier heating
(contained in solar pump line)
7170Ă933
or
7170Ă934
qR Circulation pump for calorifier heating on-site
qT Heat exchanger on request
qZ Temperature sensor (heat exchanger) 7170Ă965
*1Use a threaded elbow (standard delivery for VitocellĆB 100, accessory for Vitocell-B 300).
*2Vitocell-B 100: observe the max. connectable absorber surface;
Vitocell-B 300: Use a cylinder cap (DHW cylinder accessory).
5862Ă491Ă B
