3General Information
General Information
Product Information
The Vitotrol 100, type UTDB is a battery powered room temperature controller with switching output.
The Vitotrol 100, type UTDB-RF is a battery powered room temperature controller with switching
output, integral wireless transmitter and separate wireless receiver.
The digital time switch provides the option to use time programs for central heating.
Energy Saving Tips
• Standard room temperature (see page 9):
Do not overheat your home. Every degree of room temperature reduction saves up to 6 % on
your heating bills.
• Time program (see page 6):
Heat your home to the standard room temperature during the day and the reduced temperature
at night. Set this via the time program.
• Short absence (see page 10):
Reduce the room temperature if you are going out shopping, for example. For this, select
"Economy mode".
• Holidays (see page 9):
If you are going away, select the "Holiday program": The room temperature is reduced, and DHW
heating is turned off.
• Airing:
Close the thermostatic valves when airing. Open the windows fully for a brief time.
• Roller shutters:
Close roller shutters (if installed) at dusk.
• Thermostatic valves:
Ensure that thermostatic valves are properly adjusted.
• Radiators:
Never cover radiators or thermostatic valves.
For additional energy saving functions of the Vitotronic control unit, please contact your heating
contractor.
Tips for Greater Comfort
• Time program (see page 6):
Make use of the time program. In the time program, you can set time phases with different room
temperatures, for example different temperatures for day and night time.
• "Party mode" (see page 10):
If you want to heat rooms to a different temperature from the one set in the time program,
select "Party mode".
Example: Due to the time program settings, your home is heated to a reduced room temperature
during late evening, but you have visitors staying late.

4Operation
Operation
Summary of Controls & Indicators
Opening the Flap
Functions
Symbols on Display
These Symbols are not always displayed, but appear subject
to operating conditions.
Heat Demand
Party Mode Active
Economy Mode Active
Manual Mode Active
Holiday Program Active
Frost Protection Mode Active
Replace Battery
Controls Locked

5Operation
How to Use the Controls
Default Display
Press key , or :
The display illumination is activated and you are taken to the
operating display
Operating Display
1. If the display illumination has gone out, press key
The display illumination is activated.
2. If the display illumination is activated, press key again:
this will take you to the menu.
3. Use to make the required settings and conrm
them with OK. Temperature changes made with are
accepted automatically after 5 seconds.
Note: The menu is automatically exited approx. 30 seconds
after the last key was pressed.
Display Illumination
Press any key to activate the display illumination. The
display illumination automatically switches off approx. 15
seconds after the last key was pressed.
Locking the Controls
You can lock the control keys of the Vitotrol 100. To do so,
press and simultaneously for 5 seconds. To unlock the
keys, again press and simultaneously for 5 seconds.

6Central Heating
Central Heating
Selecting the Operating Mode
You can select between the following operating modes:
• Heating mode in accordance with the time program: see below
• Frost protection mode: see page 9
• Operation with constant room temperature (manual): see page 9
Selecting a Time Program for Heating Mode
You can choose from 3 preset time programs (Prog 1 to Prog 3).
You can change the preset time programs in accordance with your individual requirements.
Within each time program, you can change between 3 different room temperatures:
• Comfort (factory setting: 21°C)
• Eco (factory setting: 19°C)
• Reduced (factory setting: 16°C)
You can change the set values for the room temperatures: see page 9
1. Open the flap.
2. Press twice.
3. Use to select the required time program. (e.g. "Prog 1")
4. Conrm with OK.
Heating mode operates according to the selected time program.
Time Programs in the Delivered Condition
Time Program 1 - Prog 1
Monday to Friday
Time Phase Start End Room Temperature
1 06:00 08:00 Comfort
2 08:00 12:00 Comfort
3 12:00 14:00 Comfort
4 14:00 18:00 Comfort
5 18:00 22:00 Comfort
6 22:00 06:00 Reduced
Saturday and Sunday
Time Phase Start End Room Temperature
1 07:00 08:00 Comfort
2 08:00 12:00 Comfort
3 12:00 14:00 Comfort
4 14:00 16:00 Comfort
5 16:00 23:00 Comfort
6 23:00 07:00 Reduced

7Central Heating
Time Program 2 - Prog 2
Monday to Friday
Time Phase Start End Room Temperature
1 06:00 08:00 Comfort
2 08:00 12:00 Reduced
3 12:00 14:00 Reduced
4 14:00 16:00 Reduced
5 16:00 22:00 Comfort
6 22:00 06:00 Reduced
Saturday and Sunday
Time Phase Start End Room Temperature
1 07:00 08:00 Comfort
2 08:00 12:00 Comfort
3 12:00 14:00 Comfort
4 14:00 18:00 Comfort
5 18:00 23:00 Comfort
6 23:00 07:00 Reduced
Time Program 3 - Prog 3
Monday to Friday
Time Phase Start End Room Temperature
1 06:00 08:00 Comfort
2 08:00 12:00 Eco
3 12:00 14:00 Comfort
4 14:00 18:00 Eco
5 18:00 23:00 Comfort
6 23:00 06:00 Reduced
Saturday and Sunday
Time Phase Start End Room Temperature
1 07:00 08:00 Comfort
2 08:00 12:00 Comfort
3 12:00 14:00 Comfort
4 14:00 18:00 Comfort
5 18:00 23:00 Comfort
6 23:00 07:00 Reduced

8Central Heating
12. Conrm with OK
13. Use to select the required time phase, or
rst the required day
14. Use to set the required start time, stop
time and room temperature (e.g. "Reduced")
in succession.
15. Conrm each respectively with OK
16. Proceed as described in points 11 to 13 to set
further time phases.
Note: If the settings create gaps between the
time phases, these are closed automatically by
extending the preceding time phase.
Changing the Time Phases of Time Programs
In the delivered condition, the day is split into 6 time phases.
You can also split the day into less than 6 time phases, for example:
Time phase 1: Operation with standard room temperature from 06:00 to 22:00 h and;
Time phase 2: Operation with reduced room temperature from 22:00 to 06:00 h
After entry, the last time phase is automatically assigned to time phase 6. The other time phases are
then disabled.
Enter a start time, stop time and a room temperature for each active time phase ("Comfort", "Eco",
"Reduced") (see example).
You can select time phases for several days (day groups) or for individual days:
"MO - SU" for the same time phases on every day of the week
"MO - FR" for the same time phases on Monday to Friday
"SA - SU" for the same time phases on Saturday and Sunday
"SINGLE DAY" for different time phases on individual days
Note: Settings for individual days take priority over settings for several days.
1. Open the flap
2. Press twice
3. Use to select "Settings"
4. Conrm with OK
5. Use to select "Programs"
6. Conrm with OK
7. Use to select the program you want to
change (e.g. "Prog 1").
8. Conrm with OK
9. Use to select "Set"
10.Conrm with OK
11. Use to select the required group of days/
single day
Deactivating Time Phases
To deactivate a time phase, set the same value for the start and stop time.
Copying Time Programs
You can copy time programs, for example if you want to create a new time program based on an
existing one with only minor differences.
1. Open the flap
2. Press twice
3. Use to select "Settings"
4. Conrm with OK
5. Use to select "Programs"
6. Conrm with OK
7. Use to select the program you want to
change (e.g. "Prog 1").
1. Conrm with OK
2. Use to select "Copy from"
3. Conrm with OK
4. Use to select the program you want to
copy
5. Conrm with OK
6. Use to select "Set" to make the changes

9Central Heating
Frost Protection Mode
If you do not want to heat the interior but would like to have frost protection.
If the room temperature falls below 5°C, central heating starts.
1. Open the flap
2. Press twice
3. Use to select "Frost pr."
4. Conrm with OK.
The display shows and the current room temperature
Operation with Constant Room Temperature (Manual)
Continuous central heating with the set temperature
1. Open the flap
2. Press twice
3. Use to select "Manual"
4. Conrm with OK.
5. Use to set the required room temperature (min. 10°C)
6. Conrm with OK.
The display shows and again the current room temperature
Setting a Permanent Room Temperature
You can set 3 room temperatures:
• Standard room temperature "Comfort"
Factory setting: 21°C
• Room temperature "Eco"
Factory setting: 19°C
• Reduced room temperature "Reduced"
Factory setting: 16°C
The rooms are heated to one of the 3 room
temperatures, in accordance with the active
time phase of the selected time program.
1. Open the flap
2. Press twice
3. Use to select "Settings"
4. Conrm with OK
5. Use to select "Tmp settings"
6. Conrm with OK
7. Use to select the required temperature to
"Comfort", "Eco" or "Reduced"
8. Conrm with OK
Changing the Room Temperature for a Few Days Only
The following energy saving options are available for times when you are on holiday:
You can shut central heating down completely by selecting frost protection mode
or
You can set the central heating to minimum energy consumption (e.g. to prevent your house plants
from being damaged by the cold). To do so, select the holiday program . If the holiday program is
active, the rooms are heated to the reduced temperature ("Reduced").
Setting a Holiday Program
1. Open the flap
2. Press twice
3. Use to select "Holiday"
4. Conrm with OK
5. Use to select "ON"
6. Conrm with OK
7. Use to select the required day and time
for the starting and ending of the holiday
function
8. Conrm each respectively with OK

10 Central Heating
Terminating the Holiday Program
The holiday program terminates automatically when the end time has been reached.
If you want to terminate the holiday program early:
1. Open the flap
2. Press twice
3. Use to select "Holiday"
4. Conrm with OK
5. Use to select "OFF"
Changing the Room Temperature for a Few Hours Only
The following functions enable you to change the room temperature for a few hours without
permanently altering you settings.
The modied room temperature remains enabled until the next changeover within a program or
until the next switch to a different program.
If you want an unscheduled increase in room temperature:
• In programs "Prog 1" to "Prog 3" and "Manual", you can increase the room temperature with
or
• In programs "Prog 1" to "Prog 3", select party mode by pressing
If you want an unscheduled reduction in room temperature:
• In programs "Prog 1" to "Prog 3" and "Manual", you can lower the room temperature with
or
• In programs "Prog 1" to "Prog 3", select economy mode by pressing
Using to Make Adjustments
1. Press or
The current set room temperature is displayed
2. Use to set the required temperature
3. Conrm with OK or wait approx. 5 seconds until the value is adopted automatically
Setting Party Mode
In party mode, the reduced room temperature is automatically set to 21°C.
1. Press for approx. 5 seconds
The display shows
2. Use to set the room temperature for party mode
3. Conrm with OK
Ending Party Mode
Party mode ends automatically at changeover to the next time phase of the time program
Press again for approx. 5 seconds if you want to terminate party mode early

11Central Heating
Setting Economy Mode
In economy mode, the set room temperature is automatically reduced.
You can set economy mode during reduced mode "Eco" and "Reduced".
The lowest room temperature in economy mode is 10°C.
1. Press for approx. 5 seconds
The display shows
2. Use to set the room temperature for economy mode
3. Conrm with OK
Ending Economy Mode
Economy mode ends automatically at changeover to the next time phase of the program.
Press again for approx. 5 seconds if you want to terminate economy mode early.

12 Further Adjustments
Further Adjustments
Time and Date
1. Open the flap
2. Press twice
3. Use to select "Settings"
4. Conrm with OK
5. Use to select "Standard settings"
6. Conrm with OK
7. Use to select "Date - time"
8. Conrm with OK
9. Use to set the current date and time
10. Conrm each respectively with OK
Summertime/Wintertime
The changeover from summertime to wintertime and vice-versa is automatic. You can stop this
automatic changeover.
1. As described above, select "Date - time"
2. Use OK to select "Summertime ON"
3. Use to select "OFF"
4. Conrm with OK
Setting the Language
1. Open the flap
2. Press twice
3. Use to select "Settings"
4. Conrm with OK
5. Use to select "Standard settings"
6. Conrm with OK
7. Use to select "Language"
8. Conrm with OK
9. Use to set the required language
10. Conrm with OK
Renaming Time Programs
You can individually rename programs "Prog
1" to "Prog 3". The designation is limited to 5
characters
1. Open the flap
2. Press twice
3. Use to select "Settings"
4. Conrm with OK
5. Use to select "Programs"
6. Conrm with OK
7. Use to select the program you want to
rename (e.g. "Prog 1")
8. Conrm with OK
9. Use to select "Rename"
10. Conrm with OK
11. Use to enter the required characters on
line "New name"
12. Conrm each respectively with OK
Temperature Balancing
If your Vitotrol 100 is installed in an unfavourable position, e.g. on an external wall or near an open
replace, the displayed room temperature can deviate from the actual room temperature. You can
compensate for this temperature deviation with a correction value.
Example:
The room temperature displayed by the Vitotrol 100 is 2°C higher than the actual room
temperature. The correction value is then -2°C
1. Open the flap
2. Press twice
3. Use to select "Settings"
4. Conrm with OK
5. Use to select "Service"
6. Conrm with OK
7. Use OK to select the required value to be set
for "Ctrller offset"
8. Use to set the required value
9. Conrm with OK
10.Only for the Vitotrol 100, type UTDB-RF: Exit
the menu with the back button.

13Calling Up Information
Scanning Temperatures and Further Settings
1. Press
The display shows the following details:
• Room temperature
• Date and time
• Current program
• Day of the week
2. Use to call up the current set temperature
Scanning Time Programs
On the display, you see the selected time program Prog 1, Prog 2 or Prog 3. The time phases of the
current day are shown in a time slot graphic.
Example:
Central heating will operate from 06:00 Ato 22:00 Bwith standard room temperature and from
22:00 to 06:00 with reduced room temperature
Calling Up the Holiday Program (If Set)
1. Open the flap
2. Press twice
3. Use to select "Holiday"
4. Conrm with OK
Start and end of the set holiday period are displayed.
Calling Up Information

14 Possible Problems
System Characteristics Cause Remedy
Rooms are too cold The Vitotrol 100 is set incorrectly Check the settings and correct if
required:
• Time program for heating mode
(see page 6)
• Room Temperature (see page 9)
• Time (see page 12)
Rooms are too cold The wireless connection to the
boiler control unit is interrupted
(only for Vitotrol 100, type UTDB-RF
with wireless connection).
At the receiver unit , the display
flashes
Change the address code (see page
15)
Rooms are too hot The Vitotrol 100 is incorrectly set Check the settings and correct if
required:
• Time program (see page 6)
• Room temperature (see page 9)
• Time (see page 12)
flashes on the display The batteries are spent Change the batteries (see below)
Faults with Controller
Replacing the Batteries
• Use only alkaline batteries 1.5V
• Never use rechargeable batteries
• Replace both batteries every 18 months
The Vitotrol 100 has a power reserve of 3
minutes. If you replace the batteries within this
time, all set data is retained. If power reserve
has been exceeded, a reset will need to be
carried out (see below for more information).
Reset
Press the reset button with a suitable
instrument. After a reset, the language, time and
date will need to be set again.
Possible Problems

15Possible Problems
Changing the Address Code
Only for the Vitotrol 100, type UTDB-RF, if flashes on the wireless receiver.
1. Press on the wireless receiver for approx. 10 seconds until flashes
2. Open the flap on the Vitotrol 100
3. Press twice
4. Use to select "Settings"
5. Conrm with OK
6. Use to select "Service"
7. Conrm 3 times with OK
8. Use to select "Address code"
9. Conrm with OK
The display shows a number combination for approx. 30 seconds. Then "Send data" appears on the
display. The transfer takes 30 seconds. flashes during the transfer.
If the receiver recognises the address code, and go out. If the address code is not recognised,
repeat the process from point 3.
