Viking Installation Guide
PHK23 Professional Series Handle Kit
For Use with DFWD Warming Drawers,
FRDI Refrigerated Drawers and DFB FDB Dishwashers

IMPORTANT–Please Read and Follow!
2 3
•Before beginning, please read these instructions completely and carefully.
•Use caution during assembly to minimize scratches.
•Do not remove permanently affixed labels, warnings or plates from the product. This may
void the warranty.
•Please refer to the product Installation Instructions for more information on installing the
door panel.
•The installer should lea e instructions with the customer who should retain for local
inspector’s use and future reference.
Parts Included
Part Quantity
Professional Series Handle T be
Professional Series End Caps
1/4” x 1” Phillips Head Screws
Installation Instr ctions
Required Tools
Electric Drill
/16” (.8 cm) Drill Bit
/8” (1.6 cm) Spade or Forstner Bit (Counterbore)
Tape Measure
Phillips Head Screwdriver
Masking Tape and Pencil
Rubber Mallet
Handle Installation - DFWD Warming Drawer
To Install:
Installation with Wooden Full Overlay
Custom Door Front
(1)
(2)
(4)
1. Locate the wooden custom panel.
2. Using the illustrations on the next page, layout the handle location on the panels. It is
recommended that masking tape be placed where the four holes will be drilled to help mark
the hole placement and to prevent any damage to the door when drilling the holes.
3. The Professional handle will be mounted using (4) of the 1/4” x 1” Phillips head screws
provided. Using the /16”(.8 cm) drill bit, drill completely through the door in the hole
locations. Using the /8” (1.6 cm) bit, counter-bore two holes 1/4” (.6 cm) deep on the
BACKSIDE of the custom door panel.
4. Place a handle end cap on both ends of the handle tube. Tap the endcaps firmly into place
with a rubber mallet ensuring that both endcaps mounting surfaces are parallel.
. Align the holes in the endcaps with the holes on the panel and attach the Professional
handle to the panel using the (4) 1/4” (.6cm) screws provided.
5/8” (1.6 cm) Ø x 1/4” (0.6 cm) counterbore
1-3/8” (3.5 cm)
5/16” (0.8 cm) Ø through-holes
3/4” (1.8 cm)
Full Overlay Panel
Section A-A
Professional Series Handle
21-3/4”
(55.2 cm)
1-3/8”
(3.5 cm)
1”
(2.5 cm)
10-7/8”
(27.6 cm)
A A
C
L
5/16” (0.8 cm) through-holes
with 5/8” x 1/4” counterbore
*See section A-A.

Handle Installation - FRDI Refrigerated Drawer
4
Handle Installation - DFB/FDB Dishwasher Door
Specifications subject to change without notice.
21-3/4”
(55.2 cm)
1-3/8”
(3.5 cm)
1-1/4”
(3.2 cm)
10-7/8”
(27.6 cm)
A A
C
L
5/16” (0.8 cm) through-holes
with 5/8” x 1/4” counterbore
*See section A-A.
Note: Hole locations are typical
as above panel.
21-3/4”
(55.2 cm)
1-3/8”
(3.5 cm)
1-1/4”
(3.2 cm)
10-7/8”
(27.6 cm)
A A
C
L
5/16” (0.8 cm) through-holes
with 5/8” x 1/4” counterbore
*See section A-A.

6 7
