Viking Designer Select DEDO127 User manual

F20366B (102407J)
Viking Range Corporation
111 Front Street
Greenwood Mississippi 38930 USA
[phone]
For product information
call 1-888-VIKING1 (845-4641)
or visit the Viking Web Site at
vikingrange.com
Viking Use & Care Manual
Built-In Electric
Touch Control Ovens

3
Warnings
2
Congratulations
Your purchase of this product attests to the importance you
place upon the quality and performance of the major
appliances you use. With minimal care as outlined in this
guide this product is designed to provide you with years of
dependable service. Please take the few minutes necessary to
learn the proper and efficient use and care of this quality
product.
Some key features of this appliance include:
• 14 different cooking modes to make even your most
challenging baking projects a success.
• Split baking and broiling elements reducing your
preheating time and heating your food more evenly.
• An extra-large reversing fan allowing you to cook even
large quantities of food more quickly and evenly.
• Four convection modes offering greater air circulation to
shorten cooking times and cook foods more evenly.
• Dual broiling elements producing intense radiant heat for
faster broiling and a larger coverage area.
• Three broiling modes including a special low-broil mode for
delicate broiling and top-browning.
• A profiled hidden bake element for easier cleaning.
• Six adjustable rack positions with the largest usable baking
space available in this class.
Your complete satisfaction is our ultimate goal. If you have
any questions or comments about this product please
contact the dealer from whom you purchased this product or
contact our consumer support center at 1-888-VIKING1.
We appreciate your choosing a Viking® Range Corporation
product and hope that you will again select our products for
your other major appliance needs. For more information
about the complete selection of Viking products contact your
dealer or go to www.vikingrange.com.
WARNING
If the information in this manual is not followed exactly a fire or
explosion may result causing property damage personal injury
or death.
WARNING
NEVER use this appliance as a space heater to heat or warm
the room. Doing so may result in carbon monoxide poisoning
and overheating of the oven.
WARNING
Do not use commercial oven cleaners inside the oven. Use of
these cleaners can produce hazardous fumes or can damage
the porcelain finishes.
WARNING
NEVER cover any slots holes or passages in the oven bottom
or cover an entire rack with materials such as aluminum foil.
Doing so blocks air flow through the oven and may cause
carbon monoxide poisoning. Aluminum foil linings may also
trap heat causing a fire hazard.
WARNING
To avoid sickness and food waste when using automatic time
baking:
• Do not use foods that will spoil while waiting for cooking to
start such as dishes with milk or eggs cream soups custards
fish pork poultry or foods with stuffing.
• Any food that has to wait for cooking to start should be very
cold or frozen before it is placed in the oven.
• Do not use foods containing baking powder or yeast when
automatic time baking. They will not rise properly.
• Do not allow food to remain in the oven for more than two
hours after the end of the cooking cycle.
WARNING
To avoid sickness and food waste do not allow defrosted food
to remain in the oven for more than two hours.

4 5
Cooking Tips
Rack Positions ______________________________________39
Pan Placement Tips_________________________________40
Baking Tips ________________________________________40
Multiple Rack Baking _______________________________41
Conventional Baking Chart __________________________42
Convection Baking Chart____________________________43
Solving Baking Problems ____________________________44
Broiling Tips________________________________________45
Broiling Chart ______________________________________46
Roasting Tips_______________________________________47
Conventional Roasting Chart ________________________48
Convection Roasting Chart __________________________49
Product Car
Cleaning and Maintenance__________________________50
Self-Clean Cycle _______________________________53
Replacing Light_____________________________________54
Trouble Shooting ___________________________________55
Error Handling______________________________________55
Service Information _________________________________56
Warranty ___________________________________________57
G tting Start d
Important Safety Instrutions ________________________6
Product Controls
Oven Control Panel________________________________8
Built-In Electric Oven Features______________________10
Touch Pad Functions_______________________________11
Programming Mod s
Clocks and Timers
Setting the Clock _____________________________16
Setting the Timer _____________________________17
Cook Time and Stop Time ____________________18
Oven Settings
Brightness____________________________________20
Degree Format (Fahrenheit or Celsius) _________20
Tones ________________________________________21
Tone Volume _________________________________23
Timeouts ____________________________________23
Clock Format (12-hour or 24-hour) _____________24
Sabbath Mode _______________________________25
Showroom Mode __________________________________25
Lock and Unlock ______________________________26
Interior Oven Lights___________________________26
Recipe Function ___________________________________27
Warming Modes __________________________________29
Bake Modes ______________________________________30
Broil Modes ______________________________________33
Roast Modes______________________________________35
Meat Probe _______________________________________37
Table of Contents Table of Contents

6 7
G tting Start d
G tting Start d
• Do not heat unopened food containers; build-up of pressure
may cause the container to explode and result in injury.
• Always position oven racks in desired location while oven is
cool. If rack must be moved while oven is hot do not let
potholder contact hot heating element in oven.
• Use care when opening oven door. Let hot air or steam
escape before removing or replacing food. Hot air or steam
can cause burns to hands face and/or eyes.
• Keep oven vents unobstructed. The oven vent is located at
the front of the oven and vents into the room.
• Do not clean door gasket. It is essential for a good tight
seal. Care should be taken not to rub damage or move
the gasket.
• No commercial oven cleaner or oven liner protective
coating such as aluminum foil should be used in or around
any part of the oven. Improper oven liners may result in a
risk of electric shock or fire. Keep oven free from grease
buildup.
• Before self-cleaning the oven remove broiler pan broiler
grid oven racks and other utensils. Do not use your oven
to clean other parts. A fan noise should be heard during
the cleaning cycle. If not call service before self-cleaning
again.
•DO NOT TOUCH HEATING ELEMENTS OR INTERIOR
SURFACES OF OVEN. Heating elements may be hot even
though they are dark in color. Interior surfaces of an oven
become hot enough to cause burns. During and after use
do not touch or let clothing or other flammable materials
contact heating elements or interior surfaces of oven until
they have had sufficient time to cool. Other surfaces of the
oven may become hot enough to cause burns such as the
oven vent opening the surface near the vent opening and
the oven door window.
• Use this appliance only for its intended use as described in
this manual. Never use your appliance for warming or
heating the room. This is based on safety considerations.
• Your unit should be installed by a qualified technician. The
appliance must be installed and electrically grounded
according to local codes.
• Do not attempt to repair or replace any part of this
appliance unless specifically recommended in this manual.
All servicing should be referred to a qualified technician.
Warranty service must be performed by an authorized
service agency.
• Children should not be left alone in the kitchen while the
oven is in use.
CAUTION: Do not store items of interest to children over
the unit. Children climbing to reach items could be seriously
injured.
• GREASE - Grease is flammable and should be handled
carefully. Do not use water on grease fires. Flaming grease
can be extinguished with baking soda or if available a
multipurpose dry chemical or foam-type extinguisher. Let fat
cool before attempting to handle it. Do not allow grease to
collect around the oven or in vents. Wipe up spillovers
immediately.
• Loose-fitting or hanging garments should never be worn
while using the appliance. Do not drape towels or materials
on oven door handles. These items could ignite and cause
burns.
• Use only dry potholders. Moist or damp potholders on
hot surfaces may result in burns from steam. Do not let
potholder touch hot surface areas. Do not use a towel or
other bulky cloth.
• Keep area clean and free from combustible materials
gasoline and other flammable liquids. Never use your oven
as a storage space. Combustible items (paper plastic etc.)
may ignite and metallic items may become hot and cause
burns.
Important Safety Instructions Important Safety Instructions

98
Oven Control Panel
Product Controls
Product Controls
*Note: Premiere model control panel and features are shown.
Ov n Function and
T mp ratur Controls
Each oven function has a separate setting.
(See descriptions)
The SET control up and down arrows can be
used to set any temperature from
150° F (65.6° C) to 550° F (287.8° C).
El ctronic Timing C nt r
The Electronic Timing Center is
used to program and control all
timing functions.
IMPORTANT–The time-of-day
must be set before any other
program can be used.
El ctronic K ypad
Entry
The Electronic Keypad
Entry is used to program
and control all oven
functions.
Bak
Conventional single-rack baking
(breads cakes cookies pastry pies
entrees vegetables)
Conv ction Bak
Multi-rack baking for heavier or frozen
foods (e.g. frozen pies pizzas entrees
vegetables)
D frost
Natural defrosting of food using fan
without heat
Auto Roast*
Automatic searing of the outside of
meats; simplifies roasting
TruConv cTM
Multi-rack baking for breads cakes
cookies (up to 6 racks of cookies at
once)
Conv ction Roast
Roasting whole turkeys whole chickens
hams etc.
S lf-Cl an
A self-cleaning cycle using high heat to
burn off soils and deposits
Proof*
Creates an optimal environment for the
rising of yeast in many kinds of dough
R cip s*
Accesses programs and saves cooking
cycles from favorite recipes
Ov n Light Controls
Controls the interior lights in the upper
and lower ovens
Ov n Lock
Childproofing feature preventing the
controls from being activated when the
oven is not in use
S ttings
Accesses custom features such as display
brightness Sabbath/Showroom modes
and tones
Broil
Three conventional broil settings for cuts of
flat pieces of meat or meat 1-2 inches thick
Conv ction Broil
Faster than regular broiling with less smoke
generation for thicker meats
D hydrat
Using the convection fan over a
period of time water is removed
from food by evaporation
M at Prob *
Automatically turns the oven off when the
internal temperature of the meat being
roasted is reached
Ov n S l ctor Options
Ov n S l ctor
Controls
The Oven Selector Controls
are used to turn the upper or
lower oven on and off.
Oven Control Panel

10
Built-In Electric Oven Features
11
Touch Pad Functions
T mp ratur Control
Both ovens share the temperature control. To use this feature select the
upper or lower oven and then set the desired temperature. The controls
can be set at any temperature from 150° F (65.6° C) to 550° F (287.8° C).
El ctronic K ypad Entry
Both ovens share the electronic keypad entry. The alphanumeric keys can
be used to program and control all oven functions.
Ov n Function S l ctor Control
Both ovens offer 14 separate cooking modes from which you can choose
the one that best meets your cooking needs.
Bak
When using this function
full-power heat is radiated
from the bake element in
the bottom of the oven
cavity while supplemental
heat is radiated from the
broil element. This function
is recommended for single-
rack baking. Use this setting
for baking roasting and
casseroles.
Broil
This function is a dry-heat
cooking method using
direct or radiant heat on
three different settings: low
medium and high. The
distance between the
foods and the broil
elements determines
broiling speed. This
function is recommended
for small individualized
cuts such as steaks chops
and patties.
Bake
Product Controls
Product Controls
Premiere Designer double oven is s own above.
Broil El m nt
Int rior
Ov n Light
Ov n Racks
(3/upp r ov n;
3/low r ov n)
Bak El m nt
Low r Ov n
Mod l/S rial
Numb r Plat
(und r control
pan l)
TruConv c™
El m nt
(b hind baffl )
Int rior Ov n Light
Ov n Function
and T mp ratur
Controls
Broil
Ov n Control Pan l
El ctronic K y
Pad Entry
M at Prob (available on Premiere models)
Plug
Cable Probe
Handles
M at Prob Jack

12
TruConv c™
With this function only the rear
element operates at full power.
There is no direct heat from the
bottom or top elements and
the motorized fan in the rear of
the oven circulates for even
heating. Use this setting for
foods that require gentle
cooking such as pastries
soufflés yeast breads quick
breads and cakes. This setting
produces breads cookies and
other baked goods with an even texture and golden crusts. No special
bakeware is required. Use this function for single-rack baking multiple-rack
baking roasting and preparation of complete meals. This setting is also
recommended when preparing large quantities of baked goods at one time.
Conv ction Bak
With this function the bottom
element operates at full power
and the top broil element
operates at supplemental
power.Themotorizedfaninthe
rear of the oven circulates
heated air providing a more
even heat distribution. This
even circulation of air equalizes
the temperature throughout
the oven cavity and eliminates
the hot and cold spots found in
conventional ovens. A major benefit of convection baking is the ability to
prepare food in larger quantities using multiple racks. When roasting using this
setting cool air is quickly replaced searing meats on the outside and retaining
more juices and natural flavor on the inside with less shrinkage. With this
heating method foods can be baked and roasted at the same time with
minimal taste transfer even when different dishes are involved such as cakes
fish or meat. The hot air system is especially economical when thawing frozen
food. Use this setting for baking and roasting.
13
Touch Pad Functions Touch Pad Functions
Conv ction Broil
Using this function the top
element operates at full
power. This function is
exactly the same as regular
broiling with the additional
benefit of air circulation by
the motorized fan in the
rear of the oven. Smoke is
reduced since the airflow
also reduces peak
temperatures on the food.
Use this setting for broiling
thick cuts of meat.
Conv ction Roast
With this function the
convection element runs in
conjunction with the inner
and outer broil elements.
The reversible convection
fan runs at a higher speed
in each direction allowing
the moisture to be sealed
inside large cuts of meat
such as roasts. This saves
time when compared with
single fan convection roast
modes. Use this setting for
whole turkeys whole
chickens and roasts.
NOTE: Because t is function uses a ig -speed convection fan for
optimum cooking performance, some noise may be noticed from t is
ig fan speed. T is is normal.
D frost
With the temperature control off a motorized fan in the
rear of the oven circulates air. This fan accelerates natural
defrosting of the food without heat.
NOTE: To avoid sickness and food waste, do not allow
defrosted food to remain in t e oven for more t an
two ours.
TruConvecTM
convection bake
Product Controls
Product Controls
convection broil
convection roast

1514
Touch Pad Functions Touch Pad Functions
Proof*
This function uses a low temperature to create an optimal
environment for the yeast to rise in many types of dough.
R cip s*
This setting accesses programs and saves
cooking cycles from favorite recipes.
Int rior Ov n Light Controls
The upper and lower ovens have interior oven lights
controlled by the right touch pad. Push the light button to
turn the interior oven lights on and off.
Ov n Lock
This child protection function prevents the oven controls
from being activated when the oven is not in use.
S ttings
Use this function to access program and customize
special features of your oven. Special features include
tones timeouts display brightness and the Sabbath
mode.
*Note: The AUTO-ROAST PROOF RECIPE and PROBEfunctions are
included on the Premiere models.
Product Controls
Product Controls
D hydrat
With this function a motorized fan in the rear of the oven
circulates warm air. Over a period of time the water is
removed from the food by evaporation. Removal of water
inhibits growth of microorganisms and retards the activity
of enzymes. It is important to remember that dehydration
does not improve quality; only fresh top-quality foods
should be dehydrated in your oven.
S lf-Cl an
The self-cleaning cycle is designed to eliminate the need
for scrubbing and scouring food baked onto the oven
interior. During this cycle the oven uses high
temperatures to burn off soils and deposits. An integral
smoke eliminator reduces odors associated with the soil
burn-off. A powder ash residue is left in the bottom of the
oven after completion of the self-clean cycle. When the
oven has cooled remove any ash from oven surfaces with
a damp sponge or cloth.
Auto Roast*
This function further simplifies roasting by automatically
searing the outside of meats raising the pre-set
temperature by 100° F for a short time to sear the outside
of the meat. The temperature then returns to the pre-set
temperature in the standard convection roast mode.
M at Prob *
The probe temperature function is used to automatically
turn the oven off when the internal temperature of meat
being cooked is reached.

17
16
Clocks and Timers
El ctronic
Timing C nt r
The Electronic Timing
Center is used to
program and control
all timing functions on
your Viking appliance.
It has four display and programming modes that are activated by
the four push buttons. Both the Timer and the Cook Time/Stop
Time Modes can be used to time cooking periods. These
features can even be used at the same time when both ovens are
in use. For example you can time-bake a casserole in the upper
oven using the Cook Time/Stop Time Mode while broiling in the
lower oven using the Timer. One oven can also be cleaned while
timing foods in the other oven using the timer.
Tim r Alarm
• At the end of a program the alarm will consist of three beeps
followed by two beeps every 10 seconds until the “CLEAR”
button is pressed.
• Whenever a valid function key is pressed or when a control
function starts automatically one beep will sound.
• When an invalid function key is pressed two beeps will sound.
S tting th Clock
The time-of-day must be set before any other program can be
used. When your oven is first connected to the power in your
home the timer display will show 12:00.
To Program th Tim -Of-Day:
1. Press either the “UPPER OVEN” or “LOWEROVEN” button.
2. Press the “CLOCK SET” button. The clock will begin to flash.
The word “CLOCK” will be lit on the display.
3. Type in the correct time on the electronic number keypad.
4. Press the “CLOCK SET” button again. The clock is now set.
Alt rnat M thod:
1. Press either the “UPPEROVEN” or “LOWER OVEN” button.
2. Press the “CLOCK SET” button. The clock will begin to flash.
The word “CLOCK” will be lit on the display.
Programming Mod s
Programming Mod s
3. Use the up and down arrows to change the current time.
4. Press the “SET” button on the temperature control or the
“CLOCK SET” button on the electronic timing center. The
clock is now set.
Note: T e time-of-day cannot be c anged w ile t ere is a
Bake Hours or Start Time cycle programmed into t e timer.
S tting th Tim r
The timer is designed for accurate timing and is ideal for baking
delicate items such as biscuits cookies and popovers and for
precise broiling. The timer can be used for timing up to 12 hours.
When setting the timer the time displayed will decrease in 1
minute increments. When the timer counts down to 1 minute the
timer alarm will give one short beep and the display will change
to seconds. When the timer reaches 0:00 the alarm will give one
long beep.
To S t th Tim r:
1. Press the “TIMER” button. The timer will display “0:00” and
the word “TIMER.”
2. Type in the desired duration time on the electronic number
keypad.
3. The timer will start automatically. (To cancel the entry press the
“CLEAR” button on the left side of the control panel before
the count down begins and the time is still flashing.)
4.The timer is now set.
Alt rnat M thod:
1. Press the “TIMER” button. The timer will display “0:00” and
the word “TIMER” will be lit on the display.
Pr ss and R l as Pr ss and Hold
sTime increases by one
minute Time increases by 10 minutes
tTime decreases by one
minute Time decreases by 10 minutes
Clocks and Timers

19
18
Programming Mod s
Programming Mod s
Clocks and Timers
2. Use the up and down arrows to set the timer.
3. Press “SET” or “TIMER” to program the timer. (To cancel the
entry press the “CLEAR” button on the left side of the control
panel.)
4. The timer is now set.
Cook Tim and Stop Tim
With the Viking oven you can choose what times you need to
start and stop cooking your food. The Cook Time and Stop Time
functions allow you to program your preferences.
H r ’s how it works:
It is 2:00 PM and you would like to have your dinner ready at 6:00
PM. By programming your oven with a two-hour cook time and a
6:00 PM stop time your oven will delay cooking until 3:50 PM. At
3:50 the oven will begin preheating. At 4:00 PM the oven will
begin its two-hour cook time.
Cook Tim and Stop Tim Facts:
Both ovens can be set individually for Cook Time and Stop Time
functions.
To S t Cook Tim :
1. Select UPPER OVEN or LOWER OVEN.
2. Select an oven function and temperature before setting Cook
Time and Stop Time functions.
3. Press “COOK TIME” and the display will flash “0:00” and
“COOK TIME” will be lit below.
4. Use numeric keyboard to enter the amount of time needed for
cooking.
5. After the time is entered the display will show “COOK TIME”
under the timer field. (To cancel the entry press the “CLEAR”
button on the left side of the control panel.)
6. Press “SET” or “ENTER” if the cook time is correct. Cook time
is set.
NOTE: To cancel cook time during its cycle, press “COOK TIME”
and t en press t e “CLEAR” button on t e left side of t e oven
control. Cooking will continue if t e oven is on.
To S t Stop Tim :
1. Set Cook Time following the steps provided in the previous
section.
2. Press “STOP TIME” and “STOP TIME” will be lit on the display.
3. Use numeric keyboard to enter the time you want to stop for
cooking.
4. After the time is entered the display will flash the time. (To
cancel stop time press the “CLEAR” button on the left side of
the control panel.)
5. Press “SET” or “STOP TIME” if the stop time is correct. Stop
time is set and will begin when the oven is preheated.
NOTE: Display will s ow Cook Time and Stop Time. If you
ave entered a time incorrectly, you will ear a long beep
and t e display will not c ange.
NOTE: To cancel stop time during its cycle, press “STOP TIME”
and t en press t e “CLEAR” button on t e left side of t e oven
control. Cooking will continue if t e oven is on.
When Stop Time has been reached:
1. Your oven will sound three beeps and “HOLD” will appear on
the display.
• The oven will stay at 150º F in hold mode for two hours.
• After two hours the oven will sound four long beeps and
shut off.
2. Press “OFF” to turn off the oven manually.
Clocks and Timers
Pr ss and R l as Pr ss and Hold
sTime increases by one
minute Time increases by 10 minutes
tTime decreases by one
minute Time decreases by 10 minutes
