Viking Installation Guide
DDHK23 Designer Handle Kit
For Use With DFRD Refrigerated Drawers,
DFB Dishwashers, and DFWD171 Warming Drawers

IMPORTANT–Please Read and Follow!
2
•Be ore beginning, please read these instructions completely and care ully.
•Use caution during assembly to minimize scratches.
•Do not remove permanently a ixed labels, warnings or plates rom the product. This may
void the warranty.
•Please re er to the DFRD, DFB and DFWD Installation Instructions or more in ormation on
installing the door panel.
•The installer should leave instructions with the customer who should retain for local
inspector’s use and future reference.
Parts Included
Required Tools
To Install:
Installation with Wooden Full Overlay
Custom Door Front
1. Locate the wooden custom panel.
2. Using the illustrations on the next page, layout the handle location on the panels. It is
recommended that masking tape be placed where the our holes will be drilled to help mark
the hole placement and to prevent any damage to the door when drilling the holes.
3. The Designer handle will be mounted using (4) o the #10 x 3/4” Hex head screws provided.
Using the 3/16”(0.5 cm) drill bit, drill completely through the door in the hole locations.
Using the 7/16” (1.1 cm) bit, counter-bore our holes 1/2” (1.2 cm) deep max. on the
BACKSIDE o the custom door panel.
4. Attach the Designer handle to the panel using (4) #10 x 3/4” screws provided.
Part Quantit
Designer Handles
End Caps
#10 x 3/4” Hex Head Scre s
Installation Instructions
(1)
(2)
(4)
Electric Drill
3/16” (0.5 cm) Drill Bit
7/16” (1.1 cm) Spade or Forstner Bit (Counterbore)
Tape Measure
Hex Head Screw Driver
Masking Tape and Pencil
3
Handle Installation
DFRD - REFRIGERATED DRAWER
CUSTOM FRONT DIMENSIONS
20-21/32”
(52.5 cm)
1-5/8”
(4.1 cm)
13/16” (2.1 cm) AA
C
L
3/4” (1.9 cm)
Full Overlay
Panel
3/16” (0.5 cm)
Thru Hole
7/16” (1.1 cm)
Counter Bore x 1/2”
Depth (max)
13/16”
(2.1 cm)
Section A-A
Note: Refrigerated drawers require two handle kits.

4 5
DFB - DISHWASHER
CUSTOM FRONT DIMENSIONS
20-21/32”
(52.5 cm)
1-5/8”
(4.1 cm)
13/16” (2.1 cm) AA
C
L
Handle Installation
3/4” (1.9 cm)
Full Overlay
Panel
3/16” (0.5 cm)
Thru Hole
7/16” (1.1 cm)
Counter Bore x 1/2”
Depth (max)
13/16”
(2.1 cm)
Section A-A
Handle Installation
DFWD171 - WARMING DRAWER
C
L
13/16” (2.1 cm)
20-5/8”
(52.4 cm)
AA
1-1/4”
(3.2 cm)
3/4” (1.9 cm)
Full Overlay
Panel
3/16” (0.5 cm)
Thru Hole
7/16” (1.1 cm)
Counter Bore x 1/2”
Depth (max)
13/16”
(2.1 cm)
Section A-A

76
CUSTOM FRONT INSTALLATION
1. Open the drawer and remove the pan.
2. Center the custom ront on the inside panel.
3. Attach the custom ront with the (6) six #8 x 3/4” screws provided.
Custom Front Installation
Mounting Screws
(4) - #8 x 3/4”
Cavity
Assembly
(6) - #8 x 3/4” screws
to attach custom front
Custom
Front
