Vimar 7549 User manual

Use and Configuration Manual
TAB
7549 - 7548
Due Fili Plus TAB 4.3” video entryphone with handset

2
7549 - 7548 Tab 4.3

3
7549 - 7548 Tab 4.3
General information 4
Description 4
Warnings and advice 4
Keys and LED statuses 5
Status LED 6
Operation 7
First power up 8
Programming the primary ID identification code 8
- Simplified programming mode 8
- Standard programming mode 12
Functions 17
Answering a call from an Outdoor Station 18
Answering a call from an Indoor Station or Reception switchboard 21
Audio/video settings 23
Volume and image brightness control 23
Pan/Zoom adjustment 25
Calling an Outdoor Station (Self-start) 27
Calling an Indoor Station (Intercom) or Reception Switchboard 29
Alert function 31
User Configurations 32
Call ringtone selection (for video entryphone 7549) 33
Call ringtone selection (for video entryphone 7548) 34
Ringtone volume control 35
Ringtone exclusion 36
Device cleaning 37
Installer configuration 38
Programming the secondary ID identification code
- Simplified programming mode 40
- Standard programming mode 41
Programming keys for intercom calls
- Simplified programming mode 42
- Standard programming mode 43
Programming the self-start key for a specific Outdoor Station
- Simplified programming mode 44
- Standard programming mode 45
Programming the self-start key for a specific Outdoor Station
- Simplified programming mode 46
Programming display contrast and brightness levels (video signal) 47
Restoring the default programming of each individual key
- Simplified programming mode 48 - 49
- Standard programming mode 50
Restoring the complete default settings
- Simplified programming mode 51
- Standard programming mode 52
Alert function configuration via SaveProg 53
Advanced configuration with SaveProg software 54
Index

4
7549 - 7548 Tab 4.3
Surface mounting Tab video entryphone for Due Fili Plus system with 4.3” LCD colour display, handset, loudspeaker for calls,
capacitive keypad for entryphone functions (door release, self-starting, auxiliary services, volume, brightness and contrast
controls) and intercom calls.
It is possible to differentiate the call ringtones. The visual signals are for “door/gate open,” “”missed calls from a reception
switchboard”, “user away” and “ringtone exclusion”. Can be used by people wearing hearing aids.
Audio frequency function for hearing aids (Teleloop)
The video entryphone can be used by people wearing hearing aids.
For correct functioning of the hearing aid, please refer to its instruction manual.
Any metal objects or electronic equipment in the vicinity may affect the quality of the sound received by the hearing aid.
Maintenance
Clean using a soft cloth.
Do not pour water onto the appliance and do not use any type of chemical product.
Cleaning must be done with the device powered off (disconnected from the bus) or after activating the Keypad cleaning
procedure
Warnings for the user
Do not open or tamper with the appliance.
In the event of faults, contact specialized personnel.
For installation, refer to the instruction sheet in the package.
Driver for PC
The drivers are the same as for the other device in the TAB family.
The first time a device is connected to a USB port, the PC must associate the drivers to the peripheral device even if a
TAB device has already been associated.
The Indoor Station is identified in SaveProg as ELVOX_7549 or ELVOX_7548 (depending on the model).
General information
Description
Warnings and advice
Door release of
the calling outdoor
station
Outdoor Station
Self-start
Call from Outdoor
Station
Intercoms
Call to/from
Reception
switchboard
Auxiliary
services
activation

5
7549 - 7548 Tab 4.3
The TAB 4.3 video entryphone (7549, 7548) can be operated using the touch keys described below.
Keys and LED statuses
1. 4.3” LCD 16:9 display, resolution 480x272 pixels
2. Self-start: it activates the main outdoor station (ID 1).
3. It activates the lock of the calling Outdoor Station.
4. It activates the first relay of the Due Fili Plus system (Aux 1), stair lights function
5. It sends an F2 control to Outdoor Stations (default *); (Only for 7549)
6. It sends an F1 control to Outdoor Stations (default *); (Only for 7549)
7. Free (default *); (Only for 7549)
8. Ringtone exclusion: in stand-by, press and hold down for 2 s to deactivate/activate the ringtone. Ringtone
mute: during an incoming call,press to deactivate the ringtone. The ringtone is simultaneously also deactivated for
subsequent calls.
9. It activates the second relay (Aux 2) of the Due Fili Plus system (default *); (Only for 7549)
10. It adjusts the brightness level (see Image brightness and volume control)
11. It adjusts the ringtone volume, contrast and voice unit (see Image brightness and volume control)
*N.B.: where appropriately configured, it may activate intercom calls or auxiliary functions (see installer configuration).
1
2
3
4
856791011
N.B.: with the handset replaced, the keys send the control concurrently with the sound feedback, whilst with the handset
raised, the control is activated when the key is released.

6
7549 - 7548 Tab 4.3
LED DESCRIPTION
When lit permanently, it indicates the door open status, and flashes when configuration is
under way
When lit permanently, it indicates that the ringtone is muted.
Flashing in the following cases:
– it is receiving a call from an Outdoor Station or Indoor Station (different flashes);
– configuration is under way.
If configured via SaveProg:
– indication of calls received and missed from the switchboard (1 flash every 10 seconds);
– user away (1 flash every second): the Indoor Station will refuse calls from an Outdoor
Station
Possible “Alert” signalling, see Alert Function
Some of the LEDs illustrated below only come on in certain conditions.
Status LED
KEY
Flashing keySound up
Key litSound low
beep
BEEP

7
7549 - 7548 Tab 4.3
Operation
The TAB 4.3 video entryphone is designed to receive calls from Indoor Stations, Outdoor Stations and the Reception
switchboard.
It can also perform the self-start of the Outdoor Station, intercom calls with Indoor Stations and the Reception
switchboard.
Calls can be answered using the handset and/or by releasing the lock of the Outdoor Station using the dedicated key.
Some programmable keys are also available to activate other functions such as relay actuation or intercom calls:
- keys for video entryphone 7549.
- only key for video entryphone 7548.

8
7549 - 7548 Tab 4.3
First power up
Perform the device installation (according to the assembly instructions and the installation instructions provided in the
printed instruction sheet supplied) and connect it to the Due Fili Plus bus.
Caution: installation must be carried out by qualified persons in compliance with the current regulations regarding the
installation of electrical equipment in the country where the products are installed;
1. Lift the handset and bring it to your ear
Programming the primary ID identification code
(Simplified programming mode)
1

9
7549 - 7548 Tab 4.3
4. Press and hold down for 6 seconds
5. A sound is reproduced, release the key
N.B.: release the key after the first sound; prolonged pressing leads to a different programming.
6 s
2
beep
3

10
7549 - 7548 Tab 4.3
6. Within 30 seconds, press the push button on the Master outdoor station you wish to receive the call from.
The Indoor Station starts communicating with the Outdoor Station
The video entryphone and the Outdoor Station emit a sound to confirm the operation.
N.B.: this procedure applies for Outdoor Stations with push buttons and may vary according to the Outdoor Station
used. For Outdoor Stations with a keypad and display, type in the ID code and confirm with the call key.
N.B.: if the installation already contains an Indoor Station with the same paired identification code, the entrance panel will
emit a tone and the process must be repeated from the start in order to assign a different code
4
BEEP BEEP

11
7549 - 7548 Tab 4.3
7. Press the corresponding key on the Outdoor Station to send the call to the Indoor Station
You can now use all the Functions of the Video entryphone.
5

12
7549 - 7548 Tab 4.3
Perform the device installation (according to the assembly instructions and the installation instructions provided in the
printed instruction sheet supplied) and connect it to the Due Fili Plus bus.
Caution: installation must be carried out by qualified persons in compliance with the current regulations regarding the
installation of electrical equipment in the country where the products are installed;
1. Lift the handset and bring it to your ear
Programming the primary ID identification code
(Standard programming mode)
1

13
7549 - 7548 Tab 4.3
2. Hold down simultaneously
3. The ringtone LED flashes and a sound is reproduced, release the keys
2
2
beep
3
3

14
7549 - 7548 Tab 4.3
4. Press within 5 seconds and hold down
If you exceed 5 seconds, repeat points 1 and 2
5. A sound is reproduced, release the key
4
< 5s
beep
5

15
7549 - 7548 Tab 4.3
6. Within 30 seconds, press the push button on the Master outdoor station you wish to receive the call from.
The Indoor Station starts communicating with the Outdoor Station
The video entryphone and the Outdoor Station emit a sound to confirm the operation.
N.B.: this procedure applies for Outdoor Stations with push buttons and may vary according to the Outdoor Station used.
For Outdoor Stations with a keypad and display, type in the ID code and confirm with the call key.
N.B.: if the installation already contains an Indoor Station with the same paired identification code, the entrance panel will
emit a tone and the process must be repeated from the start in order to assign a different code
6
BEEP BEEP

16
7549 - 7548 Tab 4.3
7. Press the corresponding key on the Outdoor Station to send the call to the Indoor Station
You can now use all the Functions of the TAB 4.3 Video entryphone.
7

17
7549 - 7548 Tab 4.3
The video door entry functions illustrated in the following paragraphs refer to audio/video calls from Outdoor Stations.
In the case of audio only Outdoor Stations, the display will be black.
In the case of a video door entry call with no video signal, the display will be blue.
For the operation of the video entryphone, the ID identification must be configured. To check whether an ID has been
allocated to the video entryphone, proceed as follows:
Functions
In stand-by, press any of the keys.
ID assigned
ID not assigned or deleted
beep
beep
beep beep

18
7549 - 7548 Tab 4.3
Following a call from an Outdoor Station, the display shows the images filmed and the key flashes;
Depending on the type of outdoor station installed, the identification code of the calling outdoor station may also
appear.
1. Lift the handset to answer the call.
Answering a call from an Outdoor Station
1

19
7549 - 7548 Tab 4.3
2. Press to release the lock of the Outdoor Station connected, the lock release is also available in stand-by
3. Press to activate an actuation among those programmed
In addition to communicating, actuations can be activated and/or audio/video adjustments can be made
N.B.: By Default the Indoor Station releases the lock of the last calling entrance panel.
2
3

20
7549 - 7548 Tab 4.3
4. Reposition the handset to finish communicating
4
