Viper AS6690T User guide

Use and maintenance
Operating guidelines AS6690T / AS7190TO series
December 2019
Turn on the key and verify there is enough
battery power to complete the work.
Charge batteries if required.
Install the squeegee using the thumb nuts.
Attach squeegee hose.
Remove the red cover and ll the tank
with water, max temperature 40C/104F.
Add appropriate low foaming detergent.
Maximum tank capacity 85L/22Gall.
Check level with red ball on the side of the
machine.
Disc version: place the brush/pad holder under the scrub deck then press the OneTouchTM scrub
button to enable scrubbing, the deck will lower automatically. The vacuum will start. Push on one
of the two switches ½ second to install the brush.
Boost version: attach a pad to the xed pad holder, press the OneTouchTM scrub button and the
deck will lower automatically.
Place the machine in working mode and
press any of the two red safety switches to
activate the machine.
Pressing either of the red safety switches
and the black reverse button together will
put the machine into reverse.
On disc version, the brush/pad holder can
be removed automatically by raising the
deck and then press the click off button.
Press the + or – buttons to increase /
decrease the water ow rate or brush
pressure.
Use the rabbit /turtle knob to control the
speed of the machine.
Use the handle to lower or raise the
squeegee to the oor. Adjust the squeegee
angle with the knob to adjust suction
performance if needed.
Floor Preparation Button (orbital) for
stripping: pad pressure will be set up to
maximum, solution ow will be set to
minimum, machine speed will be held at
1 km/h 0.6miles/hour

Maintenance
Operating guidelines AS6690T / AS7190TO series
December 2019
When scrubbing is complete, turn off the
key to perform the following maintenance.
Daily: Empty the clean water tank using
the solution tank drain knob under the
machine.
Daily: Empty the recovery tank using the
recovery empty hose. Bend the soft part
before removing the cap to control the
ow.
Daily: Inspect and rinse the oat ball cage.
Inspect, check and clean the debris tray and
clean the lid gasket if required.
Local Viper dealer:
Phone number:
SN:
Daily: Remove the squeegee, and clean.
Inspect the blades and ip them or replace
them if required.
Daily: to charge the battery, connect
the charger connector to the machines
outer charging connection, and connect
the charger to the wall socket. Check the
charger indication light so the charging
have started. If the machine is supplied with
On-board charger, tip the recovery tank and
connect the on-board charger in the same
way.
Weekly: Inspect the solution lter and
clean if required.
Daily: if the battery indicator is low, put the
machine on charge. Battery should be on
charge if empty, not in use or if not being
used for coming 8-10 hours.
Daily: Leave the recovery tank lid open
after it’s been cleaned to avoid bad odor.
