Viridian EcoLite Charge Points User manual

Operation manual for EcoLite Charge Points

Iss 1 - Feb 2018 Page 2 of 9
Thank you for purchasing a Viridian EV charge point.
This guide is intended to instruct in the proper use of all models of Viridian Charging stations.
Installation of this equipment should only be carried out by a fully qualified professional. Viridian
EV accepts no responsibility for damage caused by improperly installed equipment.
For installation instructions see document "Guidance to installers".
Cautions and Dangers
This guide contains several instructions to which the following symbols have been attached.
Failure to comply with instruction could result in:
DANGER Indicates where failure to comply with instructions will cause death or
serious injury.
WARNING Indicates where failure to comply with instructions could lead to death
or serious injury.
CAUTION Indicates where failure to comply with instructions could lead to minor
or moderate injury.
This document is intended to instruct on the use of and general maintenance of all models of
Viridian manufactured charging stations (current model numbers at the time of writing listed
below). Instructions specific to particular models will be highlighted and clearly marked.
Understanding the model number of your charging station
E07-T2S-32A-1P_xxx
Approximate
maximum available
power in kWh
E.g. 7kWh
Charge Point
identifier
Connector Type
E.g. Type 2
Socket or cable
(Socket type 2
only)
E.g. Socket
Maximum Available
Current per phase
E.g. 32A
Number of phases
E.g. Single Phase
May indicate electrical
protection. E.g. RCD (if
blank RCBO fitted)

Iss 1 - Feb 2018 Page 3 of 9
WARNING
The charging station is designed for electric vehicle (EV) charging only. It is designed to only
allow the flow of electricity once an EV is connected and correct communication is established.
Any tampering of the Charging station to allow the flow of electricity at any times other that this
will present a risk of electric shock.
CAUTION
The Charging station is covered by a manufacturer’s parts and labour warranty. Alterations to
the charging station that are not permitted will invalidate this warranty.
Charging Station Features
1. Key-locking access panel for resetting electrical protection
2. Status LED arrangement
3. The charging station connects to an EV via a vehicle coupler plugged into the socket
outlet. Models fitted with sockets allow the use of a range of approved interconnecting
cables.
4. Identification label
2
3
1
4
Model
Number
Charging
Current
Serial
Number

Iss 1 - Feb 2018 Page 4 of 9
Status LED arrangement
On the EcoLite charge point, the operating state is communicated to the user via two LED
arrangements: An illuminated ‘Charge Point’text and an illuminated halo on the front.
LED
Operating State and description
Text
Halo
OFF
OFF
Charge point is not active, Switched off
Possible Cause of issue:
No mains power present
Electrical protection switched off
Fault with charge point
WHITE
BLUE
A - Charging station is waiting ready to be connected to an electric
vehicle
BLUE
BLUE
B - An electric vehicle is connected but not charging
GREEN
GREEN
C - An electric vehicle is connected and charging
RED
BLUE
D - An electric vehicle is connected but ventilation is required. This
mode is not supported by Viridian EV charge points so will not
charge.
RED
(Pulsing)
OFF
Fault detected, charging is not allowed. See troubleshooting or seek
technical support.
LED Brightness
The LED brightness is configurable at the point of installation (or after during maintenance). There are 4
settings: MAX, MEDIUM, LOW & HALO OFF. Ask your installer about this if you wish it to be
changed.
Connecting / disconnecting your electric vehicle
To begin a charging session
For charging stations equipped with a built in cable:
Open the socket inlet flap on the vehicle and insert the vehicle coupler into the electric vehicle.
You may need to apply a small amount of force to ensure that the plug is housed firmly within
the socket.
For charging stations equipped with a socket:
Lift the hinged flap of the socket on the charging station and fully insert one end of the vehicle
interconnecting cable in to the socket.
Take the other end of the vehicle interconnecting cable and insert it into the vehicle as described
above.

Iss 1 - Feb 2018 Page 5 of 9
To stop the charging session
Once the charging session has finished, first remove the charging cable from the vehicle. Please
note that some vehicle models require you to manually disengage the vehicle inlet’s locking
system to enable you to do this. If this is the case please consult your vehicle’s owners manual.
For charging stations equipped with built in cable:
A wall-mounted plug holder or plug holder & cable management system is recommended for
cable storage whilst not in use. These are available from Viridian EV.
For charging stations equipped with a socket:
It is recommended that you remove the cable from the charging station and safely store it away
when not in use.
Please Note:
The cable cannot be removed from the socket on the charging station whilst it is still in a
‘connected’ state (Blue ‘Charge Point’text & Blue Halo or Green ‘Charge Point’text and Green
Halo). Trying to do so could lead to the cable remaining locked into the charging station when
the EV is disconnected.
If the cable should become stuck in the charging station it is recommended to follow the steps
below:
Firmly push the cable into the charging station. In most instances this should be sufficient to
release the lock from the connector. You may now attempt to remove the cable from the
charging station.
In the event the above does not release the connector, firmly push the cable into the
charging station once again. Disconnect then reconnect the power by switching the RCBO (or
other electrical protection) or reconnect and then disconnect the electric vehicle.
The internal locking mechanism should now have released and the cable should have become
freed. In the event that this does not occur repeat the above process ensuring you firmly
push the cable fully into the charging station socket each time.
BE AWARE in the event of a power outage or switching off of the internal RCBO during
charging, the charge will stop.
Resetting the trip switch
Viridian EV charge points are, by default, fitted with electrical protection. It is possible if an
earthing problem or another fault occurs this protection will trip out. To reset the trip switch and
begin charging again use the key provided to remove the small access panel on the front
(Feature 1 indicated above) and throw the switch on the electrical protection.
Service and maintenance
DANGER
Contact with live components can result in serious injuries. There are no user-serviceable items
within the charging station.

Iss 1 - Feb 2018 Page 6 of 9
Any repair work should only be carried out by a suitably qualified individual.
It is recommended that you test the function of the fitted electrical protection once a month by
removing the access panel and pressing the test button. If the RCBO or equivalent protection
fails its function test you should immediately stop using the charging station and contact your
installer for further assistance.
Cleaning
It is recommended that cleaning of the outside of the charging station should be performed
using a damp cloth and a mild cleaning solution.
CAUTION
Cleaning the charging station with a high-pressure water hose is not permitted and could cause
water build up within the charging station.
The charging station should not be opened and cleaned internally.

Iss 1 - Feb 2018 Page 7 of 9
Warranty
Viridian EV provides a 3 year full parts and labour warranty for operational failure of the
charging station. This is the same for charging stations installed under the OLEV EVHS & WCS.
In the event of any operational issues with your Viridian EV charging station please contact the
electrician responsible for the installation of the charging station and a solution will be put into
motion.
Installer Information
Installed By: … … … … … … …
Address: … … … … … … … … … … … … … …
… … … … … … … … … … … … … …
… … … … … … … … … … … … … …
… … … … … … … … … … … … … …
… … … … … … … … … … … … … …
… … … … … … … … … … … … … …
Tel: … … … … … … …

Iss 1 - Feb 2018 Page 8 of 9
Trouble Shooting Guide
Problem
Solution
EV not charging
Check the
status
LED
- Status LEDs not lit
Check power to the unit
-Has the main feed from the consumer
unit tripped
-Has the internal RCBO tripped
- Text & Halo Blue
Ensure that the cable is fully inserted to both
the charging cable station and EV.
- Text Pulsing Red,
Halo not lit
Disconnect and reconnect the car. If the unit
continues flashing seek further advice.
Unable to remove
charging cable
from charging
station
Please see - Connecting / disconnecting your electric vehicle
EV not charging at
the expected rate
Charging
stations
equipped
with built
in cable:
The charging rate
maybe limited by the
following
-The vehicle may not be capable of
receiving the full maximum power that
the charging station can deliver.
-The power that the battery can take is
reduced the higher the state of charge so
will draw less current.
Charging
stations
equipped
with a
socket
The charging rate
maybe limited by the
following
-As above
-The charging cable may be rated to less
than the maximum current available from
the charging station and the current will
be automatically reduced accordingly.
I can’t plug my
charging cable into
the charging
station
Charging
stations
equipped
with built
in cable:
The charging station is not designed to be used with a charging cable.
The charging station must be plugged directly into the vehicle via the
built in vehicle coupler.
Charging
stations
equipped
with a
socket
Please ensure you are
trying to insert the
correct end of the
charging cable.
You will need to use a 7-pin, Type 2 plug to
connect to the charging station.
If both plugs are 7-pins use the smaller of the
two.
I can’t plug my
charging cable into
the vehicle
There are various approved types of vehicle sockets. Please ensure you have the right
charging station or charging lead to allow you to connect to your chosen vehicle.

Viridian EV
42 Elliott Road,
Love lane Industrial Estate,
Cirencester,
Gloucestershire
GL7 1YS
Tel: [phone]
Web: www.viridianev.co.uk
Email: [email protected]
