visual engineering StreetView User manual
StreetView June 2016
Visual Engineering
Video solutions. Integrated
visualengineering.co.uk Page 1
StreetView Digital Wireless
CCTV System
Pan, Tilt and Zoom COFDM
Wireless CCTV Video System
StreetView June 2016
Visual Engineering
Video solutions. Integrated
visualengineering.co.uk Page 2
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Change History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
About the User Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
User Manual Part Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Warranty and Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Introduction to the StreetView System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
The StreetView Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Kit Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Key Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Connecting the Antennas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
PTZ Camera Antenna Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
COFDM Video Receiver Antenna Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
PTZ Camera Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
In-line Power Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
COFDM Video Receiver Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Control, Power and Telemetry Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Software Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Camera Control Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Video Transmission Control Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Telemetry Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Connector Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Table of Contents
StreetView June 2016
Visual Engineering
Video solutions. Integrated
visualengineering.co.uk Page 3
Change History
Version Date Change Summary Author
v1.0 6/6/2016 RE
v1.1 10/6/2016 Software Control Additions RE
StreetView June 2016
Visual Engineering
Video solutions. Integrated
visualengineering.co.uk Page 4
About the User Manual
This user manual describes the operation of the StreetView COFDM video system.
Initially, the user manual introduces the reader to the StreetView operation. This includes a
description of the various components in the kit and a guide to their use.
described in detail.
connector interfaces.
The guide follows a step by step approach, describing the simple initialisation sequence to get the
user up and running in the shortest possible time.
Warranty and Support
All Visual Engineering products are supplied as standard with a 12 month ‘Return to Base’ warranty.
In the event of a suspected product failure, users should contact the Visual Engineering support
team on the telephone number +44 (0) 1206 211842 or please email us at:
Should the fault persist or if the support team are unable to resolve the fault, it may be necessary
to return the equipment.
Equipment should only be returned using the RMA (Returns Management Authorisation) process.
Users should contact the support team on the above number and request an RMA form and RMA
number.
User Manual Part Number
The VE part number for this manual is 110-xxxx
StreetView June 2016
Visual Engineering
Video solutions. Integrated
visualengineering.co.uk Page 5
Introduction to the StreetView System
StreetView is a wireless video system designed for outdoor use.
It is capable of working in licence exempt frequency bands with no network running costs, unlike
3G/4G systems.
It comprises of a rugged outdoor IP67 rated pan, tilt and 36x zoom camera with an integrated
In addition, the system also includes a UHF telemetry link allowing remote PTZ camera control.
The weather proof enclosure of the StreetView camera is suitable for long term outdoor
deployment, making it ideal for surveillance, perimeter security, crime prevention and town centre
monitoring.
StreetView cameras are supplied with a bracket suitable for wall or pole mounting. The camera is
powered from an AC mains supply.
At the receive end is a COFDM video receiver, this is a stand alone IP66 rated rugged unit which
receives video via two diversity antennas, its RF connectors allow the antennas to be detached
during storage.
The video receiver also includes the same UHF telemetry link as the PTZ camera, thereby allowing
the control of the camera’s PTZ functions via a PC connection on the rear of the video receiver.
At the receiver end there is a serial data comms connector which is used to send telemetry data to
the camera. The power input to the receiver is also integrated into the same interface cable. The
video is output is on a standard BNC connector on the rear of the video receiver.
units.
StreetView June 2016
Visual Engineering
Video solutions. Integrated
visualengineering.co.uk Page 6
The StreetView Kit
Kit Contents
together with their part numbers:
• PTZ camera with video transmitter & telemetry 10245
• COFDM Video Receiver 110-8691
• COFDM Antennas x 3 110-8852
• PTZ Telemetry Antenna 110-8866
• Video Receiver Telemetry Antenna 110-8866
• Receiver Power & Comms Cable 110-8853
• Power Supply 110-8661
•
•
• Camera Control Cable 110-8899
• Mounting Bracket
• In-Line Power Connector
StreetView June 2016
Visual Engineering
Video solutions. Integrated
visualengineering.co.uk Page 7
Key Components
In addition to the principle components of the PTZ camera video transmitter and the video receiver
there are three COFDM antennas, these are interchangeable between the PTZ camera and the
unit.
PTZ
Camera
COFDM Video
Receiver
COFDM Antennas
Telemetry
Antennas
PTZ Camera
Mounting Bracket
DC Power Supply
for the COFDM
Video Receiver
StreetView June 2016
Visual Engineering
Video solutions. Integrated
visualengineering.co.uk Page 8
Connecting the Antennas
PTZ Camera Antenna Connections
appropriate connectors.
The PTZ camera requires the white
COFDM video transmitter antenna
labelled COFDM.
It is also necessary to connect the
black telemetry antenna to the
N-Type port labelled TELEM.
The antenna connections should
look like the image shown here.
COFDM Video Receiver Antenna Connections
The COFDM video receiver
requires the two white COFDM
video diversity receive antennas
either side of the unit.
It is also necessary to connect the
black telemetry antenna to the
central connector.
connections should look like the
image shown here.
StreetView June 2016
Visual Engineering
Video solutions. Integrated
visualengineering.co.uk Page 9
PTZ Camera Connections
It is necessary to connect power into the
PTZ camera.
These contacts have been left as bare
ended wires to connect the camera directly
to an AC power supply.
An IP68 rated in-line interface plug is
included in the kit. Connecting the power
into the PTZ camera should only be only
carried out by a competent electrician.
Conguration Cables
In-line Power Connector
110-8897
If the COFDM transmitter requires
connector cable shown here to the PTZ
camera. Connect the other end, the D-Type
connector, to a controlling PC and start
the Video Transmission Control Software
application.
110-8898
connect the 8 pin
binder connector
cable shown here
to the PTZ camera.
Connect the other
end, the D-Type
connector, to a
controlling PC
and start the
Telemetry Control
application.
Camera Control Cable
110-8899
For direct connection of the camera
control connect the 8
pin binder connector
cable shown here
to the PTZ camera.
Connect the other
end, the D-Type
connector, to a
controlling PC and
start the Camera
Control Software
application.
StreetView June 2016
Visual Engineering
Video solutions. Integrated
visualengineering.co.uk Page 10
COFDM Video Receiver Connections
In addition to the antenna connections there are two connectors on the rear of the video receiver.
One of these is a BNC connector for the CVBS video signal out, this should be connected to a video
monitor. The other connection is a binder connector used for the control, power and telemetry
data connections.
Video Out Connector Control & Telemetry
Connections
Video Diversity
Antennas
Telemetry Antenna
Control, Power and Telemetry Connector
The 8 pin binder connection interfaces the power, control data and telemetry data to the video
receiver. Both the control and telemetry data connections are on a 9 way D-Type connector and
should be connected to a controlling PC. The DC power connector should be connected to the DC
power supply included in the kit.
8 Pin Binder Connector
to Video Receiver
9 Way D-Type Control
Connection
9 Way D-Type
Telemetry Connection
DC Power Connector
StreetView June 2016
Visual Engineering
Video solutions. Integrated
visualengineering.co.uk Page 11
Software Control
Camera Control Software
The StreetView PTZ camera supports serial
communication control over RS232 and
RS485. It supports PelcoD, PelcoP and Sony
Visca protocols.
The user may choose to use a software
controller of their choice or use the
VE Camera Controller. This software
application is available for download at:
www.visualengineering.co.uk/support
The user should install the Software
application on a PC. The image here shows
what the software application looks like.
number 110-8899, to the 8 pin binder connection on the camera.
Connect the other end, the 9 way D-Type connector, to a RS232 to USB converter cable. The USB
end can now be connected to the controlling PC.
The operating system of the computer will allocate this a COM port number. Once this connection
between the comms lead and the computer’s operating system has been made the user can go
ahead and connect the application to the COM port. In the example below the port COM3 has been
selected. Now select Connect.
StreetView June 2016
Visual Engineering
Video solutions. Integrated
visualengineering.co.uk Page 12
Now that the software application is connected to the comms lead the functions of the software
can be used. In the example below the pan right command has been selected. This will cause
the StreetView PTZ camera to pan right. Similar commands for pan left, tilt up & down and zoom
functions can also be tried out using the intuitive software user interface.
Video Transmission Control Software
The StreetView transmitter and receiver radio system is built around Cobham COFDM technology.
relevant cable to the unit. The other end of the cable should be connected to a PC via a RS232 to
this can be downloaded from:
www.cobham.com
A user guide for the Solo4 controller can be downloaded from:
www.cobham.com/media/53143/solo4andsolo2usersmanual.pdf
For further support on this issue please contact Visual Engineering on:
Tel: +44 (0) 1206 211842
Email: [email protected]
StreetView June 2016
Visual Engineering
Video solutions. Integrated
visualengineering.co.uk Page 13
Telemetry Control
• Connect the relevant cable to either the
PTZ camera or video receiver and the
9 pin D-Type connector to a PC via a
RS232 to USB adaptor cable.
• Start a serial comms terminal program
on the PC, such as TeraTerm.
• Set the COM port settings to 9600 baud,
8 data bits, 1 stop bit, no parity.
• Connect TeraTerm to the USB adaptor,
in the example shown here the port
number allocated to the adaptor is
COM1
• Now power the unit on, the following two characters will be displayed: >!
• Within 2 seconds type the two letters “ve”
• The boot menu will be displayed as shown in the above screen grab example.
There are 5 options to select from this Main Menu: 1 to 4 and x. With all sub-menus it is possible to
return to this top level Main Menu or exit the boot menu entirely. Exiting the boot menu will return
the unit to its normal operation.
Option 1 Comm Port Options
Select this to change the comms port parameters of the telemetry channel, possible options are:
1 Mode
2 Baud Rate
3 Protocol
4 Main Menu
5 Exit
Option 1.1 Mode
Select this to change the comms method and parity setting of the telemetry channel.
1 RS485, No Parity
2 RS232, No Parity
3 RS485, Odd Parity
4 RS232, Odd Parity
5 RS485, Even Parity
6 RS232, Even Parity
7 Main Menu
8 Exit
StreetView June 2016
Visual Engineering
Video solutions. Integrated
visualengineering.co.uk Page 14
Option 1.2 Baud Rate
Select this to change the baud rate of the telemetry channel.
1 1200
2 2400
3 4800
4 9600
5 19200
6 38400
7 57600
8 115200
9 Main Menu
10 Exit
Option 1.3 Protocol
Select this to change the protocol of the telemetry channel.
1 Visca
2 Pelco D
3 Pelco P
4 Main Menu
5 Exit
Option 2 Unit Mode
Select this to change type of unit.
1 Camera
2 Controller
3 Repeater
4 Main Menu
5 Exit
Option 3 Unit Address
Select this to change address of the unit.
1-7 Address 1 to 7
Option 4 Telemetry
Select this to change telemetry parameters.
1 Band
2 Synchroniser
3 Main Menu
4 Exit
Option 4.1 Band
Select this to change the geographical licence band of the telemetry channel.
1 EU
2 IND
3 FCC
4 AUS
5 NZ
Option 4.2 Synchroniser
Select this to enable the telemetry channel synchroniser.
1 YES
2 NO
StreetView June 2016
Visual Engineering
Video solutions. Integrated
visualengineering.co.uk Page 15
Camera Re-conguration
• Connect the relevant cable to the PTZ
camera and the 9 pin D-Type connector
to a PC via a RS232 to USB adaptor
cable.
• Start a serial comms terminal program
on the PC, such as TeraTerm.
• Set the COM port settings to 9600 baud,
8 data bits, 1 stop bit, no parity.
• Connect TeraTerm to the USB adaptor,
in the example shown here the port
number allocated to the adaptor is
COM1
Warning! - Normally, most of the these settings should never need to be altered by the user.
• Now power the camera on, the following two characters will be displayed: >!
• Within 2 seconds type the two letters “ve”
• The boot menu will be displayed as shown in the above screen grab example.
There are 6 options to select from this Main Menu: 1 to 4, t and x. With all sub-menus it is possible
to return to this top level Main Menu or exit the boot menu entirely. Exiting the boot menu will
return the camera to its normal operation.
Option 1 Comm Port Options
Select this to change the comms port parameters of the PTZ camera, the possible options are:
1 Mode
2 Baud Rate
3 Protocol
4 Unit Address
5 Main Menu
6 Exit
Option 1.1 Mode
Select this to change the comms method and parity setting of the PTZ camera.
1 RS485, No Parity
2 RS232, No Parity
3 RS485, Odd Parity
4 RS232, Odd Parity
5 RS485, Even Parity
6 RS232, Even Parity
7 Main Menu
8 Exit
StreetView June 2016
Visual Engineering
Video solutions. Integrated
visualengineering.co.uk Page 16
Option 1.2 Baud Rate
Select this to change the baud rate of the PTZ camera.
1 1200
2 2400
3 4800
4 9600
5 19200
6 38400
7 57600
8 115200
9 Main Menu
10 Exit
Option 1.3 Protocol
Select this to change the communications protocol of the PTZ camera.
1 Auto Detect
2 Visca
3 Pelco P
4 Pelco D
5 Forward Vision
6 Panasonic
7 Main Menu
8 Exit
Option 1.4 Unit Address
Select this to change address of the PTZ camera.
1-7 Address 1 to 7
Option 2 Motor Options
Select this to change the motor parameters of the PTZ camera.
1 Auto Position Correction
2 Stall Detection
3 Motor Speed
4 Hold Torque
5 Main Menu
6 Exit
Option 2.1 Auto Position Detection
Select this to enable/disable the auto position detection of the PTZ camera’s motors.
1 Disabled
2 Enabled
3 Main Menu
4 Exit
Option 2.2 Stall Detection
Select this to enable/disable the stall detection of the PTZ camera’s motors.
1 Disabled
2 Enabled
3 Main Menu
4 Exit
StreetView June 2016
Visual Engineering
Video solutions. Integrated
visualengineering.co.uk Page 17
Option 2.3 Motor Speed
Select this to alter the speed of the PTZ camera’s motors.
1 High
2 Medium
3 Low
4 Main Menu
5 Exit
Option 2.4 Hold Torque
Select this to alter the hold torque of the PTZ camera’s motors.
1 High
2 Medium
3 Low
4 Main Menu
5 Exit
Option 3 Video Options
Select this to change the video output mode of the PTZ camera.
1 PAL
2 NTSC
3 720p/25
4 720p/29.97
5 720p/50
6 720p/59.94
7 1080i/50
8 1080i/59.94
9 1080p/25
10 1080p/29.97
11 1080p/50
12 1080p/59.94
13 Main Menu
14 Exit
Option 4 Select Model
Select this to change the model of the PTZ camera.
1 MKVI
2 TEDAS
3 MKIV
4 10178
5 MKIVH
6 Main Menu
7 Exit
Option t Start Diagnostic Test
Select this to change to run an internal diagnostic test on the PTZ camera.
StreetView June 2016
Visual Engineering
Video solutions. Integrated
visualengineering.co.uk Page 18
Specications
Specications
Frequency L-Band: 1 to 1.5GHz
S-Band: 2 to 2.5GHz Camera Pan Continuous
Demodulation COFDM, QPSK or 16QAM Camera Tilt +10 to -90º
Sensitivity -115dBm to -120dBm Camera Zoom 36x
Channel Bandwidth 2.5, 6, 7, 8MHz Sensitivity 0.09Lux or 0.008 in slow
shutter mode
Telemetry Frequency 868MHz Camera Resolution >550TVL
User Channels 16 Camera Power 240v AC
Encryption AES128, AES256 Receiver Power 6 to 16v DC
Connections Supplied Cables Camera Environmental IP67
Baudrate Selectable Receiver Environmental IP66
Protocol Visca, PelcoD, PelcoP Camera Weight 4kg
Comms Mode RS232 Receiver Weight 2kg
Video Output BNC Camera Dimensions ø127 x 300mm
Control Connector 8 Pin Binder Receiver Dimensions 200 x 140 x 30mm
Telemetry Link Default Settings
Serial Comms RS232
Baudrate 9600
Databits 8
Parity none
Stopbits 1
Visual Engineering Technologies LTD
Kemps Farm
Stanway
Colchester
CO3 8NB
T +44 (0)1206 211842
Visual Engineering Technologies LLC
24928 Genesee Trail Road
Suite 100
Golden CO
80401 USA
T (303)-526-0935
StreetView June 2016
Visual Engineering
Video solutions. Integrated
visualengineering.co.uk Page 19
Connector Interfaces
110-8853
COFDM Video Receiver Cable
Pin-out
8 Pin Binder 9 Pin D-Types
1. +V
2. GND
3. Telemetry Data TX 2. Data RX
4. Telemetry Data RX 3. Data TX
5. GND 5. GND
6. Radio Module Cntrl TX 2. Cntrl RX
7. Radio Module Cntrl RX 3. Cntrl TX
8. GND 5. GND
110-8897
Camera COFDM Conguration Cable
Pin-out
8 Pin Binder 9 Pin D-Type
5. TX 2. RX
6. RX 3. TX
8. GND 5. GND
110-8898
Camera Telemetry Conguration Cable
Pin-out
8 Pin Binder 9 Pin D-Type
2. TX 2. RX
1. RX 3. TX
3. GND 5. GND
110-8899
Camera Control Cable
Pin-out
8 Pin Binder 9 Pin D-Type
1. TX 2. RX
2. RX 3. TX
3. GND 5. GND
Table of contents
Other visual engineering Security System manuals
Popular Security System manuals by other brands
Haws
Haws 9001 Alarm Series Installation operation & maintenance
Digital deep sea
Digital deep sea SmartSART S1000 user manual
INIM Electronics
INIM Electronics Praesidia Configuration manual
Mobi Technologies
Mobi Technologies MobiCam Digital DXR manual
GME
GME MT40 Series Installation
Fortress Technologies
Fortress Technologies Safeguard KR-D2 manual
DSC
DSC Power832 PC5921 Mounting instructions
BT Redcare
BT Redcare Advanced installation guide
S.C.A.T. Europe
S.C.A.T. Europe KCD2-SR-EX1.LB operating manual
FM Systems
FM Systems VSA-10 Instruction book
jablotron
jablotron JA-162A-US quick start guide
Barnett Engineering
Barnett Engineering B1277-HSPA Installation & operation manual
Hexagon
Hexagon HxGN MineProtect OAS-LV 202 User's reference manual
ESP
ESP DIGI-VIEW 4 System Installation and user guide
M-system
M-system M8SED instruction manual
jablotron
jablotron JK-84 Oasis installation manual
PORTMAN
PORTMAN TLU100N Operation and installation manual
STI
STI Alert Point Installation guide & user manual
