ViTiny UM08A-CSZ064 User manual

Version 1.1A
UM08A-CSZ064
User’s Guide

1
Contents
1. Product Introduction ...........................2
1.1 Packing Contents .........................2
1.2 CSZ064 Lens Assembling .............2
1.3 IR Remote controller....................5
1.4 Microscope menu functions........8
1.5 Microscope introduction: ..........22
1.6 Microscope Focus ......................26
1.7 Microscope accessory................28
2. Printed Notice....................................29
2.1 Maintenance..............................29
2.2 Product Specification.................30

2
1. Product Introduction
1.1 Packing Contents
The box contains 1 camera and 9 accessories.
Item
Q’ty
Item
Q’ty
Microscope Camera
1
White Balance Card
1
HDMI Cable
1
IR Remote Control
1
Power adaptor
1
User’s Guide
1
S114 Stand
1
1x CSZ064 Lens
1
Stand assemble guide
1
LED Ring Light GN03
1
1.2 CSZ064 Lens Assembling
1.2.1 Fix microscope
Each CSZ064 lens has reach its parfocal distance when goods ship
out; simply screw ○athe CSZ064 lens under the microscope camera
and tighten up with stand○
b,refer to 1.5.3 section for assembling.

3
1.2.2 Start to use microscope
Connect the HDMI cable ○
cand adaptor ○ dwithin the box
to HDMI monitor and power. See below:
○
a
○
b

4
1.2.3 Power On/Off
Press Power to turn on microscope. Choose HDMI mode or
Auto on HDMI monitor to output image.
○
c
○
d

5
1.3 IR Remote controller
The microscope operation and
functions is controlled by the IR
remote controller.
(1) Power ：Turn on/off.
(2) HDMI ：No Function.
(3) PC CAM ：No Function.
(4) Snapshot ：No Function.
Only when connect to optional
accessory Image Capture Box
IMB05 for snapshot.
(5) LED Adjustment: No Function
(6) Motor Reset (Recalibrates
entire operation)：Returns to
the lens position. If a loss of
electricity occurred during operation, please reset the
operation.
(7) Manual focus: Press Zoom out till the end to set up the
sensor motor at the top, so that all optical objectives lens
reach the parfocal distance.

6
(7-1)Zoom in ：Zooms in; speed increases when held.
(7-2)Zoom out ：Zooms out; speed increases when held.
(8) Autofocus: Does not suggest to use this function in CSZ064
model. Whenever active the AF function, sensor position will
change. This might cause the sensor position not at the end so
image will not clear in every stage when manual adjust. If this
situation occurs, please refer to Section 1.6 Microscope Focus.
Press button one time to search focus in current area, press and
hold button for 2 seconds to search focus in whole area.
(8-1) Single Autofocus : Focuses one time.
(8-2) Continuous Autofocus :Re-focuses when image blurred.
(9) Exposure Value: 18 levels of exposure value are selectable,
from -9~Auto~+9.
(9-1)Increase ：Use to increase exposure when the image is
too dark.
(9-2)Decrease ：Use to decrease exposure when the image is
too bright.
(10)Menu on Screen ：Open/close menu for setting. Refer to
Section 1.4.
(11)Up ：Choose the previous item

7
(12)Down ：Choose the next item
(13)Left ：Choose the next value
(14)Right ：Choose the last value
(15)Video Ratio ：No Function
(16)Status Bar ：Status bar show [FL] for free lens. By switching
the Status bar, it will show OZ (sensor position), and EV
(Exposure). Each status only shows up 3 seconds.
(17)Auto White Balance Calibration : To calibrate the white
balance, place the white balance card (included in box) under
the lens, focus until clear, and choose On. White balance is
sometimes influenced by external light sources, it is
recommended to calibrate the white balance if the color
seems off or incorrect.

8
(18)Image Freeze : ON/Off to freeze or unfreeze the image.
(19)Sharpness : On/Off to set sharpness at Minimum and
Maximum level.
1.4 Microscope menu functions
There are 8 functions in menu, press Up and Down to
choose item, Left and Right to turn on/off or adjust
parameter. Enter means more functions, press Menu to
enter next function or confirm. means no more settings.
Return to return last page, or press Left or Right to choose
“End” to return preview window.

9
1.4.1 EXPOSURE
To set exposure time, see below:
(1) Shutter: Digitally control amount of light, the amount is
smaller the image is darker and the frame rate is also
slower.
(2) AGC (Auto Gain Control): auto control the brightness based
on setting when light is not enough.
(3) SENS-UP：Only available when item (2) AGC value is larger
than 0, use to increase Senor to light’s sensibility.
(4) Brightness Adjust image brightness.
(5) D-WDR: Digital-wide dynamic range. Digitally adjusting
exposure in areas of the frame to maintain optimum detail
in both the shadows and highlights of the image.

10
(6) DEFOG：De-Fog. When observing under strong light or
special environment, use Defog function to see clear image.
Below fig for De-Fog setting.
(6-1) POS/SIZE：Adjust de-fog position and area.
(6-2) GRADATION：To set gradation levels near the edge of
defog area.
(6-3) DEFAULT：Return to default setting.
(6-4) RETURN: Return to last page.
1.4.2 BACKLIGHT
Press left/right button to choose turn on/off Backlight mode.
(1) OFF：Disable backlight function.
(2) WDR：Wide Dynamic Range. WDR allows an imaging system
to correct for the intense back light surrounding a subject
and thus enhances the ability to distinguish features and
shapes on the subject. See below for setting WDR.

11
(2-1) GAIN: Set WDR gain level to raise up brightness of
darker image.
(2-2) WDR OFFSET：Wide Dynamic Range OFFSET.
(2-3) RETURN: Return to last page.
(3) BLC (Back Light Compensation)
To adjust brightness for darker image in back light
environment.
(3-1) GAIN: To adjust brightness level.
(3-2) AREA: Choose the back light compensation area and
size.
(3-3) DEFAULT: Return to default setting.
(3-4) Return: Return to last page, or press left or right to
choose “End” to return preview window.

12
(4) HSBLC (High Suppress Back Light Compensation)
To identify the over luminance area by backlight, and proceed
masking the area.
(4-1) SELECT: Select the areas which needs to be adjusted.
4 areas are selectable.
(4-2) DISPLAY: Display the selected area.
(4-3) LEVEL: Set value to judge if the image is too bright.
(4-4) MODE: Super back light compensation mode.
(4-5) ALL DAY: Day mode.
(4-6) NIGHT: Night mode.
(4-7) BLACK MASK: Reverse the over exposed area

13
(4-8) DEFAULT: Return to factory default setting.
(4-9) RETURN: Return to last page.
1.4.3 MANUAL WB
Calibrate the white balance.
(1) AWB: Auto white balance.
(2) ATW: Auto tracing white area and calibration.
(3) AWC->SET: Semi-auto white balance. Use to track the white
color from current image.
(4) MANUAL: Manually adjust blue and red values to find
correct white color. Refer to below fig.
1.4.4 NR
Noise Reduction：(NR) To obtain high quality output image and
increase file compression. See below:

14
(1) 2D NR：ON/OFF, Edge Preserving 2D NR.
(2) 3D NR：ON/OFF, Motion Adaptive 3D NR. See below:
(3-1)SMART NR: Distinguish the moving object not moving noise,
and auto close the “3D NR”.
(3-1-1) SMART NR：The sensitivity to detect the moving
object. The lower value gets higher sensitivity.
(3-1-2) RETURN: Return to last page.
(3-2) LEVEL：The threshold to judge noise.
(3-3) START AGC：Start auto gain control. When AGC value
is higher than setting, will start auto gain.
(3-4) END AGC：End auto gain control. When AGC value is
higher than setting, will end up auto gain.

15
(3-5) Return: Return to last page.
(3) Return: Return to last page.
1.4.5 SPECIAL
Set special functions:
(1) D-EFFECT: There are few more functions in D-EFFECT, but
(1-3), (1-4) and (1-6) function can only turn on one item at
one time. Press Left or right to turn on or off.
See below functions:

16
(1-1) FREEZE: Turn ON/OFF to freeze image. If Freeze
function is turn on, the (1-2) Mirror function can not be
used at the same time
(1-2) MIRROR: Image rotatory. (Horizontal or Vertical)
(1-3) D-ZOOM: Digitally enlarge the chose area. Digital
zoom selection can from 1-62 times. See below
setting for D-Zoom.
(1-3-1) PIP: Turn on Picture in Picture function. When
enable PIP function, the right bottom corner will
show the original image. The rest of image is
D-zoom enlarge image.

17
(1-3-2) D-Zoom: Set digital zoom times.
(1-3-3) PAN&TILT: To set the enlarge position.
(1-3-4) DEFAULT: Return to default setting.
(1-3-5) RETURN: Return to last page.
(1-4) SMART D-ZOOM: Assign 1 or 2 areas to enlarge the
image from 1-62 times whenever detected the object
moves. The Smart D-zoom will automatically enlarge
the assigned area for few seconds and then return to
original image.

18
(1-4-1) SELECT: Choose the enlarge area, totally 2 areas.
(1-4-2) DISPLAY: Display enlargement frame. Position
and area can be set in (1-4-1)
(1-4-3) SENSITIVITY: The sensitivity to detect whenever
object moves. The lower value gets the higher
sensitivity.
(1-4-4) PIP: No Function.
(1-4-5) D-Zoom: Set magnification times.
(1-4-6) TIME: Set the enlargement waiting time.
(1-4-7) DEFAULT: Return to default setting.
(1-4-8) Return: Return to last page.
(1-5) NEG. IMAGE: Turn On/Off Negative image.
