ViTiny UM22 User manual

Version 1.0A
UM22 User’s Guide
USB Microscope

1
Contents
1. Product Introduction .......................... 2
1.1 Packing Contents: ....................... 2
1.2 Start to use ................................. 2
1.3 Buttons on microscope ............... 4
1.4 Microscope focus ........................ 5
2. Printed Notice .................................... 8
2.1 Maintenance .............................. 8
2.2 Product Specification .................. 9
2.3 Safety Instructions .................... 10

2
1. Product Introduction
1.1 Packing Contents:
The box contains 1 microscope and 6 accessories.
Item Q’ty Item Q’ty
USB Microscope 1 User’s Guide 1
USB 2.0 Cable 1 Calibrator 1
Stand S107 1 White Balance card 1
Stand assemble guide 1
1.2 Start to use
(1) Assemble microscope with Stand
Tighten microscope onto stand ○
a. (See stand assemble guide)
○
a

3
(2) Connect microscope to PC via complimentary USB cable ○
b.
(3) Software Installation
Please download UmViewer and install driver ○
c and
Application Program from http://ww.vitiny.com .
(4) PC Connection
Double click microscope software icon (○
d) on desktop. Click
the connect icon(○
e) to preview image. Adjust stand height
or focus button If the image is out of focus or blurry. For
detailed operation, please refer to the software Manual.
○
b

4
1.3 Microscope Introduction
(1) Optical zoom
Zoom in/out button. Zoom in(○
f), when magnification is
higher, the distance is closer. Zoom out (○
g), when
magnification is smaller, the distance is longer. (○
h)
microscope lens.
○
c ○ d ○ e
○
i
○
f
○
k
○
m
○
l
○
n
○
O
○
j
○
g
○
h

5
(2) LED Adjustment:
Preview image in higher magnification requires higher
luminance, on the contrary, lower magnification requires less
luminance. It’s suggested to set the “Auto Exposure” as
“Manual” in the software.
(○
i) Increase luminance. (○ j) Decrease luminance. (○ k) LED
Light. (○
k) LEDs for Lower working distance. (LED x 4), (○ l)
LEDs for middle height working distance. (LED x 2), (○
m) LEDs
for higher working distance (LED x 2). LEDs options will
change automatically.
(3) USB port
USB port (○
n) supply power to microscope and PC connection
to preview image.
(4) Stand hole (○
O) to fix microscope.
1.4 Microscope focus
There are two ways to focus. First, choose focus distance to adjust
the microscope height, then zoom in/out on the software or
microscope until clear. Second, first to choose the image sensor
position then adjusts the microscope height. Distance: distance
from lens to object. Sensor position: Image sensor position.

6
(1) Fix focus distance
Use knob ( ○
P ) to adjust the distance from lens to object.
When the distance is closer, the magnification is higher. Either
use Distance control mode in the software or buttons on the
microscope to focus.
(2) Fix sensor position
Choose the desired distance or FOV from the drop down list in
the software.
When the sensor position is fixed, adjust the stand knob (○
P)
to focus.
○
P

7
(3) Magnification chart
26 focus section setting is based on the whole focus area, the
sensor position tells the magnification size, field of view, or
distance. The below chart is measured on 32” screen, it’s only
a reference data, might not be accurate enough. Based on the
full screen preview, field of view and magnification size will
change. Focus distance from 13.7mm~232mm(0.5~9.1 inch).
32” monitor Full Screen (Reference data)
Focus section
1 2 3 4 5 6 7 8 9
Distance(mm)
232 171 120 92.1 64.5 50.2 42.1 36.2 31
FOV(mm) 80 60 40 30 20 15 12 10 8
Magnification (X)
9 12 17 23 35 47 58 70 87
Focus section 10 11 12 13 14 15 16 17 18
Distance(mm) 28.3 25.4 22.6 21.2 19.8 18.8 17.7 17.1 16.5
FOV(mm) 7 6 5 4.5 4 3.6 3.2 3 2.8
Magnification (X)
99 116 139 155 174 194 218 232 249
Focus section 19 20 21 22 23 24 25 26
Distance(mm) 16.1 15.5 15.2 14.9 14.6 14.3 14 13.7
FOV(mm) 2.6 2.4 2.3 2.2 2.1 2 1.9 1.8
Magnification (X)
268 290 303 317 332 349 367 390

8
2. Printed Notice
Please read the following information before operating.
2.1 Maintenance
Please abide by the following rules while storing or using this
product:
2.1.1 Keep dry: do not place the product in a humid environment.
Dry surroundings help extend the life of the product.
2.1.2 Avoid temperature shock: temperature shock (for example,
taking the product into a warm room from a cold
environment) will cause internal condensation inside the
machine. Please put the device inside the protection bag or
handbag to prevent temperature shock, and avoid using the
device in an environment with extreme temperatures.
2.1.3 Avoid dropping: the device may malfunction if it encounters
strong collision, vibration, or distortion.
2.1.4 Turn the microscope off before cutting off the power supply :
do not forced cut off the power supply.
2.1.5 Do not face the lens against strong light or sunshine for
extended periods of time: Strong light rays may degrade
sensitive elements and generate white stains on images.
2.1.6 Handle the device carefully: do not disassemble USB
cable and Lens forcefully and avoid contact with the lens
since they are subjected to damage.

9
2.1.7 Make sure to switch the power supply off and unplug the
power cable if the device is not in operation for an extended
period of time. Store the device in a dry environment with
excellent ventilation. Do not expose the machine in an
environment lower than -5ºC or higher than 50ºC.
2.1.8 While carrying, put the device inside the box to prevent it
from being damaged.
2.2 Product Specification
CMOS Sensor UHD High quality CMOS
L e n s High Sensitive Lens
Magnification 9x-390x on 32” monitor
Light Source White LED × 8pcs
USB Port USB 2.0, 3.0 Compatible, PC connection
F o c u s w a y Microscope buttons/ Pc focus control
P o w e r
Consumption
1.125A(Max)
S i z e 48(L)×64(W)×150(T) mm
W i g h t Host weight around 363 grams
Operation
environment
Temperature -5℃ ~ 50℃; Humidity-lower
than 85% (No Condensation)
For any changes, please visit http://www.vitiny.com

10
2.3 Safety Instructions
 As an electronic product, please do not use the device in any
place in which electronic products are prohibited.
 Keep the device away from water sources to avoid electric shock
as it is not waterproof.
 Keep the device away from chemicals or substances with
explosive or fire hazards. Switch the device off near gas stations.
 In the case that there are foreign substances or water inside the
device, or the device is dropped or damaged, please switch off
and remove the power supply to avoid fire and electric shock.
 Do not look steadily into Light sources after switching on the
host as it is harmful to your eyes.
 Please use only the product accessories provided in the box for
connections. Do not use any outside products without approval
of original factory.
 Please remove the power supply from the microscope when not
in use.
 Do not disassemble the machine for inspection. For any
problems occurring in the machine itself, please power off the
device and contact us through e-mail: [e-mail]

ViTiny Warranty Sheet
P r o d u c t
Model no
S/L nos.
P u r c ha s e
d a t e
DD/MM/YYYY
Purchaser
T e l n o :
A d d r e s s
Email
Distributor Seal for Confirmation
( Stamp is necessary for validation of the Warranty )
※Distributor’s seal shall include name of the shop, telephone and address※

Please ask the distributor to fill in the name of the shop, address, purchase date, and
other contents to protect your rights and validate your one-year warranty since upon
the purchase date.
Contents of Warranty: The warranty is provided free of charge for faults caused by
manufacturing within one year from the purchase date.
Non-warranty:
1. Product appearance parts, such as the outer casing, and LED cover, etc (charged
spare parts are limited to one year after completing the product manufacturing).
2. Consumption goods of the host itself, such as LED lights, lens and Sensor.
3. Product accessories and fittings, such as the power supplier, USB cable, calibrator,
Stand…etc.
Services caused by any of the following situations in the period of the warranty shall not
be provided free of charge:
1. Improper use or disassembly, repair or refitting.
2. Any damages to the device caused by external or environmental factors.
3. Discrepancy of product serial number, unfilled or unidentified warranty. Any
inspection or repair service after the period of warranty will be charged as follows:
(1) Service fees (including transportation fees) of product inspection.
(2) Repair fees.
(3) Fees of replaced parts
ViTiny Service Center Tel: [phone] Fax: [phone]
Address: 10 F., No.1, Section 1, Syuecheng Road, Dashu District, Kaohsiung City 840,
Taiwan (R.O.C.)
Website: http://www.vitiny.com
