VC-1200
User
manual
Vacuum
cleaner
ENG
05/BB 4
05/CA 4

VC-1200
FEATURES
Warning: This appliance is for household use only. It is only used to remove
dust indoors but not applied for industrial or coating areas.
• Streamline mold -making and luxury design, representing modern fashionable
life frilly;
• Multi -filter avoids the second air pollution
Using the multi-filter system ensures all the dust stays in the body, and the air
is dean from the outlet;
• Small in dimension, but the dust bag capoity is large, it is a economical
appliance indeed;
• One appliance fitted with various suction nozzles for m ulti -purposes Various
suction nozzles are used to suck up dust on carpet or hard floor but also to
remove dust on wall, ceiling, couch, bed and all home elect lie appliance.
• Reasonable design for the dust bag holder, dust bag can
drop down automatic, when you press the clamp button, it is convenient and
healthy.
• 360' swivel at suction tube head for easy cleaning
• With bumping protection device, avoiding scratch on the
body in use
• High suction power and stepless speed regulation
Using electronic speed regulation system, you can adjust the suction power
as much as you need between 1200W to 1400W If without speed control, the
suction power is steady.
• Dust bag lull indicator function.
When the dust bag or the air liter is lull of dust, the dust lull indicator on top of
the body will be covered by red indications. This shows that you need to
empty the dust bag or dean the air filter.
DESCRIPTIONS OF PARTS
Assemble the parts for your appliance by referring to the figure as
shown below

VC-1200
PRECAUTIONS
• Keep the appliance away from stove or any other high
temperature objects so as not to influence its
operation by deforming its plastic parts(flg.1).
• Do not bend, pedal ,pull or carry by the flexible hose.
Stop using the broken or damaged hose (fig.2).
When you need to dean or repair your appliance or stop
operation, unplug from the power outlet. To unplug, be sure
to hold the plug, do not pull or carry by the power cord
(fig.3).
• To use the appliance, take care to place dust bag in good
place. Do not use it without dust bag in its position (fig.4).
• When sucking, do not suck up such particles as mud, paste
and wall ashes, otherwise it may result in obstruction to the
dust bag or air filter or damage to the motor. If sucking up
these particles, please immediately clean the dust bag and air
flow filter(fig.5).
• When in use, do not suck up suck hair rolls, large paper rolls
or other objects which may easily lead to block the suction
hole or suction tube or hose. Otherwise it may cause break-
down or deforming of body cover. If any block occur to the
sudion, immediately stop operation by unplugging from the
outlet for Cleaning(fig.6).
Airflow handle
Switch Hose
Connecting tube
Holder Dust full indicatoi
Floor brush
Combi nozzle

VC-1200
• When dealing the appliance, wet cloth soaked with water or
neutral detergent shall be used instead of gasoline or banana
water. Otherwise it may lead to breakage of fadeness of the
body cover(fig7).
• When in use, do not block or shelter the rear outlet cover to
avoid influencing normal air exhaustion. Otherwise, the motor
will be damage by overheat.
How to assemble
• Press the button on top of the plastic suction tube head
and then push it in the direction of air inlet hole till locked(fig.8).
• When discharge the hose, press the button on top of the
plastic suction tube head and then pull it (rack cut towards
you(flg.9).
• How/to use connecting tubes and curved wand?
When connecting, insert the logger end of the connecting tube
into air flow hande and then swivel it to firm connection (fig.10).
• Connection of connecting tube. Refer to the above said(fig.10).
• Connection of connecting tube with floor brush. For connection,
insert the smaller end of connecting tube into the tube on the
floor brush, and then swivel it to firm connection (fig.11).
• Regarding the connection of connecting tubes with crevice
nozzle, refer to the above said.(fig.10).
TO START OPERATION
• Pull out the power cord
The power cord can be pulled out as long as it is marked with
yellow color. lt is forbidden to exceed the red mart; (tig.12).
• Power cord rewinding
When not in use, unplug from the electrical power outlet and
then press the cord rewinding button to feed back the
power cord (fig.13).
• Power button
Alter plugging into electrical power outlet, press the power
button on the body cover to control start and stop(fig.14).
• Speed regulation
When the power button is on, move the speed button on the
middle of rear cover so that the suction power can be
controlled by stepless speed regulation(flg.15).

VC-1200
If without speed control, the suction power is steady.
• Regulation of suction power
You can control suction power not only by speed regulation knob
but also by air regulator on handle(flg.16).
• For storage
Insert the plastic holder attached en the connecting tube into the
holder hook hole on the front underside of body(fig.17).
• For clearing
Pull the connecting tube out of the holder concave(fig.17).
HOW TO USE
• For corner or crevice place, you can use combi nozzle(fig.18).
When the dearer indicator on top of the body is filled with red
• indications, it means the dust bag is full of dust. You need to
clean cloth dust bag or replace paper dust bag, and clean the
air liter immediately when clogged (fig.19).
The dust bags are sold at sale agents.
REPLACING THE DUSTBAG
1) Lilt up by the font cover damp to open the font cover(fig.20).
2)Remove dust bag holder with dust bag(ig.21).
3)If you use a paper dust bag, replace it with a new one. If a
cloth dust bag, take out the dip and open the dust bag to
empty dust, then insert it back to its position for further use
by sealing the bag well with the clip(tg.22)
4)Assembling the dust bag, you should press the clamp button
on the bag holder, and insert the dust bag into the two slots,
then release the button to dip the dust bag. (Fig 23).
5)If the dust bag is broken, replace it immediately.
Warning: The dust bag must be wel property attached

VC-1200
• Replacing the air inlet filter
Open the front cover and turn the dust lag holder over to take
out the filter tor dealing or replace a new one.(fig.24).
Replacing the air outlet filter
Press the clamp position of the air outlet cover to discharge the
air outlet cover for dean up or a new replacement.(fig.25).
Clearing the air inlet and outlet filter (fig.26).
1)Put the filter into running water for rinsing;
2)Remove some water by patting the filter with towel, then dry it
in cool place
3)Dry the liter in a ventilation place, take care not to bake it so as
to avoid being defamed by high temperature.
Warning: Neither wash the filter in a washing machine nor bake it
with a hair dryer.
TROUBLE SHOOTING GUIDE
Please check the following details before you have your appliance repaired in an
authorized servicing department:
Problem Possible reason Solution
Motor does
not work
1 .Check if he power plug is
firmly
inserted into the outlet.
2.Cheok if the power switch of
the
Insert the plug lack again
into the cutlet to secure it is
switched en and then turn
the power switch en.
Suction
power
becomes
weak
1. Check if the hose, floor brush
or connecting tube is clogged.
2. Check if the dust is full;
3. Check if the air filter is
clogged,
the connecting tube is correctly
attached.
Immediately remove the
intrusion and empty dust.
Clean the dust bag for
reassembly of connecting
tubes.
Power cord
will not fully
feed back
Check if the power cord is
twisted.
Pull out the power cord at
its certain length and rewind
it.
Power cord
cannot be
taken out
The power cord may be twisted. Rewind or pull the cord in
and out for several times by
pressing the power cad
rewind button.
Power cord
rewinds itself
The inertial rewinding by the
cord rewinder device may lead
to be out of control.
Pull the power cord out in
for 4-5 times. If still rewinds
itself, ask for an authorized
servicing department for
repair.

VC-1200
No speed
regulation
The speed regulation
device maybe out of control
Restart the appliance for
reuse at several times, if it is
exactly out of control ask for
an authorized servicing
department.
Front cover
can't be
dosed
Check if no dust lag is put
inside or the front cover
deformed without dust lag
in good position.
Put the dust hag in good
position and then take the
appliance to the authorized
servicing department.
Dust lull
indicator is
covered by red
indications
Check if the floor brush, the
hose or the long connecting
tube is blocked. See if the
dust bag is full and the air
filter is clogged.
Immediately remove
obstructions away. Clean or
replace the dust lag. Clean
the air inlet liter.
If the power cord has been broken, it must be repaired or replaced by servicing
department that appointed by manufacturer, please do not handle by yourself.
TECHNICALSPECIFICATIONS
Rating voltage 230V Rating power 1400W
Rating frequency 50HZPressure 20000Pa
SERVICE AFTER SALES
If you find the temperature of the motor too high a any unusual noise occurring when
in use, you should stop operation at once. Do be sure not to discharge it blindly before
asking for an authorized servicing department for check.

Upute za
uporabu
HR
VC-1200
BiH
CG
05/BB 4
05/CA 4
Usisivač

VC-1200
OSOBINE
UPOZORENJE: Ovaj uređaj je namijenjen za korištenje samo u kućanstvu.
Korisite ga iskljucivo za usisavanje prašine u zatvorenim prostorima i nije
namijenjen za čišćenje industrijskih prostora.
•Aerodinamično kućište i moderan dizajn, koji u potpunosti predstavljaju
moderan život.
•Sustav višestrukih filtera onemogućava ponovno onečišćenje.
Korištenje sustava višestrukih filtera osigurava ostanak sve prašine unutar
uređaja, dok iz otvora za izlaz zraka izlazi čist zrak.
•Malene dimenzije i velik kapacitet vrećice za prašinu čine ovaj uređaj uistinu
ekonomičnim.
•Uređaj je opremljen mnogim nastavcima za više namjena.
Različiti nastavci omogućavaju usisavanje prašine s tepiha ili podova, ali i
uklanjanje prašine sa zidova, stropova, naslonjača, kreveta i svih električnih
uređaja u kućanstvu.
•Razuman dizajn držača vrećice za prašinu. Vrećica se automatski izbacuje
pritiskom na tipku, što je praktično i zdravo.
•Cijev za usisavanje se može rotirati za 360° za jednostavnije čišćenje.
•Zaštita od udaraca štiti uređaj od ogrebotina za vrijeme korištenja.
•Jaka snaga usisavanja i kontinuirana regulacija jačine usisavanja.
Korištenjem elektroničkog sistema regulacije jačine usisavanja možete
podesiti snagu usisavanja na vrijednost koja Vam odgovara, između 400W i
1200W. Ukoliko kontrola snage usisavanja ne postoji, snaga usisavanja je
stalna.
•Indikator napunjenosti vrećice za prašinu
Kada se napuni vrećica za prašinu ili kada je filter za zrak pun prašine,
indikator napunjenosti vrećice za prašinu na vrhu uređaja će biti ispunjen
crvenom bojom. Ovo znači da morate isprazniti vrećicu za prašinu ili očistiti
filter za zrak.
OPIS DIJELOVA
Sastavite dijelove Vašeg uređaja na način prikazan na slijedećoj slici
