Vivo DESK-WS01W User manual

Height Adjustable Stand
Scan the QR code with your mobile device or follow the link
for helpful videos and specications related to this product.
Instruction Manual
https://vivo-us.com/products/desk-ws01w
[email protected]om www.vivo-us.com 1-800-371-5654
SKU: DESK-WS01W

2 3
STEP 1
Slide footrest (C) onto pole (B).
If you do not understand these directions, or if you have any doubts about the safety of the
installation, please call a qualied technician. Check carefully to make sure there are no missing or
defective parts. Improper installation may cause damage or serious injury. Do not use this product
for any purpose that is not explicitly specied in this manual and do not exceed weight capacity.
We cannot be liable for damage or injury caused by improper mounting, incorrect assembly, or
inappropriate use.
PACKAGE CONTENTS
ASSEMBLY STEPS
WARNING!
A (x1)
Base
TOOLS NEEDED
DO NOT EXCEED WEIGHT CAPACITY.
Failure to do so may result in serious injury.
Phillips
Screwdriver
17.6 lbs
7.98kg
B (x1)
Pole
D (x1)
Pole Mount
E (x1)
Desktop
F (x1)
Bracket
C (x1)
Footrest
G (x6)
M6x12
STEP 2
H (x4)
M6x18
I (x4)
M6x35
J (x4)
Washer
K (x1)
5mm Allen
Wrench
L (x1)
Wrench
Secure pole mount (D) to pole using M6x18
bolts (H) with lock washers (J) and tighten with
the Allen wrench (K).
STEP 3
Mount pole to base (A) with bracket (F) and
M6x35 bolts (I), then tighten with the Allen
wrench (K).
Attach desktop (E) to pole using M6x12 bolts
(G) and tighten with the Allen wrench (K).
STEP 4
STEP 5
If desk is not sitting at on the oor, adjust
feet using the wrench (L). Adjust footrest
height using the installed lever. Adjust
desktop height by loosening the knob on
the pole, then tighten at the desired height.
Raise desktop
slowly to keep
items stable.
Keep monitor and
laptop base fully on
the desktop.
Leave enough slack
in cable to allow for
full range of vertical
motion (15” / 38 cm).
Follow the cable
routing instructions to
avoid the potential to
pinch cables.
CAUTION!
Failure to follow these instructions may result in property damage and/or personal injury.
3
L
1
5mm
2
E
G
C
B
D
K
J
H
IMPORTANT!
Go back and continue to re-
tighten each of the M6x18 bolts
(H) until all bolts are securely
fastened.
IMPORTANT!
Go back and continue to retighten each of
the M6x35 bolts (I) until all bolts are securely
fastened.
A
F
I

Last Updated: 10/24/2018
