FD8135H Network Fixed Dome HD Camera
Value Series, H.264, 720P HD, P-iris, WDR Pro, PIR
Architectural and Engineering Specification
2.01 Manufacturer
A. VIVOTEK Inc.
6F, No.192, Lien-Cheng Rd.
Chung-Ho, New Taipei City, Taiwan 23553
Phone [phone]
Fax [phone]
Email [email protected]
B. Manufacturer shall warrant the camera to be free from defects in
material and workmanship for two years from the purchase date.
2.02 General Network Camera Descriptions
A. The product represents the next-generation in video quality in network
cameras. With its 1 Megapixel resolution and built-in removable IR-Cut
Filter, users will be able to experience the utmost in picture clarity.
It is also possible to transmit dual video streams in H.264/MPEG-4
and/or MJPEG formats for versatile applications.
B. Advance Audio Codec (AAC) in the camera helps to provide CD quality
for you aural applications with lowest bit-rate possible. Built-in
GSM-ARM codec provides best compatibility for aural-visual
application in cell phones, and thus best 3GPP compliance. G.711 codec
supported is almost compatible with any software you found.
C. The camera has a built-in web server for users to configure the camera
to meet different purposes. It is IEEE 802.3af compliant
Power-over-Ethernet (Class 3) ready, and with such feature the
installation can be very convenient.
D. The camera has removable ICR-cut filter and IR illuminator which
supports up to 20M far.
2.03 General Camera Requirements
A. The camera shall incorporate a progressive scan CMOS imager with a
1/3”-inch optical format, not less than 1280(H) x 800(V) pixels and
shall have a removable infrared cut-off filter.
B. The image resolution shall be no less than 1280(H) x 800(V) pixels.
Users can specify many resolutions smaller than default for a specific
purpose.
C. The camera shall produce a frame rate of 30 frames per second (fps)
at resolution 1280(H) x 800(V) 16:10.
D. The minimum illumination required to produce an image shall be
approximately 0.8 lux @ F1.2, 50 IRE (Color), and 0.001 lux @ F1.2,
50 IRE (B/W).
E. The camera shall provide automatic white balance, automatic exposure,
automatic gain control, automatic electronic shutter, backlight

FD8135H – 2014/11
2
compensation, and motion detection. The camera shall also provide
manual white balance, manual exposure, manual gain control and manual
shutter speed.
F. The camera shall have at least 128MB of RAM and 16MB of flash memory
and will use MJPEG compression for standard web browsers. H.264 and
MPEG-4 video can be available by ActiveX, ActiveX in web pages,
Quick-time Player, Real Player and VLC Player. In cell phone, the
camera is accessible by web browsers, or any built-in player that
supports RTSP and MPEG-4 video.
G. The camera shall provide a RTSP/RTP/RTCP protocol video output via an
Ethernet connection.
H. The camera shall provide on-screen text displays.
I. Viewer, Operator, and Administrator password protection levels shall
be provided.
J. A mechanical reset button shall be provided to return the camera to
factory default settings.
K. The camera shall provide board lens, vari-focal, f=3~9mm, F1.2(Wide)
F2.1(Tele), P-iris.
L. The camera shall have WDR Pro for unparalleled visibility in high
contrast environment.
M. The camera shall have ‘Focus Assistant’ function to help users obtain
best image focus when manually adjusting lens.
N. The camera shall support privacy masks.
O. The camera shall provide motion detection (3 configurable windows) and
offer “profile” capability to configure the different motion detection
settings.
P. The camera shall provide camera tampering detection.
Q. The camera shall provide built-in microphone as well as the possibility
to connect an external microphone.
R. The camera shall offer two way audio capability.
S. The camera shall be able to capture and stream out the original full
view image.
2.04 Camera Networking Requirements
A. The camera shall incorporate a built-in web server.
B. Camera functionality shall be available to users running versions of
Internet Exploreror Mozillareleased after January 1, 2010.

FD8135H – 2014/11
3
C. The camera shall provide integrated support for IPv4, IPv6, TCP/IP,
HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS,
PPPoE, CoS, QoS, SNMP, 802.1X.
D. No unique or proprietary client software shall be required for viewing
or controlling the camera.
E. The camera shall be configurable and users may modify the camera’s web
pages according to a specific purpose.
F. The camera shall be ONVIF compliant.
G. The camera shall be able to transmit H.264/MPEG4 streaming over HTTP
to pass the firewall protection (RTSP over HTTP).
H. The camera shall be able to transmit H.264/MPEG4 streaming over UDP
for time-sensitive applications to achieve a better real-time
Streaming.
I. The camera shall be able to transmit H.264/MPEG4 streaming over TCP
for applications where the video quality is a top-priority, preventing
packet losses.
J. The camera shall support encrypted data transmission (HTTPS) to
increase the overall security.
K. The camera shall allow the live viewing for up to 10 clients
simultaneously.
L. The camera shall offer at least 2 simultaneous streams.
2.05 Camera Audio/Video Requirements
A. The camera shall provide 52 video quality levels in H.264 codec.
B. The camera shall provide 30 video quality levels in MPEG-4 codec
C. The camera shall provide 191 video quality levels in MJPEG codec
D. The camera shall provide 4~16000 Kbps H.264/MPEG-4 video bit rate.
E. The camera shall support H.264 Main Profile, H.264 Baseline Profile,
H.264 High Profile.
F. The camera shall provide 9 levels of exposure compensation.
G. The camera shall provide 6 levels of gain control.
H. The camera shall able to provide the audio codec G.711 which is most
widely supported.
I. The camera shall be able to provide the audio codec AMR to support the
3GPP.

FD8135H – 2014/11
4
J. The camera shall be able to provide the audio codec AAC to obtain high
quality audio.
K. The camera shall provide 6 audio quality levels for AAC.
L. The camera shall provide 8 speech quality levels for GSM-AMR.
M. The camera shall provide 2 audio quality levels for G.711.
N. The vertical TVL of camera should reach up to 1235.
O. The camera shall provide SNR up to 60.5 dB.
P. The camera shall provide dynamic range up to 110.4 dB.
Q. The camera shall provide the shutter time from 1/15 sec. to 1/25,000
sec. The maximum and minimum shutter time have to be user-configurable.
R. The camera shall provide the possibility to sync the frequency with
the power line frequency to eliminate a flickering image.
S. The camera shall be able to provide the possibility to flip and/or
mirror the video image for increase the flexibility of the installation.
T. The camera shall provide scheduled profile settings for the exposure
management to offer different exposure settings for day and night.
U. The camera shall offer WDR Pro for unparalleled visibility in high
contrast environment.
V. The camera shall provide ePTZ function with 16x digital zoom (4x on
IE plug-in, 4x built-in)
2.06 Connectors
A. RJ-45 Ethernet connector (IEEE 802.3af, Class 3 POE compliant)
B. Three digital inputs
C. One digital output
D. One external audio input
E. One external audio output
F. One DC 12V power input
G. One AC 24V power input
2.07 Electrical Specifications
A. Power requirement: IEEE 802.3af Power-over-Ethernet on CAT-5 cable.
B. AC 24V
C. Maximum power consumption 8.0W

FD8135H – 2014/11
5
2.08 Mechanical Specifications
A. Weight: 778g
B. Dimensions:
Camera: Ø 157 mm x 110 mm
2.09 Local Storage
The camera shall have built-in MicroSD/SDHC card slot for on-board storage.
2.10 Environmental Specifications
A. Operating temperature range: -20oC to +50oC (-4oF to +122oF)
2.11 Certifications and Approvals
A. Electromagnetic Compatibility
a. Emissions:
i. FCC Class B
ii. CE
iii. LVD
iv. VCCI
v. C-Tick
B. RoHS
a. All material and/or components used in the manufacture of the
product shall be in compliance with the EU Directive 2002/95/EC
Restriction of Hazardous Substance (RoHS).
