volkano Phonic VK-2002 User manual

Please read these instructions carefully and retain for future reference.
INSTRUCTION MANUAL
Phonic Series MODEL VK-2002

Specifications
Bluetooth wireless : V4.2
Operating distance : up to 10 meters
Frequency response : 50Hz – 20kHz
Impedance : 64 Ω
Power supply : DC 5V, 1A. Micro USB
Charge time : 2.5 hours
Battery capacity : 400mAh
Included in the Box
• USB to Micro USB charging cable
• 3.5 Instruction manual
Charging
Please ensure that the battery is fully charged before using the device
for the first time.
• Connect the provided USB charger cable to the charging slot on the headset.
Connect the other end of the USB charger to a 5V USB wall charger or
available USB port on your computer.
• The LED indicator light will display a red colour when charging.
• When the headphone is fully charged, the LED indicator light will flash twice
and turn off.

Identifying Parts
1. Power On/Off
2. Next/Volume up
3. Play/Pause/Call
4. Previous/Volume down
5. Mode button: FM Radio/MP3 (Micro SD card)/Bluetooth
6. Microphone
7. USB charging port
8. AUX input
9. Micro SD card slot
6
5
4
3
2
1
7
8
9

Powering Up
• To switch the headphones on, press and hold the “power” button for about
3 seconds until the blue LED light flashes
• To switch the headphones off, press and hold the “power” button for about
3 seconds until the blue LED lights go off.
Bluetooth Wireless Mode
• Switch on the headphones.
• Press the “mode” button to switch to Bluetooth Wireless mode.
• The red and blue LED lights will flash, this means that the headphone is
ready to pair with a Bluetooth device.
• Ensure that your device’s Bluetooth Wireless is on. Search for the device
“Phonic”. When your phone finds the device, confirm pairing by selecting
the device from the list.
• When successfully paired, the blue LED light will flash slowly.
• The headphones are now paired and ready to be used with your device.
Playing Music
• Music tracks can be selected either by the control buttons on the headphone
or via the connected device. Press “volume down/backward” or “volume up/
forward” button on the headphone, or on your mobile phone to select songs
you would like to play.
• Press “play/pause” on the speaker or mobile phone to play or stop the music.
• Volume can be controlled either by the control buttons on the headphone or
via the paired device. Press and hold “volume up/forward” or “volume
down/backward” to the headphone or mobile phone to adjust the volume level.

MP3 Mode
• Press and hold the “power” button for 3 seconds to turn on the device.
• Insert your Micro SD. The device will begin reading from the card.
Alternatively, press the “mode” button until the headphone switches to MP3 Mode.
• Control the playback using the controls on the headphones.
FM Mode
• Press and hold the “mode” button for 3 seconds to turn on the headphones.
• Press the “mode” button until you have cycled to the FM Mode.
• While in FM Mode, press the “play/pause” button to automatically scan
frequencies or radio stations. Press the “volume up/forward” button to skip
a station and continue searching, or “volume down/backward” to return to
a station.
• Control the volume of the station using the controls on the headphones by
pressing and holding the “volume up/forward” or “volume down/backward”
to adjust the volume level.
Aux-In Mode
• You do not have to switch the headphones “on” for this mode.
• Insert the provided audio cable into the “aux” input on the headphones,
and the other end of the audio cable to the playback device’s output/line out.
• In this mode, you can only control the playback volume with your playback
device and not with the volume controls on the headphones.
Hands Free Mode
• To answer call, press the answer key on your phone or press the answer/end
key on the headphone.
• To end the call, press the end key on your phone or press the answer/end key
on the headphone.
• To redial your last call, double click on the call answer/end button.
Music playback will automatically be paused.

Safety Precautions
• The product should only be used with the parts provided by the manufacturer.
• Never use your headphones near water or in areas where it can come into
contact with water. Never handle the headphones if they were dropped in water
or any other liquid. If the product comes into contact with water while switched
off, but still plugged in, this is a safety hazard.
• Always make sure your hands are dry before touching the plug or power
connections.
• Do not operate the product with a damaged cord or plug, or after it malfunctions,
has been dropped, or damaged in any manner.
• The headphones are intended for personal use only. Commercial use invalidates
the warranty and the supplier cannot be held responsible for injury or damage
caused when using the device for any other purpose than that which it was
intended for.
• These headphones are not intended for use by children, or persons with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
device by a person responsible for their safety. Extreme caution must be exercised.
• Children should be supervised to ensure that they do not play with the
headphones. Packaging must never be left within reach of children, since it
is potentially dangerous.
Environmentally Friendly Disposal
Do not dispose of electrical appliances as unsorted municipal
waste, use separate collection facilities.
Contact your local government for information regarding
the collection systems available. If electrical appliances are
disposed of in landfills or dumps, hazardous substances can
leak into the groundwater and get into the food chain, damaging
your health and well being.
