volkano Resonance Series User manual

INSTRUCTION MANUAL
Please read and retain these instructions for future reference.
VK-1104-BK
Resonance Series
BLUETOOTH
®EARPHONES
DUAL DRIVER MAGNETIC

• VolkanoX Resonance Series Dual Driver Bluetooth®Earphones
• Charging Cable (Micro-USB)
• 3 x Sets of Silicone Earbuds
• Hard Carry Case
• User Manual
Bluetooth®:
Version: 4.2
Chip Set: JR
Profiles: HSP, HFP, A2DP, AVRCP
Range: 10 m
IP Rating: IPX5
Driver Size: 2 x 6 mm
Impedance: 16 Ω
Frequency Range: 20 Hz – 20 kHz
Signal to Noise Ratio: 95 dB
Sensitivity: 93 dB
Battery: 55 mAh
Playtime: 2 – 4 Hours
Charging Time: 1 Hour
Charge Input: 5 V DC, 0.3 A
PACKAGE CONTENTS
SPECIFICATIONS
1

Connect the USB A end of the Charging Cable to a USB Charging
Port and insert the Micro USB end to the port on the Resonance
earphones. Make sure it is properly connected. The LED light will
be lit while the earphones are charging and will turn off when the
earphones are ready for use.
INSTRUCTIONS FOR USE:
1. Next Track / Volume Up
2. Multi-Function Button
3. LED Indicators
4. Microphone
5. Previous Track / Volume Down
6. Charging Port
IDENTIFYING PARTS
CHARGING
1
2
3
4
5
6
2

To turn the earphones on, hold the Multi-Function button for
approximately three seconds. The earphones will prompt Power on
and the LED will start flashing blue. To turn the earphones off, hold
the Multi-Function button for approximately three seconds.
Please note that your earphones must be paired to a Bluetooth®
device before they can be used. It is only necessary to pair your
earphones once with each device.
1. Open the Bluetooth® menu on the device you wish to pair (see
“Locating the Bluetooth® Menu” for more details). Some devices
require you to select “Search for Devices” or “Add New Device” in
order to create a Bluetooth®pairing.
2. With the earphones turned off, hold the Multi-Function button
for approximately 3 seconds. The earphones will prompt Power
on. Press and hold the Multi-Function button for two seconds.
The LEDs will start flashing blue and red while the earphones are
in pairing mode.
3. Wait until you see “Resonance” on your device screen.
4. Select “Resonance” on your device and follow any further
prompts to pair. Once pairing is complete and a connection is
established, the blue and red LED lights will flash at a slower rate
and finally switch off. The earphones will then prompt
“connected to end audio”.
1. Adjusting The Volume
TURNING ON AND OFF
PAIRING WITH BLUETOOTH®DEVICES
3

iPhone, iPad, and iPod Touch:
a) On your device, go to Settings.
b) Select Bluetooth®. If Bluetooth®is not on, turn it on.
c) The iPhone / iPad / iPod will automatically search for
new devices.
Android™ Phones and Tablets:
a) On your device, go to the Settings menu.
b) Select Bluetooth® (on older Android devices Bluetooth® is found
in the Wireless and Networks menu). If Bluetooth®is not on,
turn it on.
c) Select “Search for Devices” if your phone or tablet does not
automatically search for new devices.
Once the Resonance is turned on, they will automatically connect
with the last paired Bluetooth® device that is on and within range.
If the Resonance does not connect automatically, open the
Bluetooth® menu on your device and select “Resonance” from the
Bluetooth®device list.
LOCATING THE BLUETOOTH®MENU
CONNECTING WITH PAIRED DEVICES
4

1. Adjusting The Volume
Function Operation Notes
Increase
Volume
Short press the
Next Track / Volume
Up button
When the volume
reaches the minimum or
maximum level, the
VolkanoX Resonance
Series Dual Driver
Bluetooth®Earphones
will produce a
short tone.
Decrease
Volume
Short press the
Previous Track /
Volume Down
Note: Volume can be adjusted only while media is playing or during
a phone call.
2. Navigating / Skipping Tracks
Function Operation
Navigate to Next
Track
Press and hold the Next Track / Volume Up
button
Navigate to
Previous Track
Press and hold the Previous Track / Volume
Down button
CONTROLS
5

3. Call Controls
Status Function Operation
Incoming
Call
Answer Call Short press the
Multi-Function button
Reject Call Press and hold the Previous
Track / Volume Down button
Call in
Progress End Call Short press the
Multi-Function button
Note: If you answer or make a call while listening to media,
the media will be paused until the call has ended.
1. My mobile phone cannot find any new Bluetooth® devices?
a. Ensure the device has entered the pairing mode.
b. Ensure the device is within effective working range.
2. Bluetooth® device cannot pair up?
Ensure your mobile phone allows new connections and has not
reached the maximum number of allowed devices.
3. The device does not play music or answer calls when it is
connected to a Bluetooth® mobile phone.
a. Ensure your mobile phone supports A2DP and HSF
(Hands-Free) profiles.
b. Ensure your mobile phone is within effective working range.
TROUBLE SHOOTING
6

4. When paired with my computer, Windows®asks for a new
driver. Can you supply this?
We recommend you find compatible drivers for your
computer online.
5. Why can I not remotely control the Pause / Play /
Previous / Next functions when music is playing?
This feature needs the Bluetooth® device paired with the
earphones to support AVRCP (Audio / Video Remote Control
Profile). Please ensure your device supports this.
• The product should only be used with the parts provided by
the manufacturer.
• Never use your earphones near water or in areas where it can
come into contact with water. Never handle the earphones if they
were dropped in water or any other liquid. If the product comes
into contact with water while switched off, but still plugged in,
this is a safety hazard.
• Always make sure your hands are dry before touching the plug or
power connections.
• Do not operate the product with a damaged cord or plug, or after it
malfunctions, has been dropped, or damaged in any manner.
• The earphones are intended for personal use only. Commercial use
invalidates the warranty and the supplier cannot be held
responsible for injury or damage caused when using the device for
any other purpose than that which it was intended for.
SAFETY PRECAUTIONS
7

• These earphones are not intended for use by children, or persons
with reduced physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have been given
supervision or instruction concerning use of the device by a
person responsible for their safety. Extreme caution must
be exercised.
• Children should be supervised to ensure that they do not play
with the earphones. Packaging must never be left within reach of
children, since it is potentially dangerous.
8
ENVIRONMENTALLY FRIENDLY DISPOSAL
Do not dispose of electrical appliances as unsorted
municipal waste, use separate collection facilities.
Contact your local government for information
regarding the collection systems available.
If electrical appliances are disposed of in landfills
or dumps, hazardous substances can leak into the
groundwater and get into the food chain, damaging
your health and well being.
“The Bluetooth®word mark and logos are registered trademarks
owned by Bluetooth SIG, Inc. and any use of such marks by Volkano
is under license. Other trademarks and trade names are those of
their respective owners.”
All product and company names are trademarks™ or registered®
trademarks of their respective holders. Use of them does not imply
any affiliation with or endorsement by them.
DISCLAIMER

9
This VolkanoX Resonance Bluetooth®Earphones comes with
a standard 12 limited month warranty against manufacturing
defects and faults. Should your VolkanoX Resonance Bluetooth®
Earphones be unboxed with any faulty parts, poor finishing or
visible damage, or fail to perform due to a manufacturing defect or
poor workmanship, please return it with your proof of purchase (till
slip or invoice) to the store of purchase for an exchange, or repair,
depending on the store’s returns policy.
This warranty commences from the date of purchase.
Kindly retain your proof of purchase as well as the packaging for
your warranty period.
NOTE:
The warranty does not apply to product that:
a.) Has failed due to excessive wear and tear beyond what is
considered to be reasonable.
b.) Has been misused or neglected.
c.) Has been damaged accidentally or by acts of God including fire
and flooding.
d.) Has been used or operated contrary to operating or maintenance
instructions outlined in this manual.
WARRANTY
