volkano Capricorn VK-1134-WT User manual

VK-1134-WT
Please read these instructions carefully and retain for future reference.
INSTRUCTION MANUAL
TA-2020/6112
APPROVED

• Bluetooth®:
Version: 5.0
Profiles: HFP, HSP, A2DP, AVRCP
Operating Distance: Up to 10 m / 33 feet
• Charging Case:
Battery: 380 mAh
Number of Recharges: 3 x
Charging Time: 2 Hours
Charge Input: 5 V DC, 0.38 A
• Earphones:
Battery: 50 mAh per Earphone
Charging Time: 1.5 Hours
Playback Time: 4 ~ 8 Hours
Sensitivity: 90 dB
Driver Size: 6 mm
Impedance: 16 Ω
Frequency Response: 20 Hz ~ 20 kHz
• IP Rating: IPX7
• Volkano™ Capricorn Series True Wireless Earphones with Charging Cases
• Charging Case
• 3 x Spare Earbud Caps
• USB Charging Cable
• Instruction Manual
• True Wireless Bluetooth®Technology
• Case gives up to 24 Hours Playtime
• IPX7 Waterproof
• Hands-Free Calling
• Touch Control
PACKAGE CONTENTS
HIGHLIGHTS
SPECIFICATIONS
2

IDENTIFYING PARTS
3
1. Charging Case LED Indicator
2. Micro USB Charging Input
3. Earphone LED Indicator
4. Microphone
5. Multi-function Button
6. Silicone Earbud Cap
7. Left Earphone
8. Charging Thimble
9. Right Earphone
21
8
34
579
6

CHARGING THE CHARGING CASE
INSTRUCTIONS FOR USE
• Please ensure that the battery is fully charged before using the device for
the first time.
• Connect the supplied USB Charge Cable to the Micro USB charging slot on the
Charging Case, connect the other end of the USB cable to a USB wall charger or a
compatible USB power source.
• The LED Indicator Light on the Charging Case glows white while charging.
• When charging is complete, the LED Indicator Light will switch off.
4
CHARGING THE EARPHONES
• Please ensure that the battery is fully charged before using the device for
the first time.
• Place the earphones into the charging case, charging begins automatically.
• The LED Indicators on the earphones glow red to indicate charging in progress and
switch off when charging is complete.
Note:
• Charge time is approximately one to two hours. Earphones cannot be used
while charging.
• The earphones will turn off when inserted into the charging case, even if
they are powered ON before charging.
SWITCHING ON THE EARPHONES
• Switching the Earphones On: The earphones automatically switch on when removed
from the charging case. The LED Indicator on both Earphones glow green when
switched on.
• Switching the earphones Off: The earphones automatically switch off when placed
back into the charging case. The LED Indicator will switch off.

5
CONNECTING THE LEFT AND RIGHT EARPHONES
Auto-Connect Left and Right Earphones:
Remove both earphones from the Charging Case at the same time, the earphones will
automatically power on and connect.
The LED Indicator Lights on one earphone will blink green (connected) and the other
earphone will blink red and green intermittently (Bluetooth®Pairing Mode) and is ready
to pair with your Bluetooth®device.
Using a single Earphone:
The left and right earphones can be connected individually to a Bluetooth®device by
removing either the left or right earphone individually from the charging case.
The LED Indicator Lights on the earphone will blink red and green intermittently
(Bluetooth®Pairing Mode) and is ready to pair with your Bluetooth®device.
Reconnecting Left and Right Earphones:
To reconnect the left and right earphones after individual use, place both earphones
into the charging case then remove both earphones and wait for them to connect
automatically.
If the left and right earphones do not connect automatically, they can be reset to factory
settings.
Reset to Factory Settings:
• Tap the Multi-function Button on both earphones 5 times (under connecting status).
• Android Devices: Remove both earphones from the charging case and connect to
Bluetooth®.
• Apple Devices: Delete the Earphones from paired devices before removing the
earphones from the charging case and connecting to Bluetooth®.

Your earphones must be paired to a Bluetooth®device before it can be used.
It is only necessary to pair your earphones once with each device.
1. Ensure that your device’s Bluetooth®is on.
2. Search for the device “Capricorn”.
3. Confirm pairing by selecting the device from the list.
4. When successfully paired, the earphone will emit the voice prompt “connected”.
5. The device is now ready to make / receive calls and play audio.
6
PAIRING WITH BLUETOOTH®DEVICES
iPhone, iPad, and iPod Touch
a) On your device, go to Settings.
b) Select Bluetooth®. If Bluetooth®is not on, turn it on.
c) The iPhone / iPad / iPod will automatically search for new devices
Android™ Phones and Tablets
a) On your device, go to the Settings Menu.
b) Select Bluetooth®(on older Android devices Bluetooth®is found in the
Wireless & Networks Menu). If Bluetooth®is not on, turn it on.
c) Select “Search for Devices” if your phone or tablet does not automatically search for
new devices.
Note: If you are unsure of how to access your Bluetooth®Menu on your
device, please refer to your device’s instruction manual.
LOCATING THE BLUETOOTH®MENU

7
CONTROLS
1. Audio Controls
Function Operation
Play / Pause Track Double touch the Left or Right Multi-function Button.
Navigate to Next
Track Press and hold the Left Multi-function Button for 2 seconds.
Navigate to
Previous Track Press and hold the Right Multi-function Button
3. Siri / Google Assistant
Function Operation
Siri / Voice Assistant Triple touch the Left or Right Multi-function Button
2. Phone Calls
Function Operation
Answer Call Double touch the Left or Right Multi-function Button
Reject Call Press and hold the Left or Right Multi-function Button for 2 seconds
End Call Double touch the Left or Right Multi-function Button

8
TROUBLESHOOTING
1. My smartphone cannot find any new Bluetooth®devices.
a. Ensure the device has entered the pairing mode.
b. Ensure the device is within an effective working range.
2. The Bluetooth®device cannot pair up.
a. Ensure your smartphone allows new connections and has not reached the
maximum number of allowed devices.
3. The device does not play music or answer calls when it is connected to
a Bluetooth®smartphone.
a. Ensure your smartphone supports A2DP and HSF (Hands-Free) profiles.
b. Ensure your smartphone is within an effective working range.
4. When paired with my computer, Windows®asks for a new driver.
Can you supply this?
a. We recommend you find compatible drivers for your computer online.
5. Why can I not remotely control the Pause, Play, Previous and Next functions
when music is playing?
a. This feature needs the Bluetooth®device paired with the earphones to support
AVRCP (Audio / Video Remote Control Profile). Please ensure your device
supports this.

9
• This product is not intended for commercial use and has been tested for household
use only.
• This product is not intended for use by small children, or persons with diminished
mental capabilities. Ensure that the use of this product is monitored by a guardian
or parent.
• Never use your earphones near water or in areas where it can come into contact
with water. Never handle the earphones if they have been dropped into water or
any other liquid. If the product comes into contact with water while charging,
this is a safety hazard.
• Do not operate the product after it malfunctions, has been dropped or damaged in
any way.
• WARNING: Always keep optional accessories, small parts and packaging out of the
reach of babies and small children, as these items may be a choking hazard.
• DO NOT overcharge your Volkano™ Capricorn Series True Wireless Stereo
Earphones, doing so will shorten the lifespan of the built-in battery and could cause
your device to overheat.
• CAUTION: Do not disassemble the battery or dispose of it in a fire.
• CAUTION: Should your battery show signs of overheating, smoke or fumes being
emitted during charging, remove the charging cable immediately.
SAFETY PRECAUTIONS

10
•Before Cleaning: Ensure that your Volkano™ Capricorn Series True Wireless Stereo
Earphones are turned off before cleaning or maintaining your device.
•Cleaning: Wipe down the surface of your Volkano™ Capricorn Series True Wireless
Stereo Earphones using a soft, slightly damp cloth.
• Do not use any harsh or abrasive cleaning chemicals or materials on your Volkano™
Capricorn Series True Wireless Stereo Earphones as doing so may damage or
scratch the surface finish.
• Do not expose your Volkano™ Capricorn Series True Wireless Stereo Earphones to
direct sunlight or high temperatures for extended periods of time.
• Do not store in temperatures over 60°C. Do not expose the battery to excessive heat
such as sunshine, fire or the like. Store in a cool, dry place.
CLEANING & CARE INSTRUCTIONS - GENERAL

ENVIRONMENTALLY FRIENDLY DISPOSAL
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN
ACCORDANCE WITH THE EUROPEAN DIRECTIVE ON WASTE ELECTRICAL AND
ELECTRONIC EQUIPMENT.
At the end of its working life, the product must not be disposed of as urban waste.
It must be taken to a special local authority differentiated waste collection center
or to a dealer providing this service. Disposing of a household appliance separately
avoids possible negative consequences for the environment and health deriving
from inappropriate disposal and enables the constituent materials to be recovered
to obtain significant savings in energy and resources. As a reminder of the need to
dispose of household appliances separately, the product is marked with a crossed-
out wheeled dustbin.
• Never dispose of used electronics with ordinary solid waste, since they contain toxic
substances.
• Always dispose of used electronics in accordance with the prevailing community
regulations that apply to the disposal of electronics. If there are no regulations
concerning electronics disposal, please dispose of the device in a waste bin for
electronic devices.
DISCLAIMER
The Bluetooth®word mark and logos are registered trademarks owned by Bluetooth®
SIG, Inc. and any use of such marks by Volkano™ is under license. Other trademarks
and trade names are those of their respective owners.
All product and company names are trademarks™ or registered®trademarks of their
respective holders. The use of them does not imply any affiliation with or endorsement
by them.
11

12
These Volkano™ Capricorn Series True Wireless Stereo Earphones includes a standard
12-month limited warranty against manufacturing defects and faults. Should your
Volkano™ Capricorn Series True Wireless Stereo Earphones be unboxed with any faulty
parts, poor finishing or visible damage, or fail to perform due to a manufacturing
defect or poor workmanship, please return it with your proof of purchase (till slip or
invoice) to the store of purchase for an exchange, or repair, depending on the store’s
returns policy.
This warranty commences from the date of purchase.
Kindly retain your proof of purchase as well as the packaging for your warranty period.
NOTE:
The warranty does not apply to a product that:
1. Has failed due to excessive wear and tear beyond what is considered to be
reasonable.
2. Has been misused or neglected.
3. Has been damaged accidentally or by Force Majeure including fire and flooding.
4. Has been used or operated contrary to operating or maintenance instructions
outlined in this manual.
The Store of Purchase / Seller cannot accept any returned products that have not been
returned in accordance with this warranty or which does not follow their own Returns
Policy. Please refer to the Store of Purchase / Sellers Returns Policy for details.
Should you require any further assistance or have any questions on your warranty,
please contact the store of purchase.
WARRANTY
