volkano Rhapsody Series User manual

INSTRUCTION MANUAL
Please read and retain these
instructions for future reference.
2
VK-2006-BK
ACTIVE NOISE CANCELLING
BLUETOOTH WIRELESS HEADPHONES

INSTRUCTION MANUAL
Please read and retain these
instructions for future reference.
THE HIGHLIGHTS
• Bluetooth
• Active Noise Cancelling
• 25 dB Noise Reduction
• Aux Input
• Up to 8 Hours Playtime
• Hands-free Calling
• Twisting & Folding Frame
• Aux Input
PACKAGE CONTENTS
• Volkano Rhapsody Noise Cancelling Bluetooth Headphones
• Aux Cable
• USB Charging Cable
• Instruction Manual
SPECIFICATIONS
• Bluetooth:
Version : 5.0
Chipset : JL
Distance : Up to 32.808 ft / 10 m
Profile : A2DP / AVRCP / HFP
• Sensitivity : 110 dB
• Battery Capacity : 380 mAh
• Driver : 40 mm
• Impedance : 32 Ω
• Charge Time : 2 Hours
• Charge Input : 5 V DC
• Playtime : 7 – 8 Hours
• Frequency Response : 20 Hz – 20 kHz
2

3 4
IDENTIFYING PARTS
1. Microphone
2. Micro USB Charging Port
3. LED Indicator
4. Aux Input
5. M Mode Button
6. Next Track / Volume Up Button
7. Previous Track / Volume Down Button
8. Power / Play / Pause Button
1
2
3
56
7
8
4

3
INSTRUCTIONS FOR USE
CHARGING THE HEADPHONES
• Please ensure that the battery is fully charged before using the device for the
first time.
• Connect the provided micro USB charge cable to the DC 5V charging slot on
the headphones, connect the other end of the USB to a wall charger or
an available USB port on a compatible device.
• The red LED indicator light will be lit.
• When the headphones are fully charged, the red LED indicator light will turn off.
• A voice reminder will notify you when the battery is low.
SWITCHING ON THE HEADPHONES
• To switch on the device, press and hold the Power / Play / Pause Button for
about 3 seconds until the red and blue LED lights turn on and start flashing.
• To switch off the device, press and hold the Power / Play / Pause Button for
about 3 seconds until the blue LED light turns off.
SWITCHING ON THE ANC FUNCTION
• To switch on the Active Noise Cancelling, press and hold the M Button for about
3 seconds until the green LED light turns on.
• To switch off the Active Noise Cancelling, press and hold the MButton for about
3 seconds until the green LED light turns off.
AUX-IN
These headphones can be used as wired headphones by plugging one end of the
included Aux cable into the 3.5 mm jack on the headphones and the other end
into any audio device with a standard 3.5 mm headphone jack. Plugging the audio
cable into the headphone will disable the Bluetooth functionality until the cable is
unplugged.
Note: The built-in microphone of the headphones will not work when the
headphones are used in Wired Mode.
4 5

4
PAIRING WITH BLUETOOTH DEVICES
Your headphones must be paired to a Bluetooth device before it can be used. It is
only necessary to pair your headphones once with each device.
1. Ensure that the headphones are off before pairing them for the first time.
2. Press and hold the Power / Play / Pause Button for about 3 seconds until the
blue and red LED lights turn on and start flashing.
3. This means the headphones are now ready to pair with your Bluetooth device.
4. Ensure that your device’s Bluetooth is on. Search for the device “Rhapsody”.
Confirm pairing by selecting the device from the list.
5. When successfully paired, the blue LED light will flash twice every 4 seconds.
6. The device is now ready to make/receive calls and playback music.
7. To play the next or previous track, short press the Next Track / Volume Up
Button or Previous Track / Volume Down Button accordingly.
8. To adjust the volume, long press the Next Track / Volume Up Button or
Previous Track / Volume Down Button accordingly.
9. To play or stop the music, press the Power / Play / Pause Button.
MAKING AND RECEIVING CALLS
• When the headphones are paired to your smartphone, you will be able to make
or receive calls using the built-in microphone.
• When receiving a call, press the Power / Play / Pause Button on the
headphones to answer calls and press and hold the Power / Play / Pause
Button on the headphones to end calls.
• Double press the Power / Play / Pause Button to redial the last number dialed.
5

76
2. Audio Control
Function Operation Note
Navigate to Next
Track
Short press the Next Track /
Volume Up Button.
The Next Track,
Previous Track and
Power / Play / Pause
Buttons will not work
in Aux Input Mode,
however, you can still
increase or decrease the
speaker volume.
Navigate to
Previous Track
Short press the Previous
Track / Volume Down Button.
Play or Pause
Track
Short press the Power / Play
/ Pause Button.
1. Volume Controls
Function Operation Note
Increase Volume Long press the Next Track /
Volume Up Button. When the volume reaches
the maximum level, the
headphones will produce
a short tone.
Decrease
Volume
Long press the Previous
Track / Volume Down Button.
CONTROLS
LOCATING THE BLUETOOTH®MENU
iPhone, iPad, and iPod Touch
a) On your device, go to Settings.
b) Select Bluetooth. If Bluetooth is not on, turn it on.
c) The iPhone / iPad / iPod will automatically search for new devices
Android™ Phones and Tablets
a) On your device, go to the Settings Menu.
b) Select Bluetooth (on older Android devices Bluetooth is found in the Wireless
& Networks Menu). If Bluetooth is not on, turn it on.
c) Select “Search for devices” if your phone or tablet does not automatically
search for new devices.
NOTE: If you are unsure on how to access your Bluetooth Menu on your device,
please refer to your device’s Instruction Manual.

7 8
3. Phone Calls
Function Operation
Incoming Call – Answer Short press the Power / Play / Pause Button.
Incoming Call – Reject Press and hold the Power / Play / Pause
Button for 2 seconds.
Call in Progress – End Call Short press the Power / Play / Pause Button.
CONTROLS (Continued)
TROUBLE SHOOTING
1.My smartphone cannot find any new Bluetooth devices.
a. Ensure the device has entered the pairing mode.
b. Ensure the device is within effective working range.
2.Bluetooth device cannot pair up.
Ensure your smartphone allows new connections and has not reached
the maximum number of allowed devices.
3.The Device does not play music or answer calls when it is connected to
a Bluetooth smartphone.
a. Ensure your smartphone supports A2DP and HSF (Hands-Free) profiles.
b. Ensure your smartphone is within effective working range.
4.When paired with my computer, Windows®asks for a new driver.
Can you supply this?
We recommend you find compatible drivers for your computer online.
5.Why can I not remotely control the Pause, Play, Previous and Next functions
when music is playing?
This feature needs the Bluetooth device paired with the headphones to
support AVRCP (Audio / Video Remote Control Profile). Please ensure your
device supports this.

CLEANING & CARE INSTRUCTIONS - GENERAL
Before Cleaning: Ensure that your Volkano Rhapsody Series Headphones are
turned off before cleaning or maintaining your device.
Cleaning: Wipe down the surface of your Volkano Rhapsody Series Headphones
using a soft, slightly damp cloth.
• Do not use any harsh or abrasive cleaning chemicals or materials on your
Volkano Rhapsody Series Headphones as doing so may damage or scratch the
surface finish.
• Do not expose your Volkano Rhapsody Series Headphones to direct sunlight or
high temperatures for extended periods of time.
• Do not store in temperatures over 60 °C. Do not expose the battery to excessive
heat such as sunshine, fire or the like. Store in a cool, dry place.
SAFETY PRECAUTIONS
• Never use your headphones near water or in areas where they can come into
contact with water. Never handle the headphones if they are dropped in water or
any other liquid. If the product comes into contact with water while switched off,
but still plugged in, this is a safety hazard.
• Always make sure your hands are dry before touching the plug or power connections.
• Do not operate the product with a damaged cord or plug, or after it malfunctions,
has been dropped, or damaged in any manner.
• The headphones are intended for personal use only. Commercial use invalidates
the warranty and the supplier cannot be held responsible for injury or damage
caused when using the device for any other purpose than that which they were
intended for.
• These headphones are not intended for use by children, or persons with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
device by a person responsible for their safety. Extreme caution must be exercised.
• Children should be supervised to ensure that they do not play with
the headphones. Packaging must never be left within reach of children, since it is
potentially dangerous.
8 9

ENVIRONMENTALLY FRIENDLY DISPOSAL
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN
ACCORDANCE WITH THE EUROPEAN DIRECTIVE ON WASTE ELECTRICAL AND
ELECTRONIC EQUIPMENT.
At the end of its working life, the product must not be disposed of as urban waste.
It must be taken to a special local authority differentiated waste collection center or
to a dealer providing this service. Disposing of a household appliance separately
avoids possible negative consequences for the environment and health deriving
from inappropriate disposal and enables the constituent materials to be recovered
to obtain significant savings in energy and resources. As a reminder of the need to
dispose of household appliances separately, the product is marked with a crossed-
out wheeled dustbin.
9
DISCLAIMER
All product and company names are trademarks™ or registered®trademarks of their
respective holders. Use of them does not imply any affiliation with or endorsement
by them.

WARRANTY
The Volkano Rhapsody Series Headphones come with a standard 12-month limited
warranty against manufacturing defects and faults.
Should your Volkano Rhapsody Series Headphones be unboxed with any faulty
parts, poor finishing or visible damage, or fail to perform due to a manufacturing
defect or poor workmanship, please return it with your proof of purchase (till slip
or invoice) to the store of purchase for an exchange, or repair, depending on the
store’s returns policy.
This warranty commences from the date of purchase.
Kindly retain your proof of purchase as well as the packaging for your
warranty period.
NOTE:
The warranty does not apply to a product that:
a) Has failed due to excessive wear and tear beyond what is considered
to be reasonable.
b) Has been misused or neglected.
c) Has been damaged accidentally or by force majeure including fire and flooding.
d) Has been used or operated contrary to operating or maintenance instructions
outlined in this manual.
The Store of Purchase / Seller cannot accept any returned products that have
not been returned in accordance with this warranty or which does not follow their
own Returns Policy. Please refer to the Store of Purchase / Sellers Returns Policy
for details.
Should you require any further assistance or have any questions on your warranty,
please contact the store of purchase.
