volkano Taurus Series User manual

VK-1120-BK
VK-1120-WT
Please read these instructions carefully and
retain for future reference.
INSTRUCTION MANUAL
Taurus Series
EN
TRUE WIRELESS
EARPHONES
WITH CHARGING CASE Compatible with Siri
and Google Assistant

Bluetooth®:
• Version: 5.0
• Chipset: Bluetrum
• Profiles: A2DP / AVCTP / HSP / HES
• Distance: Up to 10 m
Charging Case:
• Battery: 300 mAh
• Number of Recharges: 3 ×
• Charging Time: 1 Hour
• Charge Input: 5 V DC, 1 A
Earphones:
• Battery: 40 mAh per Earphone
• Playback Time: 3.5 ~ 4 Hours
• Sensitivity: 92 dB
• Driver: 6 mm
• Impedance: 16 Ω
• Frequency Response: 20 Hz ~ 20 kHz
• Volkano Taurus Series True Wireless Earphones
• 300 mAh Charging Case
• 3 x Spare Earbud Cap Sizes
• USB Type-C Charging Cable
• Instruction Manual
• True Wireless Bluetooth®Technology
• Touch Control
• Pocket-Sized
• Hands-Free Calling
• Up to 18 Hour Playtime with Charging Case
• USB Type-C Charging
• Auto-Reconnect
• Compatible with Siri and Google Assist
PACKAGE CONTENTS
HIGHLIGHTS
SPECIFICATIONS
2

IDENTIFYING PARTS
3
1.Magnetic Charging Pogo Pins
2.Charging Case LED Light Indicator
3.Charging Case
4.Earphone LED Light Indicator
5.Earphone Microphone
6.Multi-Function Touch Button
7.Type-C Charging Port
1
2
3
5
6
4
7

CHARGING THE CASE
INSTRUCTIONS FOR USE
• Please ensure that the battery is fully charged before using the device for the
first time.
• Connect the provided USB charge cable to the DC 5V charging slot on the charging
case, connect the other end of the USB to a wall charger or an available USB port on
a compatible device.
• The Red LED Indicator Light will pulse to indicate that charging has begun.
• The LED Indicator will pulse repeatedly to indicate that the battery is flat.
Note: Once fully charged, the Red LED will display in a solid light.
4
CHARGING THE EARPHONES
• Please ensure that the battery is fully charged before using the device for the first time.
• Place the earphones into the charging case. A Red light will pulse when the charging
has begun. The Red Light will stay lit while charging and turn off when complete.
• When the earphones are removed from the charging case they will power on
automatically.
Note: The earphones will turn off when inserted into the charging case, even if they are
powered ON before charging.
SWITCHING ON THE EARPHONES
• To switch on the device, touch and hold the Multi-Function Touch Button for about
3 seconds until the Red LED lights turn on.
• To switch off the device, touch and hold the Multi-Function Touch Button for about
3 seconds until the LED lights turn on and then off, you will then hear a voice prompt
stating that the earphones have been powered off.
Note: Please note that the earphones would need to be turned on individually.

5
PAIRING WITH EACH OTHER
Turn the earphones on first, after powering on the earphones, the earphones will
automatically pair with each other.
Note: This can be done separately to use earphones individually.
PAIRING WITH BLUETOOTH®DEVICES
Your earphones must be paired to a Bluetooth®device before it can be used. It is only
necessary to pair your earphones once with each device.
1. Ensure that your device’s Bluetooth®is on. Search for the device “Taurus”.
Confirm pairing by selecting the device from the list.
2. When successfully paired, the earphone will beep.
3. The device is now ready to make / receive calls and playback music.
4. To play or stop the music, touch the Multi-Function Touch Button on either earphone.
5. To play the next track, triple touch the left earphone’s Multi-Function Touch Button.
6. To play the previous track, triple touch the right earphone’s Multi-Function
Touch Button.
7. To increase the volume, double touch the left earphone’s Multi-Function Touch Button.
8. To decrease the volume, double touch the right earphone’s Multi-Function
Touch Button.
MAKING AND RECEIVING CALLS
• When the earphones are paired to your smartphone, you will be able to make or
receive calls using the built-in microphone.
• When receiving a call, touch the Multi-Function Touch Button on either earphone
to answer calls. Touch and hold the Multi-Function Touch Button on either earphone
to reject incoming calls.
• When in a call, touch the Multi-Function Touch Button on either earphone to end
the call.

6
LOCATING THE BLUETOOTH®MENU
iPhone, iPad, and iPod Touch
a. On your device, go to Settings.
b. Select Bluetooth®. If Bluetooth®is not on, turn it on.
c. The iPhone / iPad / iPod will automatically search for new devices.
Android™ Phones and Tablets
a. On your device, go to the Settings Menu.
b. Select Bluetooth®(on older Android devices Bluetooth®is found in the Wireless &
Networks menu). If Bluetooth®is not on, turn it on.
c. Select “Search for devices” if your phone or tablet does not automatically search for
new devices.
Note: If you are unsure of how to access your Bluetooth®Menu on your device, please
refer to your device’s instruction manual.
CONTROLS
1. Audio Controls
Function Operation
Play / Pause Track Touch the Multi-Function Touch Button on either earphone
Navigate to Next
Track Triple touch the left earphone’s Multi-Function Touch Button
Navigate to
Previous Track Triple touch the right earphone’s Multi-Function Touch Button
Increase Volume Double touch the left earphone’s Multi-Function Touch Button
Decrease Volume Double touch the right earphone’s Multi-Function Touch Button
Function Operation
Siri / Google
Assist
Activate Siri /
Google Assist
Touch and hold the Multi-function Button
on either earphone
Turn Off Siri / Google
Assist
Touch and hold the Multi-function Button
on either earphone
2. Siri / Google Assistant

7
3. Phone Calls
Function Operation
Incoming Call Answer Call Touch either earphone’s Multi-Function
Touch Button
Reject Call Hold Multi-Function Touch Button for
2 seconds
Call In Progress End Call Touch either earphone’s Multi-Function
Touch Button
TROUBLESHOOTING
1. My smartphone cannot find any new Bluetooth®devices.
a. Ensure the device has entered the pairing mode.
b. Ensure the device is within an effective working range.
2. The Bluetooth®device cannot pair up.
a. Ensure your smartphone allows new connections and has not reached the
maximum number of allowed devices.
3. The device does not play music or answer calls when it is connected to
a Bluetooth®smartphone.
a. Ensure your smartphone supports A2DP and HSF (Hands-Free) profiles.
b. Ensure your smartphone is within an effective working range.
4. When paired with my computer, Windows®asks for a new driver.
Can you supply this?
a. We recommend you find compatible drivers for your computer online.
5. Why can I not remotely control the Pause, Play, Previous and Next functions
when music is playing?
a. This feature needs the Bluetooth®device paired with the earphones to support
AVRCP (Audio / Video Remote Control Profile). Please ensure your device
supports this.

8
• This product is not intended for commercial use and has been tested for household
use only.
• This product is not intended for use by small children, or persons with diminished
mental capabilities. Ensure that the use of this product is monitored by a guardian
or parent.
• Never use your earphones near water or in areas where it can come into contact
with water. Never handle the earphones if they have been dropped into water or
any other liquid. If the product comes into contact with water while charging, this is
a safety hazard.
• Do not operate the product after it malfunctions, it has been dropped or damaged
in any way.
• WARNING: Always keep optional accessories, small parts and packaging out of the
reach of babies and small children, as these items may be a choking hazard.
• DO NOT overcharge your Volkano Taurus Series True Wireless Stereo Earphones,
doing so will shorten the lifespan of the built-in battery and could cause your device
to overheat.
• CAUTION: Do not disassemble the battery or dispose of it in a fire.
• CAUTION: Should your battery show signs of overheating, smoke or fumes being
emitted during charging, remove the charging cable immediately.
SAFETY PRECAUTIONS
• Before Cleaning: Ensure that your Volkano Taurus Series True Wireless
Earphones are turned off before cleaning or maintaining your device.
• Cleaning: Wipe down the surface of your Volkano Taurus Series True Wireless
Earphones using a soft, slightly damp cloth.
• Do not use any harsh or abrasive cleaning chemicals or materials on your Volkano
Taurus Series True Wireless Earphones as doing so may damage or scratch
the surface finish.
• Do not expose Volkano Taurus Series True Wireless Earphones to direct sunlight or
high temperatures for extended periods of time.
• Do not store in temperatures over 60 °C. Do not expose the battery to excessive heat
such as sunshine, fire or the like. Store in a cool, dry place.
CLEANING & CARE INSTRUCTIONS - GENERAL

9
ENVIRONMENTALLY FRIENDLY DISPOSAL
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN
ACCORDANCE WITH THE EUROPEAN DIRECTIVE ON WASTE ELECTRICAL AND
ELECTRONIC EQUIPMENT.
• At the end of its working life, the product must not be disposed of as urban waste.
It must be taken to a special local authority differentiated waste collection center
or to a dealer providing this service. Disposing of a household appliance separately
avoids possible negative consequences for the environment and health deriving
from inappropriate disposal and enables the constituent materials to be recovered
to obtain significant savings in energy and resources. As a reminder of the need to
dispose of household appliances separately, the product is marked with a crossed-
out wheeled dustbin.
DISCLAIMER
The Bluetooth®word mark and logos are registered trademarks owned by Bluetooth SIG,
Inc. and any use of such marks by Volkano is under license. Other trademarks and trade
names are those of their respective owners.
All product and company names are trademarks™ or registered®trademarks of their
respective holders. The use of them does not imply any affiliation with or endorsement
by them.
Lithium-ion Batteries and/or products that contain
Lithium-ion Batteries can expose you to chemicals
including cobalt lithium nickel oxide, and nickel, which
are known to the State of California to cause cancer and
birth defects or other reproductive harm. For more
information go to www.P65Warning.ca.gov.
WARNING

10
These Volkano Taurus Series True Wireless Earphones include a standard 12-month
limited warranty against manufacturing defects and faults. Should your Volkano
Scorpio Series True Wireless Earphones be unboxed with any faulty parts, poor
finishing or visible damage, or fail to perform due to a manufacturing defect or poor
workmanship, please return it with your proof of purchase (till slip or invoice) to the
store of purchase for an exchange, or repair, depending on the store’s returns policy.
This warranty commences from the date of purchase.
Kindly retain your proof of purchase as well as the packaging for your warranty period.
NOTE: The warranty does not apply to a product that:
1. Has failed due to excessive wear and tear beyond what is considered to be
reasonable.
2. Has been misused or neglected.
3. Has been damaged accidentally or by Force Majeure including fire and flooding.
4. Has been used or operated contrary to operating or maintenance instructions
outlined in this manual.
The Store of Purchase / Seller cannot accept any returned products that have not been
returned in accordance with this warranty or which does not follow their own Returns
Policy. Please refer to the Store of Purchase / Sellers Returns Policy for details.
Should you require any further assistance or have any questions on your warranty,
please contact the store of purchase.
WARRANTY
