Vollrath 4087024 User manual

Item No. 2350130-1 en Rev 02/12



Thank you for purchasing this Vollrath equipment. Before operating the equipment, read and familiarize yourself with the following operating
and safety instructions. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. Save the original box and packaging. Use this
packaging to ship the equipment if repairs are needed.
 
 
4087024 500 (226) 24” Heavy-Duty Stationary Stand
4087036 550 (249) 36” Heavy-Duty Stationary Stand
4087048 600 (272) 48” Heavy-Duty Stationary Stand
4087060 650 (317) 60” Heavy-Duty Stationary Stand
4087072 700 (317) 72” Heavy-Duty Stationary Stand
 
 
4087924 500 (226) 24” Heavy-Duty Mobile Stand
4087936 550 (249) 36” Heavy-Duty Mobile Stand
4087948 600 (272) 48” Heavy-Duty Mobile Stand
4087960 650 (317) 60” Heavy-Duty Mobile Stand
4087972 700 (317) 72” Heavy-Duty Mobile Stand

EquipmEnt
OperatOr’s Manual


















4. Slide the shelf (B) to the top of the caster (C) or to the weld stud (D) See
Figure 2. Repeat for all the legs.








5. 60” and 72” models only. Slide the center legs (D) into the center leg hole
on shelf (B). See Figure 1.
6. Slide the top (E) onto the legs (A and D) so that the legs slide completely
over the extrusions (C).
7. Tighten the eight hex bolts with the wrench (G) provided (75-80 in. lbs..).
Safety PrecautionS
To ensure safe operation, read the following statements and
understand their meaning. Please read carefully.

Warning is used to indicate the presence of a hazard that can cause
severe personal injury, death, or substantial property damage if the
warning is ignored.


Use restraining device to limit mobility of caster/
mobile stands.



 . Commercial cooking appliances
that are moved for cleaning and sanitation purposes shall be connected
in accordance with the connector manufacturer’s installation instructions
using a listed appliance connector complying with ANSI Z21.69/CSA 6.22,
Connectors for Movable Gas Appliances. The commercial cooking
appliance connector installation shall be congured in accordance with the
manufacturer’s installation instructions.
 Movement of appliances with casters shall be limited by restraining
device installed with the connector and appliance manufacturer’s installation
instructions.
To reduce risk of injury or damage to the equipment:
Use this equipment stand in a at, level position.
The included restraining device must be used with caster/mobile
stands. Install the restraining appliance in accordance to the
Restraining manufacturer’s installation instructions.
Items must not protrude or hang off the edge of this equipment stand
This equipment stand is designed to be used only with Vollrath branded
gas appliances.
function and PurPoSe
This equipment is intended to be used for supporting Vollrath gas appliances
with corresponding widths. The mobile equipment stands are not intended to
be used as carts but rather allow limited mobility for cleaning.
Before using this equipment it must be cleaned and dried thoroughly.
unPacking the equiPment and initial SetuP
When no longer needed, dispose of all packaging and materials in an
environmentally responsible manner.
1. Remove all packing material and tape, as well as any protective plastic
from the equipment.
2. Clean any glue residue left over from the plastic or tape.
3. Insert the leg (A) through the hole in the shelf (B). See Figure 1. Repeat
for all the legs.

EquipmEnt


OperatOr’s Manual



8. Stationarystands: Place the stand into the desired location. Use the
adjustable feet (E) to level the stand. See Figure 2.


9. Mobile stands: Place the stand in the desired location. Install the
restraining appliance in accordance to the Restraining manufacturer’s
installation instructions.
cleaning
To maintain the appearance and increase the service life, clean your
equipment daily.
1. Using a damp cloth, sponge dipped in soapy water to clean the outside
of the equipment stand.
Service PartS
 
23608-1 Hex Bolt, 5/16-18 x 3/4”
23750-1 Adjustable Foot, 1-1/2” Dia.
23605-1 Caster., 5” Stem w/ Brake
46411-2 Heavy-Duty Leg, Stationary
46421-2 Heavy-Duty Leg, Mobile and Center (60” and 70”)
23920-1 Tether/Restraining Kit
Service and rePair
There are no user serviceable parts within this appliance. To avoid serious
injury or damage, never attempt to repair the equipment or replace a
damaged power cord yourself. Do not send equipment directly to the Vollrath
Company. Please contact the qualied professional repair service listed
below. 
