VOLVO CONSTRUCTION EQUIPMENT
ec60E
operator’s manual

Foreword
This operator's manual is intended as a guide for the correct
use and maintenance of the machine. Read this manual
carefully before you start and move the machine or before you
carry out any preventive maintenance.
Keep this manual in the lockable storage compartment so that
it is always available for easy reference. Replace it
immediately if it is lost.
The operator's manual describes the applications for which the
machine was primarily designed. It has been written to be valid
on all markets. Therefore, please ignore any sections which
do not relate to your machine or to the work that you do with
your machine.
NOTE!
If the manual covers more than one machine, the information
relates to all machines unless otherwise specified.
When designing this machine, much time has been invested
in achieving the best possible efficiency and safety. But
accidents do happen, and most of them can be attributed to
human error. A safety-conscious person and a well-
maintained machine make up a reliable, powerful, and
profitable combination. Therefore, read the safety instructions
and follow them.
We constantly strive to develop and improve the efficiency of
our products by making changes to their design. We reserve
the right to make design modifications to the products even
after they have been delivered. Also, we reserve the right to
change data and equipment, as well as the service and
maintenance instructions, without prior notice.
OPERATOR'S MANUAL
Table of contents
Presentation
Instrument panels
Other controls
Operating instructions
Operating techniques
Safety when servicing
Maintenance
Specifications
Alphabetical index
EC60E
Ref. No. 20044040-C
The original language is English. Original instructions.
2018.05
Copyright © 2018, Volvo Construction Equipment. All rights reserved.

Safety regulations
The machine operator is responsible for being aware of and
complying with the relevant, legally prescribed, national and
regional safety instructions. The safety instructions in this
operator's manual are applicable only in cases where no
legislated safety instructions are in force.
DANGER
The safety symbol combined with this signal word indicates a
hazardous situation which, if not avoided,
will result in death
or serious injury. Danger is limited to the most extreme
situations.
WARNING
The safety symbol combined with this signal word indicates a
hazardous situation which, if not avoided, could result in
death
or serious injury .
CAUTION
The safety symbol combined with this signal word indicates a
hazardous situation which, if not avoided, could result in
moderate or minor injury .
NOTICE
Indicates a potentially hazardous situation which may result in
machine damage.
NOTE!
Used in order to refer to installation, operating, or maintenance
information which is important but not danger-related.
Get to know the capacity and limits of your machine!
2
Foreword

Identification numbers
Make a note below of the identification numbers of the machine and its components.
Always use this information when contacting the manufacturer and when ordering spare
parts.
Manufacturer:
Volvo Group Korea Co., Ltd.
Seongsan-gu, Changwon-si, Gyeongsangnam-do,
Korea 51710
Machine PIN (Serial number)
Engine
Main pump
Swing motor
Track motor
Main control valve
• Please send any comments about the Operator's Manual to [email protected].
• Open source code used in this product can be got from the following web site. (http://
webdoc.volvo.co.kr/exc-oss)
Foreword
Identification numbers 3

Table of contents
Foreword ................................................ 1
Identification numbers ..................................... 3
Presentation ........................................... 9
Machine view ................................................ 16
CE-marking, EMC-directive .......................... 18
Communication equipment, installation ........ 23
Safety components ....................................... 24
Product plates ............................................... 25
Information and warning decals .................... 27
Instrument panels ................................. 34
Instrument panel, left .................................... 35
Instrument panel, front .................................. 38
Display unit ................................................... 45
Instrument panel, right .................................. 86
Instrument panel, rear ................................... 98
Other controls ....................................... 99
Controls ...................................................... 100
Cab ............................................................. 112
Control lockout system ............................... 114
Operator comfort ......................................... 115
Operating instructions ......................... 136
Safety rules when operating ....................... 142
Measures before operating ......................... 147
Starting engine ............................................ 148
Hydraulic system, warming up .................... 152
Operating .................................................... 154
Exhaust aftertreatment system ................... 155
Stopping ...................................................... 162
Parking ........................................................ 163
Retrieving and towing ................................. 165
Transporting machine ................................. 167
Table of contents
5

Operating techniques ......................... 173
Whole-body vibrations ................................ 174
Rules for digging ......................................... 176
Working within dangerous areas ................ 179
Attachments ................................................ 191
Attachments, connecting and
disconnecting .............................................. 194
Attachment brackets ................................... 201
Mechanical attachment bracket .................. 202
Buckets ....................................................... 204
Hammer ...................................................... 206
Thumb ......................................................... 216
Hose rupture valves .................................... 219
Selecting track shoes .................................. 221
Lifting objects .............................................. 223
Signalling diagram ...................................... 226
Safety when servicing ......................... 229
Service position .......................................... 230
Before service, read .................................... 231
Entering, leaving and climbing the machine 237
Fire prevention ............................................ 238
Handling hazardous materials .................... 241
Handling line, tubes and hoses ................... 246
Maintenance ....................................... 247
Lubrication and service chart ...................... 249
Maintenance service, every 10 hours ......... 258
Maintenance service, every 50 hours ......... 265
Maintenance service, every 250 hours ....... 267
Maintenance service, every 500 hours ....... 270
Maintenance service, every 1000 hours ..... 272
Maintenance service, every 2000 hours ..... 273
Maintenance service, when required .......... 276
6
Table of contents

Specifications ..................................... 298
Recommended lubricants ........................... 298
Fuel system ................................................ 304
Service capacities and change intervals ..... 309
Engine ......................................................... 311
Electrical system ......................................... 312
Cab ............................................................. 314
Hydraulic system ........................................ 315
Machine weights ......................................... 317
Ground pressure ......................................... 318
Dimensions ................................................. 320
Working ranges ........................................... 322
Recommended bucket sizes ....................... 324
Digging forces ............................................. 325
Lifting capacities ......................................... 326
Service history ............................................ 334
Alphabetical index .............................. 337
Table of contents
7

Presentation
V1157220
Intended use
The machine is intended to be used under normal
conditions for the applications described in this
manual. If it is used for other purposes or in
potentially dangerous environments, for example
explosive atmosphere, flammable environment or
areas with dust containing asbestos and so on,
special safety regulations must be followed and the
machine be equipped for such use. Contact the
manufacturer / dealer for further information.
Environmental requirements
Be aware of the environment when operating and
during service and maintenance of the machine.
Always follow local and national environmental
legislation applicable to all handling of the machine.
Presentation
9

Engine
The new engine which provide excellent
performance is equipped with a four-cylinder,
vertical, electronic controlled high pressure fuel
injectors, in-line turbo charger and water cooled
diesel engine type. This engine fully meets the
demands of the latest EU Stage IV / US Tier 4 final
emissions regulations.
NOTE!
Machines with engines for the US market may not
be sold or used within the EU, and machines with
engines for the EU market may not be sold or used
within the USA, unless the engine is replaced with
an engine valid for the applicable market. The
market for which the engine is intended is indicated
on the emission plate and by the engine's serial
number (see page
25 ).
10
Presentation

Electrical system
The electrical system consists of engine starting
system, charging system, machine monitoring
system, engine / pump control system and air
conditioning system.
The machine is equipped with a high capacity
electrical system well protected. Waterproof
double-lock harness plugs are used to secure
corrosion-free connections. The main relays and
solenoid valves are shielded to prevent damage.
The master switch is standard.
Automatic idling system
Automatic idling system reduces engine speed to
idle when the levers and pedals are not activated
for a certain period of time, resulting in less fuel
consumption and low cab noise level.
Automatic engine shut-down system
(Optional equipment)
Automatic engine shut-down system is to stop the
engine automatically when the machine is not
operated for a certain period of time.
Automatic engine shut-down conditions
- Control lockout lever is locked position.
- Engine speed control switch is not changed.
- DPF regeneration is not on progress.
1 minute before engine shut-down, info screen will
be displayed on I-ECU so that the operator can
cancel engine shut-down by pushing the keypad
ESC button or moving the control lockout lever to
unlock position or changing engine speed control
switch (at the control lockout lever down position).
Presentation
11

Cab
The cab has a heating and ventilation system with
defrosting from front and rear windows and also air
conditioning. The cab has one emergency exit, the
rear window.
ROPS
The cab is approved as a part of protective structure
according to ROPS standard (ISO12117-2). ROPS
is an abbreviation of Roll Over Protective Structure.
Never carry out any unauthorized alterations to the
cab, for example lowering the roof height, drilling,
welding on brackets for fire extinguisher, radio
aerial or other equipment, without first having
discussed the alteration with personnel at the Volvo
Engineering Department. This department will
decide whether the alteration may cause the
approval to become void.
It is important that all parties concerned are aware
of these regulations.
12
Presentation

Hydraulic system
The machine is equipped with a flow control system
with variable flow. With this system, the working
pump can deliver flow according to demand. A
variable flow from the pump allows precision work
even with high engine speed.
Track motor and gearbox
Each track is powered by an automatic two-speed
shift track motor. The track brakes are multi-disc,
spring-applied and hydraulic released. The track
motor, brake and planetary gears are well protected
within the track frame.
The track gearbox is composed of sun gear,
planetary gear, pinion gear and housing.
Swing motor
The swing motor consists of the rotary group of 9
fixed volume pistons, cylinder blocks and a shaft
with pinion gear, the parking brake group with
washer spring and piston and the control block
group with an anti-shock relief valve.
Main control valve
The control valve consists of 10 or 11 (for rotator
option) section blocks, main relief valve, port relief
valve, holding valve and so on.
Equipment
The machine can be provided with different types
of optional equipment, depending on the
requirements of different markets. Examples of
such equipment are attachment quick coupler and
hydraulic breaker.
Presentation
13

Modifications
Modifications to this machine including the use of
unauthorised attachments, accessories,
assemblies or parts may affect the integrity of the
machine and/or the ability of the machine to perform
as designed. Persons or organisations making
unapproved modifications assume all liability
arising from or related to the modification, including
any adverse affect on the machine. No
modifications of any kind should be made to this
product unless the specific modification has been
officially approved in writing by Volvo Construction
Equipment. Volvo Construction Equipment
reserves the right to reject any and all warranty
claims which arise from or are related to
unauthorised modifications. Modifications are
officially approved if at least one of the following
conditions is met:
1 The attachment, accessory, assembly or part is
manufactured or distributed by Volvo
Construction Equipment and installed in a
factory approved manner as described in the
publications available from Volvo Construction
Equipment; or
2 The modification has been approved in writing
by the Product Line Engineering Department of
Volvo Construction Equipment.
Anti-theft device
An installed anti-theft device makes it more difficult
to steal the machine. Volvo Construction
Equipment supplies anti-theft devices. Contact
authorized dealer for more information.
Logged machine data
The machine is equipped with a software system,
which records various information about the
machine and this information is transferred from the
machine to Volvo and used by Volvo and its
authorized workshops in the product development
process and for possible malfunction detection.
Questions regarding this information can be
directed to your dealer.
14
Presentation

CareTrack
The machine may be equipped with CareTrack, a
telematics system developed by Volvo
Construction Equipment. The system stores
machine data, e.g., machine position, operating
hours, fuel consumption, fuel level, that can be sent
by wireless transmission to a computer. CareTrack
is available in different versions, depending on the
required information level.
CareTrack makes it easier to plan for service and
reduces costly downtime. Productivity is improved
by knowing if machines are being operated
correctly and how much fuel is being consumed.
CareTrack also allows the customer to restrict the
operating area of the machine, by using virtual
fences. This helps to eliminate unauthorized
machine use and theft. For further information,
contact a Volvo Construction Equipment dealer.
The CareTrack system transmits data, in the same
way a mobile phone does, with a maximum output
rate of 10 W. The transmitter is always on and the
operator cannot switch it off.
Local precautions and restrictions applicable to
mobile phones, for example safety distance, also
apply to the CareTrack system.
Presentation
15

Machine view
V1157221
123
4
5
6
8
11
12
13
14
15
16
17
18
21
22
20
19
10
9
7
1 Cab 12 Track
2 Boom 13 Idler
3 Dipper arm cylinder 14 Bottom roller
4 Dipper arm 15 Front cover
5 Bucket cylinder 16 Upper roller
6 Link 17 Track motor and gearbox
7 Bucket 18 Counterweight
8 Boom cylinder 19 Fuel tank
9 Boom swing cylinder 20 Hydraulic tank
10 Dozer blade cylinder 21 Rear cover
11 Dozer blade 22 Air compressor tank
16
Presentation
Machine view

V1157222
23
27
24
25
26
29
28
23 Rear view camera 27 Engine oil filling port
24 Engine air cleaner 28 Radiator & Hydraulic oil cooler
25 Diesel particulate filter 29 Coolant expansion tank
26 Fuel filter
Presentation
Machine view 17

CE-marking, EMC-directive
CE marking
(Declaration of Conformity : Only applies to
machines marketed within the EU/EEA.)
This machine is CE marked. This means that when
delivered the machine meets the applicable
"Essential Health and Safety Requirements", which
are given in the EU Machinery Safety Directive,
2006/42/EC.
Any person carrying out changes that affect the
safety of the machine, is also responsible for the
same.
As proof that the requirements are met, the
machine is supplied with an EU Declaration of
Conformity, issued by Volvo CE for each separate
machine. This EU declaration also covers
attachments manufactured by Volvo CE. The
documentation is a valuable document, which
should be kept safe and retained for at least ten
years. The document should always accompany
the machine when it is sold.
If the machine is used for other purposes or with
other attachments than described in this manual,
safety must at all times and in each separate case
be maintained. The person carrying out such action
is also responsible for the action which, in some
cases, may require a new CE marking and the issue
of a new EU Declaration of Conformity.
V1067840
18
Presentation
CE-marking, EMC-directive

EU EMC Directive
The electronic equipment of the machine may in
some cases cause interference to other electronic
equipment, or suffer from external electromagnetic
interference, which may constitute safety risks.
The EU EMC directive about "Electromagnetic
compatibility", 2014/30/EC, provides a general
description of what demands can be made on the
machine out of a safety point of view, where
permitted limits have been determined and given
according to international standards.
A machine or device which meets the requirements
should be CE marked. Our machines have been
tested particularly for electromagnetic interference.
The CE marking of the machine and the declaration
of conformity also cover the EMC directive.
If other electronic equipment is fitted to this
machine, the equipment must be CE marked and
tested on the machine with regard to
electromagnetic interference.
Presentation
CE-marking, EMC-directive 19
