Voxx Electronics Prestige APSSEC User manual

20 Blue Trunk Shunt Input (-/+)
19 Orange Starter Kill Relay / An-Grind Output (-)
18 Red/Black Disarm 2 Input (-/+)
17 Black/White Horn Output (-) (NOC 9)
16 Red/Yellow Disarm 1 Input (-/+)
15 Dk. Blue/Black Ch. 3 Alt Output (-) (NOC 8)
14 Green/Black Arm 2 Input (-/+)
13 Green/White Domelight Output (-) (NOC 7)
12 Green/Yellow Arm 1 Input (-/+)
11 Lt. Blue/Green Ch. 5 AUX Output (-) (NOC 6)
10 Dk. Green Instant Trigger Input (-)
9 Green/Lt. Blue Ch. 4 AUX Output (-) (NOC 5)
8 Lt. Green Trunk Trigger Input (-) (PIC 2)
7 Dk. Blue Trunk Output (-) (NOC 4)
6 Gray/Black Hood Input (-) (PIC 1)
5 White/Blue Headlight Output (-) (NOC 3)
4 Purple/Brown Door Trigger Input (- / +)
3 Green Unlock Output (-) (NOC 2)
2Empty Empty
1 Red
Lock Output (-) (NOC 1)
20 Pin Input/Output
1
2
3
4
1 2 3 4
1234
1
White Data RX
2Black Ground (-)
3 Blue Data TX
4 Red BaƩery 12V (+)
DBI
1
Green Data RX
2Blue Data TX
3 Black Ground (-)
4 Red BaƩery 12V (+)
RF
1
Blue Data TX
2White Data RX
3 Black Ground (-)
4 Red
BaƩery 12V (+)
CarLink
4 Red Baery 12V (+)
3 Black Ground (-)
2Blue Data TX
1White Data RX
Weblink
4 Red Baery 12V (+)
3 Black Ground (-)
2Blue Warn Away (-)
1Green Full Trigger (-)
Shock
1 2 3 4
VOXX
FLCART Dock
Replacement Part #4120459
Replacement Part #4120460
Replacement Part #4120461
Not Included
Not Included
Not Included
Not Included
85 Red Ignion Input (+)
86 Orange Ground While Armed (-)
87A Black Starter Output - Motor Side
30
Black/White Starter Input - Key Side
Starter Kill
86 85
87
87A
30
1 White
Parking Light (30)Output
2 Black Ground Input (-)
3 White/RedParking Light (87)Input
4 YellowIgniƟon Input (+)
5 White/Black Siren Output (+)
6 Red
BaƩery 12VInput (+)
6 Pin Power
P
Replacement Part #4360828
1 Black Ground (-)
2 Gray Valet Switch Input
Valet
1 Blue LED Output (-)
2 Red BaƩery 12V (+)
LED
Replacement Part #4120474
Replacement Part #4360833
This Harness is included with the FLCART.



Not Included
19
17
15
13
11
9
7
5
3
1 2
4
6
8
10
12
14
16
18
20
1
2
3
4
1 3 5
2 4 6
19
17
15
13
11
9
7
5
3
1 2
4
6
8
10
12
14
16
18
20
APSSEC
Security w/Keyless Entry
System Layout
2020 Voxx Electronics. All Rights Reserved.
Shock Sensor
Part #4700033
Compable RF Kits
PE1BZ
PE1BZLR
PE1BTWZ
PE5BZ
PE2LEDZ
PE2LCDZ
PE1M2LEDZ
PE1M2LCDZ

APSSEC
Security w/Keyless Entry
Quick Installaon Guide
For Complete Installaon Guide and Technical Support
Please Visit
www.voxxuniversity.com
Or Call
1-800-225-6074
Nocaons
Remote Programming
1 Chirp 2 Chirp
3 Chirp 4 Chirp 5 Chirp 6 Chirp
1 Lock / Unlock Funcon 500ms 3.5sec
500ms L, DBL UL DBL L, 500ms UL DBL L, DBL UL 500ms L, 350ms UL
2 Ignion Lock OFF ON
3 Ignion Unlock OFF Unlock All
Unlock Driver
4 Exterior Illuminaon OFF With Arm
With Disarm With Arm & Disarm
5 Auto Relock OFF Auto Lock Only
Auto Lock & Arm
6 Auto Arming / Locking OFF Auto Arm Only
Auto Lock & Arm
7 Nocaon Sound Both Siren
Horn
8 Horn Timing 16ms 30ms
40ms 50ms 10ms
9 Valet Override Method Valet Custom Code
Stand Alone Valet
10 Driver Priority Unlock OFF ON
11 Silent Choice OFF From Transmier
OEM Style
12 Security Prole All On Doors O
Hood/trunk OAll O
All On w/ OEM RS
13 Door Trigger Input Negave Posive
14 Park Light / Trunk Swap OFF ON
15 Data Port Protocol ADS DBI
16 1 or 2 Wire Disarm 2 Wire 1 Wire
17 Disarm Input 120ms Dr OR Pass 80ms Dr OR Pass 120ms, UL & Light 80ms, UL & Light
18 Arm 1 Input Auto Detect Posive Negave
19 Disarm 1 Input Auto Detect Posive Negave
20 Arm 2 Input Auto Detect Posive Negave
21 Disarm 2 Input Auto Detect Posive Negave
22 Trunk Shunt Input Auto Detect Posive Negave
23 Dome Light Delay Timer OFF / Program 15sec 30sec
45sec 60sec 120sec
24 Alarm Trigger Length 30sec 45sec 60sec
90sec 120sec
Features
Opons
Features
Negave Output Control (NOC)
AUX Output Control
Factory Keyless Upgrade
Shock Sensor
Negave output control allows any NOC to be programmed for any one of the opons
below. This feature is accessible via FlashLogic Weblink or Weblink Mobile.
Any AUX output can be congured using the AUX Control Menu. This feature is only
accessible via FlashLogic Weblink or Weblink Mobile.
The shock sensor should be mounted to a solid surface in the center of the vehicle.
Once mounted the shock sensor will require adjustment.
To increase sensivity: Turn adjustment dial clockwise.
To decrease sensivity: Turn adjustment dial counter clockwise.
To test sensivity, strike the vehicle with an open palm. Adjust the dial to provide
coverage to as much of the vehicle as possible.
Important Update:
The default data port protocol of this system is ADS. When ashing the FLCAN, or other integraon module, be sure to choose iDatalink 2-Way as the installaon method.
This module will also support DBI. This will require programming Feature Bank 2, Feature 15 to DBI. For Technical Support Visit www.voxxuniversity.com or Call 1-800-225-6074.
Feature Programming
Dome Delay Programming
The APSSEC Feature Banks can be programmed by using the valet buon and the OEM or
Presge remote. To enter Feature Bank programming:
1. Turn the ignion key to ON.
2. Press and release the valet buon three (3) mes. System will beep and ash lights
one (1) me for Feature Bank 1, Remote Programming.
3. Cycle ignion key OFF/ON. System will beep and ash lights two (2) mes for
Feature Bank 2.
4. Press valet buon to cycle features. LED will ash to display feature number.
5. Press lock buon to cycle opons. System will beep to indicate opon number.
To exit Programming cycle ignion key OFF and wait ten (10) seconds. The System will also
automacally exit programming aer sixty (60) seconds of no acvity.
This system can be programmed to ignore the vehicle’s theater dimming dome light. This
feature will be used when connecng the door trigger input to the dome light circuit for
alarm trigger. Note: Vehicle windows should be open to prevent accidental locking of keys
in the vehicle.
Start with all doors closed and the vehicle dome light o.
1. Press Lock, Unlock, Lock, Unlock, Lock, Unlock, Lock. LED will light solid.
2. Open and close the driver door.
The system will monitor the dome light circuit. When the dome light turns o the system
will set the delay me and add an addional two (2) seconds.
Dome Delay Reset
1. Key ON/OFF, ON/OFF, ON/OFF.
2. Press and hold valet buon for ve (5) seconds.
The system will beep one (1) me to indicate reset is complete.
The Feature Bank below can also be programmed using the FlashLogic Weblink or Weblink Mobile.
Please visit www.FlashLogic.com for more detail.
The APSSEC does not include an RF remote kit. The RF remote kit Includes two (2) remotes,
one (1) antenna, and one (1) cable. When added, remotes must be programmed to
the system. Remote Programming is located in Feature Bank 1. To enter Remote Auto
Programming:
1. Turn the ignion key to ON.
2. Press and release the valet buon three (3) mes. System will beep and ash the
parking lights one (1) me.
Press the lock buon on each remote. The system will beep one (1) me to indicate the
remote has been programmed. If programming one (1) buon remotes, press the Start
buon. Only primary remote funcons are auto programmed. This Includes Lock, Unlock,
and Trunk/Start.
If using AUX output control, you must manually program the AUX output channels to
the remote. Please see the complete installaon guide for manual remote programming
instrucon.
Note: If programming 2-Way remotes, wait for the remote to beep before programming
addional remotes. This beep is conrmaon that a 2-Way response has been received
from the main module.
LED Output
Ch. 7 AUX Output
Horn Output
Ground While Armed
(GWA)
Ground While Disarmed
(GWD)
Ch. 3 ALT Output
Ch. 4 AUX Output
Ch. 5 AUX Output
Ch. 6 AUX Output
Lock Output
Unlock Output
Trunk Output
2nd Unlock Output
Dome Light Output
Head Light Output
1 Second Pulse
5 Second Pulse
10 Second Pulse
15 Second Pulse
20 Second Pulse
30 Second Pulse
Push & Hold
Latch ON/OFF
1 Shock
2 Trunk/Hood
3 Door
Data Protocol Selecon
REV. B 2020 Voxx Electronics. All Rights Reserved.
The APSSEC can be used without transmiers as a Factory Keyless Alarm Upgrade. Arm /
Disarm 1 inputs will be connected to the Driver Door Lock Motor. Arm / Disarm 2 inputs
will be connected to the Passenger Door Lock Motor and / or the Lock Switch. The control
polarity, by default, will be detected automacally upon power up. The Control polarity can
also be manually congured using Feature Bank 2, Features 18-21.
Note: If this feature is supported by FLCAN Arm / Disarm Wires are not required for install.
The Trunk Shunt input will be used if the vehicle is equipped with a factory power trunk
/ hatch release. If equipped, connect the Trunk Shunt input to the factory trunk release
trigger wire. The control polarity, by default, will be detected automacally upon power up.
The control polarity can also be manually congured using Feature Bank 2, Feature 22.
Trunk Trigger
Door Trigger
Instant Trigger
N.C. Door Trigger
Pre-Warn Shock Trigger
Hood Trigger
Fill Shock Trigger
Alarm
When the alarm is triggered the system will provide feedback to the user. Upon disarm,
the system will beep 4x and ash the LED to indicate the Alarm Trigger Zone.
Chirp Delete
System ARM/DISARM chirps can be toggled ON or OFF without entering the Feature
Bank programming.
1. Turn the ignion key ON/OFF.
2. Press and release the valet buon three (3) mes.
The system will respond with one (1) chirp for ON and two (2) Chirps for OFF. This
feature will not aect alarm trigger or programming.
User Programmable LED
System LED nocaons can be turned ON or OFF without entering Feature Bank
programming.
1. Turn the ignion key ON/OFF, ON/OFF.
2. Press and hold valet buon for ve (5) seconds.
The LED will ash one (1) me for ON, two (2) mes for OFF. This feature will not aect
LED ash during programming.
The default data port protocol of this model is ADS (iDatalink 2-Way). This model is
capable of detecng the correct data port protocol (ADS or DBI) and automacally
conguring Feature Bank 2; Feature 18. To inialize the detecon procedure:
1. Press and hold the valet buon.
2. Cycle the vehicle’s Ignion ON/OFF two (2) mes.
3. Release the valet buon.
The system will automacally detect and set the correct data port protocol, ADS or DBI.
Note: This feature is only available on module rmware v2.0 or higher.
PIC Input Control
Programmable Input Control allows any PIC be congured to one of the opons listed
below. This feature is accessible via FlashLogic Weblink or Weblink Mobile.
Notes
