Vulcan-Hart ESB36 Manual

FORM 30906 Rev. A (09-06)
ELECTRIC SALAMANDER BROILER
MODEL
VB73 ML-52249
VB73R ML-52248
ESB36 ML-52462
ESB48 ML-52468
ESB60 ML-52463
CATALOG OF
REPLACEMENT PARTS
MODEL VB73
VULCAN-HART
DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC
WWW.VULCANHART.COM
For additional information on Vulcan-Hart or to locate an authorized
parts and service provider in your area, visit our website at www.vulcanhart.com
P.O. BOX 696, LOUISVILLE, KY 40201-0696
TEL. [phone]

– 2 –
VB & ESB SERIES REPLACEMENT PARTS
CONTROLS & PANELS
ILLUS. PART
PL-22336A NO. NAME OF PART AMT.
1 00-412251-00001 Knob - Infinite Switch (208 - 240 V.) ............................................................................................... 2
2 00-411503-00003 Switch - Infinite (208 V.) ................................................................................................................. 2
3 00-411503-00002 Switch - Infinite (240 V.) ................................................................................................................. 2
4 00-407727-00002 Knob - Three Heat Switch (480 V.) ................................................................................................. 1
5 00-355798-00001 Switch (480 V.) ............................................................................................................................... 1
6 00-414639-00006 Tab - I.D. (480 V.) .......................................................................................................................... 1
7 00-408712-00003 Panel - Switch R.H. (SST)(208 - 240 V.) ........................................................................................ 1
8 00-408712-00001 Panel - Switch R.H. (PTD)(208 - 240 V.) ........................................................................................ 1
9 00-408712-00008 Panel - Switch R.H. (SST)(480 V.) ................................................................................................. 1
10 00-408712-00007 Panel - Switch R.H. (PTD)(480 V.) ................................................................................................. 1
11 00-408872-00005 Trim - Front Bottom (SST)(VB Series Only) ................................................................................... 1
12 00-408712-00004 Panel - L.H. (SST) .......................................................................................................................... 1
13 00-408712-00002 Panel - L.H. (PTD) ......................................................................................................................... 1
14 00-408700-00001 Baffle - Heat (Front) ........................................................................................................................ 1
00-408721-000G1 Panel - Back Splash Assy. (VB-73) ................................................................................................ 1
00-408715-000G2 Panel - Back Splash Assy. (SST - VB-73R) ................................................................................... 1
00-411501-00014 Circuit Breaker 50 Amp (208 - 240 V.) .......................................................................................... AR

– 3 –
REPLACEMENT PARTS VB & ESB SERIES
BROILER HEAT ELEMENTS
ILLUS. PART
PL-22337 NO. NAME OF PART AMT.
1 00-410498-00004 Element - Electric Heat (L.H.)(208 V.) ............................................................................................ 1
2 00-410498-00006 Element - Electric Heat (R.H.)(208 V.) ........................................................................................... 1
3 00-410498-00003 Element - Electric Heat (L.H.)(240 V.) ............................................................................................ 1
4 00-410498-00005 Element - Electric Heat (R.H.)(240 V.) ........................................................................................... 1
5 00-410498-00001 Element - Electric Heat (L.H.)(480 V.) ............................................................................................ 1
6 00-410498-00002 Element - Electric Heat (R.H.)(480 V.) ........................................................................................... 1
7 00-408705-000G2 Shield Assy. - Heat ......................................................................................................................... 1

– 4 –
VB & ESB SERIES REPLACEMENT PARTS
BROILER GRID & DRIP PAN
ILLUS. PART
PL-22109 NO. NAME OF PART AMT.
1 00-408689-00001 Grid - Broiler ................................................................................................................................... 1
2 00-408709-00001 Pan - Drip ....................................................................................................................................... 1
00-409962-00001 Pan - Grease Collector ................................................................................................................... 1
– 4 –

– 5 –
REPLACEMENT PARTS VB & ESB SERIES
RECOMMENDED SPARE PARTS LIST
PART
NO. NAME OF PART AMT.
00-410498-00006 Right Element 208V ....................................................................................................................... 2
00-410498-00005 Right Element 240V ....................................................................................................................... 2
00-410498-00002 Right Element 480V ....................................................................................................................... 2
00-410498-00004 Left Element 208V ......................................................................................................................... 2
00-410498-00003 Left Element 240V ......................................................................................................................... 2
00-410498-00001 Left Element 480V ......................................................................................................................... 2
00-411503-00003 Infinite Switch 208V ........................................................................................................................ 2
00-411503-00002 Infinite Switch 240V ........................................................................................................................ 2
00-419621-000G1 3-Heat Switch ................................................................................................................................. 1
