Vulcan-hart Ghcb40 Manual

FORM 30907 Rev A(12-06)

MODEL GHCB40 SHOWN

CATALOG OF

REPLACEMENT PARTS

MODELS MLS

IR1 ML-52200

IR2T ML-52207

IR2B ML-52201

GHIR44 ML-52210

CERAMIC BROILERS

HEAVY DUTY GAS BROILERS

MODELS MLS

GHCB40C ML-52212

GHCB40 ML-52211

GHCB44 ML-52213

GHMCB44 ML-52214

HCB1 ML-52202

HCB2T ML-52203

HCB2B ML-52208

SUNGLOW BROILERS

For additional information on Vulcan-Hart or to locate an authorized

parts and service provider in your area, visit our website at www.vulcanhart.com

VULCAN-HART

DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC

WWW.VULCANHART.COM

P.O. BOX 696, LOUISVILLE, KY 40201-0696

TEL. (800) 814-2028

- 2 -

HEAVY DUTY GAS BROILER REPLACEMENT PARTS

PARTS - FRONT VIEW IR1

PL-40422-1A

- 3 -

HEAVY DUTY GAS BROILER REPLACEMENT PARTS

PARTS - FRONT VIEW IR1

ILLUS.

PL-40422-1A PART NO. DESCRIPTION QTY.

1 00-407727-00005 BurnerKnob(On-Off) ................................................................................................................... 2

2 00-414269-00001 BurnerKnobCoverPlate.............................................................................................................. 1

3 00-407785-00002 GridArmHandle ........................................................................................................................... 1

4 00-413609-00001 GridArmCoverIndex Plate .......................................................................................................... 1

5 00-404549-00005 Right Grid Post............................................................................................................................. 1

6 00-404549-00006 Left Grid Post ............................................................................................................................... 1

7 00-404647-00001 GridHandle .................................................................................................................................. 1

8 00-411144-000G2 Burner Shield Cover(Top) ............................................................................................................ 1

9 00-413383-000G2 Legs(SST)................................................................................................................................... 4

10 00-408161-00001 GreaseCollector Front ................................................................................................................. 1

11 00-417700-00001 VulcanNameplate ........................................................................................................................ 1

12 00-410834-000G2 DeflectorAssy.............................................................................................................................. 1

13 00-409033-000G2 LockPanel ................................................................................................................................... 1

14 00-409030-000G4 BlowerCoverAssembly ............................................................................................................... 1

00-411040-000G1 DripTrayAssembly ...................................................................................................................... 1

00-407673-000G1 GreaseCollector .......................................................................................................................... 1

00-414639-00001 I.D. TAB “R”.................................................................................................................................. 1

00-414639-00002 I.D. TAB “L” .................................................................................................................................. 1

00-412681-00001 AdjustableFoot ............................................................................................................................ 4

- 4 -

HEAVY DUTY GAS BROILER REPLACEMENT PARTS

PARTS - FRONT VIEW IR2

PL-40423-1

- 5 -

HEAVY DUTY GAS BROILER REPLACEMENT PARTS

PARTS - FRONT VIEW IR2

ILLUS.

PL-40423-1 PART NO. DESCRIPTION QTY.

1 00-407727-00005 BurnerKnob(On-Off) ................................................................................................................... 4

2 00-414269-00001 BurnerKnobCoverPlate.............................................................................................................. 2

3 00-407785-00002 GridArm Handle ........................................................................................................................... 1

4 00-413609-00001 GridArmCoverIndex Plate .......................................................................................................... 2

5 00-404549-00005 Right Grid Post............................................................................................................................. 1

6 00-404549-00006 Left Grid Post ............................................................................................................................... 1

7 00-408161-00001 GreaseCollectorFront ................................................................................................................. 1

8 00-411144-000G2 Burner Shield Cover(Top) ............................................................................................................ 1

9 00-409840-00006 Legs(SST)................................................................................................................................... 4

10 00-410834-000G2 DeflectorAssembly ...................................................................................................................... 1

11 00-404647-00001 GridHandle .................................................................................................................................. 1

12 00-417700-00001 VulcanNameplate ........................................................................................................................ 1

13 00-411144-000G4 Burner Shield Cover (Bottom) ...................................................................................................... 1

14 00-409033-000G2 LockPanel ................................................................................................................................... 1

15 00-409030-000G4 BlowerCoverAssembly ............................................................................................................... 1

00-411040-000G1 DripTrayAssembly ...................................................................................................................... 1

00-407673-000G1 GreaseCollectorAssembly .......................................................................................................... 1

00-414639-00001 I.D.KnobTab“R” (New style notshown) ...................................................................................... 2

00-414639-00002 I.D.KnobTab“L” (New style notshown)....................................................................................... 2

- 6 -

HEAVY DUTY GAS BROILER REPLACEMENT PARTS

PL-40424-1

22-23

PARTS - FRONT VIEW GHCB40

- 7 -

HEAVY DUTY GAS BROILER REPLACEMENT PARTS

PARTS - FRONT VIEW GHCB40 / GHCB40C

ILLUS.

PL-40424-1 DESCRIPTION PART NO. QTY.

1 00-420560-00001 BurnerValveKnob........................................................................................................................ 2

2 00-404647-00001 GridHandle .................................................................................................................................. 1

3 00-407785-00002 GridArm Handle (Old style shown) ............................................................................................... 1

4 00-413609-00002 GridArm Cover/Index Plate (SS) .................................................................................................. 1

5 00-404549-00005 Right Grid Post............................................................................................................................. 1

6 00-404549-00006 Left Grid Post ............................................................................................................................... 1

7 00-409776-000G2 ManifoldCoverAssembly(SS) ....................................................................................................1

8 00-405488-000G2 AugratinOvenDoorAssembly .....................................................................................................1

9 00-409840-00006 (Adj.)Legs(SS)............................................................................................................................ 4

10 00-409790-00003 Right Oven Door Post .................................................................................................................. 1

11 00-409790-00004 Left Oven Door Post .................................................................................................................... 1

12 00-417700-00001 VulcanNameplate ........................................................................................................................ 2

13 00-401847-00001 OvenDoorHandle........................................................................................................................ 1

14 00-405499-00002 LowerBurner Cover (SS) ............................................................................................................. 1

15 00-409793-00001 Oven Handle (Lower).................................................................................................................... 1

16 00-404549-00001 Right Door Post ........................................................................................................................... 1

17 00-404549-00002 Left Door Post ............................................................................................................................. 1

18 00-420774-00001 ControlPanel-GHCB40(UsedUntil Oct. 2004) ............................................................................ 1

19 00-420784-00001 ControlPanel-GHCB40C(UsedUntil Oct. 2004).......................................................................... 1

20 00-402957-00002 Valve Handle(Red)....................................................................................................................... 1

21 00-420775-000G1 LowerFrontPanel ........................................................................................................................ 1

22 00-409791-000G2 OvenDoorAssembly (StdOven).................................................................................................. 1

23 00-409791-000G4 OvenDoorAssembly(Convection Oven) ..................................................................................... 1

24 00-409873-00001 GreaseCollectorFront ................................................................................................................. 1

00-417862-00009 Hinge Pin for Oven Door (RH or LH on Std Oven) (LH on Convection Oven) ............................. AR

00-497549-00001 HingePin (RH on ConvectionOven Door) ................................................................................... 1

00-404629-00002 DoorBushing ............................................................................................................................... 2

00-497126-00001 ControlPanel(GHCB40) (Oct. 2004 to Present) .......................................................................... 1

00-497126-00002 ControlPanel(GHCB40C)(Oct. 2004 to Present)........................................................................ 1

(SS)StainlessSteel

Photoshowsoldstylegrid handle assembly.

- 8 -

HEAVY DUTY GAS BROILER REPLACEMENT PARTS

PL-40425-1

9-10

FRONT VIEW IR44

PARTS - FRONT VIEW GHIR44

- 9 -

HEAVY DUTY GAS BROILER REPLACEMENT PARTS

PARTS - FRONT VIEW GHIR44

ILLUS.

PL-40425-1 PART NO. DESCRIPTION QTY.

1 00-407727-00004 BurnerValve Knob Hi-Med-Lo ...................................................................................................... 2

2 00-414878-000G2 FlueRiser ..................................................................................................................................... 1

3 00-407785-00002 GridArm Handle ........................................................................................................................... 1

4 00-413609-00002 GridArm Cover/IndexPlate(SS).................................................................................................. 1

5 00-404549-00005 Right Grid Post............................................................................................................................. 1

6 00-404549-00006 Left Grid Post ............................................................................................................................... 1

7 00-412945-000G3 Left HandDoorPanelAssembly (SS) .......................................................................................... 1

8 00-412945-000G4 Rt. Hd. Door PanelAssembly (SS)............................................................................................... 1

9 00-409840-00005 AdjustableLeg(Flanged Foot) ...................................................................................................... 4

10 00-409840-00006 AdjustableLeg (SS) (Bullet Foot).................................................................................................. 4

11 00-409653-00006 ManifoldCoverAssembly(SS) ....................................................................................................1

12 00-417700-00001 VulcanNameplate ........................................................................................................................ 1

13 00-408246-00001 GridHandle .................................................................................................................................. 1

14 00-405488-000G2 AugratinOven DoorAssembly .....................................................................................................1

15 00-404549-00001 Right Oven Door Post .................................................................................................................. 1

16 00-404549-00002 Left Oven Door Post .................................................................................................................... 1

17 00-401847-00001 Door Handle ................................................................................................................................. 1

18 00-405499-00002 BurnerBox Cover......................................................................................................................... 1

19 00-411496-000E4 PilotLight ..................................................................................................................................... 1

20 00-417812-00001 ToggleSwitch ............................................................................................................................... 1

21 00-408615-00021 CabinetDoor Handle .................................................................................................................... 2

00-411040-000G1 DripTrayAssembly ...................................................................................................................... 1

00-412942-00001 Lt.DoorPanel Lining .................................................................................................................... 1

00-412942-00002 Rt.DoorPanel Lining ................................................................................................................... 1

00-414639-00001 I.D. Tab “R”................................................................................................................................... 1

00-414639-00002 I.D. TAB “L” .................................................................................................................................. 1

00-405651-00001 HingePin(AugratinDoor) ............................................................................................................ 1

00-404629-00002 DoorBushing(AugratinDoor) ...................................................................................................... 1

00-405886-000G2 DoorHinge (LH) (Augratin Door).................................................................................................. 1

00-405886-000G1 DoorHinge (RH) (Augratin Door) .................................................................................................1

(SS)StainlessSteel

- 10 -

HEAVY DUTY GAS BROILER REPLACEMENT PARTS

PL-40426-1

9-10

PARTS - FRONT VIEW GHCB44

- 11 -

HEAVY DUTY GAS BROILER REPLACEMENT PARTS

PARTS - FRONT VIEW GHCB44

ILLUS.

PL-40426-1 PART NO. DESCRIPTION QTY.

1 00-402957-00002 BurnerValveKnob........................................................................................................................ 2

2 00-408246-00001 GridHandle .................................................................................................................................. 1

3 00-407785-00002 GridArm Handle (Old style shown) ............................................................................................... 1

4 00-413609-00002 GridArm Cover/Index Plate (SS) .................................................................................................. 1

5 00-404549-00005 Right Grid Post............................................................................................................................. 1

6 00-404549-00006 Left Grid Post ............................................................................................................................... 1

7 00-412945-000G1 DoorPanelAssembly,Left ........................................................................................................... 1

8 00-412945-000G2 DoorPanelAssembly,Right ......................................................................................................... 1

9 00-409840-00005 Adj. Leg (FlangedFoot) ................................................................................................................ 4

10 00-409840-00006 Adj.Leg (SS) (Bullet Foot)............................................................................................................ 4

11 00-409776-000G2 Manifold CoverAssembly (SS) ....................................................................................................1

12 00-405488-000G2 AugratinOvenDoorAssembly .....................................................................................................1

13 00-404549-00001 Right Oven Door Post .................................................................................................................. 1

14 00-404549-00002 Left Oven Door Post .................................................................................................................... 1

15 00-401847-00001 OvenDoorHandle........................................................................................................................ 1

16 00-405499-00002 LowerBurner Cover (SS) ............................................................................................................. 1

17 00-408615-00021 Door Handle ................................................................................................................................. 2

00-412942-00001 Left Door Liner ............................................................................................................................. 1

00-412942-00003 Left Door Liner (SS) ..................................................................................................................... 1

00-412942-00002 RightDoorLiner ........................................................................................................................... 1

00-412942-00004 RightDoor Liner (SS) ................................................................................................................... 1

00-405651-00001 HingePin(AugratinDoor) ............................................................................................................ 1

00-404629-00002 DoorBushing(AugratinDoor) ...................................................................................................... 1

00-405886-000G2 DoorHinge (LH) (Augratin Door).................................................................................................. 1

00-405886-000G1 DoorHinge (RH) (Augratin Door) .................................................................................................1

(SS)StainlessSteel

Photoshowsoldstylegrid handle assembly.

- 12 -

HEAVY DUTY GAS BROILER REPLACEMENT PARTS

PL-40427-1

9-10

CB - 2L

FRONT VIEW HCB2

PARTS - FRONT VIEW HCB2

- 13 -

HEAVY DUTY GAS BROILER REPLACEMENT PARTS

ILLUS. PART NO. DESCRIPTION QTY.

PL-40427-1 HCB1 HCB2

1 00-407727-00005 BurnerKnob(On-Off) ............................................................................... 2 ............................. 4

2 00-414269-00001 BurnerKnobCoverPlate.......................................................................... 1 ............................. 2

3 00-408246-00001 GridHandle ............................................................................................ 1 ............................. 2

4 00-413609-00001 GridArm Cover IndexPlate ...................................................................... 1 ............................. 2

5 00-404549-00005 RightGridHandle Post............................................................................. 1 ............................. 2

6 00-404549-00006 Left Grid HandlePost ............................................................................... 1 ............................. 2

7 00-408161-00001 GreaseCollectorFront ............................................................................. 1 ............................. 2

8 00-408132-000G6 BurnerShieldCover(Top) ........................................................................ 1 ............................. 1

9 00-413383-000G1 Adj.Legs ............................................................................................ 4 .............................

00-409840-00005 Adj.Legs ............................................................................................................................. 4

10 00-413383-000G2 Adj. Legs (SS) .......................................................................................... 4 .............................

00-409840-00006 Adj.Legs (SS) ........................................................................................................................... 4

11 00-411040-000G1 DripTrayAssembly .................................................................................. 1 ............................. 1

12 00-417700-00001 VulcanNameplate .................................................................................... 1 ............................. 1

13 00-408132-000G4 BurnerShieldCover (Bottom) ................................................................................................... 1

14 00-414639-00002 I.D. KnobTab “L”(Old style shown) .......................................................... 1 ............................. 2

15 00-414639-00001 I.D. KnobTab “R” (Oldstyle shown).......................................................... 1 ............................. 2

16 00-410834-000G2 DeflectorAssy. ......................................................................................... 1 ............................. 1

17 00-407785-00002 GridArm Handle ....................................................................................... 1 ............................. 1

00-407673-000G1 GreaseCollectorAssembly ...................................................................... 1 ............................. 1

(SS)StainlessSteel

FrontViewGHCB1Not Shown.

PARTS - FRONT VIEW HCB2

- 14 -

HEAVY DUTY GAS BROILER REPLACEMENT PARTS

PL-40428-1

PARTS - REAR VIEW IR1, IR2, GHIR44

ILLUS. PART NO. NAME OF PART QTY.

PL-40428-1 IR1 IR2 GHIR44 HCB1 HCB2

1 00-408987-000G1 BodyBack (Cabinet) ....................................................... 1 ............1 .................................................

00-408987-000G3 BodyBack(Cabinet) ........................................................................................................ 1................

00-408214-000G1 BodyBack(Cabinet) ........................................................................................................................... 1

2 FP-085-88 InletPipe ................................................................... 1............1 .................................................

FP-085-97 InletPipe .................................................................................................................... 1............... 1

3 00-405016-00001 Elec.Supply Cord............................................................ 1............1 ............. 1 ................................

4 00-408647-00001 Elec.Cover Plate ............................................................ 1............1 ............. 1 ................................

5 00-409896-00001 Body Back .................................................................................................... 1 ................................

00-408210-00003 BodyBack(Upper)..........................................................................1 ................................................ 1

00-405407-00003 BodyBack(Upper)........................................................................................... 1 ................................

00-408210-00001 BodyBack (Lower).......................................................... 1 ............1 ............................. 1............... 1

00-409158-00001 BodyBack (Lower)........................................................................................... 1 ................................

- 15 -

HEAVY DUTY GAS BROILER REPLACEMENT PARTS

PL-40429-1

2 3 4

7 thru 10

11 12

15-16 17

19 18

PARTS - FRONT VIEW FRAME REMOVED IR1 & IR2

ILLUS. PART NO. DESCRIPTION QTY.

PL-40429-1 IR1 IR2

1 00-415095-000G1 FrontBurner ShieldAssembly................................................................... 1 ............................. 2

2 FP-012-49 Fitting 1/2CC to 1/2MPT............................................................................ 2 ............................. 4

3 00-414861-00001 BurnerSub-Manifold(Priorto July 2004) .................................................. 2 ............................. 4

4 00-415133-00001 RightHand BurnerTube ........................................................................... 1 ............................. 2

5 00-415134-00001 Left Hand BurnerTube ............................................................................. 1 ............................. 2

6 FP-035-01 CloseNipple1/8" ....................................................................................... 4 ............................. 8

7 00-405643-0000F PilotElbowBurner .................................................................................... 4 ............................. 8

8 00-010901-00044 OrificeSpud(NAT.) .................................................................................. 4 ............................. 8

9 00-010901-00055 OrificeSpud(PROPANE)......................................................................... 4 ............................. 8

10 00-010901-00056 Orifice Spud(BUTANE)............................................................................ 4 ............................. 8

11 00-415089-00001 Air Transition Box ..................................................................................... 1 ............................. 1

12 00-409759-00002 PressureSwitchTubing ............................................................................ 1 ............................. 1

13 00-413552-00004 Blower Motor ........................................................................................... 1 ............................. 1

14 00-428578-000G1 Solenoid ............................................................................................ 1 ............................. 1

15 00-408279-00020 Regulator(NAT.)....................................................................................... 1 ............................. 1

16 00-408279-00021 Regulator (PROPANE & BUTANE) .......................................................... 1 ............................. 1

17 00-409033-000G2 LockPanel ............................................................................................ 1 ............................. 1

18 00-417812-00001 Toggle Switch ........................................................................................... 1 ............................. 1

19 00-411496-000E4 SignalLight ............................................................................................ 1 ............................. 1

20 00-415300-000G1 Air Transition Box ..................................................................................... 1 .............................

00-415299-000G1 AirTransitionBox ...................................................................................................................... 2

00-415807-00001 PilotShield ............................................................................................ 4 ............................. 8

00-497022-00001 BurnerSub-Manifold(July2004toPresent) ............................................. 1 ............................. 1

- 16 -

HEAVY DUTY GAS BROILER REPLACEMENT PARTS

PARTS - FRONT VIEW FRAME REMOVED HCB2

ILLUS. PART NO. DESCRIPTION QTY.

PL-40430-1 HCB1 HCB2

1 00-010901-00042 PilotBurner Orifice (NAT.) ........................................................................ 4 ............................. 8

2 00-010901-00053 PilotBurner Orifice(PROPANE) .............................................................. 2 ............................. 4

3 00-405643-0000F ElbowNozzle ........................................................................................... AR .......................... AR

4 00-411463-000G1 Pilot ManifoldAssembly ........................................................................... 1 .............................2

5 00-413607-000G1 GridArm LiftingAssembly ........................................................................ 1 ............................. 2

6 00-408770-000G1 UpperLeverArmAssembly ...................................................................... 1 ............................. 2

7 00-408774-000G1 LowerLeverArmAssembly ...................................................................... 1 ............................. 2

8 00-497762-000G1 GridCarriageAssembly ........................................................................... 1 ............................. 2

9 00-405655-00003 RollerBearing With Shaft ......................................................................... 2 .............................4

10 00-408078-00001 Rt.Hd. Burner Tubing ............................................................................... 1 ............................. 2

11 00-408328-00001 Rt.BurnerTubingValvetoDouble CCFitting ........................................... 1 ............................. 1

12 00-408329-00001 Lt.BurnerTubingFittingto Valve .............................................................. 1 ............................. 1

13 00-407789-00001 BurnerValve ............................................................................................ 2 ............................. 4

14 00-408076-000G1 Sub - ManifoldAssembly .......................................................................... 1 ............................. 2

15 00-407724-00001 SpringLiftingArm(Inner) .......................................................................... 2 ............................. 4

16 00-401992-00002 SpringLiftingArm(Outer) ......................................................................... 2 .............................4

17 FP-012-01 Fitting 3/8" to 1/2" CC .................................................................................. 2 ............................. 4

18 FP-016-02 Elbow Street 1/2" x 3/8" ............................................................................... 2 ............................. 4

19 FP-012-49 FittingStraight1/2" x 1/2" CC....................................................................... 2 ............................. 4

20 FP-077-36 FittingStraightDouble 1/2" CC................................................................... 2 ............................. 4

21 FP-012-21 Elbow 1/8" NPS x1/4" CC........................................................................... 1 ............................. 2

22 00-426505-00014 Pilot Tube Valve to CC Elbow .................................................................. 1 .............................

00-415229-00001 Pilot Tube Valve to CC Elbow ................................................................................................... 2

23 00-408199-000G1 1" Manifold Pipe ....................................................................................... 1 ............................. 2

24 FP-079-97 ElbowReducing 1" x3/4" ........................................................................... 2 ............................. 4

00-405655-00001 RollerBearingWithoutShaft .................................................................... 2 ............................. 4

PL-40430-1

1-2-3

- 17 -

HEAVY DUTY GAS BROILER REPLACEMENT PARTS

PARTS - GRID ASSEMBLY HCB2

ILLUS. PART NO. DESCRIPTION QTY.

PL-40431-1 HCB1 HCB2 GHCB40 GHCB44

1 00-417074-000G1 GridFinalAssembly...................................................................................... 1 ........ 2 ..........1........... 1

2 00-411551-000G1 BurnerAssembly .......................................................................................... 4 ........ 8 ..........4........... 4

3 00-404146-00001 BurnerSideCeramics .................................................................................. 8 ........ 16 ........8........... 8

4 00-404145-00001 BurnerCenter Ceramics ............................................................................... 12 ...... 24 .......12......... 12

5 SC-036-08 Grid Stop Bolt Hex Head 1/4" x 1 1/4" ............................................................. 3 ........ 6 ..........3........... 3

6 00-497762-000G1 GridCarriage................................................................................................ 1 ........ 2 ..........1........... 1

00-408111-00002 Drip Shield Rod ............................................................................................ 1 ........ 2 ..........1........... 1

00-413607-000G1 LiftingArmAssembly .................................................................................... 1 ........ 2 .........................

00-413612-000G1 LiftingArmAssembly ..............................................................................................................1........... 1

00-416844-00001 FrontCookingGrate..................................................................................... 1 ........ 2 ..........1........... 1

00-416845-00001 RearCookingGrate ..................................................................................... 1 ........ 2 ..........1........... 1

00-408726-000G2 CeramicSet (8 Sides & 12 Centers) ............................................................ 1 ........ 2 ..........1........... 1

00-408244-000G2 Brick Support(Left Side) .............................................................................. 1 ........ 2 ..........1........... 1

00-408244-000G1 BrickSupport(RightSide) ............................................................................ 1 ........ 2 ..........1........... 1

PL-40431-1

346

- 18 -

HEAVY DUTY GAS BROILER REPLACEMENT PARTS

PL-40432-1

PARTS - UPPER MANIFOLD ASSEMBLY GHCB40

ILLUS.

PL-40432-1 PART NO. DESCRIPTION QTY.

1 00-404738-00003 PilotValve .................................................................................................................................... 4

2 00-409873-00001 GreaseCollector Front Panel(SS) ...............................................................................................1

3 00-409899-000G1 GreaseCollectorAssembly .......................................................................................................... 1

4 00-408379-00003 BurnerValve ................................................................................................................................. 2

5 00-408079-00001 BurnerValveTube,Rt................................................................................................................... 1

6 00-408079-00002 BurnerValveTube,Lt. .................................................................................................................. 1

7 00-411696-00001 PilotSupplyTube ......................................................................................................................... 1

00-010901-00032 OrificeSpudNat.Gas (Ceramic Burner)....................................................................................... 4

00-010901-00053 OrificeSpudPropaneGas(Ceramic Burner) ................................................................................ 4

00-010901-00054 OrificeSpudButane Gas (Ceramic Burner) .................................................................................. 4

00-405643-0000F ElbowNozzle(CeramicBurner) ...................................................................................................4

00-411469-00002 Pilot LighterTube(CeramicBurner).............................................................................................. 4

00-408485-00080 Nozzle(Nat.Gas)......................................................................................................................... 4

00-408485-00010 Nozzle (LP or MFG Gas) ............................................................................................................. 4

(SS)StainlessSteel

- 19 -

HEAVY DUTY GAS BROILER REPLACEMENT PARTS

PL-40433-1

123-4

PARTS - GHIR44 WITH MANIFOLD COVER DROPPED

ILLUS.

PL-40433-1 PART NO. DESCRIPTION QTY.

1 00-413500-00E98 Drop Pipe 3/4" x 12 1/4" .................................................................................................................. 1

2 00-408422-000G1 Sub-Manifold ................................................................................................................................1

3 00-408119-0001L Valve HI-MED-LO (PROPANE & BUTANE)................................................................................. 2

4 00-408119-0001N Valve HI-MED-LO (NAT.).............................................................................................................. 2

5 FP-013-22 Elbow 3/4" 90° ............................................................................................................................... 1

- 20 -

HEAVY DUTY GAS BROILER REPLACEMENT PARTS

PARTS - BURNER TUBING ASSEMBLY LT. & RT. GHIR44

ILLUS.

PL-40434-1 PART NO. DESCRIPTION QTY.

1 00-407785-00002 GridHandle .................................................................................................................................. 1

2 00-414863-00001 BurnerTubing ............................................................................................................................... 2

3 FP-077-36 Fitting 1/2x1/2CC .......................................................................................................................... 2

4 00-414749-00001 Lt.Hd. BurnerTubing.................................................................................................................... 1

5 00-414866-00001 Rt. Hd.Burner Tubing ................................................................................................................... 1

PL-40434-1
