MODEL: ESB SERIES Medium Duty Electric Elevated Salamander Broilers
ESB SERIES
MEDIUM DUTY ELECTRIC ELEVATED
SALAMANDER BROILERS
■■ESB36 For use with a 36" wide range.
■■ESB60 For use with a 60" wide range. Includes a EDD24
double deck high shelf with left end cap.
STANDARD FEATURES
■Stainless steel front, sides, top and backsplash.
■Two 3 KW solid sheathed heating elements, 6 KW total input.
■Elements controlled individually by separate infinite heat
switches.
■Three position broiler grid measures 25"w x 13"d.
■208 or 240 volt, 1 or 3 phase.
■One year limited parts and labor warranty.
OPTIONS
■■Stainless steel finishing back.
■■Second year extended limited parts and labor warranty
contract.
SPECIFICATIONS:
Medium duty electric elevated broiler, Vulcan-Hart Model No.
(ESB36) (ESB60) for use over Vulcan Model No. __________
electric range. Stainless steel front, sides, top and backsplash.
Broiler grid measures 25"w x 13"d and has three locking positions.
One gallon capacity drip pan located outside of the heat zone.
Two solid sheathed heating elements rated at 3 KW each, 6 KW
total input. Elements are controlled individually by separate
infinite heat control switches. Requires 208 volt or 240 volt, 1 or
3 phase power supply.
NSF listed. U L listed. U L listed to Canadian safety standards.
Model ESB36 Shown

VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
Printed On Recycled Paper
NOTE: In line with its policy to continually improve its products, Vulcan-Hart Company reserves the right to change materials and
specifications without notice.
F-32250 (10-02)
ESB SERIES
MEDIUM DUTY ELECTRIC ELEVATED
SALAMANDER BROILERS
IMPORTANT
1. An adequate ventilation system is required for commercial
cooking equipment. Information may be obtained by writing to
the National Fire Protection Association, Batterymarch Park,
Quincy, MA 02269. When writing refer to NFPA No. 96.
2. All models require an 8" clearance at both sides and a 2"
clearance in the rear adjacent to combustible and non-
combustible construction.
3. This appliance is manufactured for commercial installation
only and is not intended for home use.
Model ESB60
Amps with Broiler
KW with Broiler 208V 240V
Model X-Y Y-Z Z-X 1 ph X-Y Y-Z Z-X 1ph X-Y Y-Z Z-X 1ph
E36L 78823.0 62.5 62.5 66.6 110.6 54.1 54.1 57.7 95.8
E366SL 77.4 8 22.4 62.5 60.0 64.1 107.7 54.1 52.0 55.6 93.3
E36FL 76.8 8 21.8 62.5 57.5 61.6 104.8 54.1 49.8 53.4 90.8
E36XL 6.4 6.8 8 21.2 60.0 55.0 61.6 101.9 57.0 47.6 53.4 88.3
E60L 12 12 12 36 99.9 99.9 99.9 173.1 86.6 86.6 86.6 150
E60SL 12 11.4 12 35.8 99.9 97.4 97.4 170.2 86.6 84.4 84.4 147.5
E60FL 12 11.4 11.4 34.8 97.4 97.4 94.9 167.3 84.4 84.4 82.3 145
E60XL 12 10.8 11.4 34.2 97.4 94.9 92.4 164.4 84.4 82.3 80.1 142.5
Model ESB36
ESB Side View
