Vulcan-Hart GHCB40 User manual

Item # __________________________
C.S.I. Section 11420
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
0
8
7
2
A
1
0
0
9
O
S
I
.
o
C
t
r
a
H
-
n
a
c
l
u
V
F-31539 (05-06)
0
4
B
C
H
G
:
L
E
D
O
M
Oven Base
d
n
a
n
e
v
O
g
n
i
h
s
i
n
i
F
h
t
i
w
r
e
l
i
o
r
B
c
i
m
a
r
e
C
s
a
G
SPECIFICATIONS
Heavy duty single section gas ceramic broiler with nishing oven.
Vulcan-HartModelNo.GHCB40.Stainless steel body and 6"
adjustable legs. 1 1⁄4" diameter front gas manifold. Four 25,000
BTU/hr. ceramic burners, 100,000 BTU/hr. input. Pilot ignition
system. Two innite heat control valves. Floating grid .
assembly with positive positioning control handle. Eight grid
positions. Broiler grid measures 25"w x 27 1⁄2"d. 26"w x 28"d
nishing oven heated by broiler burners. Standard oven mea-
sures 26"w x 28"d x 14"h. Porcelain enamel on steel hearth,
door and side liners. One oven rack and two rack positions.
50,000 BTU/hr. "Flame Retention" burner with pilot ignition.
Thermostat adjusts from 150° to 500°F. Oven controls located in
the cool zone.
Exterior dimensions: 34"w x 39 1⁄8"d x 79"h on 6" legs.
CSA design certied. NSF listed.
SPECIFY TYPE OF GAS WHEN ORDERING.
SPECIFY ALTITUDE WHEN ABOVE 2,000 FT.
MODEL GHCB40
HEAVY DUTY GAS CERAMIC BROILER WITH
FINISHING OVEN AND OVEN BASE
STANDARD FEATURES
Stainless steel body and 6" adjustable legs.
11⁄4" diameter front gas manifold.
Four 25,000 BTU/hr. ceramic burners, 100,000 BTU/hr. input.
Pilot ignition system.
Two innite heat control valves.
Floating grid rack assembly with positive positioning
control handle. Eight grid positions. Broiler grid measures
25"w x 27 1⁄2"d.
26"w x 28"d nishing oven heated by broiler burners.
Oven interior measures 26"w x 28"d x 14"h. Porcelain
enamel on steel hearth, door and side liners. One oven rack
and two rack positions. 50,000 BTU/hr. "Flame Retention"
burner with pilot ignition. Thermostat adjusts from 150° to
500°F. Oven controls located in the cool zone.
One year limited parts and labor warranty.
OPTIONS
Stainless steel back nishing panel.
Common front top ledge up to 68" wide. (Not for use on griddle
tops, spreader plates and deep fat fryers.)
Cap and cover manifold end(s). (No charge.)
15⁄8" stainless steel toe base, 74 5⁄8" overall height.
Set of four 5" diameter casters, two locking.
Stainless steel dolly frame with casters, up to 102" wide.
Cooling fan for Snorkel convection oven motor. Required
whenunitisinstalledwitha back nishing panel or a toe base.
Rear gas connection. (Reference spec sheet F-31525.)
Second year extended limited parts and labor warranty.
ACCESSORIES
Additional oven rack(s).
Gas pressure regulator (specify size and type of gas).
Flexible gas hose with quick disconnect and restraining
device. Consult price book for available sizes.
GHCB40 Ceramic Broiler with Finishing Oven
and Standard Oven Base
GHCB40C Ceramic Broiler with Finishing Oven
and Convection Oven Base
Convection oven in place of standard oven. Add sux “C” to
the model number.

Printed On Recycled Paper
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
NOTE: In line with its policy to continually improve its products, Vulcan-Hart Company reserves the right to change materials and
specications without notice.
F-31539 (05-06)
MODEL GHCB40
HEAVY DUTY GAS CERAMIC BROILER WITH
FINISHING OVEN AND OVEN BASE
IMPORTANT
1. A gas pressure regulator suitable for battery or single unit
application must be furnished and installed. Natural gas 6.0"
W.C., propane gas 10" W.C.
2. An adequate ventilation system is required for commercial
cooking equipment. Information may be obtained by writing to
the National Fire Protection Association, Batterymarch Park,
Quincy, MA 02289. When writing, refer to NFPA No. 96.
3. These units are manufactured for installation in accordance
with ANSZ223.1A (latest edition), National Fuel Gas Code.
Copies may be obtained from the American Gas Association,
1515 Wilson Blvd., Arlington, VA 22209.
4. All models require a 6" (152 mm) clearance at both sides and
rear adjacent to combustible construction.
5. This appliance is manufactured for commercial installation
only and is not intended for home use.
