Vulcan-Hart VST4B Manual

F-35697 (10-07)
CATALOG OF
REPLACEMENT PARTS
GAS FIRED
STEAK BROILER
MODEL
VST4B ML-136590-Z
For additional information on Vulcan-Hart or to locate an authorized parts
and service provider in your area, visit our website at www.vulcanhart.com.
VULCAN-HART
DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC
WWW.VULCANHART.COM
3600 NORTH POINT BLVD.
BALTIMORE, MD 21222

- 2 -
GAS FIRED BROILER
VST4B GAS FIRED BROILER
1
2
3, 39, 39a, 39b
4
11
97
12
16
14
20
13
26
27
28
32
25
24
24
17
19
18
33
34
35
31 15
6
5
22
30
29
29
21
39, 39a
40
21a
21b
21c
8
10
13a
13a
13c
13c
13c

- 3 -
GAS FIRED BROILER
VST4B GAS FIRED BROILER PARTS LIST
ITEM P/N YTQNOITPIRCSED
1 499143-2 CASTER, W/LOCK ....................................................................................................... 2
2 499143-1 CASTER, W/OUT LOCK ............................................................................................... 2
3 499180-G2 UPPER LEG ASSEMBLY (LONG - 56” GRIDDLE HEIGHT)........................................ 4
4 499179-G2 STAND SHELF .............................................................................................................. 1
5 404193-1 PILOT ADJUSTMENT VALVE ...................................................................................... 3
6 408379-4 BURNER VALVE 7/16 TUBE FITTING.......................................................................... 3
7 497844-1 RIGHT INTERIOR GRIDDLE PLATE SUPPORT .......................................................... 1
8 497828-1 LEFT INTERIOR GRIDDLE PLATE SUPPORT .............................................................. 1
9 499942-1 PLATE SUPPORT ......................................................................................................... 1
10 497851-2 BURNER BRICK BRACKET........................................................................................ 6
11 499136-1 LIFT SPRING ................................................................................................................. 2
12 499135-1 LIFT SPRING EYE BOLT............................................................................................... 2
13 499130-1 BROILER BEARING ...................................................................................................... 10
14 499409-G1 ELEVATOR ASSEMBLY .............................................................................................. 1
15 499408-G1 HANDLE LIFT ASSEMBLY .......................................................................................... 1
16 499206-1 SPACER .343 X .750 X .125 ....................................................................................... 8
17 499137-1 BROILER PILOT ............................................................................................................ 3
18 499128-G1 STEAK BROILER PILOT TUBE ASSEMLBY ............................................................... 3
19 404079-F NOZZLE & NUT ............................................................................................................ 3
19b 418051-44 BURNER ORIFICE HOOD-PROPANE GAS.............................................................. 3
20 499930-G2 FLUE ASSEMBLY...................................................................................................... 1
22 499060-1 FRONT LOWER TRIM PANEL ...................................................................................... 1
23 DELETED DELETED........................................................................................................................ 0
24 497850-3 BURNER BRICK SUPPORT .......................................................................................... 6
25 499181-G1 STEAK BROILER BURNER ASSEMBLY....................................................................... 3
26 499217-G1 STEAK BROILER CARRIAGE WITH BEARINGS ......................................................... 1
27 497810-1 RIGHT GRILL ................................................................................................................. 1
28 497809-1 LEFT GRILL ................................................................................................................... 1
29 499220-G1 STEAK BROILER DRIP TRAY ASSEMBLY ................................................................ 1
30 499055-1 DRIP TRAY ................................................................................................................... 1
31 499132-1 HANDLE BALL .............................................................................................................. 1
32 499218-G1 STEAK BROILER DRIP PAN ASSEMBLY ................................................................... 1
33 499407-G1 DRIPCOLLECTOR ........................................................................................................ 1
34 499062-1 FRONT UPPER TRIM PANEL ........................................................................................ 1
36 DELETED DELETED.................. .................................................................................................... 0
37 DELETED DELETED....................................................................................................................... 0
38 FP-028-42 PIPE PLUG 1/8 NPT..................................................................................................... 1
39 723369 SCREW 1/4-20 x 1/2 TRUSS HEAD ............................................................................. 18
40 499432-1 WIRE BRUSH ................................................................................................................ 1
426505-36 PILOT FLEX TUBE 36”(LEFT)(NOT SHOWN) ................................................................ 1
426508-42 MAIN GAS FLEX TUBE 42”(RiIGHT)(NOT SHOWN) ..................................................... 1
3a 499180-G3 UPPER LEG ASSEMBLY (SHORT - 52” GRIDDLE HEIGHT)...................................... 4
13a SC-126-59 SCREW.......................................................................................................................... 10
13b NS-041-04 NUT................................................................................................................................ 10
13c SC-113-90 SCREW.......................................................................................................................... 6
19a 418051-31 BURNER ORIFICE HOOD-NATURAL GAS............................................................... 3
21 499122-G1 STEAK BROILER GRIDDLE PLATE ASSEMBLY ....................................................... 1
21a SC-113-65 LEVELING BOLT................................... .................................................................... 2
21b WS-022-21 WASHER (LEVELING BOLT)..................................................................................... 2
21c NS-046-86 NUT (LEVELING BOLT)............................................................................................. 2
35 499480-G1 CERAMIC BRICKS, SET (30 CENTER BRICKS, 12 END BRICKS)............................ 1 BOX
426505-54 PILOT FLEX TUBE 54” (CENTER) (NOT SHOWN) .................................................... 1
426508-36 MAIN GAS FLEX TUBE 36”(LEFT)(NOT SHOWN) ....................................................... 1
426505-42 PILOT FLEX TUBE 42” (RIGHT)(NOT SHOWN)............................................................. 1
426508-54 MAIN GAS FLEX TUBE 54”(CENTER)(NOT SHOWN).................................................. 1
39a NS-046-52 NUT, ASSY 1/4-20 ......................................................................................................... 18
39b WS-017-06 WASHER, FLAT 1/4....................................................................................................... 16
408279-12 REGULATOR - NAT 1 1/4 NPT (NOT SHOWN) ....................................................... 1
408279-13 REGULATOR - PRO 1 1/4 NPT (NOT SHOWN) ...................................................... 1
