Vulcan-Hart VGLT20 User manual

Item # __________________________
C.S.I. Section 11420
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
A2780
ISO9001
Vulcan-Hart Co.
F-32051 (10-03)
SPECIFICATIONS:
Self generating gas fired power burner, all welded type 304,
2/3jacketed tilting steam kettle, Vulcan-Hart Model
No. (VGLT20) (VGLT30) (VGLT40) (VGLT60). Fully welded
hemispherical bottom kettle with type 304 stainless steel
jacket and lining. (Type 316 stainless steel liner 20, 30 & 40
gallons only.) Jacket tested to 50 psi (3.4 kg/cm2). Factory
charged with chemically pure water, rust inhibitor, and
antifreeze for protection against freezing to -30°F. Kettle
exterior is fully insulated. Kettles mounted on trunnions
connected to the control and gear consoles. The worm gear
tilting mechanism is self locking and allows the kettle to tilt a full
90°. Trunnion cover with provision for faucet. Recessed control
panel located on front of kettle. Controls include direct immersion
thermostat, water sight glass, cooking light, pressure gauge
and electronic ignition with ignitions indicator light. Safety
features include low water cut-off, pressure relief valve,
pressure switch and gas shut-off valve. Requires a 120 volt,
60 Hz, 1 phase power supply, 3.0 amp. 6' cord and plug
supplied. 3/4" rear gas connection with gas pressure regulator.
CSA design certified. NSF listed. Meets ASME code.
SPECIFY TYPE OF GAS WHEN ORDERING.
SPECIFY ALTITUDE WHEN ABOVE 2,000 FT.
VGLT SERIES
GAS TILTING 2/3JACKETED KETTLE
MODELS: VGLT SERIES Gas Tilting 2/3Jacketed Kettle
■■VGLT20 80,000 BTU/hr., 20 gallon capacity.
■■VGLT30 100,000 BTU/hr., 30 gallon capacity.
■■VGLT40 100,000 BTU/hr., 40 gallon capacity.
■■VGLT60 120,000 BTU/hr., 60 gallon capacity.
STANDARD FEATURES
■Self generating gas fired power burner, all welded type
304 stainless steel, 2/3jacketed tilting steam kettle.
■Fully welded hemispheric bottom kettle with type 304 stainless
steel jacket and liner. (Type 316 stainless steel liner 20, 30 &
40 gallons only). Jacket tested to 50 psi (3.4 kg/cm2).
■Factory charged with chemically pure water, rust inhibitor, and
anti-freeze for protection against freezing to -30°F.
■Kettle exterior is fully insulated.
■Kettles mounted on trunnions connected to the control and
gear consoles. The worm gear tilting mechanism is self locking
and allows the kettle to tilt a full 90°. Trunnion cover with
provision for faucet.
■Recessed control panel located on front of kettle. Controls
includedirectimmersionthermostat,watersightglass,cooking
light, pressure gauge and electronic ignition with ignitions
indicator light.
■Safety features include low water cut-off, pressure relief valve,
pressure switch and gas shut-off valve.
■Requires a 120 volt, 60 Hz, 1 phase power supply, 3.0 amp. 6'
cord and plug supplied.
■3/4" rear gas connection with gas pressure regulator.
■One year limited parts and labor warranty.
OPTIONS
■■Spring assist cover.
■■Spring assist cover with condensate ring.
■■Two piece hinged cover.
■■Correction facility package.
a. Controls protected by lockable cover (lock by others).
b. Security type tamper resistant fasteners with tack welds.
c. Perforated flue cover.
d. Stainless steel cover over draw-off with chain.
■■Tilting kettle strainer.
■■2" draw-off valve with perforated strainer.
■■3" draw-off valve with perforated strainer.
■■Type 316 stainless steel liner, 60 gallons.
■■Second year extended limited parts and labor warranty.
ACCESSORIES
■■18" double jointed single pantry faucet.
■■18" double jointed double pantry faucet.
■■Double pantry washdown hose with 16" add-on faucet with
backflow preventer.
■■Double pantry washdown hose with backflow preventer.
■■Double pantry pot filler and backflow preventer.
■■Contour measuring strip.
■■Triple perforated stainless steel basket assembly.
■■Draw-off valve strainer, solid.
■■Clean-up kit; includes draw-off brush, clean-up brush w/36"
handle and paddle scraper w/40" handle with nylon blade.
■■Stainless steel 48" wire whip.
Shown with optional spring assist cover

Printed On Recycled Paper
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
NOTE: In line with its policy to continually improve its products, Vulcan-Hart Company reserves the right to change materials and
specifications without notice.
F-32051 (10-03)
VGLT SERIES
GAS TILTING 2/3JACKETED KETTLE
GS: See #1 & #2 above.
EC: See #3 above.
5. These units are manufactured for installation in accordance with
ANSZ223.1a (latest edition), National Fuel Gas Code. Copies may be
obtained from the American Gas Association, 1515 Wilson Blvd.,
Arlington, VA 22209.
6. Equipment clearance: Combustible Non-Combustible
Rear 4" 4"
Right 0" 0"
Left 0" 0"
Floor N/A 6"
7. This appliance is manufactured for commercial installation only and is
not intended for home use.
IMPORTANT:
1. A pressure regulator sized for this unit is included. Minimum supply
pressure: Natural gas 7" W.C. Propane 11" W.C.
2. Gas line connecting to unit must be 3/4" or larger. If flexible connectors
are used, the inside diameter must be at least the same as the 3/4" iron
pipe and rated for the correct gas input.
3. Requires 120 volt, 60 Hz, 1 phase electrical connection. Furnished
with 6' cord and 3 prong plug. 3 amp total draw.
4. An adequate ventilation system is required for commercial cooking
equipment.Informationmaybeobtainedby writing to theNational Fire
Protection Association, Batterymarch Park, Quincy, MA 02269. When
writing, refer to NFPA No. 96.
MODEL BTU/HR. BRIMFUL 4 OZ.
NO. INPUT CAPACITY* SVGS. A B C D E F G H J K L M
VGLT20 80,000 20 gal., 80 qts. 640 20 481/8405/819 401/8761/2161/224 11 10 32 301/2
76 liters 508 1222 1032 483 1020 1943 419 610 280 254 813 775
VGLT30 100,000 30 gal., 120 qts. 960 26 541/4435/8161/2371/4733/4151/2221/471/211 34 291/2
114 liters 660 1378 1108 419 946 1874 394 565 190 279 864 749
VGLT40 100,000 40 gal., 160 qts. 1280 26 541/4435/8161/2411/276 151/2221/471/212 35 301/2
152 liters 660 1378 1108 419 1054 1930 394 565 190 305 889 775
VGLT60 120,000 60 gal., 240 qts. 1920 30 581/8455/8177/8451/282 191/2221/451/215 38 303/8
227 liters 762 1378 1108 454 1156 2083 496 565 140 381 965 772
* Working capacity 70% to 80% of brimful depending on model.
