MODEL: E36L SERIES Electric Restaurant Ranges
■ E12HT Hot Tops
■ E12FP French Hot Plates
STANDARD FEATURES
■Stainless steel front, 2 stainless sides.
■Stainless steel front top ledge.
■5" stainless steel vented back splash.
■Fully enclosed 31"h body with removable front panel.
■6" stainless steel adjustable legs.
■One year limited parts and labor warranty.
OPTIONS
■480 volts, 60 Hz, 1 ph (E12HT & E12FP).
■480 volts, 60 Hz, 3 ph (E12FP only).
■Second year extended limited parts and labor warranty.
E12HT & E12FP
ELECTRIC EXPANDO RANGES
SPECIFICATIONS:
E12HT (Hot Top)
1 - 12" x 24" (305 mm x 610 mm) 5 KW cast hot top
thermostatically controlled. Temperatures range from 340°
to 750°F (171° to 427°C). Hot top not suitable
for griddle work. (Available in single phase only.)
E12FP (French Plate)
2 - 91⁄2" (241 mm) diameter, infinite heat controlled 2 KW
round cast* surface units supported in top sections of
porcelain enameled steel. Total 4 KW input for range top.
*The 9 1/2" round cast surface units are identified as E.G.O. units.
Each 9 1/2" round casting is rated 2000 watts at either 208, 240
or 480 volts. Each 9 1/2" round casting is controlled by an infinite
heat switch on 208 and 240 volt units. On 480 volt units each
casting is controlled by a 3 position heat switch.
High= 2000 W
Med= 1000 W
Low= 500 W
NSF listed. U L listed. U L listed to Canadian safety standards.
SPECIFY VOLTAGE AND PHASE WHEN ORDERING.
Model E12FP

VULCAN-HART COMPAN Y, P.O. BOX 696, LOUISVILLE, KY 40201,TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
NOTE: In line with its policy to continually improve its products, Vulcan-Hart Company reserves the right to change materials and
specications without notice.
Printed On Recycled Paper
F-32153 (4-07)
E12HT & E12FP
ELECTRIC EXPANDO RANGES
E12FP & E12HT
208/240 VOLT
UNIT
TOTAL
KW
CONN.
LOAD KW P ER P HASE
3-P HASE
L1-L2 L2-L3 L1-L3
E12HT 5 — — —
E12FP 4 2.0 2.0 —
NOR MAL A MP S P ER LINE
3- P HASE 1- P HASE
208V 240V 208V 240V
L1 L2 L3 L1 L2 L3 L1-L2 L1-L2
E12HT — — — — — — 24 21
E12FP 8 17 8 7 14 7 19 17
E12FP & E12HT
480 VOLT
UNIT
TOTAL
KW
CONN.
LOAD KW P ER P HASE
3-P HASE
X- Y Z Y -Z
E12HT 5 — — —
E12FP 4 2.0 2.0 —
NOR MAL A MP S P ER LINE
3-P HASE 1-P HASE
480V 480V
X Y Z X-Z
E12HT — — — 10.4
E12FP 3.6 7.2 3.6 8.3
