Vutlan HAT-100Q1 Operating and maintenance instructions

Quick Installation
& Conguration manual
AC Measurement
HAT-100Q1 & VT407

Installation Manual AC measurement
Function
Simple open loop AC current transducer HAT-
100Q1 can measure AC currents in range of
0-100A. To transfer data to the monitoring
system it can be used together with AC current
transceiver VT407.
Safety instructions
• Please observe the valid regulations for
installation in the country in which cur-
rent transducer is installed and operated,
and the national regulations for accident
prevention. Please also observe any inter-
nal company regulations, such as work,
operating and safety regulations.
• Thetechnicalspecicationsandlimitvalues
stated must not be exceeded under any
circumstances. In particular, this applies to
thespeciedambienttemperaturerange
and IP protection category.
Siting location requirements
To ensure proper functionality, the conditions
speciedinsection“Technicalspecications”
must be observed.
01
Components
The transducer consists of a plastic housing with
open/closed AC current loop and 4 pins terminal
connector. Current transceiver is a simple plastic
case with 4 pins input, power 12V socket and
analog 0-5V RJ12 output.
Functional description &
components
Installation procedure
Notes on assembly
• Be careful, transducers max. voltage for
isolation is 2kV.
• The transducer can measure AC current on
any current wire, not more then 10 mm in
diameter. Just open the cover, insert the
wire and close.
Installation
The transducer and the transceiver installed
together.
• Mount transducer using M4 screws and M4
nuts. Distance between mounting holes is
50 mm.
• Mount current transceiver using M4 screws
and M4 nuts. Distance between mounting
holes is 60 mm.
• Usea4-coreatcableandtwogreencon-
nectors supplied with the transceiver and
the transducer to assemble the connecting
cable.
Connection
Connect one end of RJ11 / RJ12 cable to moni-
toring unit and the other end to analog output
of transceiver. Connect transceiver to power
adapter 12V. Connect transceiver and trans-
ducer with Connecting cable. The monitoring
system will automatically sense current trans-
ducer as sensor. Click on the current or voltage
sensor element in the tree. A modal window
with sensor properties will pop up. Change the
name of the needed sensor, chage type of a
sensoron“current”,useExpressionformulalike
20*xwithK=20,andclick“Save”or“Apply”at
thebottomofthe“Properties”window.Inthe
interface system tree You will see A (ampers) in
front of the sensor.
• Max. distance for AC current transducer
from monitoring unit is 50 meters.
Testing transducers
U
pon a time, the Hall sensor readings may vary
due to physical reasons. On a sensor head You
can see the two variable resistors, which can
customize measuring. Change can be done only
like a last resort!

02
www.vutlan.com
Technical specications
HAT-100Q1 / AC current transducer
Dimensions 60 × 61 × 16 mm
Weight 150 g
Power input -12V / +12V
Operating
temperature Min. -10° C, Max.80° C
Operating
humidity
Min. 5% - Max. 95% (Non-
Condensing)
Outputs 4 pin terminal
Power
Consumption 1 Watt
Max. distance 50 m
VT407 / HAT-100Q1
Dimensions 68 × 47 x 26 mm
Weight 160 g
Inputs RJ-12 / RJ-11
Operating
temperature Min. -10° C, Max.80° C
Operating
humidity
Min. 5% - Max. 95% (Non-
Condensing)
Power input 12V DC, 1A
Power
Consumption 100 mW
Max. distance 50 m
Special Fea-
tures Transferred voltage - 0 .. 5V
