Vutlan VT960i User manual

VT335i / Remote Monitoring Unit
Documentation page: https://vutlan.atlassian.net/l/c/gTr18F3Q
Product page: https://vutlan.com/remote-monitoring-units/164-vt335i-monitoring-unit.html
Function and purpose
The unit is used for environmental monitoring (e.g. temperature, humidity, voltage, leakage, smoke, airflow). It is also used
as an I/O controller (e.g. door control, fans, generator, control panels, UPS, circuit breakers, alarms). Can use up to 700
different elements - notifications, triggers, timers, logic schemes, sensors, dry contacts. Has built-in Web interface with virtual
sensors, logic schemes, different types of notification, and control panels. Has a slot for an LTE modem for an ethernet
connection reservation.
Physical Description
Front panel:
VT335i is a new model and it replaces VT335S. New features include:
two times more powerful processor.
ability to handle more elements (+200)
slightly smaller dimensions
slot modem
power reservation
USB camera higher max. resolution

Back panel:
1. " .. " - x8 RJ12 6P4C analog sensor inputs with auto-sensing. Read instructions at "Analog sensors: A1 A8 Analog sensors
", " ".connection Sensor configuration
2. " " - digital connector RJ12 6P4C for the connection of CAN sensors/extensions/devices on a CAN bus. Modules can be CAN
chained together. Read instructions at " ", " ".CAN devises connection Setting up CAN
" " - green LED indicates CAN bus status.LED: CAN
The LED blinks slowly - nothing is connected
The LED blinks fast - configuration is in process
The LED glows constantly - connected to CAN devices
3. " " - Ethernet 10/100 Base-T port, provides an Ethernet connection. Read more in this section "LAN port LAN, GSM, LTE,
".RADIUS, DNS, SSL, VPN
" " - orange LED for Ethernet port. It shows network traffic.Orange LED
" " - green LED for Ethernet port. It shows network traffic. Flashes green when the system starts up. Shows Green LED
the connection state (constant green light - the connection is established, blinking green - the connection attempt).
4. " " - MicroSD card slot with an ejector. The card is needed for data storage or the "system restore". Read SD card
instructions at " ", " ".Saving system logs to SD card Restore of the appliance (for VT960 series)
5. " " - accuracy +/- 1 °C.TEMPERATURE SENSOR
6a. " " - green LED indicates appliance system status,LED: ACT
- operating mode of the device: switches at a frequency of 2 times per second;
- successful completion of the software update process: switches at a frequency of 4 times per second;
6b. " " - The button can be programmed from the interface for alarm indication.LED: ALARM
6c. " " - red LED indicates error and traffic.LED: ERR
the operating mode of the device: If everything is normal, the LED is extinguished, if not - there's a constant glow;
software update mode: switches at a rate of 2 times per second;
6d. " " - green LED indicates CAN bus status.LED: CAN

7. " " - micro USB-port 2.0 is needed for USB camera recording, USB Flash for system logs, and the system restore. Read USB
instructions at " ", " ", " "Connecting USB camera USB camera settings. How to save a video Saving system logs on USB flash drive
, " ".USB upgrade or restore of default settings
8. " " Dip switch
Normal mode: The switch is switched to the left . The switch should be always in this position.
Recovery mode: The switch is switched to the right . Use this option only in case you need to recover manufacturing
settings.
9. - 12V 0.25A (for each output) terminals outputs (electronic relay). Pitch 3.81mm, 3P. Read "OUTPUTS 12V 0.25A"
instructions at " ".Connecting 12V devices to 12V outputs
" " - status indicators for two 12V 0.25A output on the front panel.LEDs: E1, E2
The LED is ON (orange) - the output is ON (the initial state can be configured).
The LED is OFF (orange) - the output is OFF ((the initial state can be configured).
10. " " - Chassis grounding, M4 thread. Enhances the immunity of the equipment against conducted and Chassis grounding
radiated RF disturbances. Please contact a professional electrician before connecting it.
11. " " - A hole for mounting GNSS antenna. Antennas are purchased separately from VT335i and separately from VT740. GNSS
Read more at , and .GPS location GPS Service API
12a. " " - the button restarts the appliance. Hold the button for 2 seconds and then let go, the system will restart.Restart
12b. " " - reset smoke sensors. Read more at .Reset settings Operation of smoke detectors in dusty conditions
12c. " " - reset settings to default factory settings.Factory reset
13. " " - "VT790 / LTE slot modem" can be installed in this slot. Modem slot Read instructions This modem is ordered separately.
at "VT790 / LTE slot modem", "LAN, GSM, LTE, RADIUS, DNS, SSL, VPN".
14. " " - Digital inputs (Type IN). Pitch 3.5mm, 6P. Read instructions at " ", "DRY CONTACT INPUTS 1...4 Connecting dry contacts
".Dry contacts settings
15. " " - 12V DC 2A alternative power input. Pitch 3.81mm, 2P.DC 12V BACKUP POWER
16. " "- 12V DC 2A main power input.DC 12V POWER
Connection overview diagram

Drawing dimensions
Installing LTE slot modem
Product page: https://vutlan.atlassian.net/l/c/17p817yG
Datasheet page: https://vutlan.atlassian.net/wiki/spaces/DEN/pages/2309947438/VT790+LTE+modem

1.
2.
3.
4.
Usage
Can be installed in VT960i v3, VT960ii v3, VT855i v2.6, VT855ii v2.6, VT825i v2.6, VT825ii v2.6, VT335i monitoring systems.
Description
4G LTE slot modem for Vutlan monitoring units. Allows to receive and send SMS messages. Provides Ethernet over 4G LTE.
Power-cycling is an embedded function.
Panel
" " - Connector, used when the modem is installed inside of the appliance to connect LTE auxiliary antenna. The Auxiliary
additional antenna helps to strengthen the signal level. (Auxiliary LTE antenna and antenna output are ordered
separately from the modem).
" " - displays modems status. Blinking = working.Status
"SIM card" - SIM card slot with an injector.
" " - Connector, used when the modem is installed inside of the appliance to connect GSM or LTE main Main antenna
antenna. (The main antenna is supplied together with the modem).
Installation
You can install the modem while the system is turned On. You may wait up to 3 minutes until the Telecom operator
information is renewed.
Step 1 1.1 Use the to cut off wire cutter tool
the labeled “metal panel LTE Modem
”.slot
You can dispose of the metal panel
after.
VT740 has a miniature RF connector on the board for connecting GNSS antenna. GNSS antenna is not sold together
with VT740.

Step 2 Plug the as VT740 slot modem
shown on the picture into the
opening. The board should slide into
the guide rails (marked as “1”) and
plug into the jack (marked as “2”).
Step 3 3.1 Screw the main LTE antenna into
“ ” jack.Main” antenna
3.2 If you want to strengthen the
signal, you can screw in the second
auxiliary antenna into “ ” Auxiliary
jack.

1.
Step 4 Plug in the . The SIM card SIM card
slot has an .injector
Step 5 You are ready to go! Turn on the
system.
You can install the modem while the
system is turned On. You may wait
up to 3 minutes until the Telecom
operator information is renewed.
Configuring the modem
Please read the following section for the configuration instructions:
Online documentation page link: Setting up a modem
The direct page link for users with paper documentation:
https://vutlan.atlassian.net/wiki/spaces/DEN/pages/1016347/Setting+up+a+modem
Accessories
“ ” for mounting on DIN rail. VT124 is ordered separately. The package includes a holder and VT124 / DIN rail holder
screws.

2. “ ” for mounting onto the wall. The package includes 2 brackets and screws.VT123 / Wall mounting brackets
3. “ ” for mounting onto a 19” 1U rackmount.VT122i / 19” holder
Inventory
Make sure that the contents of the delivery meet the following configuration. Report a missing or damaged component to your
supplier. If damage occurred during transportation, contact the appropriate delivery service.
Package content Description

1 Monitoring unit VT335i.
2 12V adapter.
3 RJ-45 3m patch cable
4OTG Micro USB cable adater
5 Terminal plug 6 pins, 3.5 mm - 1 pc
6 Terminal plug 3 pins, 3.81 mm - 1 pc

7
Terminal plug 2 pins, 3.81 mm -1pc
8 Self-adhesive rubber foot - 4 pcs
9 Configuration manual
10 Warranty card

Technical details
VT325, VT335i, VT336, VT825i, VT825ii, VT855i, VT855ii, VT960i, VT960ii are the monitoring units and can not connect to
each other. For scalability please use extension units and embedded boards. All units except produced in DC / DC version.
● Built-in □ None Extension possible ◊ Not extendable
Versions VT960i / VT960ii
DC/DC; AC/DC
VT855i / VT855ii
DC/DC; AC/DC
VT825i / VT825ii
DC/DC; AC/DC
VT335i VT336 VT325
Device Management: Web, SNMP,
manually via SMS
● ● ● ● ● ●
Interface VT960i VT855i VT825i VT335i VT336 VT325
LAN: Ethernet 10/100 Mbit ● ● ● ● ● ●
OS: Linux v.5.10 v.5.40 v.5.40 v.5.40 v.3.10 v.3.10
RAM: 1Gb 128Mb 128Mb 64Mb 64Mb 64Mb
CPU speed: 720mHz 600mHz 600mHz 600mHz 300mHz 300mHz
Clock: Built-in clock
Watchdog: Built-in watchdog timer
● ● ● ● ● ●
Max. amount of sensors: physical
sensors, dry contacts, relays
400 150 150 100 30 6
Max. amount of elements: notificatio
ns, triggers, timers, logic, sensors,
dry contacts, SNMP Get, SNMP Trap,
Dial task and other elements
2000 1000 1000 700 500 500
Protocol support VT960i VT855i VT825i VT335i VT336 VT325
Network protocols: DHCP; HTTP;
HTTPS; DynDNS; SSL/TLS; SNMP
v1, v2c, v3; SMTP; FTP; Syslog;
RADIUS; Modbus RTU; OpenVPN
● ● ● ● ● ●
VPN: secure data communications;
secure change of connection
between LTE and LAN
● ● ● ● ● ●
SSH: Provided as a separate patch. □ □
Alerts / Notifications VT960i VT855i VT825i VT335i VT336 VT325
Alert types: E-mail, FTP log, Syslog,
SMTP, SNMP Traps, SMS (Modem is
ordered separately), Web-to-SMS,
● ● ● ● ● ●
A maximum number of "mail to"
recipients in an E-mail notification:
50 20 20 20 10 10
A maximum number of "SMS to"
recipients in an SMS notification:
also the maximum amount of phone
numbers
50 20 20 20 10 10
Virtual sensors VT960i VT855i VT825i VT335i VT336 VT325
Pings: Built-in function for server ● ● ● ● ● ●

Pings: Built-in function for server
pinging. Test the reach-ability of a
host in a network.
● ● ● ● ● ●
IP cameras: Connect the IP MJPEG
camera with a proxy via the master
module. Only view, no record.
4 4 4 4 4 4
Get SNMP: Read data from external
equipment via SNMP PDU GET (v1
/2c)
● ● ● ● ● ●
User keys: Add users who have
access using RFID reader.
● ● ● ● ● ●
Logic schemes: U sed to specify auto
matic actions to events that occur in
the system.
● ● ● ● ● ●
Timers: Allows you to plan the
events in the system.
● ● ● ● ● ●
Triggers: Generate events in the
system if logic is triggered.
● ● ● ● ● ●
Push notifications ● ● ● ● ● ●
SNMP traps ● ● ● ● ● ●
Virtual Math element (combine
several sensor data and calculate
new data)
● ● ● ● ● ●
Logic schemes ● ● ● ● ● ●
Modbus TCP/IP: read / write ● ● ● ● ● ●
Power VT960i VT855i VT825i VT335i VT336 VT325
Power input: 90-230V 90-230V 90-230V 12V 12V 12V
Power input DC: 24 48V ÷ 24 48V ÷ 24 48V ÷ 12V □ □
Fuse: Fuse at the inlet 1A 1A 1A 1A □ □
Max. power consumption: 30W 30W 10W 10W 12W 6W
The maximum current load on the
relay:
10А 10А 250mА 250mА 250mА 250mA
Redundant power supply: built-in
voltage monitor, voltage range 9-
12.6V.
Yes
AC/DC
DC/DC
Yes
AC/DC
DC/DC
Yes
AC/DC
DC/DC
Yes
DC 12V
□ □
Outputs VT960i VT855ii VT825i VT335i VT336 VT325
Relay outputs: latching relays
240V*10A
2 2 □ □ □ □
Relays outputs: 12V 0.25A 2 2 2 2 2 2
Max. dry contact outputs (contact
closures/digital outputs)
8 8 □ □ □ □
Audio output: AV OUT 1 □ □ □ □ □
Video output: AV OUT 1 □ □ □ □ □
Inputs VT960i VT855i VT825i VT335i VT336 VT325
Analog port: 6P6C for connection of
any analog sensor.
8 8 8 4 6 2
CAN port: Max number of sensors 32 32 32 32 20 □

Use for connecting CAN-12V-1A
more than 12 devices.
Dry contact inputs: 32 32 16 4 4 2
Modbus: (Max. 32 sensors, Max. line
length 1000m)
1 1 □ □ ●
Reader 1-Wire 1 1 □ □ □ Extension
possible
Video VT960i VT855i VT825i VT335i VT336 VT325
Video cameras: AV, USB, x4 IP USB, x1 IP USB, x1 IP USB, x1 IP USB, x1 IP USB, x1 IP
Video power supply: DC 12V 0,25A
for analog camera
● □ □ □ □ □
Other connectors VT960i VT855i VT825i VT335i VT336 VT325
Ethernet port: 10/100Mbit ● ● ● ● ● ●
USB 2.0 Type A 111 □ □ □
USB 2.0 micro 1 1 1 1 1 1
Switch Normal / Recovery: returns
the device to factory settings
□ □ □ □ ● ●
FEL button: softly restarts SATA
drive
● □ □ □ □ □
Shutdown button: Softly shuts down
the device.
● □ □ □ □ □
External Memory VT960i VT855i VT825i VT335i VT336 VT325
SD card slot ●●● ● □ □
SATA Drive: 2.5" HDD or SSD
(ordered separately)
◊ ◊ ◊ ◊ ◊
Extensions (modules
are ordered separately)
VT960i VT855i VT825i VT335i VT336 VT325
SATA: 2.5" HDD or SSD (ordered
separately)
◊ ◊ ◊ ◊ ◊
Modem (extensions) VT960i VT855i VT825i VT335i VT336 VT325
4G LTE modem: ordered separately. VT790 VT790 VT740 VT740 VT770 □
GSM modem: ordered separately □ □ □ □ □ □
Modem modes:
Gateway: Internet access
Access: Internet access over LTE
SMS: SMS notifications
Gateway /
Access / SMS
Gateway /
Access / SMS
Gateway /
Access / SMS
Gateway /
Access /
SMS
Access /
SMS
SMS
(external
modem)
Embedded sensors VT960i VT855i VT825i VT335i VT336 VT325
Temperature sensor: +/- 1 C Case °
temperature.
● ● ● ● ● ●
Power supply voltage sensor:
Accuracy (1%)
2 2 2 2 1 1

Environmental
characteristics
VT960i VT855i VT825i VT335i VT336 VT325
Operating temperature: -10 to 80 °C ● ● ● ● ● ●
Storage temperature: –25 to 85 °C ●●● ● ● ●
Operating humidity: 0 to 90 %, non-
condensing
● ● ● ● ● ●
Storage humidity: 0 to 95 %, non-
condensing
● ● ● ● ● ●
Other Features VT960i VT855i VT825i VT335i VT336 VT325
Installation: 19” 1U 19” 1U 19” 1U Desktop DIN rail Desktop
Dimensions (L x W x H) in mm: 440*44*120 440*44*90 440*44*90 180*35*80 160*90*58 95*35*80
Weight: 2 kg 1,5 kg 1,5 kg 0,7 kg 0,4 kg 0,4 kg
External chassis grounding: M4
thread
● ● ● ● □ ●
Web interface (panels) VT960i VT960ii VT855i VT335i VT336 VT325
Dashboard panel: ● ● ● ● ● ●
System tree panel: sensors and
devices displayed in a hierarchy
● ● ● ● ● ●
Event log panel: 500 logs 300 300 300 200 200
List of latest sent SMS messages: 500 200 200 150 100 100
Supported Vutlan environmental
sensors
Temperature, Outdoor Temperature,
Humidity, Water leakage, Wind
speed meter, Access sensor, Door
sensor, Water Level, AC / DC
current meters, AC voltage monitor,
Smoke detector, Vibration, Motion /
PIR, Converter
● ● ● ● ● ●
● Built-in □ None Extension possible ◊ Not extendable
Copyright:
Vutlan s.r.o. (LLC)
Remote Infrastructure Monitoring and Control
43 ul.Svornosti, 821 06 Bratislava,
Slovak Republic
www.vutlan.com
