VWR avantor Premium Balance Analytic PBA User manual

Operating Instructions
Original Operating Instructions
VWR®Premium Balance Analytic PBA
VWR®Premium Balance Precision PBP
Analytical and Precision Balances
1000085028 | Last updated: 07 | 2021
C

Legal Address of Manufacturer
Europe
VWR International bv,
Researchpark Haasrode 2020
Geldenaaksebaan 464 B-3001
Leuven
[phone]
be.vwr.com
UK Importer
VWR International Ltd
Hunter Boulevard, Magna Park
Lutterworth, Leicestershire, LE17 4XN
uk.vwr.com
Country of Origin
Germany

Contents
Operating Instructions 3
Contents
1 About these Instructions.............................5
1.1 Scope...........................................5
1.2 OtherApplicable Documents...................5
1.3 Target Groups ..................................5
1.4 Symbols Used...................................5
1.4.1 Warnings in Operating Instructions....5
1.4.2 Other Symbols .........................6
2 Safety Instructions ...................................6
2.1 Intended Use ...................................6
2.2 Personnel Qualification.........................6
2.3 Significance of these Instructions...............6
2.4 Proper Working Order of the Device ...........6
2.5 Symbols on the Device .........................7
2.6 Electrical Equipment ...........................7
2.6.1 Damage to the Electrical
Equipment of the Device ..............7
2.6.2 Working on the Device’s Electrical
Equipment .............................7
2.6.3 Power Supply Unit and
Power Supply Cable....................7
2.7 Conduct in an Emergency......................7
2.8 Accessories and Spare Parts ....................7
2.9 Personal Protective Equipment.................7
2.10 Glass Breakage .................................7
3 Device Description ...................................8
3.1 Device Overview................................8
3.2 Device Connections ............................8
3.3 Weighing Pan andAssociated Components....9
3.4 Symbols on the Device .........................9
4 Operating Concept..................................10
4.1 Operating Display in Weighing Mode .........10
4.2 Menu and System Settings Display ............10
4.2.1 Buttons ................................11
4.3 Displays in the Operating Display..............12
4.4 Menu Structure................................13
4.4.1 “Main Menu” Menu Structure.........13
4.4.2 “Toggle BetweenWeight Units”
Menu Structure .......................14
4.5 Navigating the Menus .........................14
5 Installation...........................................15
5.1 Scope of Delivery ..............................15
5.2 Selecting an Installation Site...................15
5.3 Unpacking .....................................15
5.4 Installing the Weighing Pan and
Associated Components ......................15
5.4.1 Installing a Device with
Analytical Draft Shield ................15
5.4.2 Installing a Device with
Round Draft Shield....................15
5.5 Acclimatizing the Device ......................16
6 Getting Started......................................17
6.1 Installing the Power Supply Unit...............17
6.1.1 Assembling the Power Supply Unit ...17
6.1.2 Dismantling the Power Plug Adapter ..17
6.2 Connecting the Power Supply.................17
7 System Settings .....................................18
7.1 Performing System Settings ...................18
7.2 Setting the Calibration and Adjustment .......18
7.2.1 Setting Internal Calibration and
Adjustment (Only Model I-1x).........18
7.2.2 Setting the External Calibration
and Adjustment.......................18
7.3 Parameter List .................................19
7.3.1 “SETUP”/”BALANCE” Menu..........19
7.3.2 “SETUP”/”GEN.SERV.” Menu ........20
7.3.3 “DEVICE”/”RS232” Menu.............21
7.3.4 “DEVICE”/”USB” Menu . . . . . . . . . . . . . . .22
7.3.5 “DEVICE”/”EXTRAS” Menu...........22
7.3.6 “DATA.OUT.”/”COM. SBI” Menu ......23
7.3.7 “DATA.OUT.”/”PRNT.PAR.” Menu.....24
7.3.8 “DATA.OUT.”/”PC.DIREC.” Menu
(only PC.TABL.) .......................25
7.3.9 “APPLIC.”/”WEIGH” Menu ...........25
7.3.10 “APPLIC.”/”COUNT” Menu ...........25
7.3.11 “APPLIC.”/”PERCENT” Menu.........25
7.3.12 “APPLIC.”/”ANIM.WG” Menu.........26
7.3.13 “APPLIC.”/”DENSITY” Menu..........26
7.3.14 “INPUT” Menu ........................26
7.3.15 “INFO” Menu .........................27
7.3.16 “LANGUAG.” Menu...................27
8 Operation ...........................................27
8.1 Switching the Device On and Off..............27
8.2 Warming Up the Balance......................27
8.3 Leveling the Balance Using
the Level Indicator.............................28
8.4 Overview of Calibration and Adjustment ......28
8.5 Calibrating and Adjusting
the Device Internally
(Only Model I-1x) ..............................28
8.6 Externally Calibrating and Adjusting
the Device .....................................29
8.7 Printing Results of the Calibration and
Adjustment Process ...........................29
8.8 Weighing ......................................29
8.9 Setting or Changing an Application ..........30
8.10 Running Applications (Examples) ............30
8.10.1 Executing the “Toggle Between
Weight Units” Function ..............30
8.10.2 Selecting Convertible Units and
their Decimal Places .................30
8.10.3 Running the “COUNT” Application ..30
8.11 Printing Weighing Result with ID Marking ....30

Contents
4 Operating Instructions
9 Cleaning and Maintenance..........................31
9.1 Detaching the Draft Shield ....................31
9.1.1 Detaching the Analytical Draft
Shield, Weighing Pan, and
Associated Components..............31
9.1.2 Dismantle the Round Draft Shield,
Weighing Pan, and Associated
Components..........................31
9.2 Cleaning the Device ...........................31
9.3 Installing the Draft Shield......................32
9.3.1 Installing theAnalytical Draft Shield ..32
9.3.2 Installing the Round Draft Shield .....32
9.4 Maintenance Schedule ........................32
9.5 Software Update...............................32
10 Malfunctions ........................................33
10.1 Warning Messages ............................33
10.2 Troubleshooting ...............................34
11 Decommissioning .................................. 35
11.1 Decommissioning the Device................. 35
12 Transport ........................................... 35
12.1 Transporting the Device ...................... 35
13 Storage and Shipping............................... 35
13.1 Storage ....................................... 35
13.2 Returning the Device and Parts............... 35
14 Equipment Disposal ................................ 35
15 Technical Data.......................................36
15.1 Ambient Conditions ...........................36
15.2 Contamination Type, Overvoltage
Category (Device) .............................36
15.3 Power Supply ..................................36
15.3.1 Power Supply Device..................36
15.3.2 Power Supply Unit ....................37
15.4 Electromagnetic Compatibility ................37
15.5 Backup Battery ................................37
15.6 Materials.......................................37
15.7 Warm-up Time.................................38
15.8 Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
15.8.1 Specifications of the RS232
Interface ..............................38
15.8.2 Specifications for the USB-C
Interface ..............................38
15.9 Device Dimensions ............................39
15.10 Metrological Data.............................40
15.10.1 Models PBA224 | PBA124 |
PBP623 | PBP423....................40
16 Accessories ..........................................41
16.1 Balance Accessories ...........................41
16.2 External Calibration and Adjustment
Weights........................................41
17 Technical Service ....................................41
18 Warranty.............................................42
19 Compliance with
Local Laws and Regulations .........................42

About these Instructions
Operating Instructions 5
1.2 OtherApplicable Documents
In addition to these instructions, observe the following
documentation:
−Installation instructions for the accessories, e.g. printer
1.3 Target Groups
These instructions are addressed to the following target
groups. The target groups must possess the specified
knowledge.
Target group Knowledge and qualifications
User The user is familiar with the operation of
the device and the associated work
processes.They understand the hazards
which may arise when working with the
device and know how to prevent them.
They have been trained in the operation
of the device.
Operator The operator of the device is responsible
for ensuring compliance with workplace
health and safety regulations.
The operator must ensure that all persons
who workwith the device have access to
the relevant information and are trained
in working with the device.
1.4 Symbols Used
1.4.1 Warnings in Operating Instructions
WARNING
Denotes a dangerwith the risk that death or severe injury
may result if it is not avoided.
CAUTION
Denotes a hazard that may result in moderate or minor
injury if it is not avoided.
NOTICE
Denotes a dangerwith the risk that property damage may
result if it is not avoided.
1 About these
Instructions
1.1 Scope
These instructions are part of the device. These
instructions apply to the device in the following versions:
Device Model 1) 2)
A analytical balance with
manual analytical draft
shield, readability of 0.1 mg
PBA224I-1x | PBA224-1x |
PBA124I-1x | PBA124-1x
A precision balance with
round glass draft shield,
readability of 1 mg
PBP623I-1x | PBP623-1x |
PBP423I-1x | PBP423-1x
1) Country-specific marking in model, x =
S Standard balances without country-specific
additions
2) Model-typical marking in model
I-1x Devices with internal calibration and adjust-
ment function
x-FC Incl. factory acceptance test report

Safety Instructions
6 Operating Instructions
1.4.2 Other Symbols
t Required action: Describes actions which must
be carried out.
y Result: Describes the result of the actions
carried out.
[ ] Text inside brackets refers to control and
display items.
[ ] Text inside brackets indicates status, warning,
and error messages.
Indicates information for legal metrology for
conformity-assessed (verified) devices.
Conformity-assessed devices are also referred
to as “verified” in these instructions.
Figures on the Operating Display
The figures on the operating display of the device may
deviate from those in these instructions.
2 Safety Instructions
2.1 Intended Use
The device is a high-resolution balance, which can be
used indoors, e.g. in industrial areas. The device was
developed for the accurate determination of the mass of
materials in liquid, paste, powder, or solid form.
Appropriate containers must be used for loading each
type of material.
The device is exclusively designed for use according to
these instructions. Any further use beyond this is
considered improper.
If the device is not used properly: the protective systems
of the device may be impaired. This can lead to
unforeseeable personal injury or property damage.
Operating Conditions for the Device
Do not use the device in potentially explosive
environments. The device may only be used indoors.
The device may only be used with the equipment and
under the operating conditions described in the
Technical Data section of these instructions.
Modifications to the Device
You may not modify or repair the device or make any
technical changes. Any retrofitting or technical changes
to the device are only permitted with prior written
permission from VWR.
2.2 Personnel Qualification
If people who do not have sufficient knowledge on the
safe handling of the device carry out work on the device:
Those people may injure themselves or other people
nearby.
t Ensure that all individuals working on the device
possess the necessary knowledge and qualifications
(description see Chapter “1.3 Target Groups”,
page 5).
t If a particular qualification is indicated for the actions
described: Have these activities carried out by the
required target group.
t If no particular qualification is indicated for the actions
described: Have these activities carried out by the
“user” target group.
2.3 Significance of these
Instructions
Failure to follow the instructions in this manual can have
serious consequences, e.g. exposure of individuals to
electrical, mechanical, or chemical hazards.
t Before working with the device: Read the instructions
carefully and completely.
t If these instructions are lost, request a replacement or
download the latest version from the VWR website
(www.vwr.com).
t Ensure that the information contained in these
instructions is available to all individuals working on
the device.
2.4 ProperWorking Order
of the Device
A damaged device or worn parts may lead to
malfunctions or cause hazards which are difficult to
recognize.
t Only operate the device when it is safe and in perfect
working order.
t In the event of damage to the housing, disconnect the
device from the power supply and prevent it from
being restarted.
t Do not open the device housing. Have any
malfunctions or damage repaired immediately by
VWR Service.
t Complywith the maintenance intervals (for intervals
and maintenance work, see Chapter “9.4 Maintenance
Schedule”, page 32).

Safety Instructions
Operating Instructions 7
2.5 Symbols on the Device
All symbols appearing on the device, such as warnings
and safety labels, must be legible.
t Do not conceal, remove, or modify the symbols.
t Replace the symbols if they become illegible.
2.6 Electrical Equipment
2.6.1 Damage to the Electrical
Equipment of the Device
Damage to the device’s electrical equipment, e.g.
damaged insulation, can be life-threatening. There is
a danger to life from contact with live parts.
t If the electrical equipment of the device is defective,
cut off the power supply and contact VWR Service.
t Keep live parts away from moisture. Moisture can
cause short circuits.
2.6.2 Working on the Device’s
Electrical Equipment
OnlyVWR Service personnel may work on or modify
the electrical equipment of the device.The device may
only be opened byVWR Service personnel.
2.6.3 Power Supply Unit and
Power Supply Cable
Serious injury can result, e.g. from electric shocks, if an
unsuitable/inadequately dimensioned power cord or
unsuitable power supply unit is used.
t Only use the original power supply unit and original
power supply cable.
t If the power supply unit or power supply cable must be
replaced: Contact VWR Service. Do not repair or
modify the power supply unit or power cable.
2.7 Conduct in an Emergency
If there is immediate danger of personal injury or
equipment damage, e.g., due to malfunctions or
dangerous situations, the device must be immediately
taken out of operation.
t Disconnect the device from the power supply.
t Malfunctions should be remedied byVWR Service.
2.8 Accessories and Spare Parts
The use of unsuitable accessories and spare parts can
affect the functionality and safety of the device and
have the following consequences:
−Risk of injury to persons
−Damage to the device
−Device malfunctions
−Device failure
t Only use approved accessories and spare parts
supplied byVWR.
t Only use accessories and spare parts that are in
proper working order.
2.9 Personal Protective Equipment
Personal protective equipment protects against risks
arising from the material being processed.
t If the workplace or the process in which the device is
being used requires personal protective equipment:
Wear personal protective equipment.
2.10 Glass Breakage
Glass components can break if they fall or are handled
incorrectly. Glass fragments can cause cuts.
t Only lift the device by its base, not by the draft shield.
t When lifting and transporting, ensure that no
personnel or objects are in the way.
t Only operate the operating displaywith your fingers.
Do not use pointed or sharp objects.

Device Description
8 Operating Instructions
3 Device Description
3.1 Device Overview
124
3
5
67
8
Fig.1: Precision balance with round draft shield and analytical balance
with analytical draft shield (example)
Pos. Designation Description
1 Round draft shield
2 Cover of the round
draft shield
3 Upper draft shield
panel Used to manually open the upper panel
4 Analytical draft
shield
5 Side draft shield
panel Used to manually open the side panel
6 Leveling foot Used to level the balance,
manually adjustable
7 Control module
8 Level
3.2 Device Connections
2
13 5
4
Fig.2: Precision balance with round draft shield (rear view)
Pos. Designation Description
1 Access switch Protects the device from
changes to the device settings. Is
sealed for conformity-assessed
devices
2 Power supply Connection for power supply to
the device
3 USB-C
connection For connection to a printer, PC
4 RS232
connection 9-pin, for connection to a printer. PC
5 Slot For attaching an anti-theft device
or a Kensington lock

Device Description
Operating Instructions 9
3.3 Weighing Pan and Associated Components
1
2
3
1
2
3
Fig.3: Analytical balance with analytical draft shield, precision balance with analytical draft shield, and precision balance with round draft shield
(example)
Pos. Designation Description
1 Weighing pan
2 Pan support
3 Pan retainer
3.4 Symbols on the Device
Symbol Meaning
NOTICE! Read the operating instructions.

Operating Concept
10 Operating Instructions
4 Operating Concept
4.1 Operating Display in
Weighing Mode
Fig.4: Operating display in weighing mode (example)
Pos. Designation Description
1 Metrological
data
2 Menu
3 Application
overview Displays the selected application program during
operation
4 Toolbar
5 Weighing unit Displays the selected unit,
e.g. grams, [g]
6 Navigation bar For navigation in the menu and
system settings
7 Measurement
display
8 Visual touch
feedback
9 Toolbar
123
4
5
6
7
8
9
4.2 Menu and System Settings
Display
Fig.5: Menu and System Settings Display (example)
Pos. Designation Description
1 Menu or
parameter entry
2 [Selection] display
3 Menu level Shows the position of the
displayed menu or parameter
in up to 4 levels
3
12

Operating Concept
Operating Instructions 11
4.2.1 Buttons
Symbol Designation Description
[On/Off] button −When the button is pressed: Switches the operating display on.
−If the button is held down: Switches the operating display off.
[Menu] button −When the button is pressed: The settings menu opens.
−If the button is held down: It switches to version display.
[Zero] button Zeroes the device.
[Tare] button Starts taring.
[Print] button Exports the readouts to the integrated data interfaces.
[Adjust] button Starts the set calibration and adjustment function.
[GLP] button Exits the GLP printout and starts printing the GLP footer.
[Toggle between
weight units]
button
If the “Toggle between weight units” function is active:
−If the button is held down: Accesses the “Toggle between weight units” function
menu.
−When the button is pressed: Switches between the basic unit display and up to
4 other units.
[Back] button −In the menu:
−When the button is pressed: Returns to the previous display.
−If the button is held down: Saves the menu settings.
−When entering digits: Selects the previous digit position.
−For an active application: Exits the application and deletes the set reference
value.
[Up] button −In the menu: Scrolls through the menu levels or the available parameters.
−When entering digits: Increases the displayed value.
−In the main display of an active application: Switches to the display of the current
weight value/parameter.
[Down] button −In the menu: Scrolls through the menu levels or the available parameters.
−When entering digits: Decreases the displayed value.
−In the main display of an application that is not active: Accesses the display to set
the reference values.
−In the main display of an active application: Switches to the display of the current
weight value/parameter.
[Confirm] button −In the menu:Accesses the displayed menu level or confirms the displayed
parameter.
−When entering digits: Selects the next digit position.
−In the main display of an application that is not active: Starts the application
process and saves the set reference value.
−In the main display of an active application: Adopts the next component or the
next parameter.

Operating Concept
12 Operating Instructions
4.3 Displays in the Operating Display
Symbol Designation Description
[Counting] display Indicates that the “Counting” application is selected.
[Weighing in percent]
display Indicates that the “Weighing in percent” application is selected.
[Animal weighing]
display Indicates that the “Animal weighing” application is selected.
[Density
determination] display Indicates that the “Density determination” application is selected.
[Ambient condition]
display Switches between the ambient conditions “V.STABLE”, “STABLE”, UNSTABL.” and “V.UNSTBL.”.
[Application filter]
display Switches between the “weighing” and “filling” application filters.
[Busy] display Indicates that the device is processing a command.
[Sign] display Indicates whether the value being displayed is positive or negative.
[Zero] display For some conformity-assessed devices: Indicates that the device has been
zeroed.
[AUTO] display Indicates that the “Animal weighing” application starts automatically.
[R12] display Indicates the active range for multi-range balances.
[Printer] display −Indicates that a printer has been detected at the USB port.
−Flashes if the data output is active.
[PC-Connect] display −Indicates that a PC or a second display has been detected at the USB port.
−Flashes if the data connection is active.
[Percent] display Indicates that a percentage value is being displayed.
[Net] display Indicates that a net value is being displayed.
[Gross] display Indicates that a gross value is being displayed.
[Selection] display In the menu: Identifies the selected parameter.
If the “Calculation” or “Density determination” application is active: Indicates that
a calculated value is being displayed.
[Unit symbol] display Indicates the set weight unit, e.g. [g] for “grams”.
[Quantity] Indicates that a quantity is being displayed.
[Invalid weight value]
display −Indicates that the display does not contain a weight value, but is instead the calculated result of an application, e.g. for the “Totalizing” application.
−For conformity-assessed devices: Indicates a fault. The cause of this fault is
displayed after pressing the [Change] key.

Operating Concept
Operating Instructions 13
4.4 Menu Structure
4.4.1 “Main Menu” Menu Structure
t Navigating in menus (see Chapter 4.5, page 14).
Level 1 Level 2 Description
SETUP BALANCE Set the functions of the device.
GEN.SERV.
“General services” Reset the menu to factory settings.
DEVICE RS-232
“RS232, 9-pin” Define the parameters for the COM interface.
USB
“USB-C” Define the parameters for the USB interface.
EXTRAS Define the functions of the operating display.
DATA.OUT.
“Data output” COM. SBI “SBI communication” Configure the automatic data output.
PRNT.PAR.
“Printout settings” Perform the settings for the printout.
PC.DIREC.
“Direct transfer of data
(PC)”
Define the output format for the data exchange between the balance
and the PC.
APPLIC.
“Applications” WEIGH −Determine the weight value of a sample. −Activate the functions for all applications.
COUNT Determine the number of parts that have approximately equal weight.
PERCENT
“Weighing in percent” Determine the percentage share of a sample based on a reference weight.
ANIMALW.
“Animal weighing” Weigh unstable samples, e.g. animals. This program calculates the average of several measurement cycles.
DENSITY
“Density determination” Determine the density of solid samples based on the buoyancy method.
INPUT DEV.ID. Save the entered ID number for the device.
DATE Set the date.
TIME Set the time.
USER.PW Set the user password.
SERV.PW Activate the service mode.
PW. DEL. Deletes the entered password.
INTERV. The SBI output rate can be set from 0 - 9999 seconds.

Operating Concept
14 Operating Instructions
Level 1 Level 2 Description
INFO
“Device
information”
VERSION
“Version number” Display the software version number.
SER. NO.
“Serial number” Display the device’s serial number.
MODEL Display the device’s model ID.
BAC VER. Display the version of the BAC processor.
LANGUAGE Set the menu language of the operating display.
4.4.2 “Toggle Between Weight Units” Menu Structure
t Navigating in menus (see Chapter 4.5, page 14).
Level 1 Description
Unit 1 - unit 4 Define the displayed weight unit and the resolution for the 1st to 4th convertible unit.
4.5 Navigating the Menus
Procedure
t To open the main menu: Press the [Menu] button.
t To display menu items or parameters of a level: Press the [Up] or [Down] button.
t To return to the next higher menu level or exit the menu: Press the [Back] button.
t To open a displayed menu level or a displayed parameter: Press the [Confirm] button.

Installation
Operating Instructions 15
5 Installation
5.1 Scope of Delivery
Item Quantity
Device 1
Weighing pan 1
Pan support 1
Power supply unit with country-specific
adapters 1
Draft shield 1
Operating instructions 1
5.2 Selecting an Installation Site
Procedure
t Ensure that the following conditions are met at
the installation site:
Condition Characteristics
Ambient condi-
tions −Suitability tested (for ambient conditions, see Chapter 15.1, page
36)
Setup surface −Stable, even surface with little
vibration
−Sufficient space for the device
(for space requirements, see
Chapter “15.9 Device Dimen-
sions”, page 39)
−Sufficient load bearing capacity
for the device (for device weight,
see Chapter “15.10 Metrological
Data”, page 40)
Access to parts
relevant to
operation
Convenient and safe
5.3 Unpacking
Procedure
t Unpack the device.
t CAUTION Glass breakage due to the incorrect
handling of the device! Do not lift the device by the
draft shield. Only lift the device by its base.
t Install the device at the intended installation site.
t If the device is stored temporarily: Observe the
storage information (see Chapter 13.1, page 35).
t Keep all parts of the original packaging, e.g. to return
the device.
5.4 Installing the Weighing Pan and
Associated Components
5.4.1 Installing a Device with
Analytical Draft Shield
Procedure
t Fully open the side
panel of the analytical
draft shield.
t Fit the pan support on
the pan retainer and
place the weighing pan
on top.
5.4.2 Installing a Device with
Round Draft Shield
Procedure
t Place the base of the
draft shield into the
round recess on the
device.
t Fit the pan support on
the pan retainer.
t Place the weighing pan
onto the pan support.
t Place the round glass
ring on the base of the
draft shield.
t Place the cover of the draft shield onto the round
glass ring.

Installation
16 Operating Instructions
5.5 Acclimatizing the Device
When a cold device is brought into a warm environment:
The temperature difference can lead to condensation
from humidity in the device (moisture formation).
Moisture in the device can lead to malfunctions.
Procedure
t Allow the device to acclimatize for approx. 2 hours at
the installation site. Ensure that the device is
disconnected from the power supply during that time.

Operating Instructions 17
Getting Started
6 Getting Started
6.1 Installing the Power Supply Unit
6.1.1 Assembling the Power Supply Unit
Item number
on packaging Power supply unit with connection cable and country-specific power plug
adapters (packed in PE bag with
printed country identification, e.g. EU)
611-4917 USA and Japan (US+JP), Europe and
Russia (EU+RU), Great Britain (UK),
India (IN), SouthAfrica (ZA), Australia (AU),
China (CN)
Procedure
t Select the country-specific
power plug adapter.The
power plug adapter must
be suitable for use with the
wall outlet at the installa-
tion site.
t Insert the power plug
adapter into the power
supply unit.The grooved
button must be facing
upwards.
t Push the power plug adapter as far as you can until it
clicks into place.
t Check whether the power plug adapter is securely
locked in place by pulling it gently.
y If the power plug adapter does not move: It is locked
in place.
6.1.2 Dismantling the Power Plug Adapter
Procedure
t Press the grooved button
from above and pull back
on the power plug adapter.
t Push the power plug
adapter out of the power
supply unit and remove it.
6.2 Connecting the Power Supply
Procedure
t WARNING Severe injuries caused by using
defective power supply cables! Check the power
supply cable for damage, e.g. cracks in the insulation.
t If required: Contact VWR Service.
t Check whether the country-specific power plug
matches the power connections at the installation site.
t If required: Replace the country-specific power
plug adapter.
t NOTICE Damage to the device due to excessive input
voltage! Checkwhether the voltage specifications on
the manufacturer’s ID label match those of the power
supply at the installation site.
t If the input voltage is too high: Do not connect the
device to the power supply.
t Contact VWR Service.
t Connect the right angle plug to the “Power Supply”
connection.
t Connect the mains plug to the wall outlet (mains
voltage) at the installation site.
y The [BOOTING] display appears in the operating
display.
y The device performs a self-test.

18 Operating Instructions
System Settings
7 System Settings
7.1 Performing System Settings
Default settings can be adjusted for the device and the
applications in order to align with the ambient conditions
and individual operating requirements.
The following settings are necessary to operate the
device togetherwith connected components:
−Set up the communication of the connected devices
−Set up additional components
The following settings are recommended to set up the
device:
−Set the menu language
−Set the date and time
−Set the calibration and adjustment
Procedure
t Press the [Menu] button.
t To adjust settings: Open the desired menu.
t Select and confirm the desired parameter
(parameters, see Chapter “7.3 Parameter List”,
page 19).
t Exit the menu.
7.2 Setting the Calibration and
Adjustment
7.2.1 Setting Internal Calibration and
Adjustment (Only Model I-1x)
The following functions can be set for the internal
calibration and adjustment:
−Internal calibration with automatic start of the
adjustment.
−Internal calibration with manual start of the
adjustment.
Procedure
t Open the “SETUP”/”BALANCE” menu. Call up
the “CAL.JUST.” parameter and select the value
“CAL.INT.”.
t If the calibration function needs to be set with
subsequent automatic adjustment: In the
“SETUP”/”BALANCE” menu, for the “CAL.SEQ.”
parameter, select the “ADJUST” setting value.
t If the calibration function needs to be set without
subsequent automatic adjustment: In the
“SETUP”/”BALANCE” menu, for the “CAL.SEQ.”
parameter, select the “CAL./ADJ.” setting value.
7.2.2 Setting the External Calibration and
Adjustment
The following functions can be set for the external
calibration and adjustment:
−External calibration with manual start of the
adjustment.
Procedure
t Open the “SETUP”/”BALANCE” menu.
t If the calibration function needs to be set with
subsequent automatic adjustment: Select the
“ADJUST” calibration value for the “CAL.SEQ.”
parameter.
t If the calibration function needs to be set
without subsequent automatic adjustment:
Select the “CAL-ADJUST” calibration value
for the “CAL.SEQ.” parameter.

Operating Instructions 19
System Settings
7.3 Parameter List
7.3.1 “SETUP”/”BALANCE” Menu
Parameter Setting values Explanation
AMBIENT V.STABLE Sets the ambient conditions to “very stable”: Activates a fast change in
the weight values in the event of a load change with a high output rate.
Recommended for the following work environment:
−Very stable table near the wall
−Closed and calm room
STABLE* Sets the ambient conditions to “stable”. Recommended for the following work
environment:
−Stable table
−Slight movement in the room
−Slight draft
UNSTABL. Sets the ambient conditions to “unstable”: Activates the delayed change in
weight values with a reduced output rate. Recommended for the following work
environment:
−Simple office desk
−Room with moving machinery or personnel
−Slight air movement
V.UNSTBL. Sets the ambient conditions to “very unstable”: Activates a significantly delayed
change in the weight values and long wait for stability with a further reduction in
the output rate.
Recommended for the following work environment:
−Noticeable and slow floor vibrations
−Noticeable building vibrations
−Weighed goods moved
−Very strong air movements
APP.FILT. FINAL.RD.* Activates a filter that enables a fast change in the display for very fast load
changes. Display changes with minimal load changes (in the digit range) occur
more slowly.
FILLING Activates a filter that enables a very fast change in the displaywith minimal load
changes, e.g. when filling containers.
STAB.RNG V. ACC. Sets the stability to “very accurate”.
ACC.* Sets the stability to “accurate”.
FAST Sets the stability to “fast”.
V. FAST Sets the stability to “very fast”.
ZER./TAR. W/O STB. If the button is pressed: The function of the [Zero] or [Tare] button is executed
immediately.
W/ STAB.* The function of the [Zero] or [Tare] button is only executed after stability is
achieved.
AUTOZER. ON* Activates automatic zeroing. The display is automatically set to zero in case of
a deviation of 0 less than (X).
OFF Deactivates automatic zeroing. Zeroing must be triggered with the [Zero]
button.
* Factory setting

20 Operating Instructions
System Settings
Parameter Setting values Explanation
WT.UNIT GRAMS*, KILOGR.,
CARATS, POUNDS,
OUNCES, TROY.
OZ., HKTAEL,
SNGTAEL,
TWNTAEL,
GRAINS, PENYWT.,
MILLIGR., PTS./LB,
CHNTAEL.,
MOMMES, AUSTR.
CT, TOLA, BAHT,
MESGHAL,
NEWTON
−The device displays the weight in the selected unit.
−The availability of units depends on national legislation and is therefore
country-specific.
DISP.DIG. ALL* “Show all decimal places”: All decimal places are shown in the display.
The setting change is not available on conformity-assessed devices.
MINUS 1 “Last decimal place off”: The last decimal place is switched off.
CAL./ADJ. EXT.CAL. The [Adjust] button starts an external calibration and adjustment process with
the preset calibration weight.
E.CAL.USR. The [Adjust] button starts an external calibration and adjustment process with
the user-defined calibration weight value.
REPRO Starts the reproducibility test. Determines the current calibration frequency
with a user weight.
SELECT The interface [CAL] is assigned a selection of permitted menu items from
“CAL./ADJ.”
INT.CAL.* The [Adjust] button starts an internal calibration and adjustment process.
CAL.SEQ. ADJUST* The adjustment starts automatically after the calibration.
CAL.-ADJ. The adjustment must be started or exited manually after calibration with the
[Confirm] button.
ON Z/T ON* Activates the initial taring/zeroing. The device is tared or zeroed after it is
switched on.
OFF Deactivates the initial taring/zeroing: After it is switched on, the device shows
the same value as before it was last switched off.
EXT.CAL. UNLCKED* Activates the external calibration/adjustment function under [CAL./ADJ.].
LOCKED Deactivates the external calibration/adjustment function under [CAL./ADJ.].
* Factory setting
7.3.2 “SETUP”/”GEN.SERV.” Menu
Parameter Setting values Explanation
MENU.RES. DEFAULT Resets the system settings to the factory default settings.
NO* Deactivates the option of resetting the device menu.
* Factory setting
