VWR avantor TubeRoller 5 User manual

Instruction manual
VWR® TubeRoller 5 and TubeRoller 10
EU cat. no 444-1339
444-1342
___
Version 01 Issue 07/2022

2vwr.com I Instruction manual VWR®TubeRoller 5 and TubeRoller 10
Legal address of Manufacturer
Europe
VWR International bv,
Researchpark Haasrode 2020
Geldenaaksebaan 464 B-3001
Leuven
[phone]
be.vwr.com
UK Importer:
VWR International Ltd
Hunter Boulevard, Magna Park
Lutterworth, Leicestershire, LE17 4XN
uk.vwr.com
Country of Origin
Taiwan
Table of Contents
Warning
Safety information
Package Contents
Unpacking
Intended Use
Symbols and conventions
Specifications
Instructions for use
Troubleshooting
General maintenance
Accessories and spares
Technical Service
Warranty
Disposal
Warning
The VWR® TubeRoller 5 and VWR® TubeRoller 10 are for research use only. Not intended for medical, diagnostic, or therapeutic
use, human or otherwise.

3vwr.com I Instruction manual VWR®TubeRoller 5 and TubeRoller 10
Safety Information
Avoiding Electrical Shock
Please follow the guidelines below and read this manual in its entirety to ensure safe operation of the unit.
To avoid electrical shock:
Always plug the instrument into a properly grounded AC outlet.
Ensure that your hands, work area, and instruments are clean and dry before plugging the instrument into an
outlet.
Ensure that local voltage is within the voltage range of the instrument.
Avoiding Damage to the Instrument
Ensure there are no obstructions to the motion of the instrument prior to use.
Ensure that the total weight of the load is below the maximum weight specified.
Always place the instrument on a flat, level surface.
Package Contents
Description
Quantity
TubeRoller 5 or TubeRoller 10
1
UK Plugged Lead
1
EU Plugged Lead
1
Swiss Plugged Lead
1
Unpacking
Ensure all components are present prior to continuing. If any are missing, contact your VWR® representative.
Intended use
The VWR® TubeRoller 5 and TubeRoller 10 are intended for gentle, thorough mixing of a wide range of sample containers,
through a rolling motion alongside a gentle vertical rocking motion. Sample vessels are intended to lay flat on the rollers to be
mixed. Intended users of the VWR® TubeRoller 5 and TubeRoller 10 are clinical labs, doctor’s offices, and researchers needing
non-vigorous sample mixing.
For research use only. Not intended for any animal or human therapeutic or diagnostic use.

4vwr.com I Instruction manual VWR®TubeRoller 5 and TubeRoller 10
Symbols and conventions
The following chart is an illustrated glossary of the symbols that are used in this manual.
CAUTION This symbol indicates a potential risk and alerts you to
proceed with caution
Product Specifications
VWR® TubeRoller 5 (444-1339)
Speed Range 2 to 80 RPM, Variable
Operating Temperature 4°C to 40°C ambient temperature
Individual Roller Dimensions 3 x 32 cm
Vessels Accepted, Diameter 8 mm to 200 mm
Rolling Spacing 5 mm on 35 mm centers
Number of Rollers 5
Load Capacity 2 kg
Dimensions 45 x 18 x 9 cm
Weight 5 kg
Electrical 230V, 50-60 Hz
Warranty 2 Years
VWR® TubeRoller 10 (444-1342)
Speed Range 2 to 80 RPM, Variable
Operating Temperature 4°C to 40°C ambient temperature
Individual Roller Dimensions 3 x 32 cm
Vessels Accepted, Diameter 8 mm to 200 mm
Rolling Spacing 5 mm on 35 mm centers
Number of Rollers 5
Load Capacity 2 kg
Dimensions 45 x 18 x 9 cm
Weight 5 kg
Electrical 230V, 50-60 Hz
Warranty 2 Years

5vwr.com I Instruction manual VWR®TubeRoller 5 and TubeRoller 10
Overview
The VWR® Tube Rollers are designed for gentle yet complete mixing of a wide range of sample vessels, including Vacutainers™,
media bottles, blood tubes, centrifuge tubes, and roller bottles. With both models, speed is controlled digitally, and is variable
between 2 and 80 rpm.
In addition to the rolling motion, the VWR® Tube Rollers also feature a gentle 0.5 in (13mm) elevation function on the right-side
end of each roller. The tilting feature provides a heightened level of mixing homogeneity and uniformity without placing
unnecessary stress on samples.
VWR® Tube Rollers additionally feature an integrated timer, which is controlled digitally. The timer can be set from 1 minute to
100 hours, with an additional continuous operation mode. The VWR® Tube Rollers are the right choice for research laboratories,
clinical laboratories, and physician’s offices in need of a tube mixing solution.
Description of Buttons and Switches
Main View
VWR® TubeRoller 5 VWR® TubeRoller 10
Operational keys
Key Functions
START|STOP Key: Used to start instrument run, or to stop instrument run during use.
CONT|TIME Key: Used to switch between continuous run mode and timed run mode.
TIME Key: In timed run mode, used to enter timer adjustment mode.
Down arrow key: Used during adjustment modes to reduce timer and speed.
Up arrow key: Used during adjustment modes to increase timer and speed.
SPEED Key: Used to enter speed adjustment mode.

6vwr.com I Instruction manual VWR®TubeRoller 5 and TubeRoller 10
Getting Started
Installing the VWR® TubeRoller 5 and TubeRoller 10
Place the roller on a clean, flat, stable surface. Prior to connecting the unit to power, ensure the power switch located on the
rear of the unit is in the OFF position. Plug the roller into a properly grounded outlet at the correct voltage. Always ensure that
there are no obstructions blocking the vertical rocking motion of the rolling platform.
Operation
Load the roller platform prior to powering the unit on. Ensure to load the unit from the center out, creating a balanced load
about the center line of the platform. Once the unit is loaded to satisfaction with a balanced load, power the unit on by pressing
the power switch to the ON position.
Enter time adjustment mode by pressing the “TIME” key. The timer display will begin flashing. Use the up arrow and down arrow
keys to adjust run time. Once finished, press the “TIME” key again to store the time value. Enter speed adjustment mode by
pressing “SPEED”. The speed display will begin flashing. Use the up arrow and down arrow keys to adjust speed. Once finished,
press the “SPEED” key again to store the speed setting. To switch to continuous operation, press the “CONT.|TIME” button. The
display should read “cont”. To switch back to timed run mode, press “CONT.|TIME” again. To start operation, press
“START|STOP”. The unit will run until time elapses, or continuously. Press “START|STOP” again to stop the run at any time.
Troubleshooting
Review the information in the table below to troubleshoot operating problems.
Problem
Cause
Solution
Unit is not powering on
Faulty outlet
Check outlet with other electronics known to work
Damaged fuse
Replace fuse
Rolling motion is stiff, not
fluid, or stops
Obstructions underneath
rollers
Clear obstructions
Unit stops rolling prior to
time end or during
continuous mode
Faulty motor
Return unit to manufacturer for service
Unit not running
Faulty components
Return unit to manufacturer for service
Repair and maintenance of VWR® TubeRoller 5 and TubeRoller 10
Routine maintenance of this unit only involves keeping the unit clean. No other routine maintenance or repair is
required. Cleaning can be done with a damp cloth. Avoid the use of solvents to avoid the risk of damage to the
housing or rollers.
Technical service
Web Resources
Visit the VWR website at www.vwr.com for:
• Complete technical service contact information
• Access to the VWR Online Catalogue, and information about accessories and related products
• Additional product information and special offers
Contact us For information or technical assistance contact your local VWR representative or visit. www.vwr.com.

7vwr.com I Instruction manual VWR®TubeRoller 5 and TubeRoller 10
Warranty
VWR warrants that this product will be free from defects in material and workmanship for a period of two (2) years from date
of delivery. If a defect is present, VWR will, at its option and cost, repair, replace, or refund the purchase price of this product to
the customer, provided it is returned during the warranty period. This warranty does not apply if the product has been damaged
by accident, abuse, misuse, or misapplication, or from ordinary wear and tear. If the required maintenance and inspection
services are not performed according to the manuals and any local regulations, such warranty turns invalid, except to the extent,
the defect of the product is not due to such non-performance.
Items being returned must be insured by the customer against possible damage or loss. This warranty shall be limited to the
aforementioned remedies. IT IS EXPRESSLY AGREED THAT THIS WARRANTY WILL BE IN LIEU OF ALL WARRANTIES OF FITNESS
AND IN LIEU OF THE WARRANTY OF MERCHANTABILITY.
Compliance with local laws and regulations
The customer is responsible for applying for and obtaining the necessary regulatory approvals or other authorisations necessary
to run or use the Product in its local environment. VWR will not be held liable for any related omission or for not obtaining the
required approval or authorisation, unless any refusal is due to a defect of the product.
Equipment disposal
This equipment is marked with the crossed out wheeled bin symbol to indicate that this equipment must not be disposed of
with unsorted waste.
Instead it's your responsibility to correctly dispose of your equipment at lifecycle -end by handling it over to an
authorized facility for separate collection and recycling. It's also your responsibility to decontaminate the
equipment in case of biological, chemical and/or radiological contamination, so as to protect from health
hazards the persons involved in the disposal and recycling of the equipment.
For more information about where you can drop off your waste of equipment, please contact your local dealer from whom you
originally purchased this equipment.
By doing so, you will help to conserve natural and environmental resources and you will ensure that your equipment is recycled
in a manner that protects human health.
