WABECO F1410 LF User manual

Operating instructions
Milling machines
CNC milling machines
with linear guides
F1410 LF F1410 LF hs
F1410-C LF F1410-C LF hs
CC-F1410 LF CC-F1410 LF hs

2
Please read before putting into operation for the rst time!
Every person that operates the machine, maintains or repairs it, must have read the operating instruc-
tions, and in particular, the safety notes prior to putting the machine into operation. Please store these
documents for subsequent use.
Original version in German/translation in English
Status at 06/2018
Dear Customer!
With the purchase of the WABECO machine you have decided in favour of a quality tool. This machine
has been manufactured with the greatest of care and subject to precise quality controls.
These operating instructions are designed to help your to use your new machine safely and correctly.
For this reason, we ask you to read the appropriate notes through attentively and to take care to observe
them.
After unpacking the tool, check whether any transportation damages have occurred. Complaints, wha-
tever their nature, should be communicated immediately. Subsequent claims cannot be recognised.
For all queries and replacement part orders, please always specify the machine number (see type
plate).
Reprinting and reproductions of any kind, even extracts, require the written permission of
WABECO
The transportation and protective packaging is made of the following materials:
■ Corrugatedcard
■ PolystyrenewithoutFreon
■ Polyethylenefoil
■ Timberassingle-usepallet(untreated)
■ Europallet(multipleusepackaging)
Ifyounolongerneedtheitems,oryoudonotwanttoreusethem,disposeoftheseitemsattheofcially
recognised recycling points.
The machine is manufactured in such a way that 98% of the used materials that can be recycled, for
example, steel, cast iron, aluminum and only 2% are chemical materials, e.g. cable sleeves of electrical
cables, PCBs.
Ifyouhaveanydifcultiesindisposingofthesepartsproperly,wewouldbehappytohelp:withprior
agreement we will take back the machine in full and dispose of it. You must, however, cover the costs
of sending it to us.
Disposing of the machine
wabeco-rs.de
Walter Blombach GmbH
42899 Remscheid
Am Blaffertsberg 13
Germany
Phone [phone]
Fax [phone]
E-Mail [email protected]

3
Index
Declaration of conformity F1410 LF – F1410 LF hs 7
Declaration of conformity F1410-C LF – F1410-C LF hs 8
Declaration of conformity CC-F1410 LF – CC-F1410 LF hs 9
1. Important safety notes 10
1.1 Intended use 10
1.2 Improper and incorrect use 10
1.3 Modicationstothemachine 10
1.4 Safety regulations for proper use 10
1.5 Safety features 13
1.5.1 for all milling machines 13
1.5.2 for milling machines for the installation of a CNC controller and 13
for CNC milling machines
1.5.3 for CNC milling machines 13
1.6 Explanations of the symbols 14
2. Delivery and set up 14
2.1 Transporting the machine 15
2.2 Transport-lock on milling machines with ball screws 16
3. Putting into operation 17
3.1 for all milling machines 17
3.2 for all CNC machines 17
3.2.1 Setting up and connecting the control computer 17
4. Specications regarding the machine 18
4.1 Identicationofthemodel 18
4.2 F1410 LF – F1410 LF hs 18
4.2.1 Declaration of noise levels 18
4.2.2 Technical data 19
4.2.3 Dimensions F1410 LF (1.4 kW) with trapezoidal thread spindle 20
4.2.4 Dimensions F1410 LF (1.4 kW) with ball screws 21
4.2.5 Dimensions F1410 LF hs (2.0 kW) with trapezoidal thread spindle 22
4.2.6 Dimensions F1410 LF hs (2.0 kW) with ball screws 23
4.3 F1410-C LF – F1410-C LF hs 24
4.3.1 Declaration of noise levels 24
4.3.2 Technical data 25
4.3.3 Dimensions F1410-C LF (1.4 kW) with trapezoidal thread spindle 26
4.3.4 Dimensions F1410-C LF (1.4 kW) with ball screws 27
4.3.5 Dimensions F1410-C LF hs (2.0 kW) with trapezoidal thread spindle 28
4.3.6 Dimensions F1410-C LF hs (2.0 kW) with ball screws 29
4.4 CC-F1410 LF – CC-F1410 LF hs 30
4.4.1 Declaration of noise levels 30
4.4.2 Technical data 31
4.4.3 Dimensions CC-F1410 LF (1.4 kW) with trapezoidal threaded spindle 32
4.4.4 Dimensions CC-F1410 LF (1.4 kW) with ball screws 33
4.4.5 Dimensions CC-F1410 LF hs (2.0 kW) with trapezoidal threaded spindle 34

4
Index
4.4.6 Dimensions CC-F1410 LF hs (2.0 kW) with ball screws 35
4.5 Revolution setting 36
4.6 Electrical equipment (1.4 kW) 37
4.7 Electrical equipment (2.0 kW) 37
5. Achieving optimum results 37
and avoiding incorrect usage
6. Installation and removal of collets 39
6.1 Installation 39
6.2 Removal 39
7. Fitting and removing the tools 40
8. Swiveling the milling head 42
9. Drill stroke – depth stop 43
10. Feed motions of the X-, Y- and Z-axes 44
11. Adjustment of the spindle nuts with trapezoidal thread spindle 46
11.1 X-axis 46
11.2 Y-axis 47
11.3 Z-axis 47
12. Maintenance 48
13. Lubrication of the machines 48
14. Operational faults and the elimination of such 50
15. Control elements 53
15.1 Control elements F1410 LF (1.4 kW) 53
15.2 Control elements F1410 LF hs (2.0 kW) 54
15.3 Control elements F1410-C LF (1.4 kW) 55
15.4 Control elements F1410-C LF hs (2.0 kW) 56
15.5 Control elements CC-F1410 LF (1.4 kW) 57
15.5.1 Switch cover on CNC control panel 58
15.6 Control elements CC-F1410 LF hs (2.0 kW) 59
15.6.1 Switch cover on CNC control panel 60
16. Drawings and legends 61
16.1 Protective hood 61
16.2 Electronic hood with 1.4 kW motor 62
16.2.1 F1410 LF – F1410-C LF 62
16.2.2 CC-F1410 LF 64
16.3 Milling head with 1.4 kW motor 66
16.4 Milling head wtih 2.0 kW motor 68
16.5 Z-column with vertical slide with trapezoidal thread spindle 72
16.6 Spindle Z-axis with trapezoidal thread spindle 76
16.6.1 F1410 LF – F1410 LF hs 76

5
Index
16.6.2 F1410-C LF – F1410-C LF hs – CC-F1410 LF – CC-F1410 LF hs 78
16.7 Lateral drive for Z-axis with trapezoidal thread spindle 80
16.8 Cross slide support – top slide – base plate with trapezoidal thread spindle 82
16.9 Spindle X-axis with trapezoidal thread spindle 86
16.9.1 F1410 LF – F1410 LF hs 86
16.9.2 F1410-C LF – F1410-C LF hs – CC-F1410 LF – CC-F1410 LF hs 88
16.10 Spindle Y-axis with trapezoidal thread spindle 90
16.10.1 F1410 LF – F1410 LF hs 90
16.10.2 F1410-C LF – F1410-C LF hs – CC-F1410 LF – CC-F1410 LF hs 92
16.11 Z-column with vertical slide with ball screws 94
16.12 Spindle Z-axis with ball screws 98
16.12.1 F1410 LF – F1410 LF hs 98
16.12.2 F1410-C LF – F1410-C LF hs – CC-F1410 LF – CC-F1410 LF hs 100
16.13 Lateral drive for Z-axis with ball screws 102
16.14 Cross slide support with ball screws 104
16.15 Spindle X-axis with ball screws 106
16.15.1 F1410 LF – F1410 LF hs 106
16.15.2 F1410-C LF – F1410-C LF hs – CC-F1410 LF – CC-F1410 LF hs 108
16.16 Spindle Y-axis with ball screws 110
16.16.1 F1410 LF – F1410 LF hs 110
16.16.2 F1410-C LF – F1410-C LF hs – CC-F1410 LF – CC-F1410 LF hs 112
16.17 Limit switch for X-axis 114
16.17.1 F1410-C LF – F1410-C LF hs – CC-F1410 LF – CC-F1410 LF hs 114
16.18 Limit switch for Y-axis 115
16.18.1 F1410-C LF – F1410-C LF hs – CC-F1410 LF – CC-F1410 LF hs 115
16.19 Limit switch for Z-axis 116
16.19.1 F1410-C LF – F1410-C LF hs – CC-F1410 LF – CC-F1410 LF hs 116
16.20 Control panel for 1.4 kW motor 118
16.21 Control panel for 2.0 kW motor 122
16.22 Support arm for control panel 126
16.23 Industrial monitor and membrane keyboard 128
16.23.1 Industrial monitor and membrane keyboard for 1.4 kW motor 130
16.23.2 Industrial monitor and membrane keyboard for 2.0 kW motor 132
16.24 Support arm for industrial monitor and membrane keyboard 134
17. Circuit diagram 135
17.1 for motor 1.4 kW 135
17.2 for motor 1.4 kW and machine safety cabin 136
17.3 Industrial monitor and membrane keyboard for 1.4 kW motor 137
17.4 for motor 2.0 kW 138
17.5 for motor 2.0 kW and machine safety cabin 139
17.6 Industrial monitor and membrane keyboard for 2.0 kW motor 140
17.7 Stepper motor with limit switch 141

6
Index
17.8 NC-rotary table 141
17.9 Legend for ciruit diagrams 142
18. Coolant unit (optional) 143
18.1 Setting up the coolant unit 143
18.2 Mounting of the coolant unit to the machine base cabinet (optional) 143
18.3 Mounting of the coolant return plate (optional) 144
18.4 Safety regulations for the handling of cooling lubricant 145
18.5 Filling the coolant unit 145
18.6 Operating the coolant unit without CNC controller 146
18.7 Operating the coolant unit with CNC controller 146
18.8 Positioning the segmented coolant hose 147
18.9 Controllingtheowofcoolantusingthecoolantshut-offvalve 147
18.10 Drawings and legend 148
19. Machine safety cabin (optional) 149
19.1 Setting up the machine safety cabin 149
19.2 Mounting of the machine safety cabin to the machine base cabinet (optional) 149
19.3 Safety regulations for the handling of cooling lubricant 150
19.4 Filling the coolant unit integrated in the machine safety cabin 150
19.5 Operating the coolant unit with CNC controller 150
19.6 Positioning the segmented coolant hose 150
19.7 Controllingtheowofcoolantusingthecoolantshut-offvalve 150
19.8 Drawing and legend 151
20. Mounting bracket (optional) 152
20.1 Mounting the mounting bracket to the milling machine 152
20.2 Inserting the drive unit into the mounting bracket 153
20.3 Drawing and legend 153
21. NC-rotary table (optional) 154
21.1 Clamping of workpieces on the NC-rotary table 154
21.2 Swiveling the worm shaft in and out 154
21.3 Setting the axial play of the NC-rotary table 155
21.4 Removing the NC drive unit 156
21.5 Setting the axial play of the worm shaft 157
21.6 Setting the axial play of the eccentric tappet 157
21.7 Drawing and legend 158

7
Declaration of conformity
We hereby declare, in the name of the manufacturer
Walter Blombach GmbH
Werkzeug- und Maschinenfabrik
with headquarters in Remscheid and Neuerburg
D-42871 Remscheid Postfach 12 01 61 Telephone: [phone] Fax: [phone]
D-54673 Neuerburg WABECO Str. 1-10 Telephone: [phone] Fax: [phone]
that the following named
Universal boring and milling machine
Type:
F1410 LF - F1410 LF hs
iin the serial version, meets the following relevant regulations
- EU Machine Directive 2006/42 EG
- EMC Directive 2014/30/EU
- EU Low Voltage Directive 2014/35/EU
Inordertofulll/implementtherequirementsofthedirectivesnamedabove,thealreadypublishedand
applicable standards were drawn upon:
EN ISO 12100:2010
DIN EN 60204-1:2007
DIN EN 13128:2009
Proxy for the compilation of the technical documentation is the operational head of the above named
manufacturer, Mr Christoph Schneider.
D-54673 Neuerburg 2018
________________________________
Place and date of issue
________________________________
Operational head Christoph Schneider

8
Declaration of conformity
We hereby declare, in the name of the manufacturer
Walter Blombach GmbH
Werkzeug- und Maschinenfabrik
with headquarters in Remscheid and Neuerburg
D-42871 Remscheid Postfach 12 01 61 Telephone: [phone] Fax: [phone]
D-54673 Neuerburg WABECO Str. 1-10 Telephone: [phone] Fax: [phone]
that the following named
CNC milling machine
Type:
F1410-C LF - F1410-C LF hs
in the serial version, meets the following relevant regulations
- EU Machine Directive 2006/42 EG
- EMC Directive 2014/30/EU
- EU Low Voltage Directive 2014/35/EU
Inordertofulll/implementtherequirementsofthedirectivesnamedabove,thealready
published and applicable standards were drawn upon:
EN ISO 12100:2010
DIN EN 60204-1:2007
DIN EN 13128:2009
Proxy for the compilation of the technical documentation is the operational head of the above named
manufacturer, Mr Christoph Schneider.
D-54673 Neuerburg 2018
________________________________
Place and date of issue
________________________________
Operational head Christoph Schneider

9
Declaration of conformity
We hereby declare, in the name of the manufacturer
Walter Blombach GmbH
Werkzeug- und Maschinenfabrik
with headquarters in Remscheid and Neuerburg
D-42871 Remscheid Postfach 12 01 61 Telephone: [phone] Fax: [phone]
D-54673 Neuerburg WABECO Str. 1-10 Telephone: [phone] Fax: [phone]
that the following named
CNC milling machine
Type:
CC-F1410 LF – CC-F1410 LF hs
in the serial version, meets the following relevant regulations
- EU Machine Directive 2006/42 EG
- EMC Directive 2014/30/EU
- EU Low Voltage Directive 2014/35/EU
Inordertofulll/implementtherequirementsofthedirectivesnamedabove,thealreadypublishedand
applicable standards were drawn upon:
EN ISO 12100:2010
DIN EN 60204-1:2007
DIN EN 13128:2009
Proxy for the compilation of the technical documentation is the operational head of the above named
manufacturer, Mr Christoph Schneider.
D-54673 Neuerburg 2018
________________________________
Place and date of issue
________________________________
Operational head Christoph Schneider

10
1. Important safety notes
1.1 Intended use
The milling machines described in these operating instructions are designed for the processing of metal,
plastic and timber only.
To ensure safe operation of the milling machines, the regulations set out in the chapter: „Safety regula-
tions“ must be observed.
The milling machines described in these operating instructions have been developed and manufactured
for the purpose named above. Walter Blombach GmbH accepts no responsibility for property damage
and personal injury caused as a result of not intended and incorrect use of the milling machines
1.2 Improper and incorrect use
1.3 Modications to the machine
Forreasonsofsafety,itisforbiddenfortheusertomakemodicationsofanytypetothemillingmachine.
Walter Blombach GmbH accepts no responsibility for property damage and personal injury caused as
aresultofanymodicationstothemillingmachinebytheuserthathavenotexpresslybeenauthorised
by the company.
1.4 Safety regulations for proper use
The machine may represent a source of danger if it is not used correctly. For this reason, it is important
that the following safety regulations are read attentively and observed carefully.
Every person that operates the machine, maintains or repairs it, must have read the operating instruc-
tions, and in particular, the safety notes prior to putting the machine into operation.
Inordertofulltheserequirements,theseoperatinginstructionsmustaccompanythemachinethroug-
hout its entire lifetime and be available for research.
In the event that the machine changes owners, the operating instructions must thus be passed on to the
new owner along with the machine.

11
1. Important safety notes
1.4 Safety regulations for proper use
1. Only specially trained persons may operate the machine. The guarantee and warranty are voided
if damages are caused by improper operation.
2. We remind you that no liability will be accepted for damages caused by not observing these ope-
rating instructions.
3. The operator of the machine is to ensure that at least one copy of the operating instructions is
stored in the immediate vicinity of the machine and available to the people who work with the
machine.
4. Theoperatoristoensurethatthesafetyanddangernoticationsonthemachineareobserved
and that the signs are kept in a legible state.
5. Do not work without goggles.
6. Wearclosettingclothingand,ifyouhavelonghair,wearahairnet.Donotwearloosettingor
loose items (ties, shirt sleeves, jewellery etc.).
7. Gloves may not be worn.
8. In the event of an emission noise level as of 80 dB (A) at the workplace, ear defenders must be
worn.
9. The machine may not operate without supervision.
10. Secure your machine in such a way that it cannot be switched on by children. Persons who have
not been trained may not operate the machine.
11. Before using the machine, make sure it is in good working condition. Pay special attention to any
damage to the grounded plug or the electrical connections. Never operate the machine with a
defective, crushed or exposed cable.
12. Plug the grounded plug into a suitable socket for the machine. The cable for the machine may
only be connected to a safety socket or a connection box. Have the safety socket or connection
box checked by an electrical specialist before hand.
13. The safety socket or connection box must be close enough to the machine that the power cable
is not under strain.
14. When carrying out maintenance and cleaning work, the machine must be switched off and the
grounded plug pulled out.
15. Set-up work is only to be carried out with the machine switched off.
16. Do not reach into the operating machine.

12
1. Important safety notes
1.4 Safety regulations for proper use
17. Always switch the machine off when you are not using it.
18. Remain with the machine until it has come to a standstill.
19. Onlyhaverepairscarriedoutbyaqualiedspecialist!Repairworkmayonlybecarriedoutby
personswhoarequaliedfortherelevantrepairsandwhoarefamiliarwiththeappropriatehealth
and safety requirements.
20. Protect the machine from damp
21. Constantly check the machine for damages. Replace damaged parts only with original parts and
have these replaced by a specialist. The guarantee and warranty is voided if accessories and
replacement parts are use that are not designed for the machine.
22. Toavoidinsufcientlighting,werecommendsettingupalightsourcethatprovidesavalueofat
least 500 Lux at the tool‘s cutting edge.
23. Do not remove the generated shavings with your hand. Use the appropriate tools (hand-held
sweeper, hook, brush).
24. Tools and workpieces may never be changed when the machine is running.
25. Workpieces must be secured in such a way that they are not moved from their position by the
rotation of the boring or milling machine.
26. Workpiecesmustbesecuredbysuitablexturese.g.prisms,machineviceetc..
27. Chuck keys or similar tools may not be attached to the machine to ensure that they cannot be
caught by the spindle and thrown about.

13
1.5 Safety features
1. Important safety notes
1.5.1 for all milling machines
In order to enable you to work safely with our machines, we have incorporated the following safety me-
chanisms. These meet the relevant European safety requirements:
Protective hood
The protective hood is secured to the machine housing and is designed to prevent touching of the rota-
ting tool spindle. The protective hood is constructed in such a way that the working height (depending
on the dimensions of the workpiece and tool) can be adjusted. The protective hood can be swiveled to
enable fast exchange of tools.
ON/OFF switch with under-voltage trigger
TheON/OFFswitchisttedwithanunder-voltagetrigger,thus,intheeventofapowerfailure,thema-
chine does not switch itself back on automatically. This prevents risks caused by the unexpected motion
of the tool spindle.
Emergency off switch
The emergency off switch acts to quickly stop the machine.
Overload protection
The machine is tted with an overload protection feature. This overload protection feature switches
the main drive motor off automatically when the machine is overloaded. The machine can only then be
switched on after a waiting period.
1.5.2 for milling machines for the installation of a CNC controller and
for CNC milling machines
Machine safety cabin (optional)
In CNC mode, the door to the machine safety cabin must be closed in order for the milling machine to
work in CNC operation.
You can only work in CNC mode with the doors closed.
Work carried out in conventional mode is carried out with the door open. The mode switch must be
switched to manual mode.
The main spindle can be switched on when the doors are closed or open.
Working in CNC mode without machine safety cabin may pose a serious risk to the machine
operator and cause serious accidents.
1.5.3 for CNC milling machines
Switch for operating modes
The mode switch has 3 settings (CNC mode – Idle position – Manual mode) that can only be selected
with a key. After selecting the mode, the key can be removed in order to prevent a switching of the mode
type by unauthorised persons.

14
1. Important safety notes
1.6 Explanations of the symbols
With a measured noise level of 80 dB (A) at the workpla-
ce the operator should wear Ear Protection.
Caution:
Always pull the power plug prior to any maintenance
work!
Read the operating instructions prior to initial operation or
maintenancework!
Caution:
Dangerouselectricvoltage!
2. Delivery and set up
The machine is packed with care at the factory.
The following should be checked after delivery:
1. Whether the packaging shows damages to be reported or
2. Whether the machine shows transportation damages to be reported If this is the case, we ask you to
communicate this information immediately. Subsequent claims cannot be recognised.
Theboringandmillingmachinemustbesetuponasuitable,evenandrmsurface.Suitablesurfaces
are, for example:
■A machine base cabinet (available optionally)
■A separate workbench with a level surface (spirit level) that is strong enough to carry the weight of
the machine without bending.
■A steel plate with a level surface (spirit level)
The machine must be screwed securely to the surface it is set up on. There are holes in the base of the
machine that are designed for this purpose. Good working results and low-vibration operation can
only be ensured when the prerequisites for xture as set out above are maintained.

15
2. Delivery and set up
The place of set up should be selected in such a way that
■ Thereissufcientlighting
■The electrical power supply with safety socket and earth are installed close enough to the machine
that the power cable is not subject to any strain.
■The power cable should also be dimensioned in such a way that a multiple socket can be used, for
example, to power a coolant unit.
2.1 Transporting the machine
We recommend three people to lift the machine, using the positions shown (1). In doing so, two people
should hold the machine on the left and right of the upper skid, the third should hold and balance the ma-
chine at the end of the base plate.
Due to the weight of the machine it is advisable to lift the machine by crane, if this is possible. To lift, wrap
suitable lashing (2) as shown around the head of the machine. Before lifting the machine, ensure that the
milling head has been moved to the upper end position to prevent damage to the machine
Whenlifting,payattentiontoanergonomicstanceandsufcientsafety!
1
1
1
2

16
2. Delivery and set up
2.2 Transport-lock on milling machines with ball screws
Caution – prior to machine startup the transport-lock must be removed
How to proceed:
1. With the hand wheel via the Z-axis, drive the milling head a minimal distance up.
2. Remove the wooden support below the milling spindle
3. at least on one side, loosen the transport-lock (1)the bolts (2)
4. the transport-lock (1) must be slidable without resistance
5. if this is not the case, then the milling head must be moved via the hand wheel ofthe Z-axis far enough
away, so that the wire cables under tension and are supportingthe weight.
now the transport-lock (1) is relieved and ca be pulled off.
A ( 1 : 1 )
1
2

17
3. Putting into operation
3.1 for all milling machines
■Use a dry cloth to remove the corrosion protection that was applied to all exposed parts for transport
■In the event of marine impregnation of exposed parts, it is recommended you spray them with oil,
allow it to work, and then remove the impregnation with a dry cloth.
■Once set up properly (see the section on delivery and set up) connect the grounded plug directly to
a safety socket and the 230 V 50/60 Hz (optional 110 V 60 Hz) mains power supply.
■ Provisionofsufcientcoolantfortheoperationofacoolantunit
■(optional)
■Release the axis clamps and check the individual feed spindles for easy operation
■Bei konventionelle Maschinen die Achsklemmungen lösen
■Check all electronic control elements, for example, ON/OFF switch, emergency off switch, potenti-
ometer etc. for functionality.
3.2 for all CNC milling machines
WhenputtingCNCmachinesintooperationforthersttime,alwaysreadthestart-upmanual.
3.2.1 Setting up and connecting the control computer
When selecting a suitable control computer, pay attention to the system prerequisites of the
control software. These are listed on the rear of the CD case sent with the machine.
Follow the instructions in the start manual of the software to install the control software on the computer.
The start manual can be found in the CD case of the control software included with the machine.
In the next step, the software must be adapted to your machine. To do this, follow the instructions sent
with the machine which detail the editing of the parameters.
When the software has been successfully installed on the control computer and all parameters have
been adapted successfully, the control computer must be connected with the machine controller.
The machine controller communicates with the computer via the serial interface (COM port). In order to
establish a connection between the machine controller and the computer, connect the end of the inter-
face cable that is on the machine console to the COM port of the computer.
CAUTION:
The axial cable of the step motors and the serial interface cable may only be plugged in or remo-
ved when the controller is switched off. Otherwise this may lead to damage to the controller, the
machine or the control computer.

18
4. Specications regarding the machine
4.1 Identication of the model
The precise model designation of your machine can be found on the type plate attached to the machine.
4.2.1 Declaration of noise levels
Declaration of noise levels in accordance with DIN EN ISO 3744
Emission values in idle
F1410 LF F1410 LF hs
Emission sound pressure level at the workplace
at 50 % = 66.8 dB (A) = 74.8 dB (A)
at 100 % = 66.7 dB (A) = 76.4 dB (A)
Sound power level
at 50 % = 73.7 dB (A) = 84.1 dB (A)
bei 100 % = 79.1 dB (A) = 80.3 dB (A)
At an emission sound pressure level from 80 dB (A) and above at the workplace
ear protection is required.
4.2 F1410 LF – F1410 LF hs

19
F1410 LF F1410 LF hs
Working range
Longitudinal travel X-axis 500 mm
Vertical travel Z-axis 280 mm
Transverse travel Y-axis 200 mm
Drill stroke 55 mm
Distance milling table - tool spindle min. 65 mm
max. 350 mm
Outreach tool spindle - Z-column 185 mm
Main drive motor
Nominal voltage 230 V
Nominal frequency 50/60 Hz
Nominal performance of the spindle motor 1.4 kW 2.0 kW
Spindlerevolutions,innite 140 - 3000 rpm 100 – 7500 rpm
Machine precision
True running accuracy of the tool spindle 0.01 mm
Milling head
Swiveling feature in both sides 90° (-90° to +90°)
Tool spindle
Tool holder MT2 tightening thread M10
optional
MT3 tightening thread M12
ISO30 DIN2080 tightening thread M12
Work table
700 x 180 mm
Number of T-slots 3
Width of T-slots 12 mm
4. Specications regarding the machine
4.2.2 Technical data
4.2 F1410 LF – F1410 LF hs

20
4. Specications regarding the machine
4.2.3 Dimensions F1410 LF (1.4 kW) with trapezoidal thread spindle
4.2 F1410 LF – F1410 LF hs
53 305
404
197 min. 70 - max. 350
min. 710 - max. 990
185
180
225
250 max. 710max. 505
700
690
min. 0 - max. 200
35
720
950
