WAC SWIRL F-074L User manual

SWIRL
Installation Instructions
works with the
Google Assistant

Please read and review instructions
before installation

For all questions about your ceiling fan please read all
included instructions, installation procedures, trouble-
shooting guidelines and warranty information before
starting installation
For fast service have the following information below
when you call:
For missing parts or general inquiries
call our trained technical sta at:
• Model Name and Number
• Part Number and Part Description
• Date Of Purchase and Purchase Location
Email: [email protected]
Or live chat at www.waclighting.com
Email: [e-mail]
1-800-526-2588 option 01-800-526-2588 option 3
MON-FRI 8AM-8PM EST MON-FRI 8AM-8PM EST
GENERAL INQUIRIES FAN SUPPORT
DO NOT RETURN TO STORE

1. To reduce the risk of electric shock, ensure electricity has been turned o
at the circuit breaker before beginning.
2. All wiring must be in accordance with the National Electrical Code “ANSI/
NFPA 70”and local electrical codes. Electrical installation should be per-
formed by a licensed electrician.
3. To reduce the risk of re, electric shock, personal injury or damage to the
fan or other items, the outlet box and support structure must be securely
mounted and capable of reliably supporting a minimum of 35 Ibs (15.9
kg). Use only UL/cUL
listed outlet boxes marked “FOR FAN SUPPORT.” Use only
the screws and washers provided with the outlet box.
4. The fan must be mounted with a minimum of 7 ft. (2.1m)
clearance from the trailing edge of the fan blades to the oor
and a minimum of 1.5 ft (0.5m) from the edge of the fan blades to the
surrounding walls.
5. Never place objects in the path of the fan blades.
6. To avoid personal injury or damage to the fan and
other items, please be cautious when working around
or cleaning the fan.
7. To avoid electrical shock or damage to the motor or nish, do not use wa-
ter or chemicals when cleaning the fan or fan blades. A dry cloth or lightly
dampened cloth will be suitable for most cleaning.
8. After making electrical connections, spliced conductors should be turned
upward and pushed carefully up into the outlet box. The wires should be
spread apart with the grounded conductor and the equipment-ground-
ing conductor on one side of the outlet box, and the
ungrounded conductor on the other side of the outlet box.
9. All set screws must be checked and re-tightened where necessary before
installation.
SAFETY RULES
For operation, maintenance, and troubleshooting information, visit http://waclighting.com/fan-support/
Hanging Weight:
F-074L: Net Weight: 11.90 LBS. (5.4kgs)
F-074L: Gross Weight: 16.75 LBS.(7.6kgs)

WARNING: Do not install or use your fan if any part(s) is/are damaged or
missing. This product is designed for use only with the supplied parts and/or
accessories designated for use with this product by WAC. Substitution of parts
or accessories not designated for use with this product by WAC could result
in personal injury or property damage and will void the warranty. Contact an
authorized dealer or the manufacturer if any parts are damaged or missing.
WARNING: To reduce the risk of electric shock, this fan must
be installed and operated with the supplied wall control, or controlled from the
WAC app or Wall Control (not included).
WARNING: Do not use power tools to assemble or install your fan. Using power
tools can result in improper assembly which can lead to noise or fan dam-
age,personal injury or property damage.
WARNING: To reduce the risk of personal injury, do not bend the
blade arms when installing the brackets, balancing the blades or cleaning the
fan.
WARNING: Do not insert foreign objects between rotating fan blades.
WARNING: Do not operate fan unless fan blades are in place.
Noise and fan damage can occur
WARNING: This appliance is not intended for use by young
children without supervision.
CAUTION: Before assembling your fan, refer to the “Making
the Electrical Connections“ section. If you feel you do not have
enough wiring knowledge or experience, have your fan installed
by a licensed electrican.
NOTE: Before servicing or cleaning the fan, switch power o at
the circuit breaker.
02 SAFETY RULES

This WAC Smart Fan is:
DC
MOTOR
The WAC app synchronizes seamlessly with smart home devices you already own
GET SMART
works with the
Google Assistant
WALL CONTROL
WC20-WT
Optional accessory
Sold separately
6 fan speeds
Dims light to 1%
ON/OFF
APP DOWNLOAD
Available for purchase on
the Google Pay and App Store
Quiet, reliable, and up to 70%
more ecient than AC motor fans
Wi-Fi and Bluetooth enabled
for unlimited control
Wet location-listed to the strictest UL/cUL
safety regulations
Compatible with our WAC app
Coordinates with smart devices
for voice-activated control
REMOTE CONTROL
RC20-WT White
Included with
each fan
6 fan speeds
Dims light to 1%
ON/OFF

WALL CONTROL
WC20-WT
Optional accessory
Sold separately
6 fan speeds
Dims light to 1%
ON/OFF
Package Contents
Mounting Options
Installing the Mounting Bracket
Attaching the Fan Blades
Hanging the Fan
Making the Electrical Connections
Installing the Optional Wall Control
Finishing Hanging the Fan
Installing the Adapter Plate
Installing the Luminaire Module/Glass
Controlling the Fan
Reset
App Instructions
Accessories
Troubleshooting
9.
10.
10.
11.
12.
16.
17.
19.
20.
21.
22.
25.
26.
27.
29.
4
7
7
8
9
10
11
12
13
14
15
16
5
5
6
TABLE OF CONTENTS

F-074L
8
Electrical tape
Phillips screwdriver Step ladder Wire cutters
NOTE: Before discarding packaging materials, be certain all parts have been removed.
NOTE: Place the parts from the hardware bag into a small container to keep them from being lost.
MAC ID
03 TOOLS & MATERIALS REQUIRED
IMPORTANT: Please make note of the MAC ID on the receiver and keep it in a safe place.

9F-074L
NOTE: ** denotes nish code of fan / blade sweep
1
10
7
3
9
5
4
13
2
8
11
12 10
A: Junction Box
Machine Screws (2)
Spring Washers (2)
Flat Washers (2)
B: Blades
Blade Screws (16)
C: Safety Cable
Flat Washer (1)
Spring Washer (1)
Wood Screw (1)
D: Wire Connectors/Ties(8)
(included with receiver)
Canopy Ring
RPL-CAN-RND-**
Adapter Plate
RPL-F074-ADP-**
Coupling Cover
RPL-F074-COUCVR-**
Hardware Bag
RPL-F074-PARTS
Canopy
RPL-CAN-RND-**
Motor
Housing
Fan Blade
RPL-F074-54-BD-**
Remote Control
RC20-WT
PACKAGE CONTENTS 04
Downrod
Assembly
RPL-HGR-ASM-**
Mounting
Bracket
RPL-HGR-ASM-**
PC Shade
RPL-F074-GLA
Luminaire Module
F4IN-120V-R1-30
Receiver
F-R3-074-054

F-074L
10
12
05 MOUNTING OPTIONS INSTALLING THE MOUNTING BRACKET
1. Secure the hanger bracket to the ceiling outlet box using
screws included with your outlet box, lock washers included
with the fan. Use the screws included with your outlet box to
mount the hanger bracket.
2. Pass supply wires through mounting bracket and secure
to outlet box.
Standard Ceiling Slope Ceiling
Caution: Remember to disconnect
the power at the circuit breaker.
CAUTION: To prevent electrical shock, ensure electricity
has been turned o at the circuit breaker before beginning.
Figure 1 is an example of how to mount the outlet box.
If needed use Ahardware to mount the outlet box to the ceiling
joist.
To Switch To Switch
(Hot) (Hot)/
Switch
(Ground) (Ground)
(No Neutral)
(Neutral) *Bare or
Green
*Bare or
Green
AA
B

1. Place the blade on the top of the housing. Align the holes in
the blade with the fan motor assembly holes and secure with
blade attachment screws. Use Bhardware.
2. Repeat this procedure with the remaining blades.
3. Flip the fan over and place on soft cloth or the foam in
the carton to stabilize the fan. Screw in the other side
of the blades with same screws as used in the prior
step. Make sure all screws are on tight.
11F-074L
3
ATTACHING THE FAN BLADES 06

lHanger Bal
nPi
dDownro
Set Screw
1. Remove the hanger ball portion from the
downrod/ hanger ball assembly by loosening
the set screw in the hanger ball until the ball falls
freely down the downrod. Remove the pin from
the downrod, then remove the hanger ball. Retain
the pin and hanger ball for reinstallation.
2. Remove the hairpin clip and clevis pin from the
bottom of the downrod. Retain the pin and clip for
reinstallation.
3. Loosen the two set screws in the downrod
support of the motor assembly. Route the blue/
white, red, gray, yellow wires and safety cable
through the downrod.
4. Thread downrod into the collar on top of the
motor. Install the clevis pin by aligning the holes in
the downrod support with holes in the downrod.
Secure clevis pin with hairpin clip. Tighten the two
set screws with nuts in the downrod support.
5. Slip the coupling cover, canopy screw cover
Black/White, Blue,
Red, Gray, Yellow
wires and safety cable
Downrod
Set Screws (2)
dDownro
Hairpin Clip
)Locking Nuts (2
Set Screws and
nClevis Pi
Blue/White, Bl
F-074L
12
07 HANGING THE FAN
4
6
5
7
nClevis Pi
Hairpin Clip
Cross Pin
Blue/white, red,
gray, yellow wires
and safety cable

(painted side face down), and canopy (opened side up) onto
the downrod. Coupling cover goes all the way to the bottom.
6. Carefully reinstall the hanger ball onto the downrod, being
sure that the cross pin is in the correct position, the setscrew
is tightened and wires are not twisted. A loose set screw could
create fan wobble.
7. Carefully lift the fan motor assembly up to the mounting
bracket and seat the hanger ball in the mounting bracket
socket. Make sure the tab on the mounting bracket socket is
properly seated in the groove in the hanger ball. Rotate the
socket assembly until the ball drops and locks into
the hanger bracket screw. You may cut o excess lead wire
approximately 6-9 inches above the top of the downrod. Strip
wire insulation o 1/2 inch from the end of each lead wire.
10
13F-074L

HANGING THE FAN 07

NOTE: A Safety cable is required for all installations in Canada.
Safety cable is required for ceiling fan and light combinations over
35 lbs. in both ush and downrod models in the United States.
Make sure you have the correct down-rod size prior to
cutting said lead wire. Make sure the electrical supply
wires, including the hanger bracket grounding wire and
safety cable are pulled through the downrod, between
the hanger bracket and the outlet box so that electrical
connections can be made later.
8. Secure the safety cable into the structure beams using
the wood screw, washers, and spring washers provided.
Use Chardware.
9
F-074L
14
07 HANGING THE FAN

WARNING: Installation of this fan requires that a three-con-
ductor cable (including ground and neutral wire) which should run
between ceiling and wall outlet box.
WARNING: Check to see that all connections are tight,
including ground, and that no bare wire is visible at the wire nuts,
except for the ground wire.
1. * Make note of the MAC ID as refrenced prior.
2. Insert the receiver into the mounting bracket with the at side
of the receiver facing the ceiling.
1
2
1. Mounting Bracket
2. Receiver
11
15F-074L
HANGING THE FAN 07

11A 1. Connect the hanger ball/downrod assembly ground wire,
mounting bracket ground wire and receiver ground wire to
the ground wire in outlet box. Make sure all connections are
made correctly or you will permanently damage the receiver.
You may also refer to the labels on the receiver wires for
direction on how to make proper connections.
Use DHardware.
WARNING: Failure to connect ground wires could result in
poor fan control functionality.
2. Connect the red wire from the fan to the red wire marked
“TO MOTOR” from the receiver.
3. Connect the grey wire from the fan to the grey wire marked
“TO MOTOR” from the receiver.
4. Connect the yellow wire from the fan to the yellow wire
marked “TO MOTOR” from the receiver.
5. Connect the white wire from the fan to the white wire marked
“FOR LIGHT”from the receiver.
6. Connect the blue wire from the fan to the blue wire marked
“FOR LIGHT”from the receiver.
7. Connect the black (hot) wire from the ceiling to the black wire
marked “AC in L” from the receiver.
8. Connect the white (neutral) wire from the ceiling to the white
wire marked “AC in N”from the receiver.
F-074L
16
07 MAKING THE ELECTRICAL CONNECTIONS
GREY(to Receiver)
GREEN(Hanger Ball)
YELLOW(to Receiver)
RED(to Receiver)

17F-074L
INSTALLING THE OPTIONAL WALL CONTROL 08
12
NOTE:Wall control not included. A Bluetooth wall control accessory can be purchased separately. Skip this section if you did not purchase a wall control.
NOTE: For multi-location wiring, skip to the next step.
1. Connect the green wire marked“GROUND”from the wall control to the copper wire from the wall outlet box that
feeds back to the circuit breaker – important for proper fan function.
2. Connect the black wire marked “LINE IN”from the wall control to the black LINE VOLTAGE wire from the wall
outlet box that feeds back to the circuit breaker.
3. Connect the red wire from the wall control to the black wire from the wall outlet box that feeds up to the fan.
4. Connect the white wire from the wall control to the white (neutral) wire from the wall outlet box.
5. Carefully tuck the wire connections inside the outlet box. Secure the wall control with the two (2) wall control screws provided.
6. Attach the wall mounting plate over the wall switch and secure with the two (2) wall mounting plate screws provided.
7. Fasten the wall plate to the wall mounting plate.

1. Install the wall control using the wiring diagram above.
2. Individually pair each of the wall controls with the fan receiver using the pairing instructions in section 12.
Wall Control 1 Wall Control 2 Wall Control 3
08 INSTALLING THE OPTIONAL WALL CONTROL

FINISHING HANGING THE FAN 09
19
13 1. Secure wire connectors with supplied wire ties.
2. Install canopy to mounting bracket with the screw
removed in section 2.
3. Install canopy screw ring as shown.

F-074L
20
14
10 INSTALLING THE ADAPTER PLATE
1. Remove 1 screw from the mounting ring and loosen 2 others.
2. Tighten the two mounting ring screws previously loosened
and the one previously removed to secure adapter plate.
