Wacker Neuson WP User manual

Operator’s Manual
Vibratory plate
WP
Machine Type WP1050A, WP1550Aw
Material Number 5100069895
Version 2
Date 01/2023
Language [en-US] 5100069895

Imprint
Publisher and copyright holder:
WackerNeusonProduktionGmbH&Co.KG
Wackerstraße 6
85084 Reichertshofen,
Registered office: Reichertshofen
Register court and number: Local Court Ingolstadt, HRA3195
VAT ID No./VAT Number: DE277138620
Telephone: [phone]
www.wackerneuson.com
Original operator’s manual
All rights reserved, in particular the copyright, the right of reproduction and the right of distribution applicable
worldwide.
This document may be used by the recipient only for the designated purpose. It may in no way be duplicated or
translated in any other language, in whole or in part, without prior permission in writing from the manufacturer.
Reproduction or translation of this publication, in whole or part, is not permitted without the written consent of
Wacker Neuson Produktion GmbH & Co. KG.
Violations of legal regulations, in particular of the copyright protection, will be subject to civil and criminal prosecu-
tion.
Wacker Neuson Produktion GmbH & Co. KG reserves the right to change its products and their technical specifi-
cations for further technical development at any time without any claim to changes to machines already delivered.
The information in the technical documentation supplied with the product applies in each case.
The machine on the cover is for illustration purposes only and may therefore have special equipment (options).
Wacker Neuson Produktion GmbH & Co. KG, responsibility for errors or omissions not accepted, printed in Ger-
many
Copyright © 2023

California Proposition 65 Warning
WARNING
The engine exhaust from this product contains chemicals known to
the State of California to cause cancer, birth defects, or other repro-
ductive harm.
WARNING
Diesel engine exhaust and some of its constituents are known to the
State of California to cause cancer, birth defects, and other reproduc-
tive harm.
WARNING
Cancer and Reproductive Harm
www.P65Warnings.ca.gov
WARNING
Batteries, battery posts, terminals and related accessories contain
lead and lead compounds, and other chemicals known to the State of
California to cause cancer and birth defects or other reproductive
harm. WASH HANDS AFTER HANDLING.

Contents
iv Operator’s Manual | WP | 5100069895 | 01/2023 | [en-US]
Contents
1 EC Declaration of conformity
2 Foreword
2.1 Introduction ....................................................................................................................................... 8
2.2 Storage Location of the Operator's Manual ...................................................................................... 8
2.3 Accident Prevention Regulations ...................................................................................................... 9
2.4 Contact person.................................................................................................................................. 9
2.5 Limitation of liability......................................................................................................................... 10
2.6 Use of the operator’s manual.......................................................................................................... 10
3 Usage
3.1 Designated use ............................................................................................................................... 11
3.2 Unintended use............................................................................................................................... 11
4 Safety
4.1 Safety symbols and signal words.................................................................................................... 12
4.2 Principle .......................................................................................................................................... 12
4.3 Structual changes ........................................................................................................................... 13
4.4 Responsibility of the operator ......................................................................................................... 13
4.5 Obligations of the operator.............................................................................................................. 14
4.6 Qualification of staff ........................................................................................................................ 14
4.7 General safety instructions ............................................................................................................. 14
4.8 Specific vibration plate safety instructions ...................................................................................... 18
4.9 Safety features................................................................................................................................ 20
4.10 Service ............................................................................................................................................ 21
4.11 Vehicle fluids................................................................................................................................... 23
4.12 Combustion engine ......................................................................................................................... 24
5 Description of the Machine
5.1 Scope of delivery ............................................................................................................................ 25
5.2 Type plates and labels .................................................................................................................... 25
5.3 Components.................................................................................................................................... 27
5.4 Control elements............................................................................................................................. 27
6 Transportation
6.1 Safety instructions for transport ...................................................................................................... 29
6.2 Prerequisites and preparations ....................................................................................................... 29
6.3 Lifting the machine.......................................................................................................................... 29
6.4 Lashing the machine....................................................................................................................... 30
7 Commissioning
7.1 Safety instructions for operation ..................................................................................................... 31
7.2 Mounting the guide bracket............................................................................................................. 32
7.3 Tests before commissioning ........................................................................................................... 33
7.4 Putting into operation with Honda engine ....................................................................................... 33

Contents
v
[en-US] | 01/2023 | 5100069895 | WP | Operator’s Manual
8 Operation
8.1 Operating the machine.................................................................................................................... 36
8.2 Take out of operation with Honda engine ....................................................................................... 36
9 Maintenance
9.1 Safety instructions for maintenance................................................................................................ 37
9.2 Maintenance plan............................................................................................................................ 39
9.3 Maintenance work........................................................................................................................... 39
10 Troubleshooting
10.1 Troubleshooting machine................................................................................................................ 45
11 Shutdown
11.1 Temporary decommissioning.......................................................................................................... 46
11.2 Final shutdown................................................................................................................................ 46
12 Accessories
12.1 Accessories..................................................................................................................................... 47
13 Technical Data
13.1 General instructions ........................................................................................................................ 49
13.2 Noise and vibration data ................................................................................................................. 49
13.3 WP .................................................................................................................................................. 49
13.4 Combustion engine ......................................................................................................................... 50
13.5 Conversion table ............................................................................................................................. 51

2006/42/EC•2000/14/EC•2014/30/EU•EN500-1:2006+A1:2009•EN500-4:2011
EN ISO 13766-1:2018
WP1550_CE_en
Person responsible for technical documents
Wacker Neuson Produktion GmbH & Co. KG, Wackerstraße 6, 85084 Reichertshofen (DE)
Reichertshofen (DE), 11.10.2022
Helmut Bauer
Managing Director
Original Declaration of Conformity
Conformity assessment procedure
2000/14/EC, Annex VIII
Notified body
TÜV Rheinland LGA Products GmbH, Tillystr. 2, 90431 Nürnberg (DE) (NB 0197)
Directives and standards
We hereby declare that this product complies with the relevant provisions and requirements of the
following directives and standards:
Net installed power
3,6 kW
Measured sound power level
107 dB(A)
Guaranteed sound power level
108 dB(A)
Product type
Vibratory plate
Function of product
Soil compaction
Material number
5100062423, 5100062424, 5100065600
EU Declaration of Conformity
Manufacturer
Wacker Neuson Produktion GmbH & Co. KG, Wackerstraße 6, 85084 Reichertshofen (DE)
This declaration of conformity is issued under the sole responsibility of the manufacturer.
Product
WP1550

SI 2008 No. 1597 • SI 2001 No. 1701 • SI 2016 No. 1091 • EN 500-1:2006 + A1:2009
EN 500-4:2011 • EN ISO 13766-1:2018
WP1550_UKCA_enuk
Person responsible for technical documents
Andy Williams (Operations Manager), Wacker Neuson Ltd, WN Place, Beacon Way, Stafford ST18
0DG (GB)
Reichertshofen (DE), 11.10.2022
Helmut Bauer
Managing Director
Original Declaration of Conformity
Conformity assessment procedure
SI 2001 No. 1701, Schedule 11
Approved Body
Until 11/2023: TÜV Rheinland LGA Products GmbH, Tillystr. 2, 90431 Nürnberg (DE) (NB 0197)
Starting 12/2023: TUV Rheinland UK Ltd., Friars Gate, 1011 Stratford Road, Shirley, Solihull,
B90 4BN (GB) (No. 2571)
Directives and standards
We hereby declare that this product complies with the relevant provisions and requirements of the
following directives and standards:
Net installed power
3,6 kW
Measured sound power level
107 dB(A)
Guaranteed sound power level
108 dB(A)
Product type
Vibratory plate
Function of product
Soil compaction
Material number
5100062423, 5100062424, 5100065600
UK Declaration of Conformity
Manufacturer
Wacker Neuson Produktion GmbH & Co. KG, Wackerstraße 6, 85084 Reichertshofen (DE)
This declaration of conformity is issued under the sole responsibility of the manufacturer.
Product
WP1550

Foreword
2.1 Introduction
8Operator’s Manual | WP | 5100069895 | 01/2023 | [en-US]
2 Foreword
2.1 Introduction
This operator’s manual contains important information and procedures for
the safe, proper and economical operation of this machine. Careful read-
ing, understanding and observing it helps to avoid hazards, reduce repair
costs and downtimes and thus increase the availability and service life of
the machine.
This operator’s manual is not a manual for extensive maintenance or re-
pair work. Such work must be carried out by the service partner or by
technically trained personnel. The machine must be operated and main-
tained in accordance with the instructions in this operator’s manual. Im-
proper operation or maintenance can cause hazards.
Defective machine parts must be replaced immediately!
The manufacturer is always available to answer questions on operation
or maintenance.
2.2 Storage Location of the Operator's Manual
This operator's manual must be kept in the immediate vicinity of the ma-
chine and accessible to personnel at all times.
If a second copy of this operator’s manual is lost or required, the following
options are available for obtaining a replacement:
• On the Internet at http://www.wackerneuson.com.
• Contact the manufacturer.
2.2.1 Understanding These Instructions
This section helps to understand the operator’s manual and the illustra-
tions used therein.
Target group
People working with this machine must be regularly trained with regard to
the dangers and risks occurring when using this machine.
This operator’s manual is aimed at:
• Operating personnel:
– These people have been instructed in working with the machine
and about possible dangers and risks arising due to improper be-
havior.
• Technically trained personnel:
– These people have a professional training as well as additional
knowledge and experience. They are capable of assessing the
tasks assigned to them and recognizing any possible risks and
dangers.
Explanation of symbols
Symbol Explanation
1., 2., 3… Indicates an activity. The sequence of the steps must be observed.

Foreword
Accident Prevention Regulations 2.3
9
[en-US] | 01/2023 | 5100069895 | WP | Operator’s Manual
Symbol Explanation
⇨Indicates a result or an intermediate result of an action.
✓Indicates prerequisites that must be established for the activity.
● Indicates a list, e.g. if several components are named one after the other.
- Indicates a sub-list, e.g. if components consist of further components
I
Identifies a position, usually a component or control element, in a graphic. The numbering
may be sequential or in Roman numerals.
1; AIndicates the naming of components in explanatory texts. It is identical with the adjacent po-
sitions in the illustrations.
III
III
Indicates a direction of movement or different positions for switches.
► Indicates the avoidance of hazards in warning notices.
[▸52] Indicates a cross-reference in tables. Here e.g. reference to page 52
2.2.1.1 Explanation of symbols
The symbols used in the operator's manual are explained below. The
symbols are used exclusively in warning or environmental instructions or
information. Warnings must always be observed to protect the operator
and third parties from personal injury and damage to property.
Symbol for warning notices
This symbol marks general warnings. It is used to alert you
of possible hazards, e.g. risks of injury or accidents.
Symbol for indications of technical damage
This symbol is a warning symbol that indicates a danger of
technical damage. It is used to indicate situations where
damage to the machine or third-party property may occur.
Symbol for environmental information
This symbol indicates environmental information. It is used
to warn of possible environmental hazards.
Symbol for information
This symbol indicates information. This information can in-
clude tips on operation, for example. It helps to better un-
derstand and use the machine.
2.3 Accident Prevention Regulations
In addition to the notes and safety instructions in this operator’s manual,
the local accident prevention regulations and the national industrial safety
regulations apply.
2.4 Contact person
Depending on the country, the contact person is a service partner, a sub-
sidiary or a dealer.
• On the Internet at http://www.wackerneuson.com.
2

Foreword
2.5 Limitation of liability
10 Operator’s Manual | WP | 5100069895 | 01/2023 | [en-US]
2.5 Limitation of liability
In the event of the following infringements, the manufacturer disclaims
any liability for personal injury and damage to property:
• Actions contrary to this operator’s manual.
• Non-designated use
• Deployment of untrained personnel.
• Use non-approved spare parts and accessories.
• Improper handling.
• Structural changes of any kind.
• Non-observance of the General Terms and Conditions (GTC).
2.6 Use of the operator’s manual
This operator’s manual:
• must be regarded as an integral part of the machine and must be
kept in a safe place throughout its service life.
• must be passed on to each subsequent owner or operator of this ma-
chine.
• applies to various machine types from one product range. For this
reason, some illustrations may differ from the appearance of the pur-
chased machine. Variant-dependent components that are not in-
cluded in the scope of delivery can also be described.
The manufacturer reserves the right to change the information in this op-
erator's manual without notice.
It must be ensured that any changes or additions made by the manufac-
turer are immediately incorporated into this operator’s manual.
Group - Type Material number (Mat. no.)
Configurable machine* 5100065600
WP1550A 5100062423
WP1550Aw 5100062424
* In the case of configurable machines, technical data is assigned via the
machine's sales designation.

Usage
Designated use 3.1
11
[en-US] | 01/2023 | 5100069895 | WP | Operator’s Manual
3 Usage
3.1 Designated use
Designated use also includes observing all notes and safety instructions
in this operator’s manual and observing the prescribed care and mainte-
nance instructions.
The machine is used for:
• Compaction in earth and gravel construction.
• Compaction of mixed and granular soils.
• Compaction of asphalt.
• Shaking in cobblestones.
Any other use or use that goes beyond this is considered improper use.
The manufacturer shall not be liable or liable for any damage resulting
therefrom. The risk is borne solely by the operator.
3.2 Unintended use
The manufacturer is not liable for personal injury or damage to property
resulting from unintended use. The following activities, among others, are
not intended:
• Compaction of strongly cohesive soils.
• Compaction of frozen soils.
• Compaction of hard, non-compactable soils.
• Compaction of non-load-bearing soils.
3

Safety
4.1 Safety symbols and signal words
12 Operator’s Manual | WP | 5100069895 | 01/2023 | [en-US]
4 Safety
4.1 Safety symbols and signal words
The following symbol identifies safety instructions. It is used for warning
against potential personal risk or danger.
DANGER
DANGER identifies a situation causing death or serious injury if it is
not avoided.
Consequences in case of non-observance.
► Avoidance of injury or death.
WARNING
WARNING identifies a situation that can cause death or serious in-
jury if it is not avoided.
Consequences in case of non-observance.
► Avoidance of injury or death.
CAUTION
CAUTION identifies a situation that can cause injury if it is not
avoided.
Consequences in case of non-observance.
► Avoidance of injury.
NOTICE
INFORMATION identifies a situation that causes damage if it is not
observed.
Consequences in case of non-observance.
► Avoidance of damage to property.
4.2 Principle
The machine has been designed and built in accordance with latest state-
of-the-art standards and the recognized safety regulations.
Warning! Risk of injury due to improper use.
Improper use can result in danger to life and limb for the operator and
third parties or machine and other property damage.
• Read and observe the notes and safety instructions in this operator’s
manual. Failure to follow these instructions may result in electric
shock, fire and/or serious injury, as well as damage to the machine
and/or other objects.
• Keep safety instructions and information for the future.

Safety
Structual changes 4.3
13
[en-US] | 01/2023 | 5100069895 | WP | Operator’s Manual
4.3 Structual changes
Warning! Risk of injury due to structural changes.
Unauthorized structural changes to this machine can pose a risk to oper-
ators and/or third parties, as well as damage to the machine and/or other
property.
• Do not make any structural changes without the manufacturer's writ-
ten consent.
In particular, a structural change shall be deemed to have occurred:
• When opening of the machine and permanent removal of compo-
nents.
• Installation of spare parts that do not come from the manufacturer or
are not equivalent in design and quality to the original parts.
• Attachment of accessories of any kind that do not originate from the
manufacturer.
The manufacturer's liability and warranty are also void in the event of
unauthorized structural alterations.
Spare parts or accessories from the manufacturer can be installed or re-
moved safely.
Further information is available on the Internet at - http://www.wackerneu-
son.com.
4.4 Responsibility of the operator
The operator is the person who operates this machine himself for com-
mercial or economic purposes or who leaves it to a third party for use/ap-
plication and bears the legal product responsibility for the protection of
personnel or third parties during operation.
• The operator must make the operator’s manual accessible to the per-
sonnel at all times and ensure that the operator has read and under-
stood the operator’s manual.
• The operator’s manual must be kept ready to hand at the machine or
at the place of use.
• The operator must hand over the operator's manual to any other op-
erator or subsequent owner of the machine.
• The country-specific regulations, standards and directives on acci-
dent prevention and environmental protection must also be observed.
The operator’s manual must be supplemented by further instructions
for compliance with operational, official, national or generally applica-
ble safety guidelines.
4

Safety
4.5 Obligations of the operator
14 Operator’s Manual | WP | 5100069895 | 01/2023 | [en-US]
4.5 Obligations of the operator
• Know and implement applicable health and safety regulations.
• In a risk assessment, identify hazards arising from working conditions
at the place of use.
• Create operating instructions for the operation of this machine.
• Regularly check whether the operating instructions correspond to the
current status of the regulations.
• Clearly regulate and define responsibilities for installation, operation,
troubleshooting, maintenance and cleaning.
• Train personnel at regular intervals and inform them about possible
dangers.
• Refresh instruction at regular intervals.
• Keep records of the training received and make them available to the
competent authority on request.
• Provide personnel with the necessary protective equipment.
4.6 Qualification of staff
Warning! Risk of injury due to misuse.
In the event of misuse, abuse or operation by untrained personnel, there
is a risk to the health of the operator and/or third parties, as well as dam-
age or total failure of the machine and/or other property damage.
• The machine may only be commissioned and operated by trained
personnel.
In addition, the following requirements apply to the operator:
• Physical and mental suitability.
• Minimum age 18 years.
• No influence on reactivity by drugs, alcohol or medication.
• Familiarity with the safety instructions in this operator’s manual.
• Familiarity with the intended use of this machine.
• Instructed in the independent operation of the machine.
4.7 General safety instructions
The safety instructions in this chapter contain the "General safety instruc-
tions", which must be listed in the operator’s manual in accordance with
the applicable standards. It may contain instructions which are not rele-
vant for this machine.

Safety
General safety instructions 4.7
15
[en-US] | 01/2023 | 5100069895 | WP | Operator’s Manual
4.7.1 Workplace
Warning! Hazard of poisoning from exhaust gases.
Exhaust gases contain carbon monoxide. Inhaling exhaust gases can
lead to death in a few minutes.
• Do not inhale exhaust gas.
• Do not operate machine in an enclosed/partially enclosed or poorly
ventilated or vented area.
• Particular caution is required when operating in ditches, because a
high concentration of carbon monoxide can form in ditches after a
short time.
• Ensure adequate ventilation/exhaustion.
Warning! Risk of explosion from fuel vapors.
Fuel vapors are highly flammable and can cause an explosion. This can
seriously injure people and cause damage to property.
• Do not start the engine near spilled fuel.
• Open fire and smoking prohibited.
Warning! Risk of injury due to unsafe work environment.
Unsafe working environment can cause the machine to tip, roll, slide and
fall. People can be injured as a result.
• Before starting work, familiarize yourself with the working environ-
ment, e.g. load-bearing capacity of the floor or obstacles in the envi-
ronment.
• Always secure the machine against tipping, rolling, slipping and fall-
ing.
• Observe the changing ground conditions, especially on uneven and
soft ground or on slopes. Secure the machine against slipping!
• When working near pits, ditches or plateaus, exercise caution! The
load-bearing capacity capacity of the ground must safely carry the
weight of the machine and the operator.
Warning! Risk of injury if distracted by third parties.
Distraction by others can result in loss of machine control. This can seri-
ously injure people and cause damage to property.
• Secure work area to public transport area.
• Keep unauthorized persons and children away when working with this
machine.
Warning! Risk of injury due to adverse working conditions.
Cluttered and poorly lit work areas can lead to accidents. People can trip,
fall and be seriously injured as a result.
• Keep work area tidy.
• Provide adequate lighting.
4

Safety
4.7 General safety instructions
16 Operator’s Manual | WP | 5100069895 | 01/2023 | [en-US]
4.7.2 Personal safety
Warning! Risk of injury due to physical impairment.
Physical impairment can reduce the ability to react. This can lead to loss
of machine control. People can be injured as a result.
• Do not work under the influence of drugs, alcohol or medication.
Warning! Danger of being drawn in by unsuitable clothing and long hair.
Wide or loose clothing, protective gloves, jewelery and long hair can be
caught and pulled in by moving/rotating machine parts. This can result in
severe injuries.
• Keep loose or loose clothing and protective gloves away from mov-
ing/rotating machine parts.
• Remove jewelry before starting work.
• Tie up long hair or use a hair net.
Warning! Danger of falling due to unsafe position.
Working in an unstable position can lead to falls. Falls can cause serious
injuries.
• Always ensure a safe footing.
• Always have both feet on the ground.
Warning! Risk of injury to third parties
Bystanders can be seriously injured by incidents in the work area.
• Make sure there are no other people in the danger area.
Caution! Damage to health from exposure to vibration.
Prolonged use of this machine may result in long-term vibration-related
damage or impaired circulation in the fingers, hands or wrists. Signs of
this can be body parts falling asleep, tingling, hurting, stinging and discol-
oring.
In the case of personal predisposition to poor blood circulation, working
time can be reduced despite safety gloves and regular breaks from work.
• Take regular breaks from work.
• If these symptoms are detected, consult a doctor immediately.
• Observe national occupational safety requirements.
Vibration exposure, see Technical Data on page 49
Personal protective equipment
Suitable protective equipment must be used for all work. Personal protec-
tive equipment considerably reduces the risk of injury.
Warning! Risk of hearing damage from exceeding permissible noise lim-
its.
Working with the machine without hearing protection can lead to hearing
damage in the long-term.
• Always use hearing protection when working with the machine.
• When working with hearing protection, work particularly attentively
and carefully, because noises, e.g. screams or beeps, are only per-
ceived to a limited extent.

Safety
General safety instructions 4.7
17
[en-US] | 01/2023 | 5100069895 | WP | Operator’s Manual
4.7.3 Handling and use
Warning! Risk of injury from falling loads.
In the event of improper transport or transport with unsuitable lifting gear,
loads can fall. People can be hit and seriously injured or killed.
• Do not stay under lifted loads.
• Only use suitable and tested lifting gear and slings with sufficient
load-bearing capacity.
• Secure the machine safely to the lifting gear.
• Use appropriate transport method.
Warning! Risk of crushing from swinging loads.
Improper transport can cause loads to swing. People can be hit or
crushed by this and be seriously injured or killed.
• Keep a sufficient distance from the lifted loads.
• Secure raised loads against swinging.
Warning! Danger to life due to unauthorized troubleshooting
Unauthorized troubleshooting can lead to unforeseen machine states.
People can be injured as a result.
• If faults occur on this machine which are not described in this opera-
tor’s manual, contact the manufacturer.
• Do not rectify faults on your own.
Warning! Risk of injury from defective machines or components.
Defective machines or components can lead to unforeseen machine
states. People can be injured as a result.
• Handle machines with care.
• Do not start a defective engine.
• Have defective parts replaced before operating the machine.
Warning! Risk of injury due to functionally restricted controls.
Controls that are not fully functional can lead to unforeseen machine
states. People can be injured as a result.
• Check the machine's controls for functionality before operation.
• Do not lock, manipulate or alter the machine controls in an inadmissi-
ble manner.
Warning! Risk of injury due to unauthorized start-up.
Unauthorized start-up can lead to dangerous situations. Persons involved
can be seriously injured as a result.
• Only allow the machine to be operated by authorized personnel.
• Secure unused machines against unauthorized putting into operation.
• After operation, store the machine in a locked, clean, frost-free and
dry place that is inaccessible to other people and children.
• Use the machine, accessories, tools etc. in accordance with these in-
structions.
4

Safety
4.8 Specific vibration plate safety instructions
18 Operator’s Manual | WP | 5100069895 | 01/2023 | [en-US]
4.8 Specific vibration plate safety instructions
4.8.1 External influences
Warning! Fire and explosion hazard.
Operating machines in potentially explosive atmospheres or near open
flames can result in an explosion or fire. This can seriously injure people
and cause property damage.
• Do not operate the machine in a potentially explosive environment.
• Do not operate machine in oilfield environments - methane gas leak-
ing from ground.
• Do not operate the machine in the vicinity of open flames.
• Do not operate the machine in dry, highly flammable vegetation.
Caution! Risk of injury from slipping machine.
In heavy rain, the machine may slip on sloping surfaces. This can injure
people and damage the machine.
• Do not operate the machine on inclined surfaces in heavy rain.

Safety
Specific vibration plate safety instructions 4.8
19
[en-US] | 01/2023 | 5100069895 | WP | Operator’s Manual
4.8.2 Operational safety
Warning! Risk of injury from uncontrolled guided machine.
Loss of machine control can result in serious injury to the operator or oth-
ers.
• Always hold the machine with both hands.
• Take a firm stand.
Warning! Risk of injury from tipping or slipping machine.
The machine can tip over or slide off in the vicinity of escarpments. Peo-
ple can be hit and seriously injured.
Make sure at least 2/3 of the machine is on a stable surface.
Otherwise, take the machine out of operation and move it to a stable sur-
face.
Caution! Risk of injury from the machine slipping.
When operating the machine on inclined surfaces, the machine can slip
and tip over. This can injure people and damage the machine.
• Only approach gradients from below.
• Stay above the machine during compaction work across the slope.
• Do not leave the designated operating position when the machine is
in operation.
• Exercise the utmost degree of caution near abysses or slopes.
• Ensure stability.
Caution! Danger of being buried in ditches and pits.
When operating the machine in ditches and pits, side walls can collapse
due to vibration. People can be buried and injured.
• Check side walls for stability before starting work.
• Pay close attention to sidewalls in ditches and pits.
Caution! Risk of injury to third parties when the machine is running.
When operating the machine, people in the work area can be injured.
• Never let the machine run unattended.
• Block off a large work area and keep unauthorized persons away.
• Make sure people in the work area keep a minimum distance of 2
meters from the running machine.
Caution! Risk of injury when starting with the recoil starter.
Improper handling when starting can cause injury to the operator or third
parties.
• Only pull the starter handle on the recoil starter when there is suffi-
cient space and no one is in the immediate vicinity.
4

Safety
4.9 Safety features
20 Operator’s Manual | WP | 5100069895 | 01/2023 | [en-US]
4.8.2.1 Safety distances
Note! Material damage due to careless work.
Careless work can damage lines laid in the floor.
• When operating the machine, make sure that no gas, water or electri-
cal lines or pipes are damaged.
Note! Material damage caused by vibrations.
Compaction work in the vicinity of buildings can lead to building damage.
• Check all possible effects and vibrations on surrounding buildings be-
forehand.
• Observe the relevant regulations and rules for measuring, assessing
and reducing vibrations, in particular DIN 4150-3.
Information! The manufacturer shall not be liable for any damage to
buildings.
4.9 Safety features
Safety features protect the operator of this machine from being exposed
to the existing hazards. These are barriers (separating protective de-
vices) or other technical measures that serve to avert or reduce hazards.
Warning! Risk of injury due to modified or removed safety devices.
Modified or removed safety devices lose their protective function. People
can be injured as a result.
• Operate the machine only when the safety devices are correctly in-
stalled and functional.
• Do not change or remove safety devices.
• Reattach safety and protective devices removed for maintenance/ser-
vice (e.g. V-belt protection).
1
The V-belt guard 1 protects the operator against crushing and entrap-
ment.
