BordBar TF08
EN 14 Thermoelectric cooler
Operating manual
Autogoods “130”
130.com.ua

BordBar TF08
3
31 2
1
1
2
390 160
304
342
297
279
3
Autogoods “130”
130.com.ua

EN
BordBar TF08
14
Please read this operating manual carefully before starting the device.
Keep it in a safe place for future reference. If the device is passed on to
another person,this operating manual must be handed overto the user
along with it.
The manufacturer cannot be held liable for damage resulting from
improper usage or incorrect operation.
Contents
1 Explanation of symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
6 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
7 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
8 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
9 Cleaning and maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
10 Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
11 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
12 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Autogoods “130”
130.com.ua

EN
BordBar TF08 Explanation of symbols
15
1 Explanation of symbols
D
!
!
A
I
➤Action: This symbol indicates that action is required on your part. The
required action is described step-by-step.
✓This symbol describes the result of an action.
Fig. 15, page 3: This refers to an element in an illustration. In this case,
item 5 in figure 1 on page 3.
DANGER!
Safety instruction: Failure to observe this instruction will cause
fatal or serious injury.
WARNING!
Safety instruction: Failure to observe this instruction can cause
fatal or serious injury.
CAUTION!
Safety instruction: Failure to observe this instruction can lead to
injury.
NOTICE!
Failure to observe this instruction can cause material damage and
impair the function of the product.
NOTE
Supplementary information for operating the product.
Autogoods “130”
130.com.ua

EN
Safety instructions BordBar TF08
16
2 Safety instructions
2.1 General safety
!WARNING!
Do not operate the device if it is visibly damaged.
If this device's power cable is damaged, it must be replaced by
the manufacturer, customer service or a similarly qualified
person in order to prevent safety hazards.
This device may only be repaired by qualified personnel.
Improper repairs can lead to considerable hazards.
This device can be used by children aged 8 years or over, as
well as by persons with diminished physical, sensory or mental
capacities or a lack of experience and/or knowledge, providing
they are supervised or have been taught how to use the device
safely and are aware of the resulting risks.
Cleaning and user maintenance must not be carried out by
children without supervision.
Children must not play with the device.
Children must be supervised to ensure that they do not play with
the device.
Always keep and use the device out of the reach of children
under the age of 8 years.
Do not store any explosive substances such as spray cans with
a flammable propellant in the device.
!CAUTION!
Disconnect the device from the mains
– before each cleaning and maintenance
– after every use
Food may only be stored in its original packaging or in suitable
containers.
ANOTICE!
Check that the voltage specification on the type plate
corresponds to that of the energy supply.
Only connect the device to a DC plug socket in the vehicle (e. g.
cigarette lighter) with the DC cable.
Autogoods “130”
130.com.ua

EN
BordBar TF08 Safety instructions
17
Never pull the plug out of the socket by the cable.
Disconnect the cooler and other power consuming devices from
the battery before connecting the quick charging device.
Disconnect the cooler or switch it off when you turn off the
engine. Otherwise you may discharge the battery.
The cooling device is not suitable for transporting caustic
materials or materials containing solvents.
2.2 Operating the device safely
DDANGER!
Do not touch exposed cables with your bare hands.
!CAUTION!
Before starting the device, ensure that the power supply line
and the plug are dry.
ANOTICE!
Do not use electrical devices inside the cooler unless they are
recommended by the manufacturer for the purpose.
Do not place the device near naked flames or other heat
sources (heaters, direct sunlight, gas ovens etc.).
Danger of overheating!
Ensure at all times that there is sufficient ventilation so that the
heat that arises during operation does not build up. Make sure
that the device is sufficiently far away from walls and other
objects so that the air can circulate.
Ensure that the ventilation openings are not covered.
Do not fill the inner container with ice or fluid.
Never immerse the device in water.
Protect the device and the cable against heat and moisture.
Autogoods “130”
130.com.ua

EN
Intended use BordBar TF08
18
3 Intended use
The cooler is suitable for cooling foodstuffs.
The device has been designed for use with a 12 Vgvehicle electrics socket
of a car (cigarette lighter), boat or caravan.
The appliance may also be used for camping use. The appliance shall not to
be exposed to rain. It can be used as a box or cupboard.
!
I
4 Scope of delivery
BordBar TF08 (Item no. 9105300001)
Connection cable for 12 Vgconnection
Operating manual
5 Accessories
Available as accessories (not included in the scope of delivery):
CAUTION! Health hazard!
Please check if the cooling capacity of the device is suitable for
storing the food or medicine you wish to cool.
NOTE
To operate the device using a 220 – 240 V AC mains supply,
we recommend using a rectifier.
The seatbelt can be fed through the lugs on the cooler to
fasten it to the car seat (fig. 1, page 3).
Description Item no.
Voltage monitor (12 V, 5 A) 9105303854
Mains adapter (230 V – 12 V) 9102600030
Autogoods “130”
130.com.ua

EN
BordBar TF08 Technical description
19
6 Technical description
The cooler is suitable for mobile use. If can cool goods to max. 20 °C under
the ambient temperature or keep them cool.
The handy shutter provides easy access to the refrigerated goods inside.
Its cooling system is a non-wearing Peltier cooling, the heat is discharged by
a fan.
6.1 Description of the device
7 Operation
!
A
I
No. in
fig. 1, page 3 Description
1 Shoulder strap
2 Safety belt tabs
3 Shutter
CAUTION! Health hazard!
Food may only be stored in its original packaging or in suitable
containers.
NOTICE!
Ensure that the objects placed in the cooler are suitable for
cooling to the selected temperature.
Ensure that food or liquids in glass containers are not exces-
sively refrigerated. Liquids expand when they freeze and can
therefore destroy glass containers
NOTE
Before starting your new cooling device for the first time, you
should clean it inside and outside with a damp cloth for hygienic
reasons (please also refer to the chapter “Cleaning and mainte-
nance” on page 21).
Autogoods “130”
130.com.ua

EN
Operation BordBar TF08
20
7.1 Energy saving tips
Choose a well ventilated installation location which is protected against
direct sunlight.
Allow warm food to cool down first before placing it in the device to keep
cool.
Do not open the cooling device more often than necessary.
Do not leave the cooler unit open for longer than necessary.
Do not leave the shutter open for longer than necessary.
7.2 Using the cooler
I
➤Place the cooler on a firm base.
➤Connect the 12 V connection cable into the cigarette lighter socket or a
12 V socket in the vehicle
✓The cooler starts cooling the interior.
➤To switch off the cooler, disconnect the plug.
7.3 Connecting to the cigarette lighter
I
NOTE
Like every cooling device, your cooler must be properly ventilated
so that any heat created can dissipate. Otherwise proper function-
ing cannot be ensured.
NOTE
If you connect the cooler to the cigarette lighter, remember that
the ignition must be turned on to supply it with power.
Autogoods “130”
130.com.ua

EN
BordBar TF08 Troubleshooting
21
8 Troubleshooting
9 Cleaning and maintenance
!
A
➤Occasionally clean the device interior and exterior with a damp cloth.
➤Make sure that the air inlet and outlet vents on the device are free of any
dust and dirt, so that heat can be released and the device is not damaged.
➤Clean the lid seal regularly.
Fault Possible cause Suggested remedy
Your cooler does not work
(plug is inserted). There is no voltage flowing from the 12 V
socket (cigarette
lighter) in your vehicle.
The ignition must be switched on in
most vehicles for voltage to flow at the
cigarette lighter.
The cooler does not cool
(plug is inserted). The inner fan or the cooling element is
defective.
This can only be repaired by an author-
ised customer services unit.
Operation with a 12 V
socket (cigarette lighter):
The ignition is on and the
cooler is not working.
Pull the plug out of the
socket and make the fol-
lowing checks.
The cigarette lighter
socket is dirty. This
results in a poor elec-
trical contact.
If the plug of your cooler becomes very
warm in the cigarette lighter socket,
either the socket must be cleaned or the
plug has not been assembled correctly.
The fuse of the 12 V
plug has blown. Replace the fuse (5 A) in the 12 V plug (fig. 21, page 3).
The vehicle fuse has
blown. Replace the vehicle's 12 V socket fuse (usually 15 A). (Please refer to the oper-
ating manual of your vehicle.)
WARNING!
Always disconnect the device from the mains before you clean
and service it.
NOTICE! Risk of damage
Never clean the cooler under running water or in dish water.
Do not use abrasive cleaning agents or hard objects during
cleaning as these can damage the cooler.
Autogoods “130”
130.com.ua

EN
Guarantee BordBar TF08
22
10 Guarantee
The statutory warranty period applies. If the product is defective, please
contact the manufacturer's branch in your country (see the back of the
instruction manual for the addresses) or your retailer.
For repair and guarantee processing, please include the following docu-
ments when you send in the device:
A copy of the receipt with purchasing date
A reason for the claim or description of the fault
11 Disposal
➤Place the packaging material in the appropriate recycling waste bins
wherever possible.
MIf you wish to finally dispose of the product, ask your local recycling
centre or specialist dealer for details about how to do this in
accordance with the applicable disposal regulations.
12 Technical data
BordBar TF08
Item no.: 9105300001
Gross capacity: 8 litres
Connection voltage: 12 Vg
Power consumption: 31 W
Cooling capacity: Max. 20 °C under ambient temperature
Dimensions (W x H x D): 390 x 342 x 160 mm
Weight: 3.5 kg
Testing/certification:
Autogoods “130”
130.com.ua
