WAGNER TexPerfect Flexio 525 User manual

2 Jahre
Garantie
2 year
Guarantee
GB/D
TexPerfect
525

TexPerfect Flexio 525
b
AB
a
8
12
13
7
4
3
1/2
9
11
14
15
5
OVERVIEW / ÜBERSICHT
16
6
10
17
+
Testposter
– +
Materialnr.2333118EBSS
A B C D E F
Coverup !
I-Spray
2
4
3
3
3
1
1 4
-
1
3
1
WallPerfect Flexio 585 I-Spray
A B C D E F
A B C D E F
A B C D E F
A B C D E F
5-15cm

20-30cm

I-Spray
5-15cm

20-30cm

2333118_Testposter_W577.indd1 19.11.201214:22:56
18

TexPerfect Flexio 525
click
c
a
b
2
1
A B C

TexPerfect Flexio 525

20-30 cm


A
B

1

1

TexPerfect Flexio 525

1
2
3



1.

2.

1
2
3

TexPerfect Flexio 525
4
3
2
1
1

SPARE PARTS / ERSATZTEILE
12
8
9
34
5
7
10

6
..........................................................................1 - 17
........ ........................................................................18 - 35
............................................. 38
GB
++ 
D

GB
1
TexPerfect Flexio 525
Contents
1. Explanation of symbols used .....................................................2
2. General Safety Instructions ......................................................2
3. Safety Instructions for Spray Guns ................................................5
4. Description/ Scope of delivery ...................................................6
5. Coating Materials Suitable for Use ................................................6
6. Coating Materials Not Suitable for Use............................................6
7. The following materials can only be processed with optional accessories ..........6
8. Preparation of the workplace.....................................................7
9. Preparing the wall ...............................................................7
10. Preparation of the Coating Material .............................................7
11. Start-up ........................................................................8
12. Selecting the Spray Setting .....................................................8
13. Adjusting the Material Volume (Fig. 6) ...........................................9
14. Setting the Amount of Air (Fig. 7)................................................9
15. Spray Technique................................................................9
16. Interruption of Work..........................................................10
17. Taking Out of Operation and Cleaning......................................... 10
18. Maintenance ................................................................. 12
19. Spare Parts ...................................................................12
20. Accessories...................................................................13
21. Correction of Malfunctions....................................................14
22. Technical Data................................................................15
23. Environmental protection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
24. Important Note regarding Product Liability! ...................................16
2 year guarantee .................................................................17
Translation of the original operating instructions
MANY THANKS FOR PLACING YOUR TRUST IN US
We would like to congratulate you on purchasing this brand product from Wagner;
we are sure that you will enjoy working with it greatly.
Please read the Operating Manual carefully and observe the safety information
before starting the device. Store the Operating Manual in a safe place close to the
product in case it needs to be used by someone else.
We would be happy to be of assistance if you have any questions, suggestions or requests.
Please contact us via the phone number included on the back page or via our homepage,
www.wagner-group.com/service.

GB
2
TexPerfect Flexio 525
1. Explanation of symbols used
This symbol indicates a potential danger for you or for the device.
Under this symbol you can nd important information on how to
avoid injuries and damage to the device.
Danger of electrical shock
i
Indicates tips for use and other particularly useful information.
This symbol identies devices and accessory devices that
are suitable for processing ne plaster, structured paint and
undercoats. If a material bears this logo, it is particularly well suited
for use with the relevant device.
2. General Safety Instructions
WARNING! Read all safety notications and instructions. Failure to comply with the safety
notications and instructions provided may result in electric shock, re and/or
serious injury. The term "power tool" used below covers both mains-operated
power tools (with mains lead) and accumulator-operated power tools (without
mains lead).
1. Safety at the workplace
a) Keep your workplace clean and well lit. Disorder or unlit workplaces may result in
accidents.
b) Never use the tool in hazardous areas that contain ammable liquids, gases
or dusts. Power tools generate sparks that can ignite the dust or vapors.
c) Keep children and other persons away when using the power tool. You can
lose control of the tool if you are distracted.
2. Electrical Safety
a) The tool plug must t into the socket. The plug may not be modied in any
form. Do not use adaptor plugs together with protective-earthed tools.
Unmodied plugs and suitable sockets reduce the risk of an electric shock.

GB
3
TexPerfect Flexio 525
b) Avoid physical contact with earthed surfaces such as pipes, heating
elements, stoves and refrigerators. The risk through electric shock increases if
your body is earthed.
c) Keep the equipment away from rain and moisture. The risk of an electric shock
increases if water penetrates electrical equipment.
d) Do not misuse the mains lead by carrying the tool by the lead, hanging it
from the lead or by pulling on the lead to remove the plug. Keep the lead
away from heat, oil, sharp edges or moving tool parts. Damaged or twisted
leads increase the risk of an electric shock.
e) If you work outdoors with a power tool, only use extension cables suitable
for outdoor use. The use of an extension lead that is suitable for outdoors reduces
the risk of an electric shock.
f) If you cannot avoid using the tool in a damp environment, use a residual
current operated circuit-breaker. Using a residual current operated circuit-breaker
avoids the risk of electric shock.
3. Safety of Persons
a) Be attentive. Pay attention to what you are doing and work sensibly with
a power tool. Do not use the tool if you are tired or under the inuence of
drugs, alcohol or medication. Just a moment of inattentiveness while using the
tool can lead to serious injuries.
b) Wear personal safety equipment and always wear safety goggles Wearing
personal protective equipment, such as dust mask, non-slip safety shoes, safety helm
or ear protection, depending on the type of power tools, reduces the risk of injury.
c) Avoid accidental starting-up. Make sure that the electric tool is switched o
before you connect it to the power supply, pick it up or carry it. Accidents can
occur if you carry the power tool while your nger is on the switch or if you connect
the power tool to the power supply which it is on.
d) Remove setting tools or wrenches before switching on the power tool. A tool
or wrench that is in a rotating tool part can lead to injuries.
e) Avoid an unnatural posture. Ensure that you are standing securely and
have your balance at all times. This ensures that you can control the tool better in
unexpected situations.
f) Wear suitable clothing. Do not wear wide clothing or jewellery. Keep your
hair, clothes and gloves away from moving parts. Loose clothing, jewellery or
long hair can be caught in moving parts.

GB
4
TexPerfect Flexio 525
g) This device can be used by children over the age of 8 as well as by people
with restricted physical, sensory or mental abilities or who have little
experience or knowledge about it, providing they are supervised or
instructed on how to use the device safely and what risks are involved.
Children may not play with the device. User maintenance and cleaning may not be
carried out by children unattended.
4. Usage and treatment of the electric tool
a) Do not overload the tool. Use the power tool designed for the work that you
are doing. You work better and safer in the specied performance range if you use
the suitable power tool.
b) Do not use power tools whose switch is defective. A power tool that cannot be
switched on or o is dangerous and has to be repaired.
c) Remove the plug from the socket before carrying out tool settings, changing
accessories or putting the tool away. This precautionary measure prevents
unintentional starting of the tool.
d) Store unused power tools so that they are inaccessible to children. Do not
let persons use the tool who are not familiar with it or who have not read
these instructions. Power tools are dangerous when they are used by inexperienced
persons.
e) Take proper care of your tools. Check whether the moving parts function
trouble-free and do not jam, whether parts are broken or damaged so that
the tool function is impaired. Have damaged parts repaired before using
the tool. Many accidents have their origin in power tools that have been maintained
badly.
f) Use the power tool, accessories, insert tools, etc. in accordance with these
instructions and in a fashion specied for this special tool type. Take the
working conditions and the activity to be carried out into consideration. The
use of power tools for purposes other than the intended ones can lead to dangerous
situations.
5. Service
a) Have your tool repaired only by qualied specialist personnel and only with
original spare parts. This ensures that the tool safety is maintained.
b) If the supply cord is damaged, it must be replaced by the manufacturer or it’s
service agent or a similarly qualied person in order to avoid a safety hazard.

GB
5
TexPerfect Flexio 525
3. Safety Instructions for Spray Guns
•
Caution! Wear breathing equipment: Paint mist and solvent vapors are damaging to
health. Always wear breathing equipment and only work in well ventilated rooms or
using supplementary ventilating equipment. It is advisable to wear working clothing,
safety glasses, ear protection and gloves.
CAUTION: DANGER OF INJURY!
Never point the spray stream towards human beings or animals.
Sockets and plugs must be masked. Risk of an electric shock as a
consequence of sprayed material entering the socket!
Attention! Never operate the device if the nozzle seal is either
damaged or missing. If the nozzle seal is either missing or damaged
liquids can enter the device and increase the risk of an electric shock.
Check the nozzle seal before each use.
•
Do not use the spray guns to spray ammable substances.
•
The spray guns are not to be cleaned with ammable solvents.
•
Caution against dangers that can arise from the sprayed substance and observe the
text and information on the containers or the specications given by the substance
manufacturer.
•
Do not spray any liquid of unknown hazard potential.
•
The device may not be used in workplaces covered by the explosion-protection
regulations.
•
To avoid the hazard of explosion when spraying, provide for eective natural or
articial ventilation.
•
There must be no sources of ignition such as, for example, open res, smoke of lit
cigarettes, cigars and tobacco pipes, sparks, glowing wires, hot surfaces, etc. in the
vicinity during spraying.
•
When working with the Flexio 525 indoors as well as outdoors ensure that no solvent
vapors are sucked in by the spray gun.
•
The spray gun is not a toy; children must therefore not be allowed to handle it or play
with it.
•
Before working on the spray gun remove the power plug from the socket.
•
Cover areas that are not to be sprayed. When working keep in mind that wind, for
example, may transport paint mist over great distances and cause damage.
•
Never open the device yourself in order to carry out repairs in the electrical system!
•
The units may only be used with a functional valve. If paints rises in the ventilating
hose (Fig. 1, item 13) do not operate the unit further! Dismantle and clean the
ventilating hose, valve and diaphragm and replace the diaphragm if necessary.
•
Do not lay the spray gun on its side.
•
The device is equipped with a thermal release which disconnects the device in case of
overheating. In this case, turn o the device, remove the plug and let the device cool

GB
6
TexPerfect Flexio 525
down for at least 1/2 hour. Eliminate the cause of heating, e.g. soiled air lter, slots for
air intake covered.
With original WAGNER accessories and spare parts, you have the guarantee that
all safety regulations are fullled.
4. Description/ Scope of delivery
Description/ Scope of delivery (Fig. 1)
1) Air cap 2) Nozzle
3) Union nut 4) TexPerfect spray attachment
5) Air volume control 6) Spray gun rear part
7) Air lter cover (right + left) 8) Trigger
9) Material volume adjustment 10) Mains lead
11) Container 12) Valve
13) Ventilating hose 14) Stirring rod
15) Feed hopper (2 pcs.) 16) Replacement air lter (2 pcs.)
17) Breathing mask (FFP2) 18) Practice poster
19) Replacement nozzle seal* 20) Lubricating grease*
* This is inside the container: remove it before starting operations!
5. Coating Materials Suitable for Use
Mansory paint (only outdoor use)
Fine plaster (maximum grain size 1 mm), structured paint, undercoats, sealing primer
6. Coating Materials Not Suitable for Use
Materials that contain highly abrasive components (grain size bigger than 1 mm), caustic
solutions and acidic coating substances. Flammable materials.
7. The following materials can only be processed with
optional accessories
Interior wall paint (dispersions and latex paint)
Water- and solvent-based paints, nishes, primers, 2-component paints, clear nishes,
automotive nishes, staining sealers and wood sealer-preservatives.

GB
7
TexPerfect Flexio 525
8. Preparation of the workplace
Sockets and plugs must be masked. Risk of an electric shock as a
consequence of sprayed material entering the socket!
Mask all the areas and objects that are not to be spray painted, or
remove them from the work area. No liability is assumed for damage
due to overspray. Silicate paint corrodes glass and ceramic surfaces
upon contact! All such surfaces must therefore be completely covered.
iPay attention to the quality of the adhesive tape used.
Do not use excessively strong adhesive tape on wallpaper and painted
surfaces, in order to avoid damaging these surfaces when removing the
tape. Remove adhesive tape slowly and evenly; do not use jerky movements.
Do not leave adhesive tape on surfaces any longer than necessary, in order
to minimise the possibility of residues when removing.
Also observe the adhesive tape manufacturer's instructions.
9. Preparing the wall
iThe spray result depends heavily on the smoothness and cleanliness of
the surface to be sprayed. Fine plaster cannot be used to level bumps or
holes in the wall. Therefore the surface should be carefully prepared and
kept free of dust.
Depending on the surface, it might be necessary to apply a suitable sealing primer/
undercoat before spraying the ne plaster on the wall. Please observe the information
about this that is provided by the manufacturer of the material.
10. Preparation of the Coating Material
iSpray material that is at least at room temperature provides a better spray
result.
The Flexio 525 is perfect for spraying mansory paint, ne plaster, structured paint and
undercoats either undiluted or partially diluted. Detailed information is available in the
technical data sheet of the manufacturer (Internet download).
1. Stir the material thoroughly and dilute it in the container as per the recommended
dilution (an agitator is recommended for stirring).
Thinning recommendation
Sprayed material
Mansory paint, undercoats, sealing primer undiluted
Fine plaster dilute by 0-5%
Structured paint observe manufacturer's instructions

GB
8
TexPerfect Flexio 525
2. If the feed rate is too low even at maximum flow setting, dilute in steps of 5 - 10 %
until the feed rate meets your requirements (observe the maximum permitted
dilution as stipulated by the manufacturer).
11. Start-up
Before connecting to the mains supply, be sure that the supply voltage is identical with
the value given on the rating plate.
•
Unscrew the container from the spray gun.
•
Aligning suction tube. (Fig. 2)
If the suction tube is positioned correctly, the container contents can be sprayed without
almost any residue.
When working on lying objects: Turn the suction tube forwards. (Fig. 2 A)
Spraying work when working on overhead objects: Turn the suction tube rearwards.
(Fig. 2 B)
•
Place the container on a paper base and pour in the prepared coating substance with the
aid of the feed hopper included in the scope of supply (Fig. 1, 15). Screw the container
tightly onto the spray gun.
•
Connect the front part with the rear part of the gun (Fig. 3).
•
Put the machine down only on a level, clean surface. Otherwise the machine could tip
over!
•
Pull the trigger. The Flexio 525 has a two-stage trigger. In the rst stage the turbine is
started. If the trigger guard is pressed further, the material is transported.
•
Adjust the spray setting on the spray gun.
iThe enclosed practice poster is ideal for familiarising yourself with
operation of the spray gun. After trying out the rst spray coatings, it
makes sense to test it further on cardboard or a similar surface in order
to nd out the right ow rate of paint and air for the best spray pattern.
Detailed information about these settings can be found in chapter 12-14.
12. Selecting the Spray Setting
WARNING! Danger of injury! Never pull the trigger guard while adjusting
the air cap.
With the union nut (g. 4, 1) slightly unscrewed, turn the air cap (2) to the desired spray
setting position (arrow). Then tighten the union nut.
Fig. 3 A = vertical at jet for applying the material horizontally
Fig. 3 B = horizontal at jet for applying the material vertically
Fig. 3 C = circular jet  for corners, edges and hard-to-reach
surfaces

GB
9
TexPerfect Flexio 525
13. Adjusting the Material Volume (Fig. 6)
Set the material volume by turning the regulator on the trigger guard of the spray gun.
lower material volume  turn anti-clockwise (-)
higher material volume turn clockwise (+)
14. Setting the Amount of Air (Fig. 7)
iDepending on the viscosity of the material to be sprayed and the nish of the
objecttobecoated,itmaybeadvisabletovarytheamountofair.Verylowviscosity
materialsdonothavetobeatomisedwiththemaximumamountofair.Inthiscaseit
is advisable to reduce the amount of air and thus minimize the spray vapour.
This also applies for the use of the low-scale and radiator/detail spray attachment
(accessory).
Turn the air quantity regulator (g. 7, 1) until the level you want is above the arrow.
thin paint Level min to 6
thick paint (e.g. interior wall paint) Level 6 to max
15. Spray Technique
General
i
The spray result depends heavily on the smoothness and cleanliness of the
surface to be sprayed. Therefore the surface should be carefully prepared and
kept free of dust.
•
Cover all surfaces not to be sprayed.
iImportant: Start at the edge of the area to be sprayed. Start the spray
movement rst of all, and then press the trigger. Avoid interruptions
within the area to be sprayed.
•
The spray movement should come from the arm, not just from the wrist. This ensures
that a uniform distance is maintained between the spray gun and the spray surface
during the spray operation.
Fig. 8 A: CORRECT Even distance to the object.
Fig. 8 B: INCORRECT An uneven distance will result in uneven paint application.
•
Move the spray gun evenly cross-wise or up-and-down, depending on the spray
pattern setting.
•
An even movement of the spray gun results in an even surface quality.

GB
10
TexPerfect Flexio 525
iImportant: Wipe o the nozzle and air cap regularly
to make sure they do not get blocked.
Undercoats, sealing primer
•
Select a distance of about 15-20 cm and a low ow rate.
Mansory paint, ne plaster, structured paint
•
Select a distance of 15-20 cm, depending on the desired spray jet width.
•
For masonry paint select a medium or high ow rate.
•
For ne plaster, the material ow should be adjusted to the grain size. When using
larger grain sizes (e.g. 1 mm) a high ow rate should be set.
•
Apply the masonry paint and ne plaster in a criss-cross movement (g. 9).
If necessary, spray another 1-2 layers (allowing the material to dry rst).
i
With ne plaster the nal result cannot be evaluated until it has dried.Therefore
wait about 20-30 minutes until the rst layer is dry before you start touching-
up the wall.
iThe ow rate for ne plaster is lower than when using undercoat.
You therefore work more slowly in order to attain an even application.
16. Interruption of Work
•
Turn the machine o.
•
With ne plaster, observe the maximum processing time (usually 20-30 minutes). If
the spray attachment is not used for a slightly longer period, clean it, as the material is
hard to remove once dry.
•
During longer breaks, vent the container by briey opening and then closing it again.
•
Clean nozzle openings after an interruption in operation.
17. Taking Out of Operation and Cleaning
Proper cleaning is the prerequisite for problem-free operation of the paint application
device. No warranty claims are accepted in case of improper or no cleaning.
Never hold the spray gun rear part under water or immerse it into liquids.
Clean the housing only with a moistened cloth.
iWith mansory paint, ne plaster, structured paint and undercoats we
recommend using warm water for cleaning.

GB
11
TexPerfect Flexio 525
1) Unplug the power plug.Vent the container in case of longer breaks and after the work
has been terminated. This can be done by briey turning open and then closing the
container or by pulling the trigger guard and letting the paint into the original paint
container.
2) Divide the spray gun. Press the hook (Fig. 3 b "click") slightly downwards.Turn the gun
front part and gun rear part against each other and take them apart.
3) Unscrew the container. Empty any remaining coating material back into the material
tin.
4) Preclean the container and feed tube with a brush. Clean the ventilating bore
(Fig. 10, 1).
5) Pour water into the container. Screw the container back on.
Do not use ammable materials for cleaning purposes.
6) Assemble the gun again (Fig. 3).
7) Insert the power plug, turn on the machine and spray the water into a container or a
cloth.
8) Repeat the above procedure until the water emerging from the nozzle is clear.
9) Turn o the machine and remove the plug.
10) Divide the spray gun. Press the hook (Fig. 3 b "click") slightly downwards.Turn the gun
front part and gun rear part against each other and take them apart.
11) Screw of the container and empty it. Pull out the suction tub with container seal.
CAUTION! Nevercleanseals,diaphragmandnozzleorairholesofthespraygunwithmetal
objects.
The ventilation hose and diaphragm are only solvent-resistant to a limited
extent. Do not immerse in solvent, only wipe.
12) Pull the ventilating hose (Fig.11, 1) at the top from the gun body. Screw o the valve
cover (2). Remove the diaphragm (3). Clean all the parts carefully.
13) Unscrew the union nut and remove the air cap and nozzle. Clean the air cap, nozzle
seal and nozzle with a brush and water (Fig. 12).
14) Clean the outside of the spray gun and container with a cloth soaked in water.
15) Assemble the parts again (see“Assembly”).
Assembly
The unit may only be operated with an integer diaphragm (Fig. 11, 3).
1) Place the diaphragm (Fig. 11 ,3) with the pin facing upwards on the bottom section
of the valve. Also see the marking on the gun body.
2) Place on the valve cover (Fig. 11 ,2) and screw it closed.
3) Place the ventilating hose (Fig. 11, 1) on the valve cover and on the nipple at the gun
body.
Attention! Never operate the device if the nozzle seal is either damaged or
missing. If the nozzle seal is either missing or damaged liquids can enter
the device and increase the risk of an electric shock.
4) Push the nozzle seal (g. 13, 1) over the needle (3); the groove (slot) should point
towards you.

GB
12
TexPerfect Flexio 525
5) Put the nozzle onto the gun body and nd the correct position by turning it.
6) Put the air cap onto the nozzle and tighten it using the union nut.
7) Place the container seal from below on the suction tube and slide it over the collar,
while turning the container seal slightly.
8) Insert the suction tube with container seal in the gun body.
18. Maintenance
WARNING! Never operate the machine without the air filter;
dirt could be sucked in and interfere with the function of the
machine. Check the air filter after each use for contaminants.
Disconnect plug before changing parts.
1) Open the air lter lid with the help of the stirring rod. (Fig. 14)
2) Pull out the air lter and replace it if necessary, depending on how soiled it is.
3) First, push the new air lter into the bottom part of the compartment. (Fig. 15)
4) Next push it completely into the compartment.
In order to push the air lter into the compartment completely, we recommend using
the stirring rod.
In order to mount the gun more easily apply lubricating grease (enclosed) liberally
to the O-ring at the gun front part. (Fig. 16, 5 ).
19. Spare Parts
Spare Parts List: TexPerfect spray attachment (Fig. 16)
Pos. Designation Order No.
TexPerfect spray attachment complete with 1300 ml container 2345 792
1 Union nut 2343 966
2 Air cap 2343 965
3 Nozzle 2343 963
4 Nozzle seal (2 pcs.) 2304 433
5 O-ring 0417 308
6 Feather with cap 2343 967
7 Ventilating hose, valve cover, diaphragm 2304 027
8 Suction tube 2328 922
9 Container seal 2328 919
10 Container with cover 1300 ml 2305 155

GB
13
TexPerfect Flexio 525
Spare Parts List Flexio 525 (Fig. 17)
Pos. Benennung Best. Nr.
1 Air lter cover (right + left) 2335 172
2 Air lter set (2 pcs.) 2333 123
3 Stirring rod 2304 419
4 Feed hopper (3 pcs.) 2304 028
Lubricating grease (no g.) 2315 539
20. Accessories
The new CLICK&PAINT SYSTEM with additional spray attachments and accessories
oers the right tool for each work.
Accessories (not included in the delivery)
Name Order No.
HVLP handle extension
For easier coating of ceilings and horizontal objects. 2307 678
Brilliant spray attachment incl. 600 ml container
Optimised nozzle and air guidance for brilliant paint results 0417 932
Small-scale spray attachment incl. 250 ml container
For ligree objects, detailed and creative work. 0417 918
Perfect Spray spray attachment incl. 1400 ml container
Rapid working at larger objects such as timber houses, garage doors,
etc. 0417 917
Detail / Radiator spray attachment incl. 600 ml container
For inaccessible places, such as radiators, cupboard corners, recesses
etc. 0417 915
WallPerfect I-Spray spray attachment incl. 1800 ml container
For processing interior wall paint and high-viscosity coating materials. 2326 477
Further information about theWAGNER range of products for renovating is available
under www.wagner-group.com

GB
14
TexPerfect Flexio 525
21. Correction of Malfunctions
Problem Cause Remedy
No coating material
emerges from the
nozzle
•
Nozzle clogged
•
Feed tube clogged
•
Material volume setting turned
too far to the left (-)
•
Feed tube loose
•
No pressure build-up in container
•
Ventilating bore (Fig. 10,1)
clogged
➞Clean
➞Clean
➞Turn to the right (+)
➞Insert
➞Tighten container
➞Clean
Coating material
drips from the
nozzle
•
Nozzle loose
•
Nozzle worn
•
Nozzle seal is missing or worn
•
Coating material assembly at air
cap, nozzle or needle
➞Tighten
➞Change
➞Insert an intact nozzle
seal
➞Clean
Atomisation too
coarse •
Coating material too thick
•
Material volume too large
Material volume adjusting screw
turned too far to the right (+)
•
Nozzle contaminated
•
Air lter heavily soiled
•
Too little pressure build-up in
container
•
Amount of air too low
➞Dilute
➞Turn material volume
adjusting screw to the
left (-)
➞Clean
➞Change
➞Tighten container
➞Increase air quantity
Spray jet pulsates • Coating material in container
running out
•
Air lter heavily soiled
•
Nozzle seal is missing or worn
➞Rell
➞Change
➞Insert an intact nozzle
seal
Coating material
causes "paint tears" •
Too much coating material
applied.
➞Turn material volume
adjusting screw to the
left (-)
➞Leave it to dry and
then sand down
Too much fog of
coating material
(Overspray)
•
Distance to the object too large
•
Too much coating material
applied
•
Amount of air too high
➞Reduce distance
➞Turn material volume
adjusting screw to the
left (-)
➞Decrease air quantity
