OPERATING INSTRUCTIONS
SAFE LOCK
CAWI BLUECAM
Electronic door lock for WA safes
Issue 08.2020

Thank you very much ❤
We would like to thank you for choosing Waldis when it comes to safety.
When buying a safe, you have chosen a product tested according to EN1143-1. A
Swiss quality product with VdS - tested security.
Please read these instructions carefully before commissioning your safe!
Your contact for questions
WALDIS Tresore AG
Hofwisenstrasse 20
CH-8153 Rümlang
Phone: [phone]
Fax: [phone]
E-Mail: [e-mail]

Table of contents
Safe lock ................................................................................................................ 1
1.1. General notes .................................................................................................. 1
1.1.1. Opening the lock ....................................................................................... 1
1.1.2. Open with the user code ........................................................................... 1
1.1.3. Open after 4 incorrect code entries........................................................... 2
1.1.4. Open with the master code ....................................................................... 2
1.1.5. Closing by the user ................................................................................... 3
Code Programming ................................................................................................ 4
1.2. Code programming menu................................................................................ 4
1.2.1. Programming/changing the user code ...................................................... 4
1.2.2. Changing the master code ........................................................................ 4
1.2.3. Changing the user code by the master code............................................. 5
Power supply.......................................................................................................... 6
3.1. General............................................................................................................ 6
Password ............................................................................................................... 7
4.1. General basic rules.......................................................................................... 7
4.1.1. Avoid obvious passwords.......................................................................... 7
4.1.2. Tips ........................................................................................................... 7
4.1.3. Last but not least....................................................................................... 7

1
Safe lock
1.1. General notes
For your safety, you should change these factory codes immediately Make
all code changes only when the safe is open and the lock is in the closed position.
1.1.1. Opening the lock
The user factory code is 1-2-3-4
The master factory code is 0-7-1-2-3-2
Procedure
1. When changing the user code/master code, the lock must first be opened with
the respectively valid user code/master code
2. Do not use personal data such as birthdays or phone numbers for your new
codes
3. If the lock is not closed or opened within 3 seconds after pressing the ON key,
the electronics will switch off. Press the ON key again and repeat the process
4. If the time period for entering a new code is exceeded, the electronics switch
off. The old code remains valid
5. Each correct key input during opening and closing is confirmed by a sound
signal and a green flashing of the LED. These signals are not considered in
the further instructions
6. Never use force
7. Never open the lock housing. Otherwise, you endanger the function of the lock
and lose any warranty claims.
1.1.2. Open with the user code
Press the ON key
Press within 10 seconds and your 4-digit user code in 10 seconds
Turn the handle within 3 seconds. The lock is open
If you have entered an incorrect user code, an acoustic signal is emitted several
times and the LED lights up red. After the LED goes out, press the ON key and
start entering the code again.

2
1.1.3. Open after 4 incorrect code entries
After 4 incorrect code entries, the lock locks for 30 seconds.
No entry is possible during this locking time
After the blocking time has elapsed, the red LED goes out
and a tone sounds several times
Press the ON key
Enter your 4-digit user code within 10 seconds 3 seconds
Turn the handle within 3 seconds. The lock is open
If an incorrect user code was entered again in step 4. the lock switches back to a
lockout time for 30 seconds.
1.1.4. Open with the master code
Press and hold the ON button until the LED turns solid green
Press in the 6-digit master code 10 seconds
Turn the handle within 3 seconds. The lock is open
The master code is intended only for emergency use when no user or
administrator code is known.

3
1.1.5. Closing by the user
Press the ON key
Wait until the signal lights up permanently 3 seconds
Turn the handle within 3 seconds. The lock is locked
The closing procedure is the same for both users.

4
Code Programming
1.2. Code programming menu
ATTENTION: All code reprogramming must be carried out with the door
open!
Edit from point to point, always within 10 seconds
1.2.1. Programming/changing the user code
Press the ON key
Enter the 4-digit user code 10 seconds
Turn the handle within 3 seconds. The lock is open
Press and hold the ON button until the green LED is
permanently lit and enter the new 4-digit user code within 5
seconds
5 seconds
The new user code is accepted
If the time period for entering the new code was exceeded in step 4, the
electronics switch off. The old code remains valid.
1.2.2. Changing the master code
Press and hold the ON button until the LED lights up
continuously
Press in the 6-digit master code 10 seconds
Turn the handle within 3 seconds. The lock is open
Enter the new 6-digit master code within 5 seconds
The new master code is accepted

5
1.2.3. Changing the user code by the master code
Press and hold the ON button until the LED lights up
continuously
Start entering the master code within 5 seconds 10 seconds
Turn the handle within 3 seconds. The lock is open
Press and hold the ON button until the LED turns solid green
Enter the new valid user code within 5 seconds 5 seconds
The new user code is accepted

6
Power supply
3.1. General
The lock is powered by a 9-volt alkaline block battery.
If the red LED flashes after pressing the ON key, the battery is almost empty.
Change the battery as soon as possible.
If the LED flashes red five times after the ON key is pressed and is followed by a
triple beep signal, the code can no longer be entered due to a lack of power. After
entering the first code digit, the LED goes out. Replace the battery immediately.
To change the battery, loosen the M4 bolt and M18 nut on the back of the lock. Lift
the battery cover on the lock housing and replace the battery. Replace the battery
cover and tighten the nut and bolt.
If the battery is so empty that it is no longer possible to enter a code and thus open
the safe, the lock can be powered from the outside. To do this, hold a 9-volt block
battery to the power supply points of the input unit (see Fig. 1) and open the lock
as described under point 3. Please always dispose of used batteries in an
environmentally friendly manner.

7
Password
4.1. General basic rules
4.1.1. Avoid obvious passwords
•No trivial values like 000000, 0815, 123456
•Do not use your own birthday, car license plate, phone number or name (your
own, wife/husband, children, pets, company, place of residence, etc.) as
password. Do not use standard passwords like: "password" or "safe".
•Writing backwards is also too easy
•Do not use a password that you already use
•Important passwords should not have a logical structure
4.1.2. Tips
•The first rule: A password is only secure if it remains secret!
•Remember passwords - don't write them down anywhere!
•Consider all keys if possible (wear marks on the keyboard betray the individual
numbers over time)
4.1.3. Last but not least
Consider how the password will still be retained if the owner can no longer
disclose the password (e.g., in the event of death). Leave a sealed envelope with
your notary.
