Walker Edison AF42LWET User manual

P.1
Copyright © 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
Please visit our website for the most current instructions, assembly tips, report damage,
or request parts. www.walkeredison.com
Revised 25/12/2019 (I)
®
Walker Edison
TM
Assembly Instructions
Item # : AF42LWET

VII. Drill may be needed for securing product to wall.
General Assembly Guidelines
I. Ensure that all parts and hardware are available before beginning assembly.
II. Follow each step carefully to ensure the proper assembly of this product.
III. Two people are recommended for ease in the assembly of this product.
IV. The main type of hardware used to assemble this product are: bolts and
screws.
V. A Phillips head screwdriver is required for the assembly of this product .
VI. Power tools should not be used to assemble this product.
Copyright © 2019, by Walker Edison Furniture Co., LLC. All rights reserved. P.2

P.3
Parts List
1
Copyright © 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
2
3
3
3
3
4

P.4
Copyright © 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
Hardware List
The hardware quantities listed above are required for proper assembly.
Some extra hardware may also have been included.
M6x27mm BoltA 8 pcs
Ø4x27mm ScrewB 6 pcs
M4 Hex KeyC 1 pc
D
Nut 2 pcs
Screw 2 pcsØ4x38mm
E

P.5
Copyright © 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
Step 1
A
A
A
A
C
2
3
3
3
3
Using Bolt (A) attach part (2) to part (3) with Hex key (C) as per diagram.
Note : Do not fully tighten all the bolts.

P.6
Copyright © 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
Step 2
C
A
A
A
A
3
3
3
3
4
Using Bolt (A) attach part (4) to part (3) with Hex key (C) as per diagram.
Note: Fully tighten all the bolts.

Step 3
P.7
Copyright © 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
B
B
B
B
B
B
2
1
Using Screw (B) attach part (2) to part (1) with Philips head screwdriver as per diagram.

P.8
Copyright © 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
Step 4 21 3
WARNING
Serious or fatal injuries can occur from furniture tipping over. To prevent the furniture from tipping over we recommend
that it is permanently fixed to the wall. Wall anchor and hardware are included with this product. Please make sure
hardware is suitable for your walls before installing, as different wall materials may require different types of anchors.
Wall
2
E
D
E
D
Wall
E
D
Using screw (D) attach part (2) to Nut (E) to Wall with Philips head screwdriver as per diagram.

Step 5
Final Assembly
P.9
Copyright © 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
