Walker Edison Hans HANB4C User manual

Copyright © 2018, by Walker Edison Furniture Co., LLC. All rights reserved. P.1
Please visit our website for the most current instructions, assembly tips, to report damage
or request parts. www.walkeredison.com
Revised 07/2022 - V1
Item: HANB4C
Assembly Instructions

Copyright © 2018, by Walker Edison Furniture Co., LLC. All rights reserved. P.2
General Assembly Guidelines
I. Ensure that all parts and hardware are available before beginning assembly.
II. Follow each step carefully to ensure the proper assembly of this product.
III. Two people are recommended for ease in the assembly of this product.
IV. The two main types of hardware used to assemble this product are: wood
dowels and screws.
V. A Phillips head screwdriver is required for the assembly of this product (not
included)

Copyright © 2018, by Walker Edison Furniture Co., LLC. All rights reserved. P.3
Parts List
01
02
09
03
10
04
05
08
07
06
11
Part # Description Qty
01 Top Panel 1
02 Right Side Panel 1
03 Left Side Panel 1
04 Bottom Panel 1
05 Drawer Front 1
06 Right Drawer Side 1
07 Left Drawer Side 1
08 Drawer Back 1
09 Back Panel 1
10 Shelf 1
11 Drawer Bottom 1
Keep the sticker for reference in
case you need a replacement
part in the future

A
Ø8x30 Wooden Dowel 20 pcs
B
Ø6x31mm Cam Bolt 10 pcs
C
Ø15x10mm Cam Lock 10 pcs
D
Ø3,5x14mm Screw 8 pcs
E
Ø3x16mm Screw 4 pcs
F
Ø4x40mm Screw 2 pcs
G
Ø7x50 Screw 12 pcs
H
14x14mm Support 4 pcs
I
Ø 19mm Sticker 6 pcs
J
21x47x4mm Hex Key 1 pcs
K
150mm Foot 4 pcs
L1
300mm Slider 1 pcs
L2
300mm Slider 1 pcs
R1
300mm Slider 1 pcs
R2
300mm Slider 1 pcs
Copyright © 2018, by Walker Edison Furniture Co., LLC. All rights reserved. P.4
Hardware List
Hammer recommended
for assembly (not included) Philips head screwdriver required
for assembly (not included)
The hardware quantities listed above are required for proper assembly.
Some extra hardware may also have been included.

Copyright © 2018, by Walker Edison Furniture Co., LLC. All rights reserved. P.5
Step 1
01
02
03
B
B
B
B
A
A
A
A
B
B
B
BA
A
A
A
Insert wooden dowel (A) to parts (2,3,10)
and insert cam bolt (B) to parts (1,2,3).
A
A
A
A
10
A
Ø8x30
12
B
Ø6x31mm
8

Copyright © 2018, by Walker Edison Furniture Co., LLC. All rights reserved. P.6
Step 2
Step 3
G
G
G
G
D
DR1
L1
D
D
L1
300mm
1
R1
300mm
1
D
Ø3,5x14mm
4
G
Ø7x50
8
J
21x47x4mm
1
K
150mm
4
04
03
02
Attach slides (L1,R1) to parts (2,3) with
screw (D).
Attach feet (K) to part (4) with screw (G)
and hex key (J).
2º Hole
D
R1
J

Copyright © 2018, by Walker Edison Furniture Co., LLC. All rights reserved. P.7
Step 4
Step 5
C
Ø15x10mm
2
C
Ø15x10mm
2
02
03
10
02
C
C
C
C
Secure parts (2,10) to part (3) using cam
lock (C) as per diagram.
Secure part (10) to part (2) using cam lock
(C) as per diagram.
10
C
C

Copyright © 2018, by Walker Edison Furniture Co., LLC. All rights reserved. P.8
Step 6
Step 7
G
Ø7x50
4
J
21x47x4mm
1
G
G
G
09
Secure part (4) to parts (2,3) using screw
(G) and hex key (J).
Slide back panel (9) into side panel (2,3).
03
02
03
02
J
G
04

Copyright © 2018, by Walker Edison Furniture Co., LLC. All rights reserved. P.9
Step 8
Step 9
01
C
CC
C
C
Ø15x10mm
4
E
Ø3x16mm
4
H
14x14mm
4
E
H
H
EH
E
EH
Secure part (1) to parts (2,3) using cam
lock (C).
Secure back panel (9) using screw (E) and
support (H).
02
03
09
E
H
C

Copyright © 2018, by Walker Edison Furniture Co., LLC. All rights reserved. P.10
Step 10
Step 11
A
Ø8x30
8
B
Ø6x31mm
2
C
Ø15x10mm
2
F
Ø4x40mm
2
AAB
B
AA
AA
A
A
F
F
C
C
07 06
08
05
08
07
06
11
05
Insert wooden dowel (A) to parts (6,7,8)
and insert cam bolt (B) to part (5).
Secure parts (6,7) to part (8) using screw (F).
Secure part (5) to parts (6,7) using cam lock (G).
07
06
C
