Walker Edison BR4DSV User manual

P.1
Please visit our websitefor the most current instructions, assemblytips, report damage,
or request parts. www.walkeredison.com
Revised 23/10/2020(C)
Walker Edison
TM
BR4DSV
Copyright
2020
, by Walker Edison Furniture Co., LLC. All rightsreserved.

VIII.Drillmaybeneededforsecuringproduct towall.
GeneralAssembly Guidelines
I. Ensure thatallpartsandhardware are available beforebeginning assembly.
II.Followeachstepcarefullytoensure theproper assembly of this product.
21
III.Twopeoplearerecommendedfor easeintheassembly of this product.
IV.Thethreemain typesofhardware usedtoassemblethis product are: wood
dowels,screwsandbolts.
V.Theprovidedglueistosecurewooddowelsin place.Whenfirst inserting dowels,
locatetheappropriatehole forthedowel,placeasmallamount of glue inthe hole
andinsertthedowel.Wipeawayexcessglueimmediately.
Infutureassemblystepswhendowelsarenecessary toattachassembly parts
together,placeasmallamountofglueonthe endofthedowelbeforeattaching
partstogether.Wipeawayexcessglueimmediately.
VI.APhillipsheadscrewdriverisrequiredfortheassemblyofthis product .
VII. Power toolsshould notbeusedtoassemblethis product.
Copyright
2020
, by Walker Edison Furniture Co., LLC. All rightsreserved.
P.2

P.3
Parts List
Copyright
2020
, by Walker Edison Furniture Co., LLC. All rightsreserved.
x 3
x 4
1
2
3
456
7
8
9
10
11 12
13
14
15
15
15
15

P.4
HardwareList
The hardware quantities listed above are required for proper assembly.
Someextrahardware may also have been included.
Philipsheadscrewdriverrequiredforassembly
(notincluded)
8x30mm WoodendowelA 26 pcs
6x35mm CamboltB 38 pcs
15x11mm CamlockC 18 pcs
30mm Sticker
D
38 pcs
6x50mm Screw
E
6pcs
5x15mm Screw
F
4pcs
M4 Hexkey
G
1 pc
Handle
H
8pcs
4x22mm HandleBolt
J
16 pcs
K
20 pcs
L
1pc
M
4x38mm Screw
N
1 pc
P
Q
R
S
Drawerslider 4 sets
*Note:Thispiece comes preassembled for
shippingpurposesand must bedisassembled
tocompletethe deskassembly.
Copyright
©
2020
, by Walker Edison Furniture Co., LLC. All rightsreserved.
8pcs
15x9mm Camlock 20 pcs
3x12mm Screw 48 pcs
6x35mm Bolt 1 pc
6x12mm Bolt 16 pcs
T
U
Screw
Screw
Plasticstrap
V
Nut
1 pc
1 pc
4x12mm
4x25mm
10''
Gluetube 2 pcsW
6x30mm Woodendowel

P.5
Step 1
Copyright
©
2020
, by Walker Edison Furniture Co., LLC. All rightsreserved.
x 4
x 3
8
11 6
5
A
AA
A
A
A
A
A
A
A
A
A
A
A
U
U
Insert wooden dowel (A) into parts (5,6,8) and wooden dowel (U) into part (11) as per diagram.

P.6
Step 2
Copyright
©
2020
, by Walker Edison Furniture Co., LLC. All rightsreserved.
17
4
A
A
A
AAA
A
A
B
B
B
B
B
B
B
B
B
B
B
B
B
B
BB
B
B
Insert wooden dowel (A) into parts (4,7), then secure cam bolt (B) into parts (1,4,7) with Philips
head screwdriver as per diagram.

Sliderbracket
Sliderarm
Sliderbracket
Sliderarm
Step 3
P.7
Copyright
©
2020
, by Walker Edison Furniture Co., LLC. All rightsreserved.
V
V
Pick up the slider arm (V) and separate the slide runner for the following Steps. Extend
the slide runner all the way forward,press the plastic release lever of the slider arm up
and pull the slide runner complete out .

Step 4
P.8
Copyright
©
2020
, by Walker Edison Furniture Co., LLC. All rightsreserved.
10 13
FF
F
F
F
F
VV
x 4
Using screw (F) attach drawer slider (V) into parts (10,13) with Philips head screwdriver
as per diagram.

Step 5
P.9
Copyright
2020
, by Walker Edison Furniture Co., LLC. All rightsreserved.
74
FFF
FF
F
FF
F
F
F
FF
FF
F
FF
F
FF
FF
F
V
V
V
VV
V
V
V
Using screw (F) attach drawer slider (V) into parts (4,7) with Philips head screwdriver
as per diagram.

Step 6
P.10
Copyright
2020
, by Walker Edison Furniture Co., LLC. All rightsreserved.
5
6
Attach part (6) to part (5) as per diagram.

P.11
Step 7 21 3
Copyright
2020
, by Walker Edison Furniture Co., LLC. All rightsreserved.
4
5
C
C
C
Using Cam lock(C) secure part (5) to part (4) with Philips head screwdriver as per diagram.

P.12
Step 8
Copyright
2020
, by Walker Edison Furniture Co., LLC. All rightsreserved.
21 3
H
3
8
8
8
C
C
C
4
Using Cam lock(C) secure part (8) to part (4) ,then using screw (H) attach part (3) to part (4) with
Philips head screwdriver as per diagram.

Step 9
P.13
Copyright
2020
, by Walker Edison Furniture Co., LLC. All rightsreserved.
21 3
38
8
8
6
7
C
C
C
C
C
C
H
Using Cam lock(C) secure parts (6,8) to part (7) ,then using screw (H) attach part (3) to part (7) with
Philips head screwdriver as per diagram.

Step 10
P.14
Copyright
©
2020
, by Walker Edison Furniture Co., LLC. All rightsreserved.
7
46
52
G
G
G
G
G
L
Using screw (G) attach part (2) to parts (4,5,6,7) with Hex key (L) as per diagram.

Step 11
P.15
Copyright
2020
, by Walker Edison Furniture Co., LLC. All rightsreserved.
2
K
L
15
15 15
15
Using bolt (K) attach part (15) to part (2) with Hex key (L) as per diagram.

Step 12
P.16
Copyright
©
2020
, by Walker Edison Furniture Co., LLC. All rightsreserved.
21 3
7
4
6
5
1
CC
C
C
J
L
1
3
Using cam lock (C) secure part (1) into parts (4,5,6,7) with Philips head screwdriver ,then using
bolt (J) attach part (3) to part (1) with Hex key (L) as per diagram.

Step 13
P.17
Copyright
2020
, by Walker Edison Furniture Co., LLC. All rightsreserved.
x 4
14
B
B
B
B
B
M
M
NN
NN
Secure cam bolt (B) into part (14) ,then using handle bolt (N) secure handle (M) to part (14) with
Philips head screwdriver as per diagram.

Step 14
P.18
Copyright
©
2020
, by Walker Edison Furniture Co., LLC. All rightsreserved.
x 4
99
13
10 10
13
12
P
P
Using screw (P) attach parts (10,13) to part (9) with Philips head screwdriver, then put part (12)
as per diagram.

Step 15
P.19
Copyright
2020
, by Walker Edison Furniture Co., LLC. All rightsreserved.
x 4
21 3
11
9
10
13
11
14
D
D
D
P
Using screw (P) attach part (11) to part (9) , then using Cam lock (D) attach part (14) to
parts (10,11,13) with Philips head screwdriver as per diagram.

Step 16
P.20
Copyright
©
2020
, by Walker Edison Furniture Co., LLC. All rightsreserved.
E
E
E
E
E
x 4
Place sticker (E) cover the holes as per diagram .
