Walker Edison W60UBC22 User manual

06/2014

Secure cam bolts (B) into top panel (1). Insert wooden dowels (A) into bottom panels (1,8,22).
Secure cam bolts (B) into side panels (2, 3, 4, 5). Insert wooden dowels (A) into side
panels (4,5).

Insert wooden dowels (A) into panel (9). Secure cam bolts (B) into panels (6, 7).
Attach panel (6) to panel (4) using cam locks (C). Attach panel (7) to panel (5) using
cam locks (C).

Attach side panels (4, 5) to shelf panel (9) using cam locks (C).
Secure legs (11) to bottom panel (8) using screws (E).

Attach side panels (4,5) to bottom panel (8) using screws (E).
Attach top panel (1) to side panels (4,5) using cam locks (C).

Attach side panels (2,3) to assembled unit using cam locks (C).
Secure back panels (12) using screws (M).

Secure back panel (14) using screws (M).
Secure back panel (13) using screws (M).

Secure cam bolts (B), attach handles (H) to panel (17) using bolts (J).
Attach panels (19, 20) to panel (18) using screws (L). Attach support bar (22) to panel (18)
using screw (L). Carefully slide panel (21) into the thin grooves as shown in the diagram.

Attach panel (17) to drawer assembly using cam locks (D).
Secure support bar (22) to panel (17) using cam lock (C).

Cover all cam locks using stickers (P).
Carefully insert drawer assembly into assembled unit.

Insert shelf support pins (K) and carefully insert shelves (10).
Attach hinge (F) to doors (15, 16) using screws (G). Attach handles (H) using bolts (J).

Attach doors (15, 16) to assembled unit using screws (G).
