Wasp 4070 HDP User manual

MANUAL OF USE AND MAINTENANCE
ORIGINAL INSTRUCTIONS
WASP 4070 HDP

Discalaimer
IMPORTANT:
We kindly suggest you to read carefully and comprehend in its integrity the content in this Manual
of Use and Maintanance.
The missing acknowledgment of the manual can be cause of personal injury, worst quality results or
damages to the printer WASP 4070 HDP. Always make sure that the operators using the 3D printer
knows and understands the content of the manual in order to achieve the best results from WASP
4070 HDP.
No part of this publication may be reproduced, stored in a filing system or transmitted to third parties in any form or by any means, without
the Manufacturer having issued a prior written authorization. The Manufacturer reserves the right to make changes to its products at any
time and without notice in order to constantly increase the quality, therefore this publication may also be subject to future modifications and
updates.
Copyright 2022 WASP S.r.l. – All rights reserved
1First edition 14/04/2022
Revision Reason for the revision Revision date

© WASP S.r.l.
Summary
0Introduction ................................................................. 5
0.1. Aim of the instruction manual............................................ 5
0.2. How to read the manual of instructions ........................ 6
0.3. Storage of the manual of instructions ........................... 6
0.4. Updating the manual of instructions .............................. 6
1 General information....................................................... 7
1.1. Manufacturer identification data...................................... 7
1.2. Indentification label................................................................ 7
1.2.1. Position of the label on the printer .....................................8
1.3. Testing..........................................................................................8
1.4. Warranty......................................................................................8
1.5. General safety warnings....................................................... 9
1.5.1. Personal protective equipment...........................................9
1.5.2. Operators for whom the manual is intended .............. 10
1.5.3. Protection systems ................................................................ 10
1.5.4. Residual risks ............................................................................10
1.5.5. Safety stickers..........................................................................12
1.6. Glossary and pictograms.................................................. 12
1.6.1. Identification of operating personnel ............................12
1.6.2. Editorial pictograms............................................................... 13
2 Description of the printer..........................................15
2.1. Control panel.......................................................................... 16
2.2. Work area................................................................................. 17
2.3. External area of the printer .............................................. 18
2.4. Tank (material storage)...................................................... 19
2.5. VACS - Vacuum Active Control System .................... 20
2.6. Technical data........................................................................ 21
2.7. Noisiness.................................................................................. 22
2.8. Intended use of the printer .............................................. 22
2.9. Improper use of the printer.............................................. 22
3 Transport and handling ..............................................23
3.1. General warnings.................................................................. 23
3.1.1. Delivery of the printer............................................................23
3.2. Content ..................................................................................... 24
3.3. Unpacking, lifting and handling of the printer ......... 24
4 Installation.......................................................................31
4.1. General warnings.................................................................. 31
4.1.1. Placement...................................................................................31
4.2. Electrical connection.......................................................... 32
4.3. Pneumatical connection ................................................... 32
5 Preparing to use the printer .....................................33
5.1. General warnings.................................................................. 33
5.2. User interface......................................................................... 34
5.2.1. Main board..................................................................................34
5.2.2. PRINT MENU ..............................................................................35
5.2.3. PREPARE menu ........................................................................36
5.2.4. ADVANCED menu ...................................................................37
5.2.5. WIFI settings..............................................................................38
5.2.6. GCODE ......................................................................................... 39
5.2.7. PRINTING board ....................................................................... 40
5.2.8. TUNE menu.................................................................................41
5.2.9. Digit window...............................................................................42
5.3. First start ................................................................................. 43
6 First use of the printer ................................................44
6.1. General warnings.................................................................. 44
6.2. Preparing the 3D file............................................................ 44
6.3. Slicing software..................................................................... 44
6.4. Autocalibration...................................................................... 45
6.5. Loading/unloading of the material ............................... 45
6.6. Placing the printing plate on the vacuum bed......... 46
6.7. Selecting gcode.................................................................... 46
6.8. Function during the print................................................... 46
6.9. Removal of the printing plate.......................................... 46
6.10. Detaching of the printed parts .................................... 46
7 Ordinary and extraordinary maintanance..........47
7.1. General warnings.................................................................. 47
7.2. Ordinary maintanance........................................................ 48
7.2.1. Belts............................................................................................... 49
7.2.2. Ball joints .....................................................................................49
7.2.3. Fans ............................................................................................... 50
7.2.4. Sliders........................................................................................... 50
7.2.5. Nozzle ...........................................................................................52
7.2.6. HEPA filters ................................................................................54
7.2.7. Moisture filter...........................................................................56
7.2.8. Ooze shield protection..........................................................56
7.3. Extraordinary maintenance ............................................. 58
7.3.1. Cleaning the screw .................................................................60
7.3.2. Replacing the extruder .........................................................64
7.3.3. Manual leveling......................................................................... 68
8 Use of the printer ..........................................................71
8.1. Adhesion to the bed............................................................ 71
8.2. Autocalibration...................................................................... 72
8.2.1. Enable Autocalibration procedure ..................................72
8.2.2. Launch Autocalibration ........................................................72
8.2.3. When is Autocalibration necessary?..............................72
8.3. Clean Extruder ....................................................................... 73
8.4. Deleting .gcode from the machine............................... 73
8.5. Free zeta system.................................................................. 74
8.6. Loading .gcode...................................................................... 76
8.6.1. Loading with pendrive USB.................................................76
8.6.2. Loading with Wi-fi....................................................................76
8.7. Loading the material ........................................................... 78
8.8. Manual control ....................................................................... 80
8.9. Network and printing server............................................ 82
8.9.1. Wi-fi connection.......................................................................82
8.9.2. Wired connection (Static IP)...............................................82
8.9.3. Printer server.............................................................................82
8.9.4. Printer server features.......................................................... 83
8.10. Resurrection system........................................................ 84
8.11. Set Z max ............................................................................... 84
8.12. Tuning the compression of the extruder................ 86
8.13. VACS (Vacuum Active Control System).................. 88
9 Additional Instructions...............................................90
9.1. General warnings.................................................................. 90
9.2. Disposal and dismantling.................................................. 90
9.3. Instructions for emergency situations ....................... 91

INTRODUCTION
© WASP S.r.l.
5
INTRODUCTION
0 INTRODUCTION
0.1. Aim of the instruction manual
IMPORTANT:
Before proceeding with the installing and starting of the printer, the technician, the user, the
maintainer and the safety responsible must read and understand the manual.
The Manual must be considered as a fundamental part of the printer. The correct use and maintanence of the
machine depends on the informations contained here.
The Manual contains instructions that must be acknowledged by the operator devoted to the use, maintanance
and transport of the machine, supposing the adequate experience, preparation and professional abilitation as
well as a psychophysical attitude.
For certain operations it may be necessary to ask for the intervent of personnel who. have achieved a specific
preparation.
The Manual must always be available for consultation, in copy and by the recipient, on the printer itself or in its
immediate vicinity. In the second case the location of the manula must me indicated on the printer clearly.
The Manual is susceptible to updates which, appropriately classified, will be transmitted to the user/owner in
order to update the consultation copy (s).
• The recipient must ensure that the personnel authorized by him/her to start up, use, maintain and transport
the printer have obtained adequate knowledge of the instructions contained in this Manual.
• The recipient must check that the maintenance operations, prescribed in the appropriate chapter, are carried
out and recorded promptly and effectively.
• We accept no responsibility for damage to persons or property resulting from improper use and / or omitted
or inadequate maintenance.
• The recipient has the right to request further information.
In case of loss and/or damage of the present Manual it is responsibility of the recipient to ask for one or more
copies.

INTRODUCTION
© WASP S.r.l.
6
INTRODUCTION
0.2. How to read the manual of instructions
This manual is composed by:
COVER WITH PRINTER IDENTIFICATION
By consulting the cover you identify to the printer model covered in the manual and the printer serial number in
your possession.
ANALYTICAL INDEX
By consulting the index it is possible to indentify the chapter and the paragraph on which all the notes relating to
a given topic are reported.
NUMERATION FIGURES
Each figure is numbered progressively, indicating with the first digit the reference chapter and with the second
the progressive image (example Fig. 3.4 is the fourth figure of chapter three)
0.3. Storage of the manual of instructions
It is mandatory to keep this manual and all attached documents in an easily accessible place near the printer and
known to all users (operators and maintenance personnel).
Operators and maintenance technicians must be able to quickly find and consult the manual in any situation.
The manual is an integral part of the printer for security purposes.
Therefore:
• It must be kept intact (in all its parts);
• It must follow the printer until its disposal (even in case of travel, sale, rental, rent, etc.);
• It must be kept up to date and report any changes made to the printer.
0.4. Updating the manual of instructions
This manual must be regularly updated by attaching additional or altered parts.
The sending of any additional parts is the responsibility of the Manufacturer; the user is responsible for the
replacement of parts that may be altered as a result of use, making a request directly to the Manufacturer.

INTRODUCTION
© WASP S.r.l.
1
7
General information 1
1 GENERAL INFORMATION
1.1. Manufacturer identification data
WASP S.r.l.
Via Castelletto, 104 - 48024 Massa Lombarda (RA) Italy
Tel. [phone]
[email protected] / www.3dwasp.com
1.2. Indentification label
The printer is CE marked and complies with all relevant provisions:
Machinery Directive 2006/42 / EC, EMC Directive 2014/30 / EU and LVD Directive 2014/35 / EU
EN 55022
EN 55024
EN 60204-1
The marking can be identified by means of an identification plate of the Manufacturer as required by the Machinery
Directive. In case of damage, the Recipient must commission a copy.
Legend:
1. Stampante 3D: 3D printer
2. Modello: Model
3. Rif. TCT: Reference
4. Input: input power
5. Potenza Max: Maximum power absorption
6. Corrente a pieno carico: full load current
7. Anno di Produzione: Year of production
8. Numero di serie: Serial number
220v-240v
Stampante 3D
Modello:
WASP 4070 HDP
Rif. TCF: WASP 4070 HDP
Input: 220V-240V 50/60Hz
Potenza Max: 2400W
Corrente a pieno carico: 9,8A
Anno di produzione: 2022
Numero di serie:
MADE IN ITALY
WASP s.r.l. via Castelletto 104
Massa Lombarda (RA) Italy
www.3dwasp.com

INTRODUCTION
© WASP S.r.l.
1
8
1
1.3. Testing
The printer is tested directly by the Manufacturer during the phase of assembly and testing.
1.4. Warranty
The printers built by WASP S.r.l. are covered by warranty for a period of 12 months for companies or VAT and 24
months for individuals, according to the specifications set out in the sales contract.
If during the period of validity, defective operations or faults of parts of the printer that fall within the cases
indicated in the warranty occur, WASP S.r.l. (after the appropriate checks) will repair or replace the defective
parts.
The defective parts under warranty are repaired or replaced free of charge by WASP S.r.l. .
The costs of transport and / or shipment are always charged to the Customer, as well as the return / return travel
expenses related to the intervention of the Manufacturer’s technicians at the Customer’s premises.
The labor costs related to the intervention of the Manufacturer’s technicians at the Customer’s premises, for the
removal of defects under warranty are the responsibility of the Manufacturer, except in cases where the nature
of the defect is such that it can be easily removed on site by part of the Customer.
All consumables are excluded from the warranty.
The court of competent jurisdiction for any legal dispute is the Court of Ravenna, Italy.
NOTE:
The guarantee lapses in the following cases:
• Default or other contractual non-fulfillment;
• Improper use of the printer
• Failure to comply with the standards and maintenance intervals
• Tampering
• The printer is returned to the Manufacturer in a different packaging from the one supplied at the
time of purchase;
• Use of non-original spare parts, ie not supplied directly by the Manufacturer;
• Extraordinary interventions not carried out by personnel not sent by the Manufacturer;
• Any variation and / or non-observance of what is indicated in the technical documents and in
this manual entails the forfeiture of the technical and functional guarantees, and release the
Manufacturer of the printer from any responsibility.
1.2.1. Position of the label on the printer
The identification label can be found on the back profile of the printer near the supply plug.

INTRODUCTION
© WASP S.r.l.
1
9
1
1.5. General safety warnings
CAUTION:
All intervention performed on the printer require particular caution on the part of the operator.
NOTE:
Any intervention on the printer must be carried out in strict compliance with the operational skills
(see paragraph 1.7.1 “Identification of Operational Staff”). WASP S.r.l. declines any responsibility in
case of non-compliance with these skills.
The purpose of this chapter is to indicate:
• which are the specific measures to avoid incurring any kind of accidents
• what may be defined as residual risks
• which are the minimum essential safety provisions to be maintained
• what characteristics must have the operators assigned to the operations on the machine
• which must be the characteristics of the maintenance operators.
WASP is not responsible for unspecified operations, as they are considered strictly pertinent to technical
assistance personnel or for operations performed differently from what we described in the documentation
presented.
Possible operations on the printer can include:
• Mechanical
• Electrical
•
MECHANICAL NATURE INTERVENTIONS
Any intervention of a mechanical nature must be carried out in strict compliance with the directives required by
current safety regulations. It is absolutely forbidden to perform any type of mechanical maintenance intervention
on the printer during the operating cycle or in any case with parts of the printer moving.
Everymechanicaloperationmustbecarriedoutwiththeprinterstoppedandonlyandexclusivelybythemechanical
maintenance technician, qualified to operate in conditions of safety (see paragraph 1.7.1 “Identification of the
operating personnel”).
Maintenance work must only be performed with the machine disconnected from the power source and taking all
the safety measures required by current laws and regulations.
ELECTRICAL NATURE INTERVENTIONS
Every electrical adjustment operation must be carried out taking all the safety measures required by current
regulations.
1.5.1. Personal protective equipment
It is mandatory to use specific personal protection devices (PPE) to the current operations made available by
the company (in relation to the risk attached to the performance of certain processes), even when not directly
concerning the use of the machine.

INTRODUCTION
© WASP S.r.l.
1
10
1
1.5.2. Operators for whom the manual is intended
The manual is written for:
• The operators involved in using the printer (in the continuation of the manual will be briefly called “users”);
• Mechanical maintenance workers: trained and authorized operators for the maintenance of mechanical
parts, pneumatic and oil-hydraulic systems;
• Electrician maintenance technicians: trained and authorized operators for the maintenance of electrical and
/ or electronic parts and systems;
• Qualified technicians (employees of the Manufacturer or authorized service center), special maintenance
staff and operations of a complex and / or particular nature.
ATTENTION:
The user must not perform operations reserved for maintenance personnel or qualified technicians.
The manufacturer is not liable for damages deriving from failure to observe this prohibition. Users
or qualified technicians.
1.5.3. Protection systems
The machine is provided with automatical systems of protection that reduces the risks for the user.
These systems are present as a standard in all machines and shall not, for any reason, be manipulated nor
damaged. Upon seeing abnormalities in the fuctions of these systems, the user is responsible of reporting them
to the Manifacturer, who’ll fix it.
Anytime the fuctions of these systems are compromised the machine must not be used for no reason as it may
be dangerous for the user and may lead to major damages to the machine itself.
DOOR SENSOR
ATTENTION:
Do not put any magnet or magnetic device near the frame of the door as it may compromise its right
behaviour
The Door sensor activates anytime the door is open and automatically pauses any action on the machine
(including heating, movements and tool-change).
OVERHEATING BLOCK
The machine is designed with a control system to prevent the overheating of its parts by blocking the heating
parts as the temperatures recorded overcome the saftey threshold.
1.5.4. Residual risks
Residual risk of scalding
This risk exists during the removal phase of the filament from the extruder and during the removal of the piece
from the plate.
CAUTION:
Remove the part only when both the extruder and the bed are cool.
ATTENTION:
During the operations on the machine the user must wear protective gauntlets.
